2000 CHEVROLET CAVALIER Owners Manual

2-41 Daytime Running Lamps
Daytime Running Lamps (DRL) can make it easier
for others to see the front of your vehicle during the
day. DRL can be helpful in many different driving
conditions, but they can be especially helpful in the
short periods after dawn and before sunset.
The DRL system will make your high and low
-beam
headlamps come on at a reduced brightness in
daylight when:

The ignition is on with the engine running,

the headlamp switch is OFF,

the parking brake is released, and

the transaxle is not in PARK (P) on models with an
automatic transaxle only.
This indicator light on
your instrument panel
cluster will come on
when the DRL are on.A flashing DRL telltale indicates a possible burned out
headlamp, or that the vehicle may need service to repair
a stuck DRL relay.
When the DRL are on, your high and low
-beam
headlamps will be on at a reduced brightness. The
taillamps, sidemarker and other lamps won't be on.
Your instrument panel won't be lit up either.
When you turn on the headlamp switch, your high and
low
-beam headlamps will go out, and your low-beam
headlamps will come on. The other lamps that come
on with your headlamps will also come on.
When you turn off the headlamp switch, the regular
lamps will go off, and your high and low
-beam
headlamps will come on to the reduced brightness.
To idle your vehicle with the DRL off, set the parking
brake. The DRL will stay off until you release the
parking brake.
As with any vehicle, you should turn on the regular
headlamp system when you need it.

2-42 Fog Lamps (If Equipped)
Use your fog lamps for
better vision in foggy or
misty conditions. The
switch for your fog lamps
is next to the instrument
panel intensity control.
Push the top of the switch to turn the fog lamps on.
Push the top of the switch again to turn the fog
lamps off.
When using fog lamps, the parking lamps or low
-beam
headlamps must be on.
A light on the switch will come on when the fog lamps
are actually on. Fog lamps will go off whenever the
high
-beam headlamps come on. When the high beams
go off, the fog lamps will come on again.
Interior Lamps
Instrument Panel Intensity Control
You can brighten or dim
the instrument panel lights
by turning the thumbwheel
up or down.
Turn the thumbwheel up all the way to turn on the
interior courtesy lamps.
Illuminated Entry
When you open either front door or open a rear door, the
lamps inside your vehicle will go on. In addition, if your
vehicle is equipped with remote keyless entry, the light
will come on when the remote keyless entry UNLOCK
button is pressed.

2-43
After you exit the vehicle and all of the doors have
been closed, the lamps will stay on for an additional
20 seconds before fading off. The lamps will also fade
to off when the key is inserted and turned to RUN
of ACCESSORY, or the lock button on the key fob
is pressed.
Front Reading Lamps (If Equipped)
These lamps are located on the rearview mirror.
Turn each one on and off by pressing its switch.
Map Lamps (If Equipped)
These lamps are located forward of the dome lamp.
To turn the lamps on, press the switch. Press the
switch again to turn them off.
Battery Saver
Your vehicle is equipped with a battery saver feature
designed to protect your vehicle's battery.
When any interior lamp (trunk, reading, dome, etc.)
is left on and the ignition is turned off, the battery
rundown protection system will automatically turn the
lamp off after 20 minutes. This will avoid draining the
battery. This system does not protect against leaving on
the headlamps or parking lamps.
To reactivate the interior lamps, either:

The ignition must be turned on,

the activated lamp switch must be turned off,
then on, or

a front door must be opened.
The battery rundown protection feature will also be
activated when any door is left open.

2-44
Mirrors
Inside Day/Night Rearview Mirror
To reduce glare from lamps behind you, move the lever
toward you to the night position.
Manual Remote Control Mirror
The outside rearview
mirror should be adjusted
so you can see a little of the
side of your vehicle when
sitting in a comfortable
driving position.
Adjust the driver's side outside mirror with the control
lever on the driver's door.To adjust your passenger's side mirror, sit in the driver's
seat and have a passenger adjust the mirror for you.
The mirror is a spring
-loaded breakaway design.
Power Remote Control Mirrors
(If Equipped)
The power mirror control is
located on the driver's door.
Turn the control clockwise
or counterclockwise to
choose the mirror you
want to adjust.
Then move the control in the direction you want the
mirror to move. Adjust each mirror so you can see
a little of the side of your vehicle when sitting in a
comfortable driving position.
The mirror is a spring
-loaded breakaway design.

2-45 Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from
the driver's seat.
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder
before changing lanes.
Breakaway Mirrors
Should the mirror control lever not operate the mirror
adjustment, you can reset the adjustment lever by
following these steps:
1. Fold the mirror toward the door.
2. Attach the ªT
-barº into the channel.
3. Carefully release the mirror to its original position.

2-46
Storage Compartments
Center Console Storage Area
To open the center console, pull the lift lever up and
the lid back.
To close the center console, push the lid down until
it clicks.
Center Console Cupholders
There are two cupholders located at the front of the
center console, in front of the shift lever. There are also
cupholders for the rear seat passengers located under the
center console lid. Open the center console lid all the
way to uncover the rear cupholders.
Convenience Net (If Equipped)
Your vehicle may have a convenience net. You'll see it
inside the back wall of the trunk. Put small loads, like
grocery bags, behind the net. It can help keep them
from falling over during sharp turns or quick starts and
stops. Un
-clip a corner of the convenience net to fit
larger objects behind the net, then re
-clip it to secure
them in place.The net isn't for larger, heavier loads. Store them in the
trunk as far forward as you can.
You can unhook the net so that it will lie flat when
you're not using it.
Ashtrays and Cigarette Lighter
(If Equipped)
To use the lighter, just push it in all the way and let go.
When it's ready, it will pop back out by itself.
NOTICE:
Don't hold a cigarette lighter in with your hand
while it is heating. If you do, it won't be able to
back away from the heating element when it's
ready. That can make it overheat, damaging the
lighter and the heating element.
To clean the center console ashtray, remove the entire
ashtray and empty it.

2-47
To clean the rear ashtray, open it, push down on the
snuffer, and pull it out.
NOTICE:
Don't put papers and other things that burn into
your ashtrays. If you do, cigarettes or other smoking
materials could set them on fire, causing damage.
Sun Visors
To block out glare, you can swing down the visors.
You can also swing them to the side.
Accessory Power Outlet (If Equipped)
The accessory power outlet is located on the instrument
panel to the right of the steering wheel. Just remove the
plug from the outlet and follow the proper installation
instructions that are included with any electrical
equipment you install.
These circuits are protected by a fuse and have
maximum current levels.
Sunroof (If Equipped)
Press and release the
rear of the switch and the
glass panel will open to
the vent position.
Open the sunshade by hand when using the
vent position.
Press and release the rear of the switch again to open
the glass panel and the sunshade. Press the front of the
switch to stop the panel in any position.
Press and hold the front of the switch to close the glass
panel. The sunshade can only be closed by hand.
The sunroof glass panel cannot be opened or closed if
your vehicle has an electrical failure.

2-48
Convertible Top (If Equipped)
The following steps explain the proper operation of your
convertible top.
NOTICE:

Remove any items from the convertible top
storage area before you lower the top. Even
small items in the storage area can damage
the top or other parts of the system.

Don't raise or lower the convertible top
when the temperature is below 20F (
-7C).
The cold can cause cracks and other damage
to the top as it is being lowered or raised.

Don't raise or lower the convertible top
while the vehicle is moving. The wind could
damage the top. Bring the vehicle to a
complete stop before attempting to raise or
lower the top. Always make sure that the top
is securely latched before driving the vehicle.
Lowering Your Convertible Top
1. Set the parking brake and shift your automatic
transaxle to PARK (P) or your manual transaxle to
NEUTRAL (N).
2. Turn the ignition to RUN.
3. Lower the side door windows completely to avoid
wear to the weatherstrips.
4. Push the button in the latch handle and turn the
handle down to unhook the latch pins from the holes
over the windshield.
