1- 48 FEATURES OF YOUR HYUNDAI
To turn on the rear fog lights, push the switch. They will come on when theheadlight switch is in the second posi-tion and the key is in the "ON" position.
B340A01A-AAT COMBINATION TURN SIGNAL, HEADLIGHT AND HIGH-BEAMSWITCH Turn Signal Operation Pulling down on the lever causes the turn signals on the left side of the car toblink. Pushing upwards on the lever causes the turn signals on the right side of the car to blink. As the turn iscompleted, the lever will automaticallyreturn to the center position and turnoff the turn signals at the same time. Ifeither turn signal indicator light blinks more rapidly than usual, goes on but does not blink, or does not go on at all,there is a malfunction in the system.Check for a burned-out fuse or bulb orsee your Hyundai dealer. B340B01A-AAT Lane Change Signal To indicate a lane change, move the lever up or down to a point where itbegins flashing.The lever will automatically return to the center position when released.
HHP269-1
B340C02E-AAT Headlight Switch To operate the headlights, turn the barrel on the end of the multi-functionswitch. The first position turns on the
parking lights, sidelights, tail lights and instrument panel lights. The second position turns on the headlights. NOTE: The ignition must be in the "ON" position to turn on the headlights. Parking light auto cut If you do not turn the parking lights "OFF" after driving, the parking lights will automatically shut "OFF" when the driver's door is opened. HHP267

6- 26 DO-IT-YOURSELF MAINTENANCE
Replacement instructions:
1. Allow the bulb to cool. Wear eye protection.
2. Always grasp the bulb by its plastic base, avoid touching the glass.
G260A01L-GAT
REPLACEMENT OF LIGHT BULBS
Before attempting to replace a light
bulb, be sure the switch is turned to the "OFF" position. The next paragraph shows how to
reach the light bulbs so they may be changed. Be sure to replace the burned-out bulb with one of the samenumber and wattage rating. See page 6-33 for the wattage de-
scriptions.
G270A03L
G270A01L-GAT
HEADLIGHT AND FRONT TURN SIGNAL LIGHT
High beam Low beam
Turn signal light
! CAUTION:
o Keep the lights out of contact with petroleum products, such as oil, gasoline, etc.
o Be sure to replace the LED type equipped bulbs with assembly.
1. Adjust headlights so that main axis
of light is parallel to center line ofthe body and is aligned with point"P" shown in the illustration.
2. Dotted lines in the illustration show
the center of headlights.
SPECIFICATIONS: "H"Horizontal center line of headlightsfrom groundGeneral type: 634 mm (24.96 in.) HID type: 628 mm (24.72 in.) "W" Distance between each headlightcenter: 1,240 mm (48.8 in.) "L" Distance between the headlightsand the wall that the lights aretested against : 3,000 mm (118.11 in.)

DO-IT-YOURSELF MAINTENANCE 6- 27
G270A07L
5. Push the bulb spring to remove the headlight bulb.
6. Remove the protective cap from the replacement bulb and install the new bulb by matching the plas- tic base with the headlight hole.Retighten the bulb spring and re- connect the power cord.
7. Use the protective cap and carton to promptly dispose of the old bulb.
8. Check for proper headlight aim.G270A08LG270A04L
General type
High beam (H1)
Low beam (H7)
Turn signal light
3. Turn the plastic cover counterclock- wise and remove it.
G270A06L
4. Disconnect the power cord from the bulb base in the back of the headlight. 9. To replace the front turn signal
light bulb, take out it from the bulb holder and install the new bulb.
1FJB5036

6- 28 DO-IT-YOURSELF MAINTENANCE
G270I01L-GAT
FRONT FOG LIGHT
G270D01L
1. Remove the headlight assembly mounting bolts.
G270D02L
o You can replace the high beam(H1 or H7) and front turn signal light. The replacement instruc-tion is same with the general type's one. But you must not replace or inspect the low beam(XENON bulb). It has a danger of an electric shock. If the low beam (XENON bulb) is not working,have your vehicle inspected by your Hyundai Dealer.
WARNING:
o This halogen bulb contains gas under pressure and if impacted could shatter, resulting in flying fragments. Always wear eye pro- tection when servicing the bulb.Protect the bulb against abra- sions or scratches and against liquids when lighted. Turn thebulb on only when installing in a headlight. Replace the head- light if damaged or cracked.Keep the bulb out of the reach of children and dispose of the used bulb with care.
HID type!
G270A05L
High beam (H7)
Low beam (XENON)Turn signal light

DO-IT-YOURSELF MAINTENANCE 6- 29
G270D03L
2. Disconnect the power cord from
the bulb base in the back of the headlight.
3. Take out front fog light from the bulb holder by turning it counter-clockwise.
G270B01L
G270D01L-GAT
REAR COMBINATION LIGHT
(Stop /Tail Light and Rear Turn
Signal Light)
1. Open the trunk lid.
2. Remove the cover on the inside of
rear luggage trim by unscrewing the screws.
4. Disconnect the power cord fromthe bulb.
5. Replace to the new bulb. G270D04L

6- 30 DO-IT-YOURSELF MAINTENANCE
G270C01L-GAT
LUGGAGE COMPARTMENT LIGHT
1. Open the trunk lid.
2. Remove the luggage compartment
light cover on the rear package tray panel with a blade screwdriver. G270E01L
Screwdriver
2. To replace the back-up light, take
out it from the bulb holder and install the new bulb. G270C01L
G270J01L-GAT
BACK UP LIGHT
1. Remove the trunk lid trim.
Back-up light
3. To replace the rear combinationlight (stop/tail light and rear turn signal light), take out it from the bulb holder and install the newbulb.
Stop/ Tail light
G270B02L
Rear turn signal light
