2001 BMW M ROADSTER COUPE Owners Manual

33n
IndexDataTechnologyRepairsCar careControlsOverview
Opening and closing from the insideTo unlock and open the doors>Pull the door handle of a door twice:
the initial pull unlocks the door, and
the second opens it.To engage the locksWhen the lock button of any door is
pressed down, the doors and luggage
compartment are locked. The anti-theft
protection system is not activated.
The fuel filler door also remains
unlocked to allow refueling.
To avoid being accidentally locked out
of the vehicle:
>The vehicle cannot be locked with
the lock button when the driver's
door is open.
>The lock button on the passenger's
door only operates the central
locking system if both doors are
closed.Children might be able to lock the
doors from the inside. For this
reason, always take the vehicle's keys
with you so that the vehicle can be
opened again from the outside at any
time.<
ProCarManuals.com

34n
Luggage compartment lidThe lockThe illustration depicts the luggage
compartment lock of the M roadster
as an example.
The operation and function for the
M coupe are the same as for the
M roadster.
Only the master keys (refer to page 30)
will fit in the luggage compartment lock.
On the M coupe the central locking
system is only actuated during opening.367de012
Locking separately(not on the M coupe)
Turn the master key to the right past the
resistance point and then pull it out in
the horizontal position
This locks the luggage compartment
and disengages it from the central
locking system. If you then surrender
only the door and ignition key (refer to
page 30), access to the vehicle through
the luggage compartment is not
possible. This is recommended for valet
parking, for instance.Manual operation(in the event of electrical malfunction)
Turn the master key in the lock of the
luggage compartment lid to the left to
the stop – the luggage compartment
opens slightly.
The luggage compartment is locked
again as soon as it is closed.
To closeThe illustration depicts the luggage
compartment lid of the M coupe.
The handle recess in the interior trim
panel of the luggage compartment lid
(arrow) makes it easier to pull the lid
down.
On the M roadster, the handle recess is
located to the left of the lock mecha-
nism.
To avoid injuries, be sure that the
travel path of the luggage
compartment lid is clear when it is
closed, as with all closing procedures.< 367de625
M coupe
ProCarManuals.com

35n
IndexDataTechnologyRepairsCar careControlsOverview
Luggage compartment lid Electric power windows
Do not drive with the luggage
compartment lid open, since
exhaust fumes could penetrate the inte-
rior of the vehicle. Should it be abso-
lutely necessary to operate the vehicle
with the luggage compartment lid open
(coupe; roadster with closed convert-
ible top):
>Close all windows. On the coupe,
close the sunroof.
>Increase the air supply of the heating
and ventilation system to a high level.
Refer to page 72.<
Opening and closing windowsFrom ignition key position 1 and up:
>Depress the rocker switch until you
feel resistance:
The window continues moving for as
long as you maintain pressure on the
switch.
>Press the rocker switch beyond the
resistance point (one-touch mode):
The window moves automatically.
Press the switch a second time to
stop the window.36mde744
After the ignition has been switched off:
Actuation is still possible for up to
15 minutes in ignition key position 0 or
if the ignition key has been removed, as
long as no doors have been opened.
Because the power windows are
sealed at high pressure to prevent
wind noise when closed, a powerful
motor is required for efficient closing.
When closing the windows, always
ensure that they are not obstructed in
any way. Unsupervised use of these
systems can result in serious personal
injury. Remove the ignition key to deac-
tivate the electric power windows
whenever you leave the vehicle. Never
leave the keys in the vehicle with unsu-
pervised children.
Never place anything that could
obstruct the driver's vision on or next to
the windows.<
For convenience closing via the door
lock, refer to page 32.
ProCarManuals.com

36n
Electric power windows Sunroof
* – coupe
Jam protectionIf one of the windows comes into
contact with an object between the
window and roof frame when it is
closing, the closing cycle is interrupted
immediately and the window will open
again slightly.
This jam protection function can
be overridden by pressing the
switch beyond the resistance point and
holding it.<
Lifting – ClosingFrom ignition key position 1 and up:
To lift: press button 1.
To close: press button 2.36mus726
M cou
pe
To prevent injuries, exercise care
when closing the sunroof. Keep it
in your field of vision until it is closed.<
To avoid pressure or drafts in the
passenger compartment when the
sunroof is open, keep the air vents in
the instrument panel open and increase
the air supply if necessary. Refer to
page 72.
ProCarManuals.com

37n
IndexDataTechnologyRepairsCar careControlsOverview
Manual convertible top – roadsterWeather protectionThe convertible top combines reliable
protection from the elements with
simple, convenient operation. Here are
a few tips to ensure that you have plea-
sure with your roadster.
It is advisable to close the convertible
top when the vehicle is parked. The
closed convertible top not only protects
the passenger compartment from
unforeseeable damage from the
weather, it also provides a certain
degree of theft protection. In addition,
keep valuables only in the locked
luggage compartment, even with the
convertible top closed.
Never mount a roof-mounted luggage
rack on the convertible top. Please
contact your BMW center for suitable
securing devices and additional acces-
sories.
To prevent damage, do not operate the
convertible top at temperatures at or
below the freezing point.
To open 1 With the doors closed, lower the side
windows a few inches (centimeters).
2 To release the convertible top: pull
the levers outward on the left and the
right of the convertible top frame
(refer to the illustration).367de046
3 Raise the convertible top approx.
8 inches (20 cm) from the convertible
top frame on the inside to relieve
tension on the top. Refer to arrow 1.
Be sure that the convertible top
folds at the front linkage joints first
(refer to arrow 2). If it does not, the
convertible top linkage could be bent.<
4 Continue to raise the top at the front
and push it toward the rear into the
convertible top compartment.
In the process, make sure the rear
window is laid down evenly and free
of creases. To prevent the rear
window from being scratched, a soft
cloth should be laid in the window
fold.367de399
ProCarManuals.com

38n
Manual convertible top – roadster5 Fold the release lever against the
convertible top frame.
In order to avoid subsequent
moisture damage, do not open
and store the convertible top when it is
wet (refer also to the chapter on vehicle
care).<
To mount the coverThe illustration depicts a representative
schematic of the fasteners for the
convertible cover.
To secure, press the outer ring of the
cover fastener onto the mating piece on
the vehicle (refer to the arrows).367de274
The attachment points of the cover are
indicated by the four arrows in the illus-
tration.
1 Position the convertible cover on the
convertible top compartment and
align the upper portions of the
fasteners with the lower portions on
the vehicle.
2 Lift the cover at the rear, reach
underneath it and engage the two
middle fasteners.
3 Attach the front fasteners.367us669
ProCarManuals.com

39n
IndexDataTechnologyRepairsCar careControlsOverview
Manual convertible top – roadster4 Push the peripheral frame of the
cover under the edge of the convert-
ible top compartment.
5 Check the convertible cover to be
sure it is properly secured.
In order to avoid damage and
soiling of the inside of the convert-
ible top, always drive with the convert-
ible cover installed.<
Be sure that the cover is secured
properly on the vehicle. If it is not
firmly secured, the flow of air while
driving could loosen the cover at higher
speeds.< 367us077
To close1 To remove the convertible top cover:
>Loosen the fasteners. Pull the cap
of the latch upward. Refer to the
arrow.367de724
>Loosen the front fasteners (outer
arrows).
>Pull the outer frame of the cover
under the edge of the convertible
top compartment.
>Lift the cover from the rear and
release the middle fasteners
(middle arrows).367us670
ProCarManuals.com

40n
Manual convertible top – roadster>To avoid damage, carefully fold the
cover and store it in the luggage
compartment.
Do not position heavy objects on
the cover.
If you store the cover away from the
vehicle, the cover should be spread
out.<
2 When the doors are closed, lower the
side windows slightly.367de247
3 Pull the release lever away from the
frame as far as possible.
4 Holding the convertible top at the
front convertible top frame, lift it out
of the convertible top compartment
and fold it forward.
When folding the convertible top
forward, do not grasp it by the
side linkage. If you do so, there is a risk
of injury to your hands and fingers.<
5 Insert the pins 1, on the left and the
right, into the guides in the wind-
shield frame. Using the handle recess
in the center of the convertible top
frame, pull the convertible top down.
Hold the top in this position and
secure both fasteners (refer also to
page 97).367de047
Be sure that the fastener hooks 2
on the left and right are securely
engaged in the frame of the windshield.
If they are not, the convertible top could
open while the vehicle is moving.<
At higher speeds, it may occur
that the lower air pressure which
is created in the passenger compart-
ment will cause the top or the rear
window to flutter. Increase the air
supply via the ventilation controls so
that a low pressure draft does not occur
in the vehicle.<
ProCarManuals.com
