2000 CHEVROLET CAVALIER Owners Manual

3-12
PUSHBUTTONS: The six numbered pushbuttons let
you return to your favorite stations. You can set up to
18 stations (six AM, six FM1 and six FM2). Just:
1. Turn the radio on.
2. Press AM
-FM to select the band.
3. Tune in the desired station.
4. Press and hold one of the six numbered buttons until
you hear a beep. Whenever you press that numbered
button, the station you set will return.
5. Repeat the steps for each pushbutton.
Setting the Tone
BASS: Press and release AUDIO until BAS appears on
the display. Then press and hold the up arrow to increase
bass. ªBº and a positive number will appear on the
display. Press and hold the down arrow to decrease bass.
B and a negative number will appear on the display.
B and a zero will appear on the display when the bass
level is set to the middle position. Release the up or
down arrow when you find the bass level you want or
when the maximum or minimum level is reached.TREBLE: Press and release AUDIO until TRE appears
on the display. Then press and hold the up arrow to
increase treble. T and a positive number will appear on
the display. Press and hold the down arrow to decrease
treble. T and a negative number will appear on the
display. T and a zero will appear on the display when the
treble level is set to the middle position. Release the up
or down arrow when you find the treble level you want
or when the maximum or minimum level is reached.
If a station is weak or noisy, you may want to decrease
the treble.
To set BASS or TREBLE to the middle position,
select the desired tone control. Then press and hold
AUDIO for more than two seconds until you hear a
beep. B and a zero or T and a zero will appear on the
display. To set all of the tone controls and speaker
controls to the middle position, end out of audio mode.
Then press and hold AUDIO for more than two seconds
until you hear a beep. CEN will appear on the display.

3-13
Adjusting the Speakers
BALANCE: Press and release AUDIO until BAL
appears on the display. Then press and hold the up arrow
to move the sound to the right speakers or the down
arrow to move the sound to the left speakers. R and a
number will appear on the display when the sound is
balanced toward the right speakers. L and a number
will appear on the display when the sound is balanced
toward the left speakers. L and a zero will appear on the
display when the the sound is balanced between the
speakers. Release the up or down arrow when you find
the speaker balance you want or when the maximum or
minimum level is reached.
FADE: Press and release AUDIO until FAD appears on
the display. Then press and hold the up arrow to move
the sound to the front speakers or the down arrow to
move the sound to the rear speakers. ªFº and a number
will appear on the display when the sound is balanced
toward the front speakers. ªRº and a number will appear
on the display when the sound is balanced toward the
rear speakers. F and a zero will appear on the display
when the the sound is balanced between the speakers.
Release the up or down arrow when you find the speaker
balance you want or when the maximum or minimum
level is reached.To set BALANCE or FADE to the middle position,
select the desired speaker control. Then press and hold
AUDIO for more than two seconds until you hear a
beep. L and a zero or F and a zero will appear on the
display. To set all of the tone controls and speaker
controls to the middle position, end out of audio mode.
Then press and hold AUDIO for more than two seconds
until you hear a beep. CEN will appear on the display.
Playing a Cassette Tape
Your tape player is built to work best with tapes that are
up to 30 to 45 minutes long on each side. Tapes longer
than that are so thin they may not work well in this
player. The longer side with the tape visible should face
to the right. If the ignition is on, but the radio is off, the
tape can be inserted and will begin playing. If you hear
nothing but a garbled sound, the tape may not be in
squarely. Press the eject button to remove the tape and
start over.
While the tape is playing, use the VOL, FAD, BAL,
TRE, BAS and SEEK controls just as you do for the
radio. The radio will display UP or the
 symbol if the
top side of the tape is playing. DN or the

symbol will
appear if the bottom side is playing.

3-14
If the player detects a tight or broken tape, Err (error)
will appear on the display and the player will eject the
tape. The radio will go back to playing the last
station selected.
If you want to insert a tape when the ignition is off,
first press the eject button or the RCL knob.
PREV (1): Press this button or the left SEEK arrow to
go to the previous selection on the tape if the selection
has been playing for less than 3 seconds. If the PREV
button or the left SEEK arrow is pressed and the current
selection has been playing for more than 13 seconds,
it will go to the beginning of the current selection. If the
PREV button or the left SEEK arrow is pressed and the
current selection has been playing from 3 to 13 seconds,
it will go to the beginning of the previous selection or
the beginning of the current selection, depending on the
position on the tape. FR will flash on the display while
the cassette player is in PREV mode. Your tape must
have at least three seconds of silence between each
selection for PREV to work. The sound will mute
while seeking.NEXT (2): Press this button or the right SEEK arrow to
go to the next selection on the tape. FF will flash on the
display while the cassette player is in NEXT mode. Your
tape must have at least three seconds of silence between
each selection for NEXT to work. The sound will mute
while seeking.
REV (3): Press this button to reverse the tape rapidly.
FR will appear on the display. Press it again to return
to playing speed. The radio will play the last selected
station while the tape reverses. You may select stations
during REV operation by using TUNE, SEEK, SCAN
or PRESET SCAN.
FWD (4): Press this button to advance quickly to
another part of the tape. FF will appear on the display.
Press the button again to return to playing speed. The
radio will play the last selected station while the tape
advances. You may select stations during FWD
operation by using TUNE, SEEK, SCAN or
PRESET SCAN.
SIDE (5): Press this button to play the other side of
the tape.

3-15
RPT (6): Press this button once to hear a selection
over again. RPT will appear on the display. The current
selection will continue to repeat. RPT will flash on the
display while the cassette player is searching for the
start of the selection. Your tape must have at least three
seconds of silence between each selection for RPT to
work. Press this button again to turn off repeated play.
OFF will appear on the display.
AM
-FM: Press this button to play the radio when
a tape is in the player. The tape will stop but remain in
the player.
TAPE: With a cassette tape in the player and the radio
playing, press this button to play a cassette tape. CAS
will appear on the display. Press AM
-FM to return to the
radio when a cassette tape is playing. The inactive tape
will remain safely inside the radio for future listening.
In order to use a portable CD player adapter or a cassette
tape head cleaner you must disable the TIGHT/LOOSE
TAPE sensor. Press and hold the TAPE button for two
seconds with the radio off and the vehicle on. CAS will
flash on the display showing the TIGHT/LOOSE TAPE
sensor has been disabled. The feature will remain
disabled until the tape is ejected.
EJECT: Press the upward triangle button to
remove a tape. The radio will play. Eject may be
activated with the radio off. Cassette tapes may be
loaded with the radio and vehicle off if this button is
pressed first.
CLN: If this message appears on the display, the
cassette tape player needs to be cleaned. It will still play
tapes, but you should clean it as soon as possible to
prevent damage to the tapes and player. See ªCare of
Your Cassette Tape Playerº in the Index. After you
clean the player, press and hold the eject button for five
seconds to reset the CLN indicator. The radio display
will flash
--- to show the indicator was reset.
Radio Calibration
Your audio system has been calibrated for your vehicle
from the factory. If CAL appears on the display it means
that your radio has not been configured properly for
your vehicle and must be returned to the dealership
for service.

3-16 AM-FM Stereo with Compact Disc Player
(If Equipped)
Playing the Radio
PWR
-VOL: Press this knob to turn the system on
and off. To increase volume, turn the knob clockwise.
Turn it counterclockwise to decrease volume.
RCL: Press this knob to recall the station being played
or to display the clock. Pressing RCL while playing a
CD will also display the CD track number or elapsed
time of CD track.
Finding a Station
AM
-FM: Press this button to switch between AM,
FM1 and FM2. The display shows your selection.TUNE: Turn this knob to choose radio stations.
SEEK: Press the right arrow to tune to the next higher
station and the left arrow to tune to the next lower
station and stay there. The radio will seek to stations
with a strong signal only.
SCAN: Press and hold one of the SEEK arrows for two
seconds until you hear a beep. Use SCAN to listen to
stations for a few seconds. The radio will go to a station,
stop for a few seconds and flash the station frequency,
then go on to the next station. Press one of the SEEK
arrows again to stop scanning. The radio will scan to
stations with a strong signal only.
PRESET SCAN: Press and hold one of the SEEK
arrows for more than four seconds until you will hear a
double beep. Use PRESET SCAN to listen to each of
your preset stations for a few seconds. The radio will go
to the first preset station stored on your pushbuttons,
except those stations with weak reception, stop for a few
seconds and flash the station frequency, then go on to
the next preset station. Press one of the SEEK arrows
again to stop scanning presets. The channel number
(P1
-P6) will appear momentarily just before the
frequency is displayed.

3-17
PUSHBUTTONS: The six numbered pushbuttons let
you return to your favorite stations. You can set up to
18 stations (six AM, six FM1 and six FM2). Just:
1. Turn the radio on.
2. Press AM
-FM to select the band.
3. Tune in the desired station.
4. Press and hold one of the six numbered buttons until
you hear a beep. Whenever you press that numbered
button, the station you set will return.
5. Repeat the steps for each pushbutton.
Setting the Tone
BASS: Press and release AUDIO until BAS appears on
the display. Then press and hold the up arrow to increase
bass. ªBº and a positive number will appear on the
display. Press and hold the down arrow to decrease bass.
B and a negative number will appear on the display.
B and a zero will appear on the display when the bass
level is set to the middle position. Release the up or
down arrow when you find the bass level you want or
when the maximum or minimum level is reached.TREBLE: Press and release AUDIO until TRE appears
on the display. Then press and hold the up arrow to
increase treble. ªTº and a positive number will appear
on the display. Press and hold the down arrow to
decrease treble. T and a negative number will appear on
the display. T and a zero will appear on the display when
the treble level is set to the middle position. Release the
up or down arrow when you find the treble level you
want or when the maximum or minimum level is
reached. If a station is weak or noisy, you may want
to decrease the treble.
To set BASS or TREBLE to the middle position,
select the desired tone control. Then press and hold
AUDIO for more than two seconds until you hear a
beep. B and a zero or T and a zero will appear on the
display. To set all of the tone controls and speaker
controls to the middle position, end out of audio mode.
Then press and hold AUDIO for more than two seconds
until you hear a beep. CEN will appear on the display.

3-18
Adjusting the Speakers
BALANCE: Press and release AUDIO until BAL
appears on the display. Then press and hold the up arrow
to move the sound to the right speakers or the down
arrow to move the sound to the left speakers. ªRº and
a number will appear on the display when the sound is
balanced toward the right speakers. ªLº and a number
will appear on the display when the sound is balanced
toward the left speakers. L and a zero will appear on the
display when the the sound is balanced between the
speakers. Release the up or down arrow when you find
the speaker balance you want or when the maximum or
minimum level is reached.
FADE: Press and release AUDIO until FAD appears on
the display. Then press and hold the up arrow to move
the sound to the front speakers or the down arrow to
move the sound to the rear speakers. ªFº and a number
will appear on the display when the sound is balanced
toward the front speakers. ªRº and a number will appear
on the display when the sound is balanced toward the
rear speakers. F and a zero will appear on the display
when the the sound is balanced between the speakers.
Release the up or down arrow when you find the speaker
balance you want or when the maximum or minimum
level is reached.To set BALANCE or FADE to the middle position,
select the desired speaker control. Then press and hold
AUDIO for more than two seconds until you hear a
beep. L and a zero or F and a zero will appear on the
display. To set all of the tone controls and speaker
controls to the middle position, end out of audio mode.
Then press and hold AUDIO for more than two seconds
until you hear a beep. CEN will appear on the display.
Playing a Compact Disc
Insert a disc partway into the slot, label side up. The player
will pull it in. The disc should begin playing. The display
will show CD. If you want to insert a compact disc with
the ignition off, first press RCL or the eject button.
If you're driving on a very rough road or if it's very
hot, the disc may not play and Err (error) may appear
on the display. When the road becomes smooth or the
temperature returns to normal, the disc should play.
If the disc comes out, it could be that:

The disc is upside down.

It is dirty, scratched or wet.

It is very humid. (If so, wait about an hour and
try again.)
If any error occurs repeatedly or if an error can't be
corrected, please contact your dealer.

3-19
PREV (1): Press this button or the left SEEK arrow to
go to the previous track if the current selection has been
playing for less than eight seconds. If the PREV button
or the left SEEK arrow is pressed and the current
selection has been playing for more than eight seconds,
it will go to the beginning of the current selection. The
track number will appear on the display. If you hold
the button or press it more than once, the player will
continue moving back through the disc. The sound
will mute while seeking.
NEXT (2): Press this button or the right SEEK arrow
to go to the next track. The track number will appear on
the display. If you hold the button or press it more than
once, the player will continue moving forward through
the disc. The sound will mute while seeking.
REV (3): Press and hold this button to reverse
quickly within a track. Release it to play the passage.
The display will show elapsed time while reversing.
FWD (4): Press and hold this button to advance
quickly within a track. Release it to play the passage.
The display will show elapsed time while forwarding.
RDM (5): Press this button to hear the tracks in
random, rather than sequential, order. RND will show
on the display. Press RDM again to turn off random
play. OFF will appear on the display.RPT (6): Press this button once to hear a selection over
again. RPT will appear on the display. The current track
will continue to repeat. Press RPT button again to turn
off repeated play. OFF will appear on the display.
RCL: Press this button to see the current track number
or how long the current track has been playing.
AM
-FM: Press this button to play the radio when
a disc is in the player. The disc will stop but remain in
the player.
CD: With a compact disc in the player and the radio
playing, press this button to play a compact disc. CD
will appear on the display. Press AM
-FM to return to
the radio when a compact disc is playing. The inactive
CD will remain safely inside the radio for future listening.
EJECT: Press the upward triangle button to
remove the disc. The radio will play. Eject may be
activated with either the ignition or radio off. CDs may
be loaded with the radio and ignition off if this button is
pressed first.
Radio Calibration
Your audio system has been calibrated for your vehicle
from the factory. If CAL appears on the display it means
that your radio has not been configured properly for your
vehicle and must be returned to the dealership for service.
