2001 GMC ENVOY Owners Manual

2-61
Heated Outside Rearview Mirrors
(If Equipped)
When you operate the rear window defogger, a defogger
also warms the heated outside rearview mirrors to help
clear them of ice, snow and condensation. See ªRear
Window Defoggerº in the Index for more information.
Power Folding Mirrors (If Equipped)
Your vehicle may be
equipped with power folding
mirrors. This feature can be
helpful when taking your
vehicle through a car wash
or through narrow spaces.To fold the mirrors in, press the blank side of the switch
located on the driver's side door panel near the window.
To have the mirrors return to their normal position, press
the side of the switch with the graphic on it. The switch
will stay on in which ever position it is placed.
If at any time your mirrors become disengaged, fold the
mirrors out manually and then use the switch to fold the
mirrors in and out. This will assure that the power fold
unit in your mirrors is properly engaged.
Storage Compartments
Glove Box
To open your glove box, lift the lever on the front of the
glove box and lower the door. The glove box should not
be open while you are driving.
ProCarManuals.com

2-62
Overhead Console (If Equipped)
The overhead console includes reading lamps, a
compartment for a garage door opener, a temperature and
compass display and a storage compartment for sunglasses.
Some models have a driver information system in the
console. See ªDriver Information Systemº later in
this section.Reading Lamps
Press the button near each
lamp to turn the reading
lamps on and off.
The lamps can also be swiveled to point in the
desired direction.
ProCarManuals.com

2-63
Installing a Garage Door Opener
If you have a garage door opener, the front overhead
compartment can be used to conveniently store
the opener.
If you have the optional HomeLink

Transmitter,
please see ªHomeLink
Transmitterº in the Index
for instructions on how to use the system.
To install the garage door opener, first open the
compartment door by pressing the latch forward.
Peel the protective
backing from the hook
and loop patch.Press it firmly to the back of your garage door opener,
as close to the center of the opener as possible.
Center the garage door opener activation button over
the console door button and press the opener firmly
into place.
The pegs inside the
compartment door are used
to make sure the button on
the compartment door will
contact the control button
on the garage door opener.
Add one peg at a time until the garage door opener
operates with the compartment door closed when you
press the button.
ProCarManuals.com

2-64
Now, with the compartment
door closed, press the
button again to make sure
the garage door opener
operates properly.
With the garage door opener positioned properly and
the right number of pegs in place, you should only
have to press the button slightly to operate the opener.
Adjust the position of the garage door opener and
add or remove pegs, as needed, until the opener
operates properly.Temperature and Compass Display
The outside air temperature and the compass are
displayed at the front of the overhead console.
The control buttons are located to the left of the display.
ProCarManuals.com

2-65
Turn the display on or off by pressing the ON/OFF
button. Display the temperature in either degrees
Fahrenheit (English) or Celsius (metric) by pressing
the US/MET button.
Before you turn on the ignition and move the vehicle,
the temperature indicated will be the last outside
temperature recorded with the ignition on.
If the outside temperature is 37
F (3
C) or lower
when you turn on the ignition, ªICEº will appear
on the display. This is a warning to the driver that road
conditions may be icy, and that appropriate precautions
should be taken.
The compass is self
-calibrating, so it does not need to
be manually set. However, when your vehicle is new,
the compass may function erratically. If it does, ªCALº
(Calibration) will appear on the display. To correct the
problem, drive in a complete 360 degree circle three
times, and the compass will function normally.Variance is the difference between magnetic north and
geographic north. In some areas, the difference between
the two can be great enough to cause false compass
readings. If this happens, follow these instructions to
set the variance for your particular location:
1. Find your location on the zone map. Record your
zone number.
2. Press and hold both the ON/OFF and the US/MET
buttons. The display will go off.
ProCarManuals.com

2-66
3. After five seconds, VAR CAL will appear on the
display. When it does, release both buttons.
4. Press US/MET until your zone number appears
on the display.
5. Press ON/OFF to enter your zone number.
Your variance is now set.
Driver Information System (If Equipped)
This system displays the outside air temperature,
compass direction and trip information in the
overhead console.
US/MET: The US/MET (United States/metric) button
allows you to switch the display between the English
and metric system.
MODE: The MODE button can be used to toggle
between three modes of operation: OFF, COMP/TEMP
and TRIP.COMP/TEMP: The display provides the outside
temperature and one of eight compass readings to
indicate the direction the vehicle is facing.
Before you turn on the ignition and move the
vehicle, the temperature indicated will be the last
outside temperature recorded with the ignition on.
If the outside temperature is 37
F (3
C) or lower,
the display will toggle between the word ªICEº and
the current temperature every eight seconds. This is a
warning to the driver that road conditions may be icy,
and that appropriate precautions should be taken.
The compass is self
-calibrating, so it does not need
to be manually set. However, if ªCº (Calibration) is
displayed, the compass will need to be calibrated.
You may also place the compass in a noncalibrated
mode by pressing and holding the MODE and US/MET
buttons simultaneously while in the COMP/TEMP
mode. After about 10 seconds, the compass will display
ªCº and you can release the buttons. Drive the vehicle
in a complete 360 degree circle three times at a speed of
less than 5 mph (8 km/h), and the compass will function
normally. Once the calibration is complete, the display
will return to a compass reading.
ProCarManuals.com

2-67
Variance is the difference between magnetic north and
geographic north. In some areas, the difference between
the two can be great enough to cause false compass
readings. If this happens, follow these instructions to
set the variance for your particular location:
1. Find your location on the zone map earlier in this
section. Record your zone number.
2. Press and hold both the MODE and the US/MET
buttons in the COMP/TEMP mode.
3. After five seconds, the compass will acknowledge
the variation mode by displaying the current zone
number. When it does, release both buttons.
4. Press US/MET until your zone number appears
on the display.
5. Press MODE to enter your zone number.
Your variance is now set and the display will
return to the COMP/TEMP mode.TRIP: Once in the TRIP mode, pressing the
MODE button will step you through the following
TRIP functions:

AVG ECON: The average fuel economy since the
last reset is displayed.

INST ECON: Instantaneous fuel economy for the
last second of driving is displayed.

RANGE: The display indicates the estimated
distance that can be travelled with the remaining fuel
in the tank, based on the fuel economy for the last
few hours of driving.

FUEL USED: The fuel used since the last reset
is displayed.

AVG SPEED: The average speed since the last
reset is displayed.
To reset the trip computer, press the MODE and
US/MET buttons simultaneously for at least two seconds.
All functions will be displayed for half a second once the
system is reset. Reset can only be performed in the
AVG ECON, FUEL USED and AVG SPEED modes.
All three modes are reset simultaneously.
ProCarManuals.com

2-68
Sunglasses Storage Compartment
The console has a sunglasses storage compartment.
To open the compartment press the release button.
Then pull the compartment down.
Door Storage
You will find a storage compartment on each of the
front doors.
Four
-door models have storage pockets and cupholders
on rear doors.
Front Storage Area (If Equipped)
If your vehicle has this console compartment, squeeze
the front lever while lifting the top to open it. You can
store cassettes and compact discs in the slots in front of
the compartment. There is also a lift
-out storage tray
in the console.
Some models will have a console with pop out cup
holders located on the front of the storage compartment.
If your vehicle has this console push in and release on the
cup holder door. The cupholders will pop out for use.
