GIVE SAFETY THE RIGHT OF WAY
GIVE SAFETY THE RIGHT OF WAY................................................. 1-1
E_5el_LabelTOC.fm Page 1 Monday, May 1, 2000 9:36 AM

1
1-1
1-give safety the right of way
EAU00021
Motorcycles are fascinating vehicles, which can give you an unsurpassed feeling of power and
freedom. However, they also impose certain limits, which you must accept; even the best motorcycle
does not ignore the laws of physics.
Regular care and maintenance are essential for preserving your motorcycle’s value and operating
condition. Moreover, what is true for the motorcycle is also true for the rider: good performance
depends on being in good shape. Riding under the influence of medication, drugs and alcohol is, of
course, out of the question. Motorcycle riders - more than car drivers - must always be at their mental
and physical best. Under the influence of even small amounts of alcohol, there is a tendency to take
dangerous risks.
Protective clothing is as essential for the motorcycle rider as seat belts are for car drivers and
passengers. Always wear a complete motorcycle suit (whether made of leather or tear-resistant
synthetic materials with protectors), sturdy boots, motorcycle gloves and a properly fitting helmet.
Optimum protective wear, however, should not encourage carelessness. Though full-coverage
helmets and suits, in particular, create an illusion of total safety and protection, motorcyclists will
always be vulnerable. Riders who lack critical self-control run the risk of going too fast and are apt to
take chances. This is even more dangerous in wet weather. The good motorcyclist rides safely,
predictably and defensively - avoiding all dangers, including those caused by others.
Enjoy your ride!
E_5el_Label.fm Page 1 Monday, May 1, 2000 9:36 AM

2
DESCRIPTION
Left view ............................................................................................. 2-1
Right view ........................................................................................... 2-2
Controls/Instruments .......................................................................... 2-3
E_5el_DescriptionTOC.fm Page 1 Monday, May 1, 2000 9:36 AM

2-1
2
EAU00026
2-DESCRIPTIONLeft view1. Shift pedal (page 3-6)
2. Fuel cock (page 3-8)
3. Rear shock absorber spring preload adjusting ring (page 3-14)
4. Helmet holder (page 3-11)
5. Storage compartment (page 3-11)
6. Tool kit (page 6-1)
7. Fuses (page 6-25)
E_5el_Description.fm Page 1 Monday, May 1, 2000 9:37 AM

DESCRIPTION
2-2
2
Right view8. Oil filter (page 6-9)
9. Battery (page 6-23)
10. Main fuse (page 6-25)
11. Main switch/Steering lock (page 3-1)
12. Air filter (page 6-10)
13. Rear brake pedal (page 3-6)
E_5el_Description.fm Page 2 Monday, May 1, 2000 9:37 AM

DESCRIPTION
2-3
2
Controls/Instruments1. Clutch lever (page 3-5)
2. Left handlebar switches (page 3-4)
3. Starter (choke) “ ” (page 3-9)
4. Speedometer (page 3-3)
5. Fuel tank cap (page 3-7)
6. Right handlebar switches (page 3-5)
7. Throttle grip (page 6-12)
8. Front brake lever (page 3-6)
E_5el_Description.fm Page 3 Monday, May 1, 2000 9:37 AM

3
INSTRUMENT AND CONTROL FUNCTIONS
Main switch/Steering lock ................................................................... 3-1
Indicator lights .................................................................................... 3-2
Speedometer...................................................................................... 3-3
Antitheft alarm (optional) .................................................................... 3-4
Handlebar switches ............................................................................ 3-4
Clutch lever ........................................................................................ 3-5
Shift pedal .......................................................................................... 3-6
Front brake lever................................................................................. 3-6
Rear brake pedal ................................................................................ 3-6
Fuel tank cap...................................................................................... 3-7
Fuel .................................................................................................... 3-7
Fuel cock ............................................................................................ 3-8
Starter (choke) “ ” .......................................................................... 3-9
Seats ................................................................................................ 3-10
Helmet holder ................................................................................... 3-11
Storage compartment ...................................................................... 3-11
Rear shock absorber adjustment ..................................................... 3-13
Luggage strap holders ..................................................................... 3-15
Sidestand ......................................................................................... 3-15
Sidestand/clutch switch operation check.......................................... 3-16
E_5el_FunctionsTOC.fm Page 1 Monday, May 1, 2000 9:37 AM

3-1
3
EAU00027
3-INSTRUMENT AND CONTROL FUNCTIONS
EAU00029
Main switch/Steering lockThe main switch controls the ignition
and lighting systems. Its operation is
described below.
EAU00036
ON
Electrical circuits are switched on. The
engine can be started. The key cannot
be removed in this position.
EAU00038
OFF
All electrical circuits are switched off.
The key can be removed in this posi-
tion.
EAU00040
LOCK
The steering is locked in this position
and all electrical circuits are switched
off. The key can be removed in this po-
sition. To lock the steering, turn the
handlebars all the way to the left. While
pushing the key into the main switch,
turn it from “OFF” to “LOCK” and re-
move it. To release the lock, turn the
key to “OFF” while pushing.
EW000016
WARNING
@ Never turn the key to “OFF” or
“LOCK” when the motorcycle is
moving. The electrical circuits will
be switched off which may result in
loss of control or an accident. Be
sure the motorcycle is stopped be-
fore turning the key to “OFF” or
“LOCK”. @1. Push
2. Turn
E_5el_Functions.fm Page 1 Monday, May 1, 2000 9:38 AM
