2001 TOYOTA COROLLA Owners Manual

'01 Corolla U (L/O 0005)
1362001MY_COROLLA_U (OM12720U)
Side vents
If air flow control is not satisfactory, check
the side vents. The side vents may be
opened or closed as shown.
ProCarManuals.com

'01 Corolla U (L/O 0005)
1372001MY_COROLLA_U (OM12720U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Other equipment
Clock138 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside temperature display138 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cigarette lighter and ashtray139 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power outlet139 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glove box140 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Auxiliary boxes140 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cup holders141 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Floor mat142 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 1± 9
ProCarManuals.com

'01 Corolla U (L/O 0005)
1382001MY_COROLLA_U (OM12720U)
Clock
The digital clock indicates the time.
The key must be in the ªACCº or ªONº
position.
To reset the hour: Push the ªHº button.
To reset the minutes: Push the ªMº button.
If the electrical power source has been
disconnected from the clock, the time dis-
play will automatically be set to 1:00 (one
o'clock).
When the instrument panel lights are
turned on, the brightness of the time in-
dication will be reduced.
Outside temperature display
Centigrade display
Fahrenheit display
The outside temperature display indi-
cates the outside air temperature.
The key must be in the ªONº position.
If there is some abnormality in the con-
nection of the outside air temperature sen-
sor, ª±Eº or ªEº will appear on the display.
If ª±Eº or ªEº appears on the display,
contact your Toyota dealer.
ProCarManuals.com

'01 Corolla U (L/O 0005)
1392001MY_COROLLA_U (OM12720U)
Cigarette lighter and ashtray
CIGARETTE LIGHTER
To use the cigarette lighter, press it in.
When it becomes heated, it automatical-
ly pops out ready for use.
If the engine is not running, the key must
be in the ªACCº position.
Do not hold the cigarette lighter pressed
in.
Use a Toyota genuine cigarette lighter or
equivalent for replacement.ASHTRAY
To use the ashtray, open out.
When finished with your cigarette, thor-
oughly extinguish it in the ashtray to pre-
vent other cigarette butts from catching
fire. After using the ashtray, push it back
in completely.
To remove the ashtray, press down on the
lock spring plate and pull out.
CAUTION
To reduce the chance of injury in
case of an accident or sudden stop
while driving, always push the ash-
tray back in completely after use.
Power outlet
The power outlet is designed for power
supply for car accessories.
The key must be in the ºACCº or ºONº
position for the power outlet to be used.
NOTICE
To prevent the fuse from being
blown, do not use the electricity
over the total vehicle capacity of 12
V/120W.
To prevent the battery from being
discharged, do not use the power
outlet longer than necessary when
the engine is not running.
ProCarManuals.com

'01 Corolla U (L/O 0005)
1402001MY_COROLLA_U (OM12720U)
Close the power outlet lid when the
power outlet is not in use. Inserting
a foreign object other than the ap-
propriate plug that fits the outlet,
or allowing any liquid into the out-
let may cause electrical failure or
short circuits.
Glove box
To open the glove box door, pull the
lever.
CAUTION
To reduce the chance of injury in
case of an accident or a sudden stop,
always keep the glove box door
closed while driving.
Auxiliary boxes
Ty p e A
Ty p e B
ProCarManuals.com

'01 Corolla U (L/O 0005)
1412001MY_COROLLA_U (OM12720U)
Ty p e C
To use the box, do the following.
Type A and type B: Pull on the handle.
Type C: Open the center console box.
CAUTION
To reduce the chance of injury in
case of an accident or a sudden stop,
always keep the auxiliary box closed
while driving.
Cup holders
Type A (front)
Type B (rear)
Type C (rear)
The cup holder is designed for holding
cups or drink±cans securely.
Type A: To use the holder, push in and
pull it out completely.
Type B: To use the holder, pull it out.
Type C: To use the holder, pull it out and
widen the arm to fit to the size of a cup
or drink±can.
ProCarManuals.com

'01 Corolla U (L/O 0005)
1422001MY_COROLLA_U (OM12720U)
Type C onlyÐ
The arms must be pushed in before the
lid is pulled up.
NOTICE
Be sure to push in the arms before
closing the cup holder lid.
CAUTION

Do not place anything else other
than cups or drink±cans on the cup
holder, as such items may be
thrown about in the compartment
and possibly injure people in the
vehicle during sudden braking or in
an accident.

To reduce the chance of injury in
case of an accident or a sudden
stop while driving, keep the cup
holder closed when it is not in use.
Floor mat
Use a floor mat of the correct size.
If the floor carpet and floor mat have a
hole, then it is designed for use with a
locking clip. Fix the floor mat with locking
clip into the hole in the floor carpet.

ProCarManuals.com

'01 Corolla U (L/O 0005)
1432001MY_COROLLA_U (OM12720U)
CAUTION
Make sure the floor mat is properly
placed on the floor carpet. If the floor
mat slips and interferes with the
movement of the pedals during driv-
ing, it may cause an accident.
