2002 Hyundai Grandeur Owner's Manual

1- 52 FEATURES OF YOUR HYUNDAI
WARNING:
When the ignition switch is on and the windshield wiper switch is placed in the "AUTO" mode, pleaseuse caution in the following casesto avoid any hand injury:
o Do not touch the upper end of the windshield glass facing the rain sensor.
o Do not wipe the upper end of the
windshield glass with a cloth.
o Do not put pressure on the wind- shield glass. HXGS251
Rain Sensor
The rear window defroster is turned on by pushing in the switch. At the same time, the rear window defroster indica-tor light on the switch is turned on. Toturn the defroster off, push the switcha second time. The rear window de-froster automatically turns itself off af- ter about 20 minutes. To restart the defroster cycle, push in the switchagain after it has turned itself off.
B380A01HP-GAT REAR WINDOW DEFROSTER
SWITCH (If Installed)
B370A01A-AAT HAZARD WARNING SYSTEM
The hazard warning system should be used whenever you find it necessary tostop the car in a hazardous location.When you must make such an emer- gency stop, always pull off the road as far as possible.The hazard warning lights are turnedon by pushing in the hazard switch.This causes all turn signal lights toblink. The hazard warning lights will operate even though the key is not in the ignition.To turn the hazard warning lights off,push the switch a second time. HXGS217
HXG122
Manual A/Con Full automatic A/Con
!

FEATURES OF YOUR HYUNDAI 1- 53
B400A01A-AAT DIGITAL CLOCK There are three control buttons for the digital clock. Their functions are: HOUR -Push "H" to advance the hour
indicated.
MIN - Push "M" to advance the
minute indicated.
RESET - Push "R" to reset minutes to
":00" to facilitate resetting the clock to the correct time. When this is done:
Pressing "R" between 10 : 30 and 11 : 29 changes the readout to 11 : 00.Pressing "R" between 11 : 30 and 12 :29 changes the readout to 12 : 00. HXG516J
CAUTION:
Do not clean the inner side of therear window glass with an abrasivetype of glass cleaner or use a scraper to remove the foreign deposits from the inner surface of the glass asthis may cause damage to the de-froster elements. NOTE: The ignition must be in the "ON" position for the rear window de- froster to operate. Without Trip Computer
With Trip Computer
!
DISTANCE TO EMPTYAVERAGE SPEEDDRIVING TIME
B400B03L-GAT TRIP COMPUTER (If installed) Trip computer is a microcomputer-con- trolled driver information gauge thatdisplays information related to driving,such as a distance to empty, averagespeed and driving time on the LCD. MODE Pushing "MODE" to select distance to empty, average speed and driving timefor the driving information. Each pushof the button changes the display as follows;

1- 54 FEATURES OF YOUR HYUNDAI
B400B06L-1
Driving time symbol
Driving time
CAUTION:
If the battery has been taken away and reinstalled or if the vehicle pos- ture is not upright, the function of DISTANCE TO EMPTY may be oper-ated incorrectly.
B400B02L-1
Average speed symbol
Average speed
oDRIVING TIME - This mode indi-
cates the total time from the starting of the vehicle to the ignition key "OFF" after resetting. When the"RESET" switch is pushed, it willinitialize to 0:00.
RESET Pushing "RESET" during more than 1 sec to initialize the displayed informa-tion such as average speed and driv-ing time.
HXGS265 oAVERAGE SPEED - This mode
indicates the average speed from the starting of the vehicle to the ignition key "OFF". When the igni-tion key is "OFF", it will initialize to0km/h(0mph).
Distance to empty symbol
Distance to empty
o DISTANCE TO EMPTY - This mode
indicates the estimated distance to empty from the current fuel in the fuel tank. When the remaining dis-tance is below 50km(30miles), "--.-" symbol will be displayed with blink-ing.
!

FEATURES OF YOUR HYUNDAI 1- 55
NOTE:
o When refueling a vehicle that is
not parked on level ground or taking away the battery, the TripComputer can recognize thewrong amount of fuel.
o The trip Computer can recognize the amount of fuel more thanactual amount if there is leakageof fuel, because it can recognizeonly the normal consumption offuel.
o When refueling with more than 7 liters at least, the Trip Computerwill recognize refueling.
The instrument panel lights can be made brighter or dimmer by turningthe instrument panel light control knob.Right-Hand Drive
B410A01L.DAG
B410A01A-AAT INSTRUMENT PANEL LIGHT CONTROL (RHEOSTAT)Left-Hand Drive
B410A02L B420A02L
For the cigarette lighter to work, the key must be in the "ACC" position orthe "ON" position.To use the cigarette lighter, push it allthe way into its socket. When theelement has heated, the lighter will pop out to the "ready" position. Do not hold the cigarette lighter pressedin. This can damage the heating ele-ment and create a fire hazard.If it is necessary to replace the ciga-rette lighter, use only a genuine Hyundai replacement or its approved equiva- lent.
B420A02A-AAT CIGARETTE LIGHTER

1- 56 FEATURES OF YOUR HYUNDAI
HXG523J
The drink holder is located on the main console for holding cups or cans. Thedrink holder can be opened by pushingat its top edge.
B450A01L-GAT DRINK HOLDER
CAUTION:
Place the drink holder in its closed position when not in use.
WARNING:
Do not place anything except drinkson the drink holder. Such objectscan be thrown out, possibly injur-ing persons in the vehicle duringsudden braking or in the event ofan accident.
!
!
B430A01Y-AAT FRONT ASHTRAY The front ashtray may be opened by pushing and releasing the ashtray/ciga-rette lighter door at its top edge.To remove the ashtray in order toclean it, the metal ash receptacle shouldbe removed from the ashtray door. Do not attempt to remove the entire ash- tray door assembly or damage will HXG055
CAUTION:
Do not use electric accessories or equipment other than the Hyundaigenuine parts in the socket.! result. Instead, push the metal ash receptacle down and forward in theashtray door, and it can then be liftedout. To reinstall it, place it in the properposition and press it down and forward to reengage the ash receptacle rear lip in the ashtray door. The ashtray lightwill only illuminate when the exteriorbody lights are switched on.
B440A01L-GAT REAR ASHTRAY The rear ashtray may be opened by pulling it up by its top edge. To remove the ashtray to empty or clean it, lift it upslightly and pull it all the way out.HXG522J

FEATURES OF YOUR HYUNDAI 1- 57
B460A01Y-AAT SUNROOF (If installed) Sun Shade Your HYUNDAI is equipped with a sliding sunshade which you can manu-ally adjust to let in light with the sunroofclosed, or to block sunlight. B460A01LB450B01L-GAT REAR DRINK HOLDER The drink holder is located on front of the rear seat arm rest for holding cups orcans. The drink holder can be used bypushing it in first and then releasing it.
HXGS223
CAUTION:
Place the drink holder in its closedposition when not in use.
WARNING:
Do not place anything except drinkson the drink holder. Such objectscan be thrown out, possibly injur-ing persons in the vehicle duringsudden braking or in the event ofan accident.
!
!
WARNING:
Never adjust the sunshade while driving.
!
B460B01Y-AAT Opening the Sunroof System
The sunroof can be electrically opened or closed with the ignition key in the"ON" position. To open or to close,press and hold the button located inthe front of the roof panel. Release thebutton when the sunroof reaches the desired position. HXGS232

1- 58 FEATURES OF YOUR HYUNDAI
B460D02Y-AAT Manual Operation of Sunroof
If the sunroof does not electrically op- erate:
1. Remove the rectangular plastic in- terior light lens in the front of the roof panel. HXGS234
WARNING:
o Do not close a sunroof if anyone's hands, arms or body are between the sliding glass and the sunroofsash, as this could result in in- jury.
o Do not place your head or arms
out of the sunroof opened at any time. B460C01Y-AAT Tilting the Sunroof System The sunroof can be tilted and closed with the ignition key in the "ON" posi-tion. Release the button when thesunroof reaches the desired position. NOTE: After washing the car or after there is rain, be sure to wipe off any waterthat is on the sunroof before oper-ating it.HXGS233!
CAUTION:
o Do not open the sunroof in se- verely cold temperature or when it is covered with ice or snow.
o Periodically remove any dirt that
may have accumulated on theguide rails.!

FEATURES OF YOUR HYUNDAI 1- 59
2. Remove the front overhead light
and switch panel, using a phillips screwdriver. HXGS235
HXGS236
3. Insert the hexagonal head wrench provided with the vehicle into the socket. This wrench can be found in the vehicle's trunk or glove box.
4. Turn the wrench clockwise to open or counterclockwise to close thesunroof.
B480A01L-GAT FRONT MAP LIGHT
(With sunroof) The two map light switches are located on both sides of the interior light. Push in the map light switch to turn the light on or off. HXG602J
