Page 1137 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual JUNCTION BLOCK C3 - BLACK 52 WAY CAV CIRCUIT FUNCTION 1 F22 20WT/PK FUSED IGNITION SWITCH OUTPUT (RUN) 2- - 3 L60 20TN RIGHT TURN SIGNAL 4 L302 20LB/YL RIGHT TURN SWITCH SENSE 5 L61 20TN/LG LEFT TURN

Page 1138 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual JUNCTION BLOCK C4 - WHITE 2 WAY CAV CIRCUIT FUNCTION 1 A148 10PK/WT FUSED B(+) 2 A148 10OR/WT FUSED B(+) JUNCTION BLOCK C5 - WHITE 3 WAY CAV CIRCUIT FUNCTION 1 A145 10WT/RD FUSED B(+) 2 A149 12RD/TN F

Page 1139 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual LEFT DOOR HANDLE COURTESY LAMP - WHITE 3 WAY CAV CIRCUIT FUNCTION 1 F70 20PK/BK FUSED B(+) 2 M20 20YL/BK COURTESY LAMP LOAD SHED 3 M2 20YL/DG COURTESY LAMP DRIVER LEFT FOG LAMP - BLACK 2 WAY CAV CIRCU

Page 1140 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual LEFT FRONT PARK/TURN SIGNAL LAMP (EXCEPT BUILT-UP-EXPORT) - BLACK 3 WAY CAV CIRCUIT FUNCTION 1 L7 20BK/PK PARK LAMP RELAY CONTROL 2 Z1 18BK GROUND 3 L61 20TN/LG LEFT TURN SIGNAL LEFT FRONT SIDE MARKER

Page 1141 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual LEFT HEADLAMP LEVELING MOTOR (BUILT-UP-EXPORT) - BLACK 3 WAY CAV CIRCUIT FUNCTION 1 Z1 18BK GROUND 2 L114 18VT/DB HEADLAMP ADJUST SIGNAL 3 L7 20BK/PK PARK LAMP RELAY OUTPUT LEFT HIGH BEAM HEADLAMP - B

Page 1142 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual LEFT MULTI-FUNCTION SWITCH - WHITE 11 WAY CAV CIRCUIT FUNCTION 1 L27 20WT/TN FOG LAMP SWITCH SENSE 2 Z234 20BK GROUND 3- - 4 L80 20WT/DG HEADLAMP SWITCH RETURN 5 L309 20PK/LG HIGH BEAM RELAY CONTROL 6

Page 1143 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual LEFT REAR WHEEL SPEED SENSOR - GRAY 2 WAY CAV CIRCUIT FUNCTION 1 B4 18LG LEFT REAR WHEEL SPEED SENSOR 12 VOLT SUPPLY 2 B3 18LG/DB LEFT REAR WHEEL SPEED SENSOR SIGNAL LEFT REMOTE RADIO SWITCH - BLACK 2

Page 1144 of 2199

JEEP GRAND CHEROKEE 2002 WJ / 2.G Workshop Manual LICENSE LAMP NO. 2 - BLACK 2 WAY CAV CIRCUIT FUNCTION 1 L7 18BK/YL PARK LAMP RELAY OUTPUT 2 Z1 18BK GROUND LIFTGATE FLIP-UP AJAR SWITCH - GRAY 2 WAY CAV CIRCUIT FUNCTION 1 Z1 20BK GROUND 2 G80 20VT/YL
