2001 TOYOTA SIENNA Owners Manual

01 SIENNA_U (L/O0008)
2052001 MY SIENNA (OM45406U)
Rear ashtray (for third seats)
CIGARETTE LIGHTER
To use the cigarette lighter, press it in.
When it becomes heated, it automatical-
ly pops out ready for use.
If the engine is not running, the key must
be in the “ACC” position.
Do not hold the cigarette lighter pressed
in.
Use a Toyota genuine cigarette lighter or
equivalent for replacement.ASHTRAYS
To use the ashtray, open out.
When finished with your cigarette, thor-
oughly extinguish it in the ashtray to pre-
vent other cigarette butts from catching
fire. After using the ashtray, push it back
in completely.
To remove the ashtray, press down on the
lock spring plate and pull out.
CAUTION
To reduce the chance of injury in
case of an accident or sudden stop
while driving, always push the ash-
tray back in completely after using.
Power outlets
Front
Rear
ProCarManuals.com

01 SIENNA_U (L/O0008)
2062001 MY SIENNA (OM45406U)
The power outlets are designed for
power supply for car accessories.
The key must be in the “ACC” or “ON”
position for the power outlets to be used.
NOTICE
To prevent the fuse from being
blown, do not use the electricity
over the total vehicle capacity of
12V/120W (front and rear outlets to-
gether).
To prevent the battery from being
discharged, do not use the power
outlets longer than necessary when
the engine is not running.
Close the power outlet lids when
the power outlets are not in use.
Inserting a foreign object other than
the appropriate plug that fits the
outlet, or allowing any liquid into
the outlet may cause electrical fail-
ure or short circuits.
Glove box
To use the glove box, do this.
To open: Pull the lever.
To lock: Insert the master key and turn it
clockwise.
CAUTION
To reduce the chance of injury in
case of an accident or a sudden stop,
always keep the glove box door
closed while driving.
Garage door opener
The garage door opener is manufac-
tured under license from HomeLink
and can be programmed to operate ga-
rage doors, estate gates, security light-
ing, etc.
(a) Programming HomeLink
The HomeLink has 3 buttons and can
be programmed to operate 3 separate
devices.
NOTICE
Unplug the garage or gate device dur-
ing programming to prevent possible
motor burn−up.
ProCarManuals.com

01 SIENNA_U (L/O0008)
2072001 MY SIENNA (OM45406U)
Prepare the HomeLink for programming
by erasing all codes or the memorized
date programmed by the former owner.
Follow the procedure in “(c) Erasing the
garage door opener memory”.
1. Decide which one of the 3 buttons you
want to program. Push and hold down
the button for about 20 seconds until
the indicator light begins to flash.
While holding this button down, follow
steps 2 and 3.
2. Bring the hand held garage door open-
er to within about 25 mm (1 in.) of the
button being programmed and push the
button on the hand held garage door
opener. The signal from the hand held
garage door opener is sent to the ve-
hicle’s opener.
3. When the frequency and code is regis-
tered, the indicator light flashers rapid-
ly. At this point, your can release both
buttons.
4. To program the remaining buttons, re-
peat steps 1 through 3.NOTICE
Canada only:
As your hand held garage door open-
er may automatically stop sending the
signal during programming, press and
re−press the hand held garage door
opener button every two seconds dur-
ing steps 1 through 4 above until the
frequency and code is registered.
If you want to replace an existing program
with a new program, select the button you
want to program. Follow the procedure
from step 1.
If the transmitter has a rolling code
feature, it is necessary to program the
in−garage receiver after programming
HomeLink.
1. Locate the training or learning but-
ton on the in−garage receiver and
push and release this button. Loca-
tion of the button may vary among
garage door opener manufacturers.
2. Firmly push and release the trained
HomeLink button 2 times (some ga-
rage door manufacturers may require
you to push the HomeLink button
up to 3 times) to complete the pro-
cess.The garage door should now operate
when the HomeLink button is pushed.
Do not use the HomeLink universal
transmitter with any garage door opener
that lacks the safety stop and reverse
feature as required by Federal Safety
Standards. This includes any garage door
opener model manufactured before April 1,
1982.
CAUTION
When programming or operating the
garage door opener, make sure there
is no one around the moving door.
(b) Operating the garage door opener
Push the appropriate button to activate the
garage door opener. The indicator light
comes on. The garage door opener contin-
ues to send the signal as long as the
button is pushed (up to 20 seconds).
(c) Erasing the garage door opener
memory
Push and hold down the 2 outside buttons
for about 20 seconds until the indicator
light flashes. All memorized data will be
erased.
ProCarManuals.com

01 SIENNA_U (L/O0008)
2082001 MY SIENNA (OM45406U)
FCC ID: CB2V94800
CANADA: 1763 102 264
This device complies with FCC Rules
Part 15. Operation is subject to the fol-
lowing two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any interfer-
ence that may be received, including
interference that may cause undesired
operation.
WARNING: This transmitter has been
tested and complies with FCC and
DOC/MDC rules. Changes or modifica-
tions not expressly approved by the
partly responsible for compliance
could void the user’s authority to op-
erate the device.
Garage door opener box
The box is designed to store a garage
door opener transmitter.
Open the cover and remove the Velcro
loop.Remove the paper strip covering the adhe-
sive on back side of loop and adhere loop
to back side of the transmitter near cen-
ter.
ProCarManuals.com

01 SIENNA_U (L/O0008)
2092001 MY SIENNA (OM45406U)
Please note if transmitter has wire clip for
sun visor, this clip must be removed prior
to adhesion of the Velcro.Place the transmitter with Velcro loop fac-
ing inside of box into the box. Make sure
the transmitter button is located above
button pins.Remove spacers from the center panel.
Place the largest spacer on the pin that
would be below transmitter button when
the cover is closed. Close the cover.
ProCarManuals.com

01 SIENNA_U (L/O0008)
2102001 MY SIENNA (OM45406U)
When the garage door opener transmitter
is properly installed, you can operate the
transmitter by pushing the center panel of
the cover.If the center panel does not contact with
your garage door opener transmitter:
Check to see if spacer is on correct
pin.
Attach another spacer to the top of
original spacer. Check operation. If re-
quired, continue add spacers until con-
tact is achieved.
If the transmitter is clattering during driv-
ing, fill in a piece of felt or pad to prevent
the transmitter from clattering.
CAUTION
To reduce the chance of injury in
case of an accident or a sudden
stop, always keep the garage door
opener box closed while driving.
Keep the remained spacers away
from children.
ProCarManuals.com

01 SIENNA_U (L/O0008)
2112001 MY SIENNA (OM45406U)
The auxiliary box and garage door
opener box (stored in the glove box)
are interchangeable.
Removing the cover—
Half open the cover. Pinch each hinge and
pull it out of its pivot one by one as
shown above.
Do not remove the cover forcibly.Installing the cover—
Align the hinges to the pivots, and press
each hinge with a thumb until you hear a
click.
Make sure that the cover opens and
closes smoothly.
Compass
The direction is indicated on the inside
rear view mirror.
If the ignition switch was turned off with
the system on, the system will automati-
cally turn back on when the ignition switch
is turned on.
Push the “COMP” switch to turn the com-
pass system on and off.
ProCarManuals.com

01 SIENNA_U (L/O0008)
2122001 MY SIENNA (OM45406U)
The compass indicates the direction
that the vehicle is heading. In the
above case, it shows that the vehicle is
heading north.
Displays
Directions
N
NE
E
SE
S
SW
W
NWNorth
Northeast
East
Southeast
South
Southwest
West
Northwest
The compass may not show the correct
direction in the following conditions:
The vehicle is stopped immediately af-
ter turning.
The compass does not adjust while the
vehicle is stopped.
The ignition switch is turned off imme-
diately after turning.
The vehicle is on an inclined surface.
The vehicle is in a place where the
earth’s magnetic field is subject to in-
terference by artificial magnetic fields
(underground parking, under a steel
tower, between buildings, roof parking,
near a crossing, near a large vehicle,
etc.).
The vehicle is magnetized. (There is a
magnet or a metal object on or near
the inside rear view mirror.)
The battery has been disconnected.
Your vehicle is out of the set zone. Refer
to the “CALIBRATING THE COMPASS” in
this section to set the zone number.
The compass works to calibrate the direc-
tion automatically while the vehicle is in
motion, if deviation is small.
For additional precision or for complete
calibrating, see “CALIBRATING THE
COMPASS” below.
Compass sensor
The compass sensor is in the inside
rear view mirror.
NOTICE
Do not put magnets or a metal object
on or near the inside rear view mirror
of the vehicle. Doing this may cause
malfunction of the compass sensor.
