2001 BMW M ROADSTER COUPE Owners Manual

153n
IndexDataTechnologyRepairsCar careControlsOverview
Limited slip differential
*
With unfavorable road conditions, the
drive forces that should be transferred
may not be accommodated by the
traditional differential, and therefore
one wheel may spin. This wheelspin is
largely avoided by the limited slip differ-
ential (cut-off value approx. 25X).
Under actual driving conditions, this
means better traction characteristics
when starting and accelerating (under
adverse road conditions) and during
performance-oriented driving on
winding roads.However, in the case of extremely
dynamic driving, the vehicle may tend
at the same time to spin around its
vertical axis in the vehicle center of
gravity on road surfaces with different
adhesion characteristics. Controlling
this rotation tendency places greater
demands on the driver and therefore
requires special alertness.
The limited slip differential is active
during actual driving without the driver
taking action.
ProCarManuals.com

154n
ProCarManuals.com

Overview
Controls and features
Operation, care
and maintenance
Owner service procedures
Technical data
Index Advanced technology
155n
IndexDataTechnologyRepairsCar careControlsOverview
Engine specifications156
Dimensions157
Weights158
Capacities159
Electrical system160
Drive belts160
Data
ProCarManuals.com

156n
M roadster, M coupe
Displacement
Number of cylinderscu in (cmm) 198.1 (3,246)
6
Maximum power output
at engine speedhp
rpm315
7,400
Maximum torqueat engine speedlb-ft (Nm)
rpm251 (340)
4,900
Compression ratioe 11.5
Stroke
Borein (mm)
in (mm)3.58 (91.0)
3.43 (87.0)
Fuel-injection system Digital-electronic engine management systemEngine specifications
ProCarManuals.com

157n
IndexDataTechnologyRepairsCar careControlsOverview
M roadster, M coupe
Length in (mm) 158.5 (4,025)
Width in (mm) 68.5 (1,740)
Height (unloaded) in (mm) 49.8 (1,266)
Wheelbase in (mm) 96.8 (2,459)
Track, front in (mm) 56.0 (1,422)
Track, rear in (mm) 58.7 (1,492)
Min. turning circle dia. ft (m) 34.1 (10.4)
Dimensions
ProCarManuals.com

158n
Weights
M roadster M coupe
Curb weight (with one person, ready for operation, full tank of fuel, options not included)
lbs. (kg)
3,131 (1,420) 3,131 (1,420)
Approved gross vehicle weight lbs. (kg) 3,660 (1,660) 3,660 (1,660)
Approved front axle load lbs. (kg) 1,874 (850) 1,874 (850)
Approved rear axle load lbs. (kg) 1,962 (890) 1,962 (890)
Approved roof load capacity lbs. (kg) 77 (35) (with hardtop
*) 110 (50)
Luggage compartment capacity cu ft (liters) 5.8 (165) 7.2 – 13.9 (205 – 395)
ProCarManuals.com

159n
IndexDataTechnologyRepairsCar careControlsOverview
Capacities
Notes
Fuel tank
reserve gal. (liters)
gal. (liters)approx. 13.5 (approx. 51)
approx. 2.1 (approx. 8.0)Fuel specification: page 26
Windshield washer system
including headlamp washer system quarts (liters)approx. 2.6 (approx. 2.5)
approx. 5.6 (approx. 5.3)For details: page 108
Cooling system including heater circuit quarts (liters) 11.3 (10.7) For details: page 111
Engine with oil filter renewal quarts (liters) 5.8 (5.5) "BMW High Performance
Synthetic Oil"
For details: page 110
Manual transmission – Lifetime fluid, no fluid change
required
Differential quarts (liters) 1.3 (1.2) Changing the oil during the
breaking-in inspection and
inspection II
ProCarManuals.com

160n
Electrical system Drive belts Battery12V, 70 AhSpark plugsNGK DCPR8EKP
This spark ignition system meets all
requirements of the Canadian Interfer-
ence-Causing Equipment Regulations
(ICES-2).AC alternator – Coolant pump –
Power steering
Drive belt 6 PK x 1470
A/C compressor
Drive belt 5 PK x 829You can obtain Original BMW
parts and accessories, as well as
professional advice from your BMW
center.<
