2001 TOYOTA COROLLA Owners Manual

'01 Corolla U (L/O 0005)
82001MY_COROLLA_U (OM12720U)
ProCarManuals.com

'01 Corolla U (L/O 0005)
92001MY_COROLLA_U (OM12720U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Keys and Doors
Keys10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Side doors10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power windows12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trunk lid14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hood16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel tank cap17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electric moon roof18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 1± 2
ProCarManuals.com

'01 Corolla U (L/O 0005)
102001MY_COROLLA_U (OM12720U)
Keys
Your vehicle is supplied with two kinds
of keys.
1. Master keyÐThis key works in every
lock.
2. Sub keyÐThis key will not work in the
trunk.
To protect things locked in the trunk when
you have your vehicle parked, leave the
sub key with the attendant.
Since the doors and trunk lid can be
locked without a key, you should always
carry a spare master key in case you
accidentally lock your keys inside the ve-
hicle.KEY NUMBER PLATE
Your key number is shown on the plate.
Keep the plate in a safe place such as
your wallet, not in the vehicle.
If you should lose your keys or if you
need additional keys, duplicates can be
made by a Toyota dealer using the key
number.
We recommend you to write down the key
number and keep it in safe place.
Side doors
LOCKING AND UNLOCKING WITH KEY
Insert the key into the keyhole and turn
it.
To lock: Turn the key forward.
To unlock: Turn the key backward.
Vehicles with power door lock systemÐAll
the doors lock and unlock simultaneously
with either front door. In the driver 's door
lock, turning the key once will unlock the
driver's door and twice in succession will
unlock all the doors simultaneously.
ProCarManuals.com

'01 Corolla U (L/O 0005)
112001MY_COROLLA_U (OM12720U)
LOCKING AND UNLOCKING WITH
INSIDE LOCK BUTTON
Move the lock button.
To lock: Push the button down.
To unlock: Pull the button up.
Closing the door with the lock button in
the lock position will also lock the door.
Be careful not to lock your keys in the
vehicle.
Vehicles with power door lock sys-
temÐThe door cannot be locked if you
leave the key in the ignition switch.With power windows (driver's side)
With power windows (passenger's side)
Without power windows
LOCKING AND UNLOCKING WITH
POWER DOOR LOCK SWITCH
Push the switch.
Vehicles with power windowsÐ
To lock: Push the switch on the front side.
To unlock: Push the switch on the rear
side.
Vehicles without power windowsÐ
To lock: Push the switch on the ªLOCKº
side.
To unlock: Push the switch on the oppo-
site side of the ªLOCKº side.
All the doors lock or unlock simultaneous-
ly.
ProCarManuals.com

'01 Corolla U (L/O 0005)
122001MY_COROLLA_U (OM12720U)
REAR DOOR CHILD±PROTECTORS
Move the lock lever to the ªLOCKº
position as shown on the label.
This feature allows you to lock a rear
door so it can be opened from the outside
only, not from inside. We recommend us-
ing this feature whenever small children
are in the vehicle.
CAUTION
Before driving, be sure that the doors
are closed and locked, especially
when small children are in the ve-
hicle. Along with the proper use of
seat belts, locking the doors helps
prevent the driver and passengers
from being thrown out from the ve-
hicle during an accident. It also helps
prevent the doors from being opened
unintentionally.
Power windows
The windows can be operated with the
switch on each door.
The power windows work when the ignition
switch is in the ªONº position.
OPERATING THE DRIVER'S WINDOW
Use the switch on the driver's door.
Normal operation: The window moves as
long as you hold the switch.
To open: Lightly push down the switch.
To close: Pull up the switch.
ProCarManuals.com

'01 Corolla U (L/O 0005)
132001MY_COROLLA_U (OM12720U)
Automatic operation (to open only):
Push the switch completely down and then
release it. The window will fully open. To
stop the window partway, lightly pull the
switch up and then release it.
Window
lock switch
OPERATING THE PASSENGERS'
WINDOWS
Use the switches on the passengers'
doors. The driver 's door also has
switches that control the passengers'
windows.
The window moves as long as you hold
the switch.
To open: Push down the switch.
To close: Pull up the switch.
If you push in the window lock switch on
the driver 's door, the passengers' windows
cannot be operated.
ProCarManuals.com

'01 Corolla U (L/O 0005)
142001MY_COROLLA_U (OM12720U)
CAUTION
To avoid serious personal injury, you
must do the following.

Always make sure the head, hands
and other parts of the body of all
occupants are kept completely in-
side the vehicle before you close
the power windows. If someone's
neck, head or hands gets caught in
a closing window, it could result in
a serious injury. When anyone
closes the power windows, be sure
that they operate the windows safe-
ly.

When small children are in the ve-
hicle, never let them use the power
window switches without supervi-
sion. Use the window lock switch to
prevent them from making unex-
pected use of the switches.

Never leave small children alone in
the vehicle, especially with the igni-
tion key still inserted. They could
use the power window switches and
get trapped in a window. Unat-
tended children can become in-
volved in serious accidents.
Trunk lidÐ
To open the trunk lid from the outside,
insert the master key and turn it clock-
wise.
See ªLuggage stowage precautionsº in
Section 2 for precautions in loading lug-
gage.
To close the trunk lid, lower it and press
down on it. After closing the trunk lid, try
pulling it up to make sure it is securely
closed.
CAUTION

Keep the trunk lid closed while
driving. This not only keeps the
luggage from being thrown out but
also prevents exhaust gases from
entering the vehicle.

Always lock the trunk lid and all
doors, and keep away the vehicle
keys out of children's reaches.

Never leave children unattended in
the vehicle. Unsupervised children
may lock themselves in the vehicle
or trunk and suffer serious injuries
or death.
ProCarManuals.com

'01 Corolla U (L/O 0005)
152001MY_COROLLA_U (OM12720U)
ÐLock release lever
To open the trunk lid from the driver's
seat, pull up on the lock release lever.After closing the trunk lid, insert the
master key and turn it counterclockwise
to deactivate the lock release lever.
After closing the trunk lid, try pulling it up
to make sure it is securely locked.If a person is locked in the trunk, pull
down the phosphorescent handle lever
on the inside of trunk lid in case of
emergency to open the trunk lid.
ÐLock release lever
cancelling systemÐInternal trunk release
handle
