2000 TOYOTA TUNDRA Owners Manual

TUNDRA (34413U)
265
Engine
Model:5VZ- FE and 2UZ- FE
Type: 5VZ- FE engine6 cylinder V type, 4 cycle, gasoline
2UZ- FE engine
8 cylinder V type, 4 cycle, gasoline
Bore and stroke, mm (in.): 5VZ- FE engine93.5
82.0 (3.68
3.23)
2UZ- FE engine
94.0
84.0 (3.70
3.31)
Displacement, cm
3 (cu. in.):
5VZ- FE engine 3378 (206.1)
2UZ- FE engine 4664 (284.6)
Fuel
Fuel type: Unleaded gasoline, Octane Rating 87
(Research Octane Number 91) or higher
Fuel tank capacity, L (gal., Imp. gal.): 100 (26.4, 22.0)
Service specifications
ENGINE
Valve clearance (engine cold), mm (in.):
5VZ- FE engineIntake 0.13Ð0.23 (0.006Ð0.009)
Exhaust 0.27Ð0.37 (0.011Ð0.014)
2UZ- FE engine Intake 0.15Ð0.25 (0.006Ð0.010)
Exhaust 0.25Ð0.35 (0.010Ð0.014)
Spark plug type: 5VZ- FE engineDENSO K16TR11
NGK BKR5EKB11
2UZ- FE engine DENSO K20R- U
NGK BKR6EYA
Spark plug gap, mm (in.): 5VZ- FE engine
1.1 (0.043)
2UZ- FE engine 0.8 (0.031)
ProCarManuals.com

TUNDRA (34413U)
266
Drive belt tension measured with Bor-
roughs drive belt tension gauge
No.BT- 33- 73F (used belt), lbf:5VZ- FE engineGenerator belt 100  20
Air conditioning compressor belt
100
+20
-10
Power steering pump belt100+20
-15
ENGINE LUBRICATION
Oil capacity (drain and ref ill), L (qt., Imp.
qt.):
5VZ- FE engineWith filter 5.2 (5.5, 4.6)
Without filter 4.9 (5.2, 4.3)
2UZ- FE engine With filter 6.1 (6.4, 5.4)
Without filter 5.7 (6.0, 5.0)
Oil grade: API grade SJ, Energy- Conservingº or
ILSAC multigrade engine oil is recom-
mended. Recommended oil viscosity (SAE):
COOLING SYSTEM
Total capacity, L (qt., Imp. qt.):
With manual transmission 10.0 (10.6, 8.8)
With automatic transmission 5VZ- FE engine 9.9 (10.5, 8.7)
2UZ- FE engine 11.6 (12.3, 10.2)
Coolant type: TOYOTA Long Life Coolantº or equiva-
lent
With ethylene- glycol type coolant for a
proper corrosion protection of aluminum
components
Do not use alcohol type antifreeze or
plain water alone. BATTERY
Open voltage
* at 20
5C (68 5F):
12.6Ð12.8 V Fully charged
12.2Ð12.4 V Half charged
11.8Ð12.0 V Discharged
*: Voltage that is checked 20 minutes af- ter the key is removed with all the
lights turned off
Charging rates: 5 A max.
CLUTCH
Pedal freeplay, mm (in.): 5Ð15 (0.2Ð0.6)
Fluid type: SAE J1703 or FMVSS No.116 DOT 3
MANUAL TRANSMISSION
Oil capacity, L (qt., Imp. qt.): Two- wheel drive models 2.6 (2.7, 2.3)
Four- wheel drive models 2.2 (2.3, 1.9)
Oil type: Gear oil API GL-4 or GL-5
Recommended oil viscosity: SAE 75W- 90
ProCarManuals.com

TUNDRA (34413U)
267
AUTOMATIC TRANSMISSION
Fluid capacity (drain and refill), L (qt.,
Imp. qt.):
Up to 2.0 (2.1, 1.8)
Fluid type: Automatic transmission fluid D- II or
DEXRON III (DEXRON II)
TRANSFER
Oil capacity, L (qt., Imp. qt.): 1.0 (1.1, 0.9)
Oil type: Gear oil API GL-4 or GL-5
Recommended oil viscosity: SAE 75W- 90
DIFFERENTIAL
Oil capacity, L (qt., Imp. qt.): Front 1.15 (1.2, 1.0)
RearTwo- wheel drive models 3.80 (4.0, 3.3)
Four- wheel drive models 3.50 (3.7, 3.1)Oil type:
Hypoid gear oil API GL- 5
Recommended oil viscosity:
Front SAE 75W- 90
Rear Above -18 5C (0 5F)
SAE 90
Below -18 5C (0 5F)
SAE 80W or 80W- 90
CHASSIS LUBRICATION
Propeller shafts: Spiders and slide yokesLithium base chassis grease, NLGI
No.2
Double cardan joint Molybdenum- disulfide lithium base
chassis grease, NLGI No.2
BRAKES
Minimum pedal clearance when depressed
with the pressure of 490 N (50 kgf, 110
lbf) with the engine running, mm (in.): 95 (3.7)
Pedal freeplay, mm (in.): 1Ð6 (0.04Ð0.24)
Pad wear limit, mm (in.): 1.0 (0.04) Lining wear limit, mm (in.):
1.0 (0.04)
Parking brake adjustment: Pedal typeÐwhen depressed with the
pressure of 294 N (30 kgf, 66.1 lbf)5Ð8 clicks
Lever typeÐwhen pulled with the force
of 196 N (20 kgf, 44 lbf) 4Ð12 clicks
Fluid type: SAE J1703 or FMVSS No.116 DOT 3
STEERING
Wheel freeplay: Less than 30 mm (1.2 in.)
Power steering fluid type: Automatic transmission fluid DEXRON II
or III
ProCarManuals.com

TUNDRA (34413U)
268
Tires
Tire size and pressure:
STANDARD CAB MODELS
Two- wheel drive modelsTire size
Tire pressure
kPa (kgf/cm2 or bar, psi)Wheel sizeTire size
FrontRear
Wheel size
P245/70R16180 (1.8, 26)240 (2.4, 35)16
7JJ
Four- wheel drive models
Tire size
Tire pressure
kPa (kgf/cm2 or bar, psi)Wheel sizeTire size
FrontRear
Wheel size
P245/70R16180 (1.8, 26)240 (2.4, 35)16
7JJ (J)
P265/70R16180 (1.8, 26)200 (2.0, 29)16
7JJ (J)
ProCarManuals.com

TUNDRA (34413U)
269
ACCESS CAB MODELS
Two- wheel drive modelsTire size
Tire pressure
kPa (kgf/cm2 or bar, psi)Wheel sizeTire size
FrontRear
Wheel size
P245/70R16180 (1.8, 26)240 (2.4, 35)16
7JJ (J)
P265/70R16180 (1.8, 26)200 (2.0, 29)16
7JJ (J)
Four- wheel drive models
Tire size
Tire pressure
kPa (kgf/cm2 or bar, psi)Wheel sizeTire size
FrontRear
Wheel size
P245/70R16180 (1.8, 26)240 (2.4, 35)16
7JJ (J)
P265/70R16180 (1.8, 26)200 (2.0, 29)16
7JJ (J)
P265/70R16
Off- road package180 (1.8, 26)200 (2.0, 29)16
7JJ
Wheel nut torque, N´m (kgf´m, ft´lbf):
110 (11.5, 83.2)
ProCarManuals.com

TUNDRA (34413U)
270
Fuses
Engine compartment (2UZ- FE engine)Engine compartment (5VZ- FE engine)
Engine compartment (with towing kit)
Fuses (type A)1. EFI NO.1 15 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system, emission control system,
fuel pump and all components in EFI
NO.2º fuse
2. ETCS 15 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system and electronic throttle con-
trol system
3. DOME 15 A: Interior light, personal
lights, vanity light and courtesy lights
4. OBD 7.5 A: On- board diagnosis sys-
tem
ProCarManuals.com

TUNDRA (34413U)
271
Instrument panel
5. PWR OUTLET 1 15 A: Power outlet
(upper)
6. PWR OUTLET 2 15 A: Power outlet
(lower)
7. FR FOG 20 A: Front fog lights
8. ALT- S 7.5 A: Charging system
9. HEAD (RH) 10 A: Right- hand headlight
10. HEAD (LH) 10 A: Left- hand headlight
11. EFI NO.2 10 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system and emission control sys-
tem
12. A/C 10 A: Air conditioning system 13. DRL 7.5 A (with daytime running
light system): Daytime running light
system
14. HEAD (LO RH) 10 A (with daytime running light system): Right- hand
headlight (low beam)
15. HEAD (LO LH) 10 A (with daytime running light system): Left- hand
headlight (low beam)
16. HEAD (HI RH) 10 A: Right- hand head- light (high beam)
17. HEAD (HI LH) 10 A: Left- hand head- light (high beam)
18. WIP 20 A: Windshield wipers and
washer
19. TURN 5 A: Turn signal lights
20. ECU- IG 5 A: Anti- lock brake system
and cruise control system
21. 4WD 20 A: Four- wheel drive control
system and A.D.D. control system
22. ACC 15 A: Cigarette lighter, audio sys-
tem, SRS airbag system and power
rear view mirrors
23. GAUGE 10 A: Gauges and meters,
back- up lights, starting system, day-
time running light system and air condi-
tioning system 24. IGN 5 A:
SRS airbag system, multiport
fuel injection system/sequential multi-
port fuel injection system, discharge
system and ignition system
25. CARGO LP 5 A: Cargo lamp
26. TAIL 15 A: Tail lights, license plate
lights, instrument panel lights, parking
lights and glove box light
27. ECU- B 5 A: SRS warning light
28. HORN´HAZ 20 A: Emergency flashers
and horns
29. ST 5 A: Starting system
30. STOP 15 A: Stoplights and high
mounted stoplight
Fuses (type B)
31. ABS 1 40 A: Anti- lock brake system
32. ABS 2 40 A: Anti- lock brake system
33. J/B 50 A: All components in PWRº,
HORN´HAZº, TAILº, CARGO LPº,
STOPº and ECU- Bº fuses
34. AM2 30 A: Ignition system
35. AM1 40 A: Starting system
36. HTR 50 A: Air conditioning system
37. PWR 30 A: Power door lock system,
power windows and power seat
38. FL 30 A: Trailer lights
ProCarManuals.com

TUNDRA (34413U)
272
Fuse (type C)
39. ALT 120 A: All components in AM1º,
ALT- Sº, HTRº, FR FOGº, PWR
OUTLET 1º and PWR OUTLET 2º
fuses
