2001 GMC ENVOY Owners Manual

2-69
The console also contains the following components:

Rear Seat Audio Controls

Rear Seat Accessory Power Outlets

Six
-disc CD Changer

Cellular Phone (if equipped)
For more information on these components, please see
the Index for that item.
If your vehicle has the center armrest compartment,
lift the cover to expose the storage area which includes
slots for cassettes or compact discs and a coinholder.
Convenience Net (If Equipped)
You may have a convenience net in the rear of your vehicle
to help keep small items, like gloves and light clothing,
in place during sharp turns or quick stops and starts.
The net is not designed to retain these items during
off
-road use. The net is not for larger, heavier items.
Attach the upper loops to the retainers on either side
of the endgate/liftgate opening (the label should be in
the upper passenger side corner, visible from the rear
of vehicle). Attach the lower hooks to the rear cargo tie
downs on the floor.
ProCarManuals.com

2-70
Cargo Cover (If Equipped)
If your vehicle has a cargo cover, you can use it to cover
items in the cargo area of your vehicle.
Grasp the handle and unroll the cover. Latch the posts
into the sockets on the inside trim panel on the
passenger's side of the vehicle to secure it.
CAUTION:
An improperly stored cargo cover could be
thrown about the vehicle during a collision
or sudden maneuver. You or others could be
injured. If you remove the cover, always store it
outside of the vehicle. When you put it back,
always be sure that it is securely reattached.
Cargo Tie Downs
There are five cargo tie
downs in the rear of your
vehicle that allow you to
strap cargo in and keep it
from moving.
Rear Convenience System (If Equipped)
CAUTION:
If the convenience system isn't secured properly,
it can move around in a collision or sudden stop.
People in the vehicle could be injured. Be sure to
secure the convenience system properly.
ProCarManuals.com

2-71
The convenience system, located in the rear of your vehicle,
provides a place to store loose items in your vehicle.
A. Collapsible Dividers
B. Anchor Bracket/
Cargo Tie
-Down
Plugs
C. PartitionsD. Soda Pop/Gallon
Jug Holder
E. Partition Storage
F. Cargo Tie
-Down
CutoutsTo increase the space in the convenience system,
do the following:
1. Remove the individual partitions (C) by pulling
upward on the partitions. Storage for the partitions
is located in area (F).
2. Then fold the collapsible dividers (A) by pulling
upward and folding the dividers toward each other.
To reinstall or rearrange the partitions, push down gently
on the partitions making sure both sides fit into the
appropriate slots of the collapsible dividers (A).
Located on the top of each collapsible divider (A) are
T
-pins designed to hold grocery bags, etc., in an
upright position.
The anchor bracket/cargo tie down plugs (B), located in
the center and on each side of the convenience system
nearest the passenger compartment, are used to help seal
the convenience system. However, the plugs also cover
the anchor bracket /cargo tie
-downs. To remove the
plugs, grasp the edges of the plugs and pull straight out.
See ªChild Restraintsº and ªTop Strapº in the Index
for more information on using anchor brackets.
ProCarManuals.com

2-72
There are two cutouts (E) for the rear cargo tie-downs
located near the liftgate/endgate sill. In order to access
the rear cargo tie
-downs, the cutouts must be removed.
You will also find a soda pop/gallon jug holder (D) on
the passenger side of the convenience system. Some
vehicles do not have this feature, but instead include a
smaller storage area.
To remove the entire convenience system,
do the following:
1. Remove the convenience net if it is in place.
See ªConvenience Netº in the Index for more
information. You may also want to remove the
partitions (C) and fold the collapsible dividers (A)
to make the convenience system easier to handle.
2. Grasp the sides of the convenience system and push
the sides together while sliding the unit out until it
clears the sides of the liftgate/endgate opening.
To reinstall the convenience system, reverse the
removal procedure.
Luggage Carrier (Option)
CAUTION:
If you try to carry something on top of your
vehicle that is longer or wider than the luggage
carrier
-- like paneling, plywood, a mattress,
and so forth
-- the wind can catch it as you
drive along. This can cause you to lose control.
What you are carrying could be violently torn
off, and this could cause you or other drivers
to have a collision, and of course damage your
vehicle. You may be able to carry something like
this inside. But, never carry something longer
or wider than the luggage carrier on top of
your vehicle.
The luggage carrier has slats, side rails and crossrails
attached to the roof to secure cargo. The adjustable tie
downs, at either end of the crossrails, should be used to
secure loads to the luggage carrier.
ProCarManuals.com

2-73
Use GM accessory racks that are compatible with
your luggage carrier for transporting sports equipment.
These are available through your GM dealer.
You can adjust the crossrails to handle loads of various
sizes. Just loosen the slider knobs at each end of the
crossrail and move them to where you want them.
Make sure both sides of the crossrails are even,
then tighten the slider knobs.
Be sure the cargo is properly loaded.
Follow these guidelines:

Carrying small, heavy loads on the roof is
not recommended.

Tie the load to the tie downs (at either end of
the crossrails). When loading cargo directly on
the roof panel, use the crossrails to keep the load
from shifting.

If you need to carry long items, move the crossrails
as far apart as possible. Tie the load to the tie downs
provided. Also tie the load to the bumpers. Do not
tie the load so tightly that the crossrails or side rails
are damaged.
NOTICE:
Loading cargo that weighs more than 200 lbs.
(91 kg) on the luggage carrier may damage your
vehicle. When you carry large things, never let
them hang over the rear or the sides of your
vehicle. When loading cargo on the roof panel,
be sure it rests on the slats and does not scratch
or damage the vehicle.
Put the cargo against the side rails and fasten it
securely to the luggage carrier. Put the main
weight as far forward as you can and move the
rear crossrail forward as far as possible to keep
the load from shifting.
Don't exceed the maximum vehicle capacity when loading
your vehicle. For more information on vehicle capacity
and loading, see ªLoading Your Vehicleº in the Index.
To prevent damage or loss of cargo as you're driving,
check now and then to make sure the luggage carrier and
cargo are still securely fastened.
ProCarManuals.com

2-74
Ashtrays and Cigarette Lighter
Pull the front ashtray door down to open it.
NOTICE:
Don't put papers and other things that burn into
your ashtray. If you do, cigarettes or other smoking
materials could set them on fire, causing damage.
To remove the front ashtray, pull the bin upward.
To use the lighter, press it in all the way, and let go.
When it's ready, it will pop back out by itself.
NOTICE:
Don't hold a cigarette lighter in with your hand
while it is heating. If you do, it won't be able to
back away from the heating element when it's
ready. That can make it overload, damaging the
lighter and the heating element.
Sun Visors
To block out glare, you can pull the visor down.
You can also swing the visor from side
-to-side.
Visor Vanity Mirror
Pull the sun visor down and lift the cover to expose the
vanity mirror.
Illuminated Visor Vanity Mirror
(If Equipped)
Pull the sun visor down and lift the mirror cover to turn
on the lamps.
ProCarManuals.com

2-75
Accessory Inflator (If Equipped)
Your vehicle may be equipped with an air inflator
system. With it, you can inflate things like air mattresses
and basketballs, and you can also use it to bring your
tires up to the proper pressure.
The air inflator is located
in the rear compartment on
the passenger's side of the
vehicle. To remove the
cover, pull the tab on the
cover and pull it off.
The air inflator kit includes an 18
-foot (5.5 m) hose with
three nozzle adapters.
CAUTION:
Inflating something too much can make it explode,
and you or others could be injured. Be sure to read
the inflator instructions, and inflate any object
only to its recommended pressure.
To use your air inflator
attach the appropriate
nozzle adapter, if required,
to the end of the hose.
Then attach that end of
the hose to the object you
wish to inflate. Remove the
protective cap covering the
outlet. Attach the other end
of the hose to the outlet.
Press the ON switch.
If the air inflator system does not turn on, the fuse may
be blown or installed incorrectly. See ªFuses and Circuit
Breakersº in the Index or see your dealer for service.
ProCarManuals.com

2-76
Your air inflator will automatically shut off after about
10 minutes. To reset, press the ON switch again.
Don't run your air inflator for longer than 30 minutes
at one time. If you do, you may damage the system.
After 30 minutes, wait at least 10 minutes before
restarting the air inflator.
To turn off the air inflator, press OFF and detach the
hose, first from the inflated object, then from the outlet.
Replace the protective cap. Place the inflator kit tools in
the pouch and store them properly.
To replace the cover, line up the tabs at the back of the
cover and put it in place.
See your dealer for more information on using the
accessory inflator.
Accessory Power Outlets
With the accessory power outlets, you can plug in
auxiliary electrical equipment. The accessory power
outlets are located near the center of the vehicle on the
lower part of the instrument panel. Just remove the
plug from the outlet and follow the proper installation
instructions that are included with any electrical
equipment you install. Some vehicles will have a small cover which must be
pulled down to access the accessory power outlets.
These vehicles will also have another power outlet
located in the lower rear of the center console.
Certain accessory power plugs may not be compatible
to the accessory power outlets and could result in blown
vehicle adapter fuses. If you experience a problem see
your dealer for additional information on accessory
power plugs.
These circuits are protected by a fuse and have
maximum current levels.
NOTICE:
Adding some electrical equipment to your vehicle
can damage it or keep other things from working
as they should. This wouldn't be covered by your
warranty. Check with your dealer before adding
anything that exceeds the fuse rating.
