2002 BMW Z3 Owners Manual

89n
IndexDataTechnologyRepairsMaintenanceControlsOverview
Seat heating
*
The seat cushion and backrest can be
heated at ignition key position 2.
Press the buttons with the heating
symbols:
Rapid heating as long as the
button comes on brightly. Auto-
matic changeover to regular
heating.
Heating as long as the button
comes on brightly. Heating
switches off automatically.
To switch over while heating: press the
section of the button that is dimly lit.
To switch off early: press the section of
the button that is brightly lit.367de732

90n
To open Pull the handle and push down the
door.To closePush the door up.
To prevent injury in the event of
an accident, close the glove
compartment immediately after use.< 367us034
Storage compartments are located in
the center console, in the doors and, on
the Z3 coupe, between the backrests
(refer to the illustration).
A coin box
* is located in the door
pocket on the driver's side.
A storage net is mounted on the
passenger side of the center console.
367de316
Z3 cou
pe
The Z3 roadster has locking storage
boxes
*:
Small storage boxPress button 1 to open the box.Large storage boxPress button 3 and lift the lid of the box.
Both of the storage boxes can be
locked with the master keys (refer to
page 30) at lock 2.367de035
Z3 roadster
Glove compartment Storage compartments Storage boxes
*

91n
IndexDataTechnologyRepairsMaintenanceControlsOverview
Beverage holder
*
Ashtray
*
The beverage holder is located in the
center console next to the parking
brake.
You will find a coin box in front of the
beverage holders.367us743
To openPress down on the left of the lid (arrow).
To extinguish a cigarette, tap off the
ash and gently press the tip into the
funnel.367de038
To emptyOpen the lid and press down (arrow):
The ashtray insert pops up and can be
removed.367de308

92n
Cigarette lighter
*
Press in. The lighter can be removed as
soon as it pops up.
Hold or touch the hot cigarette
lighter by the knob only. Holding
or touching it in other areas could result
in burns.
The cigarette lighter remains opera-
tional when the ignition key has been
removed. For this reason, children
should never be left in the vehicle unat-
tended.< 367de734
Cigarette lighter socketThis socket can be used for connecting
a ßashlight, car vacuum cleaner, or
other appliances up to approx.
200 watts at 12 volts. Do not damage
the socket by inserting plugs of a
different shape or size.
Non-smoker's equipment
package
*
On vehicles with the non-smoker's
equipment package, the socket is
concealed by a cover.
For access to the socket: lift the cover
off.367de733

93n
IndexDataTechnologyRepairsMaintenanceControlsOverview
Pull out the roll-up cover and hook it
into the holders at the rear.
The roll-up cover can carry light items
such as articles of clothing.
Do not place heavy or hard
objects on the roll-up cover.
These objects could endanger vehicle
occupants during heavy brake applica-
tions and evasive action or in a crash.
Do not allow the roll-up cover to snap
back when it is retracted. This could
damage it.< 367de628
Z3 cou
pe
Pull out the partition net on the strap
and grip the bar firmly with the other
hand. Then grasp the bar on both sides,
pull it up and position it into the
holders. This process will work out best
if you do it from inside the passenger
compartment.
Do not allow the partition net to
snap back when it is retracted. If
this is done, there is a risk of personal
injury, and the partition net could be
damaged.< 392de163
Z3 cou
pe
Roll-up cover Partition net
*

94n
Cargo loadingStowing cargoIf you are transporting cargo in your
coupe:
>Load heavy cargo as far forward as
possible Ð directly behind the
luggage compartment partition Ð and
as low as possible
>Cover sharp edges and corners
>Do not pile objects higher than the
top edge of the backrest
>Pull the partition net
* out (refer to
page 93). Be sure that no items are
able to penetrate the partition net.
367de702
Z3 cou
pe
Securing cargoFor securing luggage, you can obtain
load-securing devices
* from your BMW
center. The lashing eyes located in the
luggage compartment serve for
mounting these load-securing devices.
Comply with the information enclosed
with the load-securing devices.
367de627
Z3 cou
pe
Always position and secure the
cargo correctly. If you do not, it
can endanger the passengers during
braking or evasive maneuvers, for
example.
Do not exceed the approved gross
vehicle weight or the specified
maximum axle loads (refer to
page 172), otherwise the vehicle's
operating safety is no longer assured
and you are in violation of the law.
Do not carry hard or heavy objects
unsecured in the passenger compart-
ment. If you do so, they may be
projected through the air during braking
and evasive maneuvers, for example,
thus endangering vehicle occupants.<

95n
IndexDataTechnologyRepairsMaintenanceControlsOverview
Roof-mounted luggage rackA special roof-rack system is available
for your coupe as an optional acces-
sory. Please comply with the precau-
tions included with the installation
instructions.
Roof-mounted luggage racks raise the
center of gravity of the vehicle when
they are loaded. For this reason, they
have a major effect on the vehicle's
handling and steering response.
You should therefore always remember
not to exceed the approved roof load
capacity, the approved gross vehicle
weight or the axle loads when loading
the rack. You will find the specifications
for this under "Technical Data" on
page 172.
Make sure that the load is not too large
in size, and distribute it evenly. Always
load the heaviest pieces first (on the
bottom). Be sure that adequate clear-
ance is maintained for raising the
sunroof, and that objects do not project
into the opening path of the luggage
compartment lid.Secure the roof luggage correctly
and securely to prevent it from
shifting or being lost during driving
(danger to following traffic).<
Drive smoothly and avoid sudden
acceleration and braking. Do not corner
at high speeds.

96n
