MALFUNCTION INDICATOR LIGHT(If installed)
This light illuminates when there is a malfunction of an exhaust gas relatedcomponent, and the system is not functioning properly so that the ex- haust gas regulation values are notsatisfied. This light will also illuminatewhen the ignition key is turned to the"ON" position, and will go out in a fewseconds. If it illuminates while driving, or does not illuminate when the ignition key is turned to the "ON" position, takeyour car to your nearest authorizedHyundai dealer and have the systemchecked. B270B01L-AAT
STOP/TAIL LIGHT FAIL URE WARNING LIGHT
If the Stop/Tail Light Failure warning light comes on when the parking brakeis applied or the tail light is turned on,check the brake lines or the tail lightbulb.
B260Q01HP-DAT
CRUISE INDICATOR (If installed)
The cruise indicator light in the instru- ment cluster is illuminated only whenthe vehicle cruising speed has beenset using the control switch on thesteering wheel. The indicator light does not illuminate when the main cruise control switch isactivated.Information on the use of cruise con-trol may be found on page 1-72.
continuously comes on again, whenyou turned the ignition key to the "ON"position or started the engine, or if itcomes on while driving, have the SRSinspected by an authorized Hyundai Dealer.
B270A01A-AAT BRAKE PAD WEAR WARNING SOUND The front disc brake pads have wear indicators that should make a high-pitched squealing or scraping noisewhen new pads are needed. The soundmay come and go or be heard all the time when the vehicle is moving. It may also be heard when the brakepedal is pushed down firmly. Exces-sive rotor damage will result if the wornpads are not replaced. See your
Hyundai dealer immediately.

FEATURES OF YOUR HYUNDAI 1- 45
B300A01Y-GAT SPEEDOMETER Your Hyundai's speedometer is cali- brated in kilometers per hour or milesper hour. HXGS242
Conventional type
Super vision type
B280A01A-AAT FUEL GAUGE
B290A02A-AATENGINE COOLANT TEMPERA- TURE GAUGE
WARNING:
Never remove the radiator cap when the engine is hot. The engine cool- ant is under pressure and coulderupt and cause severe burns. Waituntil the engine is cool before re-moving the radiator cap.
HXGS243
HXGS244
The needle on the gauge indicates theapproximate fuel level in the fuel tank.The fuel capacity is given in Section 9. Conventional type
Conventional type
Super vision type
Super vision type
The needle on the engine coolant tem- perature gauge should stay in the nor-mal range. If it moves across the dial to"H" (Hot), pull over and stop as soon aspossible and turn off the engine. Then open the hood and, after the engine has cooled, check the coolant leveland the water pump drive belt. If yoususpect cooling system trouble, haveyour cooling system checked byHyundai dealer as soon as possible.
!

1- 46 FEATURES OF YOUR HYUNDAI
B310B02L
Super vision type
1. Odometer The odometer records the total driving distance in kilometers or miles, and isuseful for keeping a record for mainte-nance intervals.
B330A01Y-AAT TACHOMETER The tachometer registers the speed of your engine in revolutions per minute(rpm). It is useful to help you shift at theappropriate engine speed to avoid lug- ging or over-revving the engine. HXGS241
Conventional type
Super vision type
B310B01GK-GAT ODOMETER/TRIP ODOMETER Function of digital odometer/trip odometer Pushing in the reset switch on the right side of speedometer when the ignitionswitch is turned "ON" will display thefollowing sequence:
!
CAUTION:
The engine should not be raced to such a speed that the needle enters the red zone on the tachometer face. This can cause severe engine dam-age and may void your warranty.
B310B01L
Conventional type
HXG249-1
Conventional type Super vision type

FEATURES OF YOUR HYUNDAI 1- 47
B360B01Y-GAT FRONT FOG LIGHT SWITCH
To turn on the front fog lights, place the switch in the "ON" position. They willlight when the headlight switch is in the first or second position. HHP269-2B360A01Y-GAT REAR FOG LIGHT SWITCH (If installed)
Left-Hand Drive Right- Hand Drive
B360A02L.DAGB360A02L
NOTE: Any alteration of the odometer may void your warranty coverage. 2 Trip odometer Records the distance of 2 trips in kilo- meters or miles. TRIP A:
First distance you have trav- eled from your originationpoint to a first destination.
TRIP B: Second distance from the firstdestination to the final desti-nation.
To shift from TRIP A to TRIP B, pressthe reset switch. When pressed for 1second, it will reset to 0.

1- 48 FEATURES OF YOUR HYUNDAI
To turn on the rear fog lights, push the switch. They will come on when theheadlight switch is in the second posi-tion and the key is in the "ON" position.
B340A01A-AAT COMBINATION TURN SIGNAL, HEADLIGHT AND HIGH-BEAMSWITCH Turn Signal Operation Pulling down on the lever causes the turn signals on the left side of the car toblink. Pushing upwards on the lever causes the turn signals on the right side of the car to blink. As the turn iscompleted, the lever will automaticallyreturn to the center position and turnoff the turn signals at the same time. Ifeither turn signal indicator light blinks more rapidly than usual, goes on but does not blink, or does not go on at all,there is a malfunction in the system.Check for a burned-out fuse or bulb orsee your Hyundai dealer. B340B01A-AAT Lane Change Signal To indicate a lane change, move the lever up or down to a point where itbegins flashing.The lever will automatically return to the center position when released.
HHP269-1
B340C02E-AAT Headlight Switch To operate the headlights, turn the barrel on the end of the multi-functionswitch. The first position turns on the
parking lights, sidelights, tail lights and instrument panel lights. The second position turns on the headlights. NOTE: The ignition must be in the "ON" position to turn on the headlights. Parking light auto cut If you do not turn the parking lights "OFF" after driving, the parking lights will automatically shut "OFF" when the driver's door is opened. HHP267

FEATURES OF YOUR HYUNDAI 1- 49
B340F01L-GAT Auto Light
3A9CA44
To operate the auto light, turn the barrel on the end of the multi-functionswitch. If you set the multi-function switch to "AUTO", the tail lights and headlights will be turned automaticallyon or off according to external illumina-tion. B340D01A-AAT High-beam Switch To turn on the headlight high beams, push the lever forward (away fromyou). The High Beam Indicator Lightwill come on at the same time. For low beams, pull the lever back toward you.
HHP268
B340F01A-GAT Daytime Running Lights (If Installed) Your Hyundai is equipped with day- time running lights. The daytime run-ning lights are used to improve visibil-ity for oncoming traffic. Your vehicledaytime running lights are designed to remain on continuously when the en- gine is operating even though the head-light switch is in the "OFF" position.However, the daytime running lightswill be off while the parking brake isapplied.
To turn them "ON" again you mustsimply turn the ignition key to the "ON"position.

1- 50 FEATURES OF YOUR HYUNDAI
HHP269
B340E01A-AAT Headlight Flasher To flash the headlights, pull the switch lever toward you, then release it. Theheadlights can be flashed even thoughthe headlight switch is in the "OFF" position.
B350A01A-AAT WINDSHIELD WIPER AND WASHER SWITCH The windshield wiper switch has three positions:
1. Intermittent wiper operation
2. Low-speed operation
3. High-speed operation NOTE: To prevent damage to the wiper system, do not attempt to wipe awayheavy accumulations of snow orice. Accumulated snow and ice should be removed manually. If there is only a light layer of snow orice, operate the heater in the de- HHP272
1
2 3
B350B01Y-GAT Windshield Washer Operation To use the windshield washer, pull the wiper/washer lever toward the steer-ing wheel. When the washer lever is operated, the wipers automatically make two passes across the wind-shield. The washer continues to oper-ate until the lever is released. HHP274
frost mode to melt the snow or icebefore using the wiper.

FEATURES OF YOUR HYUNDAI 1- 51
B350C01L-AAT Adjustable Intermittent Wiper Operation
To use the intermittent wiper feature, place the wiper switch in the "INT"position. With the switch in this posi-tion, the interval between wipes can bevaried from approximately 1 to 18 sec- onds by turning the interval adjuster barrel. This is also varied automati-cally depending on your road speed. HHP273B350B01B-GAT Auto Wiper Operation (If installed)
HHP276
When the windshield wiper switch is placed in the "AUTO" position, the rainsensor located on the upper end of windshield glass senses the amount of rainfall and controls for the appropriatelength of the intervals between wipesappropriately. NOTE: If there is heavy accumulation of snow or ice on the windshield glass, there will be a 10 minute waitingperiod prior to the operation of thewindshield wipers.
Mist Wiper Operation If a single wipe is desired in mist, push the MIST operation switch at the endof the windshield wiper and washer control lever. HHP275
NOTE:
o Do not operate the washer more
than 15 seconds at a time or when the fluid reservoir is empty.
o In icy or freezing weather, be sure the wiper blades are notfrozen to the glass prior to oper- ating the wipers.
o In areas where water freezes in winter, use windshield washer antifreeze.
