2001 SUBARU LEGACY Owners Manual

In case of emergency9-7
–
CONTINUED –
sid e of the lid on the rear ed g e of the roof to kee
p the lid op en.
Remove the storag e tray. Turn the attac hing b olt c o unterc loc kwise, then
take sp are tire out.
If the sp are tire p rovid ed in your vehic le is a tem p orary sp are tire, c are-
fully read the sec tion “Temp orary sp are tire ” in this c hap ter and stric tly
follow the instruc tions.
HB7008CD
HB9001BB
The jac k is stored on the left sid e of the trunk or c arg o area.
To take out the jac k:
Remove the c over, turn the jac ksc rew c ounterc loc kwi se to loosen it, then
remove the jac k.
The jac k hand le is stored und er the sp are tire c ove r.

9-8
6. (If your vehic le has wheel c overs) Insert the whe
el nut wrenc h into the
notc h p rovid ed in the wheel c over, and p ry it off.
OM-H0376HGA012BB
7. Loosen the wheel nuts using the wheel nut wrenc h b ut d o not remove
the nuts.
8. Plac e the jac k und er the sid e sill at the front o r rear jac k-up p oint c los-
est to the flat tire.
HB9012BB
OM-H2262
Turn the jac ksc rew b y hand until the jac k head eng a
g es firmly into the
jac k-up p oint.
If your vehic le is eq uip p ed with sid e sill skirts, jac k-up p oints are p ointed
to b y arrow marks on the und ersid e of the sid e sill skirt. Plac e the jac k
und er the front or rear jac k-up p oint c losest to fl at tire.

In case of emergency9-9
–
CONTINUED –
9. Insert the jac k hand le into the jac ksc rew, and tu
rn the hand le until the
tire c lears the g round . Do not raise the vehic le hi g her than nec essary.
OM-H2263
10. Remove the wheel nuts and the flat tire.
11. Before p utting the sp are tire on, c lean the moun ting surfac e of the
wheel and hub with a c loth.
HG0104
OM-H0172
12. Put on the sp are tire. Rep lac e the wheel nuts. T ig hten them b y hand .
13. Turn the jac k hand le c ounterc loc kwise to lower t he vehic le.

9-1014. Use the wheel nut wrenc h to sec urely tig hten the
wheel nuts to the
sp ec ified torq ue, following the tig htening ord er in the illustration.
OM-H0377
The torq ue for tig htening the nuts is 58 to 72 ft-lb (78 to 98 N-m, 8 to 10
kg -m). This torq ue is eq uivalent to ap p lying ab out 88 to 110 lb s (40 to 50
kg ) at the top of the wheel nut wrenc h. Never use y our foot on the wheel
nut wrenc h or a p ip e extension on the wrenc h b ec aus e you may exc eed
the sp ec ified torq ue. Have the wheel nut torq ue c he c ked at the nearest
automotive servic e fac ility.
15. Store the flat tire in the sp are tire c omp artmen t.
HS0153
Flat tireAttaching bolt
Spacer
When storing a c onventional tire, p ut the sp ac er up sid e d own and tig ht-
en the attac hing b olt firmly.
Also store the jac k and wheel nut wrenc h in their s torag e loc ations.

In case of emergency9-11
–
CONTINUED –
Jump starting
WARNING
Battery fluid is SULFURIC ACID. Do not let it come in contact
with the eyes, skin, clothing or the vehicle. If battery fluid gets on you, thoroughly flush the exposed area
with water immediately. Get medical help if the fluid has enteredyour eyes. If battery fluid is accidentally swallowed, immediately drink a
large amount of milk or water, and obtain immediate medicalhelp.
Keep everyone including children away from the battery. The gas generated by a battery explodes if a flame or spark is
brought near it. Do not smoke or light a match while jump start-ing. Never attempt jump starting if the discharged battery is frozen.
It could cause the battery to burst or explode. Whenever working on or around a battery, always wear suit-
able eye protectors, and remove metal objects such as rings,
bands or other metal jewelry. Be sure the jumper cables and clamps on them do not have
loose or missing insulation.Do not jump start unless cables in suitable condition are avail-able. A running engine can be dangerous. Keep your fingers, hands,
clothing, hair and tools away from the cooling fan, belts and anyother moving engine parts. Removing rings, watches and ties isadvisable.
When your vehic le d oes not start d ue to a run d own (d isc harg ed ) b at-
tery, the vehic le may b e jump started b y c onnec ting your b attery to
another b attery (c alled the b ooster b attery) with j ump er c ab les.
Jump starting is d ang erous if it d one inc orrec tly. If you are unsure ab out
the p rop er p roc ed ure for jump starting , c onsult a c omp etent mec hanic .

9-12
How to jump start
1. Make sure the b ooster b attery is 12 volts and the neg ative terminal
is g round ed .
2. If the b ooster b attery is in another vehic le, d o not let the two ve-
hic les touc h.
3. Turn off all unnec essary lig hts and ac c essories.
4. Connec t the jump er c ab les exac tly in the seq uenc e illustrated .
HB8007BC

In case of emergency9-13
–
CONTINUED –
HB9031BB
1Connec t one jump er c ab le to the p ositive (+ ) termin al on the
d isc harg ed b attery. 2 Connec t the other end of the jump er c ab le to the p o sitive (+ )
terminal of the b ooster b attery.3 Connec t one end of the other c ab le to the neg ative (– ) terminal
of the b ooster b attery.4 Connec t the other end of the c ab le.
2.5 liter mod els: To the eng ine lifting b rac ket.
3.0 liter mod els: To the strut mounting nut.
Make sure that the c ab les are not near any moving p arts and that
the c ab le c lamp s are not in c ontac t with any other metal.
5. Start the eng ine of the vehic le with the b ooster b attery and run it at
mod erate sp eed . Then start the eng ine of the vehic l e that has the d is-
c harg ed b attery.
6. When finished , c arefully d isc onnec t the c ab les in exac tly the re-
verse ord er.

9-14Engine overheating
WARNING
Never attempt to remove the radiator cap until the engine has been shut off and has fully cooled down. When the engine is hot,the coolant is under pressure. Removing the cap while the engineis still hot could release a spray of boiling hot coolant, which
could burn you very seriously.
If the eng ine overheats, safely p ull off the road a nd stop the vehic le in a
safe p lac e.
If steam is coming from the engine compartment
Turn the eng ine off and g et everyone away from the vehic le until it
c ools d own. If no steam is coming from the engine compartment
1. Keep the eng ine running at id ling sp eed .
2. Op en the hood to ventilate the eng ine c omp artment .
Confirm that the c ooling fan is turning . If the fan is not turning , im-
med iately turn the eng ine off and c ontac t your auth orized d ealer for
rep air.
3. After the eng ine c oolant temp erature has d rop p ed , turn off the en-
g ine.
If the temp erature g aug e stays at the overheated zo ne, turn the en-
g ine off.
4. After the eng ine has fully c ooled d own, c hec k the c oolant level in
the reserve tank.
If the c oolant level is b elow the “MIN ” mark, ad d c oolant up to the
“ MAX ” mark.
5. If there is no c oolant in the reserve tank, ad d c oolant to the reserve
tank. Then remove the rad iator c ap and fill the rad iator with c oolant.
If you remove the rad iator c ap from a hot rad iator, first wrap a thic k
c loth around the rad iator c ap , then turn the c ap c o unterc loc kwise
slowly without p ressing d own until it stop s. Releas e the p ressure from
