1999 TOYOTA CAMRY relay

F07217
Engine Room R/B No. 3
ABS Solenoid Relay
3
ABS
Actuator
A4 1
2
5 BatteryGAUGE Instrument Panel J/B
J/C
J3
D
ABS ECU 33 3 3
EA34 6
ABS ECUD
IJ28
R±L
IG3 4
DLC1 R±L
G±B
IG3 5 Short
Pin
W±B
ABS ECU W±L
G±B
C
CC R±L
R±L 1D2
7
4
R±L
A14WA IF1 12
11 G±B 4
G±B C12
C12
J/C
J22ABS Warning
Light
23
22 R±L
± DIAGNOSTICSANTI±LOCK BRAKE SYSTEM
DI±213
ABS Warning Light Circuit
CIRCUIT DESCRIPTION
If the ECU detects trouble, it lights the ABS warning light while at the same time prohibiting ABS control. At
this time, the ECU records a DTC in memory.
After removing the short pin of the DLC1, connect terminals Tc and E
1 of the DLC1 or DLC2 to make the
ABS warning light blink and output the DTC.
WIRING DIAGRAM
INSPECTION PROCEDURE
Troubleshooting in accordance with the chart below for each trouble symptom.
ABS warning light does not light upGo to step 1
ABS warning light remains onGo to step 3
1 Check ABS warning light.
See combination meter troubleshooting on page See Pub. No. RM654U on page BE±2.
NG Repair bulb or combination meter assembly.
OK
DI03Q±04

F00043
1 2 3
4 5 6
1 2 3
4 5 6
1 2 3
4
65 Open
Continuity
Continuity
Continuity
Open
(+)(±)
(+) (±)1 2 3
4 5 6 Continuity
DI±214
± DIAGNOSTICSANTI±LOCK BRAKE SYSTEM
2 Check ABS solenoid relay.
PREPARATION:
Remove ABS solenoid relay from Engine Room R/B No. 3.
CHECK:
Check continuity between each terminal of ABS solenoid relay.
OK:
Terminals 4 and 6Continuity (Reference value 80 W)
Terminals 2 and 3Continuity
Terminals 1 and 3Open
CHECK:
(a) Apply battery positive voltage between terminals 4 and 6.
(b) Check continuity between each terminal of ABS solenoid
relay.
OK:
Terminals 2 and 3Open
Terminals 1 and 3Continuity
CHECK:
Connect the
test lead to terminal 5 and the  lead to terminal
3. Check continuity between the terminals.
OK:
Continuity
If there is no continuity, connect the  test lead to terminal 5
and the
lead to terminal 3. Recheck continuity between ter-
minals.
NG Replace ABS solenoid relay.
OK
Check for open circuit in harness and connector between DLC1, ABS solenoid relay and body
ground (See page IN±29).

± DIAGNOSTICSANTI±LOCK BRAKE SYSTEM
DI±215
3 Is DTC output?
Check DTC on page DI±177.
YES Repair circuit indicated by the code output.
NO
4 Does ABS warning light go off if short pin is removed?
NO Check for short circuit in harness and connec-
tor between ABS warning light, DLC1 and ABS
ECU (See page IN±29).
YES
5 Check ABS solenoid relay (See step 2).
NG Replace ABS solenoid relay.
OK
Check for short circuit in harness and connector between DLC1 and ABS solenoid relay (See
page IN±29).

IN0253
WRONG CORRECT
IN0252
