2001 GMC ENVOY Owners Manual

3-
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle.
Be sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-2 Standard Climate Control System
3
-3 Electronic Climate Control System
(If Equipped)
3
-7 Air Conditioning
3
-7 Heating
3
-7 Defogging and Defrosting
3
-8 Rear Window Defogger (If Equipped)
3
-9 Ventilation System
3
-10 Audio Systems
3
-10 Setting the Clock for Systems with SET Button
3
-10 Setting the Clock for Systems with HR and
MN Buttons
3
-11 AM-FM Stereo
3
-13 AM-FM Stereo with Cassette Tape Player
(If Equipped)
3
-15 AM-FM Stereo with Cassette Tape Player and
Automatic Tone Control (If Equipped)3
-20 AM-FM Stereo with Cassette Tape Player
(Bose
) (If Equipped)
3
-25 AM-FM Stereo with Compact Disc Player and
Automatic Tone Control (If Equipped)
3
-29 AM-FM Stereo with Compact Disc Player
(Bose
) (If Equipped)
3
-33 Remote Cassette Tape Player (If Equipped)
3
-34 Rear Seat Audio (RSA) (If Equipped)
3
-38 Console-Mounted CD Changer (If Equipped)
3
-42 Theft-Deterrent Feature (If Equipped)
3
-44 Audio Steering Wheel Controls (If Equipped)
3
-45 Understanding Radio Reception
3
-45 Tips About Your Audio System
3
-46 Care of Your Cassette Tape Player
3
-48 Care of Your Compact Discs
3
-48 Care of Your Compact Disc Player
3
-48 Fixed Mast Antenna
ProCarManuals.com

3-2
Comfort Controls
With this system, you can control the heating, cooling
and ventilation in your vehicle.
Standard Climate Control System
Fan Knob
The knob on the left side of the heating system control panel
controls the fan speed. To increase airflow, move the knob
clockwise. To decrease airflow, move it counterclockwise.Temperature Knob
The middle knob on the control panel lets you select the
relative temperature of the air flowing into the passenger
area of your vehicle. Move the knob clockwise
toward the red area for warmer air. Move the knob
counterclockwise toward the blue area for cooler air.
Mode Knob
The right knob on the control panel allows you to
choose the direction of air delivery.
OFF: This setting turns the system off. Some outside
air will still enter the vehicle whenever the vehicle is
moving forward. If outside air entering the vehicle is
warmer than desired, turn the temperature knob fully
counterclockwise and turn the mode knob to VENT.
MAX A/C: This setting provides maximum cooling
with the least amount of work. MAX A/C recirculates
much of the air inside your vehicle so it cools quickly.
This setting directs most of the air through the
instrument panel vents and a small amount through
the floor vents.
ProCarManuals.com

3-3
A/C: This setting cools the air entering your vehicle
and directs most of the air through the instrument panel
vents and a small amount through the floor vents.
BI-LEVEL A/C: This setting cools the air
entering your vehicle and directs it through the heater
floor outlets as well as the instrument panel outlets.
VENT: This setting directs most of the air through
the instrument panel outlets and a small amount through
the floor outlets. The air conditioning compressor is not
working when VENT is selected.
HEATER: This setting directs most of the
warmed air through the heater floor outlets and some
air through the windshield defroster outlets.
BLEND: This setting divides the airflow equally
between the heater floor outlets and the windshield
defroster outlets.
DEFROST: This setting directs most air through
the windshield defroster outlets and some through the
heater (floor) outlets.
Electronic Climate Control System
(If Equipped)
Fan Knob
The knob on the left side of the electronic climate
control panel controls the fan speed. To manually
increase airflow, move the knob clockwise. To manually
decrease airflow, move it counterclockwise.
OFF: If the knob is in OFF, outside air will still enter
the vehicle, and will be directed based on the position of
the mode knob.
AUTO: If the knob is in AUTO, the fan speed will
vary as the system maintains the selected temperature.
ProCarManuals.com

3-4
Temperature Knob
The middle knob on the control panel lets you select
the desired air temperature in your vehicle. This knob
will allow you to adjust the interior air temperature
independently of the function knob setting. Move the
knob clockwise toward 82 for warmer air. Move the
knob counterclockwise toward 66 for cooler air.
Full Hot: If you turn the temperature knob past
82
F (28
C), the system will go into the ªfull hotº
mode. The system will remain at that maximum heating
setting and the fan will blow at the speed the fan knob is
set to. If the fan is in AUTO, it will run at full speed.
Full Cold: If you turn the temperature knob past
66
F (19
C), the system will go into the ªfull coldº
mode. The system will remain at that maximum cooling
setting and the fan will blow at the speed the fan knob is
set to. If the fan is in AUTO, it will run at full speed.
Choosing either maximum setting will not cause the
system to heat or cool any faster.Mode Knob - Automatic Operation
The right knob on the control panel allows you to
choose the direction of air delivery. When the system is
set for automatic operation, sensors will control the air
delivery mode. Air will come primarily from the floor or
instrument panel outlets, with some air directed to the
windshield to prevent fogging.
When the system is in AUTO mode, the air conditioning
light will turn on, and the recirculation and outside air
lights turn off. With the system in full auto control
(both the fan and mode knobs in AUTO), you still
have the ability to override any function. However,
continually overriding the outside air or the A/C
compressor will limit the ability of the system to cool
the vehicle quickly.
If you push a button for a function which is not
available, the light next to that button will flash three
times to alert you that it's not available.
To find your comfort zone, start with the 74
F (23
C)
setting and allow about 20 minutes for the system to
adjust the temperature if necessary.
ProCarManuals.com

3-5
With the automatic setting, the air conditioning
compressor automatically cycles when needed to cool the
air. In cold weather, when the system senses the need for
heat, the airflow will be directed out of the floor outlets.
As the interior temperature approaches a desired setting,
the fan speed will decrease. To maintain interior comfort,
the airflow will adjust between the instrument panel air
outlets and floor outlets. On bright sunny days in cool
weather, the airflow may come out of the air conditioning
and floor outlets (bi
-level mode) to maintain comfort and
prevent stuffiness.
To avoid blowing cold air in cold weather, the system
will delay turning on the fan until warm air is available.
The length of delay depends on the outside air temperature,
engine coolant temperature or the time since the engine was
last started. As the coolant warms up, the fan speed will
gradually increase and air will flow from the heater outlets,
with some airflow to the windshield to prevent fogging
under most normal conditions.
If your vehicle is sitting out on a warm day and you
have the fan set on AUTO, the air will first flow out of
the floor air outlets for a few seconds. That is normal.
This is to expel hot air from the air outlets. As the air is cooled, the airflow will move through the
air conditioning outlets.
Be careful not to put anything over the solar sensor
located around the center of the instrument panel.
This sensor is used by the automatic system to
regulate temperature.
Mode Knob
- Manual Operation
The right knob on the control panel allows you to
choose the direction of air delivery.
You can choose to set the climate control system
operations yourself, or let the system work for you
by placing the system in AUTO mode. See ªMode
Knob
- Automatic Operationº earlier in this section.
VENT: This setting directs most of the air through
the instrument panel outlets and a small amount through
the floor outlets.
BI-LEVEL: This setting directs air through
the heater floor outlets as well as the instrument
panel outlets.
ProCarManuals.com

3-6
HEATER: This setting directs most of the
warmed air through the heater floor outlets and some
air through the windshield defroster outlets.
BLEND: This setting divides airflow equally
between the heater floor outlet and the windshield
defroster outlets. The air conditioning compressor may
run to dehumidify the air to prevent window fogging.
DEFROST: This setting directs most air through
the windshield defroster outlets and some through the
heater outlets. The air conditioning compressor may run
to dehumidify the air to prevent window fogging.
OUTSIDE AIR: Press this button to force
the system to use outside air. Press it again to close off
the outside air.
Pressing the OUTSIDE AIR button will cancel the
RECIRCULATION button.
RECIRCULATION: Press this button to
limit the amount of outside air entering your vehicle.
This is helpful when you are trying to limit odors
entering your vehicle. In the AUTO mode, the
system will use recirculation as necessary to cool
the air. Pressing the recirculation button will change
the operation to a manual mode. Press this button
again to turn off the recirculation feature.
RECIRCULATION may be selected with the fan knob
in OFF to limit odors, outside air and dust from entering
your vehicle.
Pressing the RECIRCULATION button will cancel the
OUTSIDE AIR button.
A/C: Press this button to turn the air conditioning
on and off. The system will cool and dehumidify the air
inside the vehicle when the A/C light is on.
Air conditioning will be automatically disabled when
the outside temperature drops below a level at which air
conditioning is ineffective.
Remember that in order for the automatic system to perform
well, it needs A/C to provide cooling performance.
ProCarManuals.com

3-7 Air Conditioning
On hot days, open the windows long enough to let hot
inside air escape. This reduces the time it takes for your
vehicle to cool down. Then keep your windows closed
for the air conditioner to work its best.
For quick cool
-down on very hot days, use MAX A/C
with the temperature knob turned to the left. This setting
should be used to keep odors and/or dust from entering
the vehicle. For normal cooling on hot days, use A/C
with the temperature knob turned to the left.
On vehicles equipped with the Electronic Climate Control
system, this same performance can be achieved as long as
the A/C is on and the outside air button is not active.
On cool but sunny days, use BI
-LEVEL A/C to deliver
warm air to the floor and cooler air to the instrument
panel outlets.
When the air conditioner is on, you may sometimes
notice slight changes in your vehicle's engine speed
and power. This is normal because the system is
designed to cycle the compressor on and off to keep
the desired temperature.
Heating
The heater works best if you keep your windows closed
while using it. On cold days, use HEATER with the
temperature knob turned clockwise. BLEND is useful
in cool weather when you have fog or ice on the
windshield or side windows.
If you use the optional engine coolant heater before
starting your engine, your heating system will produce
warmer air faster to heat the passenger compartment in
cold weather. See ªEngine Coolant Heaterº in the Index.
Defogging and Defrosting
On cool, humid days, use BLEND to keep the
windshield and side windows clear.
Use DEFROST to remove fog or ice from the
windshield quickly in extreme humid or cold conditions.
Turn the temperature knob to the right and move the
fan knob toward high.
ProCarManuals.com

3-8 Rear Window Defogger (If Equipped)
If your vehicle has this
option, the rear window
will have lines that
warm the glass.
For best results, clear the window of as much snow or
ice as possible before using the rear window defogger.
To turn on the rear window defogger, find the button
marked REAR with the defog symbol on the lower right
corner of your climate control system. Press the button
until the light in the button comes on, then release it.
It will only work if the ignition switch is turned to RUN.Pressing the REAR button on your climate control
system will also activate your heated outside mirrors
(if equipped). This will help to keep ice and snow from
collecting on your mirror surfaces.
The rear window defogger will stay on for five to seven
minutes, then turn off. If you need additional warming
time, turn it on again. You can turn the defogger off at
any time by pressing the button.
Do not attach a temporary vehicle license, tape or decals
across the defogger grid on the rear window.
NOTICE:
Don't use a razor blade or something else sharp
on the inside of the rear window. If you do, you
could cut or damage the warming grid, and the
repairs wouldn't be covered by your warranty.
ProCarManuals.com
