AUTOMATIC TRANSAXLEPREPARATION ±
AX±9
(09351±32111)Side Bearing Race Replacer
(09351±32120)Overdrive Bearing Replacer
(09351±32130)Handle
(09351±32140)Oil Seal Replacer
(09351±32150)Oil Seal Replacer
(09351±32190)Measure Terminal
(09351±32200)No.3 Piston Spring Compressor
09502±10012Differential Side Bearing Puller


09564±32011Differential Preload Adaptor
09710±28020Front Suspension Bushing Tool
Set

(09710±08040)Bushing Replacer

09950±00020Bearing Remover
RECOMMENDED TOOL
09031±00030Pin Punch .
AX0ER±02

AUTOMATIC TRANSAXLECOMPONENT PARTS ±
AX±32
COMPONENT PARTS
GENERAL NOTES
The instructions here are organized so that you work on only one component group at a time.
This will help avoid confusion from similar±looking parts of different subassemblies being on your work-
bench at the same time.
The component groups are inspected and repaired from the converter housing side.
As much as possible, complete the inspection, repair and assembly before proceeding to the next com-
ponent group. If a component group cannot be assembled because parts are being ordered, be sure
to keep all parts of that group in a separate container while proceeding with disassembly, inspection,
repair and assembly of other component groups.
Recommended fluid for the automatic transaxle:
DEXRON ® @@@@@: [g 2]
GENERAL CLEANING NOTES:
1. All disassembled parts should be washed clean and any fluid passages and holes blown through with
compressed air.
2. When using compressed air to dry parts, always aim away from yourself to prevent accidentally spray-
ing automatic transmission fluid or kerosene in your face.
3. The recommended automatic transaxle fluid or kerosene should be used for cleaning.
PARTS ARRANGEMENT:
1. After cleaning, the parts should be arranged in the correct order to allow efficient inspection, repairs,
and reassembly.
2. When disassembling a valve body, be sure to keep each valve together with the corresponding spring.
3. New brakes and clutches that are to be used for replacement must be soaked in transaxle fluid for at
least 15 minutes before assembly.
GENERAL ASSEMBLY:
1. All oil seal rings, clutch discs, clutch plates, rotating parts, and sliding surfaces should be coated with
transmission fluid prior to reassembly.
2. All gaskets and rubber O±rings should be replaced.
3. Make sure that the ends of a snap ring are not aligned with one of the cutouts and are installed in the
groove correctly.
4. If a worn bushing is to be replaced, the subassembly containing that bushing must be replaced.
5. Check thrust bearings and races for wear or damage. Replace if necessary.
6. Use petroleum jelly to keep parts in place.
AX0EY±02

AUTOMATIC TRANSAXLEPREPARATION ±
AX±7
(09351±32100)Drive Pinion Bearing Replacer
(09351±32120)Overdrive Bearing Replacer
(09351±32140)Oil Seal Replacer
(09351±32150)Oil Seal Replacer
(09351±32190)Measure Terminal
(09351±32200)No.3 Piston Spring Compressor
09608±16011Rear Hub Bearing Tool±Remove differential side bearing
09612±65014Steering Worm Bearing PullerRemove pinion shaft bearing outer
race
09950±40010Puller B Set
RECOMMENDED COOL
09031±00030Pin Punch .
AX02M±02

AUTOMATIC TRANSAXLECOMPONENT PARTS REMOVAL ±
AX±33
GENERAL NOTES
The instructions here are organized so that you work on only one component group at a time.
This will help avoid confusion from similar±looking parts of different subassemblies being on your work-
bench at the same time.
The component groups are inspected and repaired from the converter housing side.
As much as possible, complete the inspection, repair and assembly before proceeding to the next compo-
nent group. If a component group cannot be assembled because parts are being ordered, be sure to keep
all parts of that group in a separate container while proceeding with disassembly, inspection, repair and
assembly of other component groups.
Recommended fluid for the automatic transaxle: ATF D±@@@@@: [g 2] or DEXRON®@@@@@: [g
3](DEXRON®@@@@@: [g 2])
1. GENERAL CLEANING NOTES:
(a) All disassembled parts should be washed clean and any fluid passages and holes blown through with
compressed air.
(b) When using compressed air to dry parts, always aim away from yourself to prevent accidentally spray-
ing automatic transaxle fluid or kerosene in your face.
(c) The recommended automatic transaxle fluid or kerosene should be used for cleaning.
2. PARTS ARRANGEMENT:
(a) After cleaning, the parts should be arranged in the correct order to allow efficient inspection, repairs,
and reassembly.
(b) When disassembling a valve body, be sure to keep each valve together with the corresponding spring.
(c) New brakes and clutches that are to be used for replacement must be soaked in transaxle fluid for at
least fifteen minutes before assembly.
3. GENERAL ASSEMBLY:
(a) All oil seal rings, clutch discs, clutch plates, rotating parts, and sliding surfaces should be coated with
transmission fluid prior to reassembly.
(b) All gaskets and rubber O±rings should be replaced.
(c) Make sure that the ends of a snap ring are not aligned with one of the cutouts and are installed in the
groove correctly.
(d) If a worn bushing is to be replaced, the subassembly containing that bushing must be replaced.
(e) Check thrust bearings and races for wear or damage. Replace if necessary.
(f) Use petroleum jelly to keep parts in place.
AX02T±07

AUTOMATIC TRANSAXLEPREPARATION ±
AX±7
(09351±32100)Drive Pinion Bearing Replacer
(09351±32120)Overdrive Bearing Replacer
(09351±32140)Oil Seal Replacer
(09351±32150)Oil Seal Replacer
(09351±32190)Measure Terminal
(09351±32200)No.3 Piston Spring Compressor
09608±16011Rear Hub Bearing Tool±Remove differential side bearing
09612±65014Steering Worm Bearing PullerRemove pinion shaft bearing outer
race
09950±40010Puller B Set
RECOMMENDED COOL
09031±00030Pin Punch .
AX02M±02

AUTOMATIC TRANSAXLECOMPONENT PARTS REMOVAL ±
AX±33
GENERAL NOTES
The instructions here are organized so that you work on only one component group at a time.
This will help avoid confusion from similar±looking parts of different subassemblies being on your work-
bench at the same time.
The component groups are inspected and repaired from the converter housing side.
As much as possible, complete the inspection, repair and assembly before proceeding to the next compo-
nent group. If a component group cannot be assembled because parts are being ordered, be sure to keep
all parts of that group in a separate container while proceeding with disassembly, inspection, repair and
assembly of other component groups.
Recommended fluid for the automatic transaxle: ATF D±@@@@@: [g 2] or DEXRON®@@@@@: [g
3](DEXRON®@@@@@: [g 2])
1. GENERAL CLEANING NOTES:
(a) All disassembled parts should be washed clean and any fluid passages and holes blown through with
compressed air.
(b) When using compressed air to dry parts, always aim away from yourself to prevent accidentally spray-
ing automatic transaxle fluid or kerosene in your face.
(c) The recommended automatic transaxle fluid or kerosene should be used for cleaning.
2. PARTS ARRANGEMENT:
(a) After cleaning, the parts should be arranged in the correct order to allow efficient inspection, repairs,
and reassembly.
(b) When disassembling a valve body, be sure to keep each valve together with the corresponding spring.
(c) New brakes and clutches that are to be used for replacement must be soaked in transaxle fluid for at
least fifteen minutes before assembly.
3. GENERAL ASSEMBLY:
(a) All oil seal rings, clutch discs, clutch plates, rotating parts, and sliding surfaces should be coated with
transmission fluid prior to reassembly.
(b) All gaskets and rubber O±rings should be replaced.
(c) Make sure that the ends of a snap ring are not aligned with one of the cutouts and are installed in the
groove correctly.
(d) If a worn bushing is to be replaced, the subassembly containing that bushing must be replaced.
(e) Check thrust bearings and races for wear or damage. Replace if necessary.
(f) Use petroleum jelly to keep parts in place.
AX02T±07

CO067±03
Z18990
Radiator Drain Plug
Engine Drain Plug CO±2
± COOLING (5S±FE)COOLANT
1576 Author: Date:
REPLACEMENT
1. DRAIN ENGINE COOLANT
(a) Remove the radiator cap.
CAUTION:
To avoid the danger of being burned, do not remove the ra-
diator cap while the engine and radiator are still hot, as fluid
and steam can be blown out under pressure.
(b) Loosen the radiator drain plug (on the right side of the ra-
diator lower tank) and engine drain plug (on the left rear
of the cylinder block), and drain the coolant.
(c) Close the drain plugs.
Torque: 25 N´m (250 kgf´cm, 18 ft´lbf) for engine
2. FILL ENGINE COOLANT
(a) Slowly fill the system with coolant.

Use of improper coolants may damage engine cool-
ing system.

Use ºToyota Long Life Coolantº or equivalent and
mix it with plan water according to the manufactur-
er's directions.

Using of coolant which includes more than 50 %
(freezing protection down to ±35°C (±31°F) or 60 %
(freezing protection down to ±50°C (±58°F)) of eth-
ylene±glycol is recommended but not more than 70
%.
NOTICE:

Do not use an alcohol type coolant or plain water
alone.

The coolant should be mixed with plain water (prefer-
ably demineralized water or distilled water).
Capacity:
w/ Oil cooler6.9 litters (7.3 US qts, 6.1 lmp. qts)
w/o Oil cooler6.2 litters (6.5 US qts, 5.4 lmp. qts)
(b) Install the radiator cap.
(c) Start the engine, and bleed the cooling system.
(d) Refill the radiator reservoir with coolant until it reaches the
ºFULLº line.
3. CHECK FOR COOLANT LEAKS

A00434
± DIAGNOSTICSENGINE (5S±FE)
DI±93
328 Author: Date:
2 Check spark plug and spark of misfiring cylinder.
PREPARATION:
(a) Disconnect the high±tension cord from the spark plug.
(b) Remove the spark plug.
CHECK:
(a) Check the plug type.
(b) Check the electrode for carbon deposits.
(c) Check the electrode gap.
OK:
(a) Platinum±tipped spark plugs with twin ground
electrodes.
Recommended spark plug:
ND made: PK20TR11
NGK made: BKR6EKPB±11
(b) No large carbon deposit present.
Not wet with gasoline or oil.
(c) Electrode gap: 1.1 mm (0.043 in.)
PREPARATION:
(a) Install the spark plug to the high±tension code.
(b) Disconnect the injector connector.
(c) Ground the spark plug.
CHECK:
Check if spark occurs while the engine is being cracked.
NOTICE: To prevent excess fuel being injected from the in-
jectors during this test, don't crank the engine for more
than 5 ~ 10 seconds at a time.
OK:
Spark jumps across electrode gap.
NG Replace or check ignition system
(See page IG±1).
OK
