2001.5 Peugeot 206 CC Owner's Manual

PRACTICAL ASPECTS OF YOUR VEHICLE95
Punctures Because this version does not pos- sess a spare wheel, you have twoaerosols for temporary tyre repairsstored in an insulated storage box
1
secured by a strap to the right-handside of the boot. Using a repair aerosol (See also the instructions on the aerosols).
If possible remove the foreign body which caused the puncture.
 Position the wheel so that the valve
is at the 2 o'clock or 10 o'clock posi-tion.
 Shake the aerosol vigorously befo-
re use. (In very cold weather, warmthe aerosol for a few minutes in yourhands).
 In one hand hold the valve.
 With the other, firmly push the end
of the aerosol tube onto the valve,keeping the aerosol centralised.
 Maintain the pressure firmly for one
minute, then immediately drive at
moderate speed to the nearest
garage. Aersosols enable a tempo-rary repair to be carried out(maximum speed 50 mph(80 km/hour)).
After use, it is necessary to replacethe tyre. Because the aerosols are pres- surised, they must not be exposedto a temperature higher than 50¡C. Keep them away from heat in their insulated storage box.

PRACTICAL ASPECTS OF YOUR VEHICLE
96
Changing a wheel
Park the vehicle on level, stable
ground which is not slippery.
 Apply the handbrake, engage first
gear or reverse (position Pon the
automatic gearbox) and switch offthe ignition.
 Chock the rear of the wheel withshim 2diagonally opposite the
wheel to be changed.
Tools for changing a wheel 1 - Wheelbrace fitted to the lining of the boot on the rear right side.
2 - Shim stored in the jack bag.
3 - Jack (in a bag).
4 - Tool for removing wheel bolt trims Removing the wheel
Remove the wheel trim* using the wheelbrace 1by pulling next to the valve.
 Loosen the wheel bolts (for vehicles fitted with alloy wheels, remove the chrome wheel bolts first; see ÔFeatures of alloy wheelsÕ, following page).
 Position the jack 3at one of the four locations Aunderneath the vehicle, as
close as possible to the wheel to be changed. Ensure that the entire surface ofthe jack base plate is in contact with the ground.
 Extend the jack 3.
 Remove the bolts and release the wheel.
* According to specification.

PRACTICAL ASPECTS OF YOUR VEHICLE97
Refitting the wheel
After positioning the wheel, pre-tighten the bolts using the wheelbrace 1.
 Compress the jack 3and release it.
 Fully tighten the bolts using the wheelbrace 1.
 Replace the wheel trim*, starting at the valve passage hole, and press on it using the palm of the hand.
Replace the shim and the jack in their bag, then store the tools in the boot.For your safety, always change the wheel:
- on level, stable and non-slippery ground,
- with the handbrake applied and the ignition switched off,
- with the first or reverse gear engaged (position Pfor the auto-
matic gearbox),
- with the vehicle chocked using a shim.
Never go underneath a vehiclewhich is supported only by a jack(use an axle stand) .
After changing the wheel:
- As soon as possible contact a PEUGEOT dealer to check that the wheel bolts are tight.
* According to specification.

PRACTICAL ASPECTS OF YOUR VEHICLE
98
Special features of alloy wheels* Bolt covers The bolts on the alloy wheels are covered with chrome-plated trim caps. Remove them using tool
4before
slackening the bolts. Refitting the spare wheel** If your vehicle is fitted with a metal spare wheel, when fitting the wheel itis
normal to notice that the bolt wash-
ers do not come into contact with the
wheel. The spare wheel is held inplace by the conical support of eachbolt. Fitting snow tyres If your vehicle has tyres fitted to steel wheels, it is essentialto use special
bolts available from a PEUGEOT dealer. Wheel anti-theft bolts** If your wheels are fitted with anti-theft bolts (one per wheel), the chrome trimand then the plastic cover must beremoved, using tool
4, before the bolt
is unscrewed using one of the twoanti-theft sockets (which were given toyou on delivery of your vehicle alongwith the duplicate keys and the confi-dential card) and the wheelbrace 1.
Note: take a careful note of the code
number engraved on the top of the
anti-theft socket. This will enable youto obtain a duplicate anti-theft socket
from a PEUGEOT dealer.
* According to specification.
** According to model and destination.

PRACTICAL ASPECTS OF YOUR VEHICLE99
Ð Pull the tab
Aupwards and remove the protective cover.
Ð Disconnect the connector.
Ð Press the end of the securing clip to remove it. Change the faulty bulb.
Ð On fitting, ensure that the direction notches are in the cor- rect position and that the clip is secured correctly.
Ð Reconnect the connector.
Ð Replace the protective cover. Remarks
Ð Only touch the bulbs with a dry cloth.
Ð To replace the bulbs on the right side, remove the wash- wipe reservoir filler pipe first.
Ð Condensation may form inside the headlamps. It will dis- appear when the lights are used.
Changing a bulb Dipped/main headlamps H7 55WSide lights W5W
Turn the pin connector B a quarter turn and remove it.
Change the bulb.

PRACTICAL ASPECTS OF YOUR VEHICLE
100
Amber direction indicators PY21W
Turn the pin connector
Ca quarter
turn and remove it. Change the bulb. Amber direction indicator side repeater WY5W Push the repeater forwards or back-
wards and release the assembly. Hold the connector and turn the trans- parent cover a quarter turn. Change the bulb.
Use only H7 bulbs of brands:
- GE/TUNGSRAM,
- PHILIPS,
- OSRAM,
to avoid damaging the headlamps.These comply with the anti-UV (ultraviolet) specifications neces-sary for the correct operation andreliability of the headlamps. The headlamps are fitted with polycarbon glass with a protective
coating. We strongly adviseagainst cleaning them using a dryor abrasive cloth or using deter-gents or solvents. Use a soft, damp cloth.

PRACTICAL ASPECTS OF YOUR VEHICLE101
Rear lights Release the top of the boot side trim. Unscrew the wing bolt inside the boot
using the wheelbrace if necessary. Disconnect the connector
A.
Release the light unit.Release spanner B from the bulb hol-
der.Unscrew nut Cusing spanner B and
removet the bulb holder.Change the faulty bulb.When refitting, stow spanner B on
support D and refit the light .
1. Amber direction indicators
PY21W.
2. Reversing lights P21W.
3. Brake lights/side lights P21/5W.Front fog lamps H1 55W Press underneath the access flap to release it. Open the flap.
Turn the cover to remove it.Disconnect the bulb.Press both ends of the securing clip to release the bulb.
The ÒamberÓ bulbs must be replaced by bulbs of identi-
cal specification and colour.

PRACTICAL ASPECTS OF YOUR VEHICLE101
Rear lights Release the top of the boot side trim. Unscrew the wing bolt inside the boot
using the wheelbrace if necessary. Disconnect the connector
A.
Release the light unit.Release spanner B from the bulb hol-
der.Unscrew nut Cusing spanner B and
removet the bulb holder.Change the faulty bulb.When refitting, stow spanner B on
support D and refit the light .
1. Amber direction indicators
PY21W.
2. Reversing lights P21W.
3. Brake lights/side lights P21/5W.Front fog lamps H1 55W Press underneath the access flap to release it. Open the flap.
Turn the cover to remove it.Disconnect the bulb.Press both ends of the securing clip to release the bulb.
The ÒamberÓ bulbs must be replaced by bulbs of identi-
cal specification and colour.
