2001 Acura Integra Owner's Manual

Servic
e Statio n Procedure s

If you can open the hood without
lifting the hood latch handle, or the
hood latch handle moves stiffly or does not spring back as before, the
mechanism should be cleaned and
lubricated (see page 189).
SUPPOR
T RO D

CLIP
3. Pull the support rod out of its clip and insert the end into the hole on
the left side of the hood. To close the hood, lift it up slightly to
remove the support rod from the
hole. Put the support rod back into its holding clip. Lower the hood to
about a foot (30 cm) above the
fender, then let it drop.
After closing the hood, make sure it is securely latched.

Befor e Drivin g

Servic
e Statio n Procedure s

Oil Check

DIPSTICK

Check the engine oil level every time
you fill the car with fuel. Wait a few minutes after turning the engine off
before you check the oil.
1. Remove the dipstick (orange
handle).
2. Wipe the dipstick with a clean
cloth or paper towel. 3. Insert it all the way back in its tube.

CONTINUED

Befor e Drivin g

Servic
e Statio n Procedure s

UPPE R MAR K

4. Remove the dipstick again and check the level. It should be
between the upper and lower

marks.

If it is near or below the lower mark, see Addin g Oi l on page 173. Engine Coolant Check

RESERV E TAN K

Look at the coolant level in the
radiator reserve tank. Make sure it is
between the MAX and MIN lines. If
it is below the MIN line, see Addin g
Engin e Coolan t on page 178 for
information on adding the proper
coolant.
Refer to Owne
r Maintenanc e
Check s on page 171 for information
on checking other items in your
Acura.

Befor e Drivin g
LOWE
R MAR K
MA
X
MI N

Fue
l Econom y
The condition of your car and your driving habits are the two most
important things that affect the fuel
mileage you get.
Vehicl e Conditio n
Always maintain your car according to the maintenance schedule. This
will keep it in top operating condition.
An important part of that mainte- nance is the Owne r Maintenanc e
Check s (see page 171 ). For
example, an under-inflated tire causes more "rolling resistance,"
which uses fuel. It also wears out
faster, so check the tire pressure at least monthly.
In winter, the build-up of snow on
your car's underside adds weight and rolling resistance. Frequent cleaning
helps your fuel mileage and reduces
the chance of corrosion. Drivin
g Habit s
You can improve fuel economy by driving moderately. Rapid acceler-
ation, abrupt cornering, and hard
braking use more fuel.
Always drive in the highest gear that allows the engine to run and acceler-
ate smoothly.
Depending on traffic conditions, try
to maintain a constant speed. Every
time you slow down and speed up,
your car uses extra fuel. Use the cruise control, when appropriate, to
increase fuel economy. A cold engine uses more fuel than a
warm engine. It is not necessary to "warm-up" a cold engine by letting it
idle for a long time. You can drive away in about a minute, no matter
how cold it is outside. The engine
will warm up faster, and you get
better fuel economy. To cut down on
the number of "cold starts," try to combine several short trips into one.
The air conditioning puts an extra load on the engine which makes it
use more fuel. Turn off the A/C tocut down on air conditioning use.
Use the flow-through ventilation
when the outside air temperature is
moderate.

Before Drivin g

Accessorie
s an d Modification s

Modifying your car, or installing some non-Acura accessories, can
make your car unsafe. Before you
make any modifications or add any accessories, be sure to read the
following information.

Accessorie s

Your dealer has Genuine Acura accessories that allow you to
personalize your car. These accessories have been designed and
approved for your car, and are
covered by warranty.
Non-Acura accessories are usuallydesigned for universal applications.
Although aftermarket accessories may fit on your car, they may not
meet factory specifications, andcould adversely affect your car's
handling and stability. (See "Modifications" on the page 131 for
additional information.) When properly installed, cellular
phones, alarms, two-way radios, and
low-powered audio systems shouldnot interfere with your car's
computer-controlled systems, suchas the SRS and anti-lock brake

system.

However, if electronic accessories are improperly installed, or exceed
your car's electrical system capacity, they can interfere with the operation of your car, or even cause the
airbags to deploy.
Before installing any accessory: Make sure the accessory does not
obscure any lights, or interfere
with proper car operation or performance. Be sure electronic accessories do
not overload electrical circuits (see page 243). Have the installer contact your
Acura dealer for assistance before installing any electronic accessory.
If possible, have your dealer inspect
the final installation.

Befor e Drivin g
Improper accessories or
modifications can affect your
car's handling, stability and performance, and cause a

crash in which you can be hurt
or killed.

Follow all instructions in this
owner's manual regarding

accessories and modifications.

Accessorie
s an d Modification s

Modification s
Do not remove any original
equipment or modify your car in any
way that would alter its design or operation. This could make your car
unsafe and illegal to drive.
For example, do not make any
modifications that would change theride height of your car, or install
wheels and tires with a different overall diameter.
Such modifications can adversely
affect handling, and interfere with
the operation of the car's anti-lock
brakes and other systems. In addition, any modifications that
decrease ground clearance increase
the chance of undercarriage parts striking a curb, speed bump, or other
raised object, which could cause
your airbags to deploy.
Do not modify your steering wheel
or any other part of your
Supplemental Restraint System.
Modifications could make thesystem ineffective. Additiona
l Safet y Precautio n

Do not attach or place objects on the

airbag covers. Any object attached to

or placed on the covers marked "SRS
AIRBAG," in the center of the steering wheel and on top of the
dashboard, could interfere with the
proper operation of the airbags. Or,
if the airbags inflate, the objects
could be propelled inside the car and
hurt someone.

Before Drivin g

Carryin
g Carg o

CONSOL E COMPARTMEN T
CARG O ARE A GLOV
E BO X Your car has several convenient
storage areas so you can stow cargo

safely.

The glove box, and the pockets in the doors are designed for small,
lightweight items. The cargo area isintended for larger, heavier items. In
addition, the back seat can be foldeddown to allow you to carry more
cargo or longer items.
However, carrying too much cargo, or improperly storing it, can affect
your car's handling, stability and operation and make it unsafe. Before
carrying any type of cargo, be sure to
read the following pages.

Befor e Drivin g
DOO
R POCKE T

Carryin
g Carg o

Loa d Limi t
The maximum load for your car is
700 lbs (325 kg).

This figure includes the total weight of all occupants, cargo, accessories,
and the tongue weight if you are
towing a trailer.
To figure out how much cargo you can carry: Add up the weight of all occupants.
If you are towing a trailer, add the
tongue weight to the number
above.
Subtract the total from 700 Ibs
(325 kg).

The final number is the total weight
of cargo you can carry.
Carryin
g Item s i n th e Passenge r
Compartmen t Store or secure all items that could
be thrown around and hurt someone during a crash. Be sure items placed on the floor
behind the front seats cannot roll
under the seats and interfere with
the driver's ability to operate the
pedals, or with the proper operation of the seats. Keep the glove box closed while
driving. If the lid is open, a
passenger could injure their knees during a crash or sudden stop.

Before Drivin g

Overloading or improper
loading can affect handling and
stability and cause a crash in

which you can be hurt or killed.

Follow all load limits and other

loading guidelines in this

manual.
