AUTOMATIC TRANSAXLEUPPER VALVE BODY ±
AX±87
VALVE BODY SPRINGS SPECIFICATIONS
HINT: During reassembly please refer to the spring specifications above to help discriminate between
the different springs.
Mar
kName (Color)Free Length / Outer Diameter
mm (in.)Total No. of Coils
@@
@@
@:
[c A]
Lock±Up Relay Valve (Yellow)26.8 (1.055) / 10.2 (0.402)10.8
@@
@@
@:
[c B]
B1 Orifice Control Valve (White)24.8 (0.976) / 6.4 (0.252)12.0
@@
@@
@:
[c C]
Throttle Valve (Green)31.5 (1.240) / 7.0 (0.276)11.4
@@
@@
@:
[c D]
Down±Shift Plug (None)15.0 (0.591) / 11.0 (0.433)7.0
AX048±03

AUTOMATIC TRANSAXLESERVICE SPECIFICATIONS ±
AX±129
Valve Body Spring
SpringFree length / Coil outer diameter
mm (in.)Total No. of coils / Color
Upper valve body
Low coast modulator valve20.2 (0.795) / 7.9 (0.311)11.9 / Purple
B1 orifice control valve24.8 (0.976) / 6.4 (0.252)12.0 / White
Down±shift plug15.0 (0.591) / 11.0 (0.433)7.0 / None
Throttle valve31.5 (1.240) / 7.0 (0.276)11.4 / Green
Lock±up relay valve26.8 (1.055) / 10.2 (0.402)10.8 / Yellow
Lower valve body
2±3 shift valve28.0 (1.102) / 9.4 (0.370)10.3 / None
Second coast modulator valve20.2 (0.795) / 7.9 (0.311)11.9 / Purple
Accumulator control vavle25.1 (0.988) / 8.6 (0.339)8.0 / Red
Secondary regulator valve46.9 (1.846) / 5.9 (0.232)21.8 / None
Second lock valve20.7 (0.815) / 7.4 (0.291)9.5 / None
Reverse control valve38.1 (1.500) / 6.5 (0.256)19.0 / White/Purple
1±2 shift valve29.2 (1.150) / 8.9 (0.350)12.0 / Light Green
3±4 shift valve28.0 (1.102) / 7.6 (0.299)10.3 / None
Primary regulator valve36.6 (1.441) / 16.1 (0.634)6.3 / None
Cut±back valve21.8 (0.858) / 6.0 (0.236)13.5 / None
Solenoid modulator valve30.2 (1.189) / 5.6 (0.220)15.3 / Purple/Pink
Valve Body Key
KeyHeight
mm (in.)Width
mm (in.)Thickness
mm (in.)
Upper valve body
B1 orifice control valve8.9 (0.350)5.0 (0.197)3.2 (0.126)
Low coast modulator valve8.5 (0.335)5.0 (0.197)3.2 (0.126)
Lower valve body
Accumulator control valve8.5 (0.335)5.0 (0.197)3.2 (0.126)
Secondary regulator valve11.0 (0.433)5.0 (0.197)3.2 (0.126)
1±2 shift valve8.5 (0.335)5.0 (0.197)3.2 (0.126)
2±3 shift valve8.5 (0.335)5.0 (0.197)3.2 (0.126)
3±4 shift valve6.5 (0.256)5.0 (0.197)3.2 (0.126)
Second lock valve9.2 (0.362)5.0 (0.197)3.2 (0.126)
Second coast modulator valve8.0 (0.315)5.0 (0.197)3.2 (0.126)
Reverse control valve8.5 (0.335)5.0 (0.197)3.2 (0.126)
Cut±back valve9.2 (0.362)5.0 (0.197)3.2 (0.126)
Solenoid modulator valve8.5 (0.335)5.0 (0.197)3.2 (0.126)
Lock±up control valve9.2 (0.315)5.0 (0.197)3.2 (0.126)

BE09Z±03
BE±2
± BODY ELECTRICALBODY ELECTRICAL SYSTEM
2222 Author: Date:
PROBLEM SYMPTOMS TABLE
POWER OUTLET
SymptomSuspect AreaSee page
Electric power source cannot be taken out of the power outlet
11. Battery
12.POWER OUTLET Fuse (I/P J/B No.1)
13.Wire Harness±
±
±
HEADLIGHT AND TAILLIGHT SYSTEM (USA)
SymptomSuspect AreaSee page
Headlight does not light.
(Taillight is normal)1. HEAD±(LH, RH) Fuse (E/G Room J/B No.2)
2. Headlight Bulb
3. Wire Harness±
±
±
Headlight does not light.
(Taillight does not light up)
1. HEAD±(LH, RH) Fuse (E/G Room J/B No.2)
2. Headlight Control Relay (E/G Room J/B No.2)
3. Headlight Bulb
4. Wire Harness±
BE±24
±
±
Only one side light does not light.
1. HEAD±(LH, RH) Fuse (E/G Room J/B No.2)
2. Headlight Bulb
3. Wire Harness±
±
±
ºLo±Beamº does not light.
1. Headlight Bulb
2. Light Control Switch
3. Wire Harness±
BE±24
±
ºHi±Beamº does not light.
1. Headlight Dimmer Switch
2. Light Control Switch
3. Wire HarnessBE±24
BE±24
±
ºFlashº does not light.1. Headlight Dimmer Switch
2. Wire HarnessBE±24
±
ºAuto Turn±off Systemº does not operate.
1. GAUGE Fuse (I/P J/B No.1)
2. DOME Fuse (E/G Room J/B No.2)
3. Integration Relay (I/P J/B No.2)
4. Door Courtesy Switch (Driver's)
5. Ignition Switch
6. Wire Harness±
±
BE±14
BE±24
BE±14
±
Taillight does not light. (Headlight does not light)
1. Light Control Switch
2. Integration Relay (I/P J/B No.1)
3. Wire HarnessBE±24
BE±14
±
Taillight does not light.
(Headlight is normal)
1. TAIL Fuse (I/P J/B No.1)
2. Taillight Control Relay (I/P J/B No.1)
3. Light Control Switch
4. Integration Relay (I/P J/B No.1)
5. Wire Harness±
BE±24
BE±24
BE±14
±
Only one side light does not light.1. Bulb
2. Wire Harness±
±
Rear Combination light does not light.
1. Bulb
2. Light Failure Sensor
3. Wire Harness±
BE±37
±
ºAuto Turn±off Systemº does not operate.
1. GAUGE Fuse (I/P J/B No.1)
2. Integration Relay (I/P J/B No.1)
3. Door Courtesy Switch (Driver's)
4. Wire Harness±
BE±14
BE±32
±

± BODY ELECTRICALBODY ELECTRICAL SYSTEM
BE±3
2223 Author: Date:
HEADLIGHT AND TAILLIGHT SYSTEM (CANADA)
SymptomSuspect AreaSee page
Headlight does not light.
(Taillight is normal)1. Wire Harness±
Headlight does not light.
(Taillight does not light up)1. Wire Harness±
Only one side light does not light.
1. Headlight Bulb
2. HEAD LO (LH, RH) Fuse (E/G Room R/B No.2)
3. Wire Harness±
±
±
ºLo±Beamº does not light.
1. Headlight Bulb
2. HEAD LO (LH, RH) Fuse (E/G Room R/B No.2)
3. Headlight Control Relay (E/G Room J/B No.2)
4. Integration Relay (I/P J/B No.1)
5. Light Control Switch
6. Wire Harness±
±
BE±24
BE±14
BE±24
±
ºHi±Beamº does not light.
1. Headlight Bulb
2. ECU±B Fuse (E/G Room J/B No.2)
3. HEAD HI (LH, RH) Fuse (E/G Room J/B No.2)
4. DRL Fuse (E/G Room R/B No.2)
5. Daytime Running Light Relay No.2
(E/G Room R/B No.2)
6. Daytime Running Light Relay No.3
(E/G Room R/B No.2)
7. Daytime Running Light Relay No.4
(E/G Room R/B No.2)
8. Daytime Running Light Relay (Main)
9. Headlight Dimmer Switch
10.Wire Harness±
±
±
±
±
BE±24
±
BE±24
±
BE±24
BE±24
BE±24
±
ºFlashº does not light.
1. Headlight Bulb
2. ECU±B Fuse (E/G Room J/B No.2)
3. HEAD HI (LH, RH) Fuse (E/G Room J/B No.2)
4. DRL Fuse (E/G Room R/B No.2)
5. Daytime Running Light Relay No.2
(E/G Room R/B No.2)
6. Daytime Running Light Relay No.3
(E/G Room R/B No.2)
7. Daytime Running Light Relay No.4
(E/G Room R/B No.2)
8. Daytime Running Light Relay (Main)
9. Headlight Dimmer Switch
10.Wire Harness±
±
±
±
±
BE±24
±
BE±24
±
BE±24
BE±24
BE±24
±
ºAuto Turn±off Systemº does not operate.
1. GAUGE Fuse (I/P J/B No.1)
2. DOME Fuse (E/G Room J/B No.2)
3. Integration Relay (I/P J/B No.2)
4. Door Courtesy Switch (Driver's)
5. Ignition Switch
6. Wire Harness±
±
BE±14
BE±24
BE±14
±
Headlight does not light with engine running and light control SW
OFF.
1. Headlight Bulb
2. ECU±B Fuse (E/G Room J/B No.2)
3. GAUGE Fuse (I/P J/B No.1)
4. HEAD HI (LH, RH) Fuse (E/G Room J/B No.2)
5. Daytime Running Light Relay (Main)
6. Wire Harness
7. Other Parts*±
±
±
±
BE±24
±
±

BE±4
± BODY ELECTRICALBODY ELECTRICAL SYSTEM
2224 Author: Date:
Taillight does not light.
(Headlight does not light)1. Integration Relay (I/P J/B No.1)
2. Light Control Switch
3. Wire HarnessBE±14
BE±24
±
Taillight does not light.
(Headlight is normal)
1. TAIL Fuse (I/P J/B No.1)
2. Taillight Control Relay (I/P J/B No.1)
3. Integration Relay (I/P J/B No.1)
4. Light Control Switch
5. Wire Harness±
BE±24
BE±14
BE±24
±
Only one side light does not light.1. Bulb
2. Wire Harness±
±
Rear Combination light does not light.
1. Bulb
2. Light Failure Sensor
3. Wire Harness±
BE±37
±
ºAuto Turn±off Systemº does not operate.
1. GAUGE Fuse (I/P J/B No.1)
2. Integration Relay (I/P J/B No.1)
3. Door Courtesy Switch (Driver's)
4. Wire Harness±
BE±14
BE±24
±
*Terminal L of generator and parking brake switch
TURN SIGNAL AND HAZARD WARNING SYSTEM
SymptomSuspect AreaSee page
ºHazardº and ºTurnº do not light up.
1. Hazard Warning Switch
2. Turn Signal Flasher
3. Wire HarnessBE±30
BE±30
±
The flashing frequency is abnormal.
1. Bulb
2. Turn Signal Switch
3. Wire Harness±
BE±30
±
Hazard warning light does not light up.
(Turn is normal.)1. HORN Fuse (E/G Room J/B No.2)
2. Wire Harness±
±
Hazard warning light does not light up in one direction.1. Hazard Warning Switch
2. Wire HarnessBE±30
±
*1Turn signal does not light up.
1. Ignition Switch
2. TURN Fuse (I/P J/B No.1)
3. Turn Signal Switch
4. Wire HarnessBE±14
±
BE±30
±
*2Turn signal does not light up.
1. TURN Fuse (I/P J/B No.1)
2. Turn Signal Switch
3. Wire Harness±
BE±30
±
Turn signal does not light up in one direction.1. Turn Signal Switch
2. Wire HarnessBE±30
±
Only one bulb does not light up.1. Bulb
2. Wire Harness±
±
*1: Combination meter, wiper and washer do not operate.
*
2: Combination meter, wiper and washer are normal.
INTERIOR LIGHT SYSTEM
SymptomSuspect AreaSee page
ºIlluminated Entry Systemº does not operate.
1. Door Courtesy Switch
2. Integration Relay (I/P J/B No.1)
3. Wire HarnessBE±32
BE±14
±
Only one interior light does not light up.1. Bulb
2. Wire Harness±
±
Interior light does not light up (All).1. DOME Fuse (E/G Room J/B No.2)
2. Wire Harness±
±

± BODY ELECTRICALBODY ELECTRICAL SYSTEM
BE±7
2227 Author: Date:
Seat Belt warning light does not light up.
1. Bulb
2. Seat Belt Buckle Switch
3. Integration Relay (I/P J/B No.1)
4. Wire Harness±
BE±47
BE±47
±
Discharge warning light does not light up.
1. IGN Fuse (I/P J/B No.1)
2. Bulb
3. Wire Harness
4. Generator (5S±FE)
(1MZ±FE)±
±
±
CH±1
CH±1
Light Failure warning light does not light up.
1. Bulb
2. Light Failure Sensor
3. Bulb Check Relay
4. Wire Harness
5. Taillight system±
BE±37
BE±47
±
BE±24
Brake warning light does not light up.
1. Bulb
2. Parking Brake Switch
3. Brake Fluid Level Warning Switch
4. Bulb Check Relay
5. Meter Circuit Plate
6. Wire Harness±
BE±47
BE±47
BE±47
BE±46
±
SRS Warning light does not light up.
1. ECU±B Fuse (E/G Room J/B No.2)
2. Bulb
3. Airbag Sensor Assembly
4. Meter Circuit Plate
5. Wire Harness±
±
DI±626
BE±46
±
Open Door warning light does not light up.
1. DOME Fuse (E/G Room J/B No.2)
2. Bulb
3. Door Courtesy Switch
4. Meter Circuit Plate
5. Wire Harness±
±
BE±32
BE±46
±
Washer Level warning light does not light up.
1. Bulb
2. Washer Fluid Level Warning Switch
3. Meter Circuit Plate
4. Wire Harness±
BE±47
BE±46
±
COMBINATION METER
INDICATOR LIGHTS:
SymptomSuspect AreaSee page
O/D OFF indicator light does not light up.
1. Bulb
2. O/D OFF Switch (A140E)
(A541E)
3. Meter Circuit Plate
4. Wire Harness±
DI±431
DI±487
BE±46
±
Cruise Control indicator light does not light up.
1. Bulb
2. Cruise Control ECU
3. Meter Circuit Plate
4. Wire Harness±
IN±31
BE±46
±
High beam indicator light does not light up.
1. Bulb
2. Meter Circuit Plate
3. Wire Harness
4. Headlight System±
BE±46
±
BE±22
Turn indicator light does not light up.
1. Bulb
2. Meter Circuit Plate
3. Wire Harness
4. Turn Signal and Hazard Warning System±
BE±46
±
BE±29

BE±8
± BODY ELECTRICALBODY ELECTRICAL SYSTEM
2228 Author: Date:
Shift indicator lights do not light up.
1. Bulb
2. Meter Circuit Plate
3. Park/Neutral Position Switch (A140E)
(A541E)
4. Wire Harness±
BE±46
DI±424
DI±479
±
Only one shift indicator does not light up.1. Bulb
2. Meter Circuit Plate±
BE±46
Malfunction indicator light does not light up.
1. Bulb
2. ECM
3. Meter Circuit Plate
4. Wire Harness±
±
BE±46
±
SLIP indicator light does not light up.
1. Bulb
2. Traction ECU
3. Meter Circuit Plate
4. Wire Harness±
±
BE±46
±
TRAC OFF indicator light does not light up.
1. Bulb
2. Traction ECU
3. Meter Circuit Plate
4. Wire Harness±
±
BE±46
±
Security indicator light does not light up.
1. Bulb
2. Security ECU
3. Meter Circuit Plate
4. Wire Harness±
±
BE±46
±
Indicator lights do not light up. (Except Turn, Hi±beam and
security)1. GAUGE Fuse (I/P J/B No.1)
2. Wire Harness±
±
DEFOGGER SYSTEM
SymptomSuspect AreaSee page
All defogger systems do not operate.
1. DEFOG M±Fuse (I/P J/B No.1)
2. HTR Fuse (I/P J/B No.1)
3. Defogger Relay (I/P J/B No.1)
4. Defogger Switch
5. Wire Harness±
±
BE±56
BE±56
±
Rear window defogger does not operate.
1. Defogger Wire
2. Choke Coil
3. Wire HarnessBE±56
±
±
Mirror defogger does not operate.
1. MIR/HTR Fuse (I/P J/B No.1)
2. Mirror Defogger
3. Wire Harness±
BE±56
±
POWER WINDOW CONTROL SYSTEM
SymptomSuspect AreaSee page
Power window does not operate (ALL).
(Power Door Lock does not operate)1. POWER M±Fuse (I/P J/B No.1)
2. Power Main Relay (I/P J/B No.1)
3. Wire Harness±
BE±60
±
Power window does not operate (ALL).
(Power Door Lock is normal)1. Ignition Switch
2. Power Window Master Switch
3. Wire HarnessBE±14
BE±60
±
ºOne Touch Power Window Systemº does not operate.1. Power Window Master SwitchBE±60
Only one window glass does not move.
1. Power Window Master Switch
2. Power Window Switch
3. Power Window Motor
4. Wire HarnessBE±60
BE±60
BE±60
±
ºWindow Lock Systemº does not operate.1. Power Window Master SwitchBE±60

± BODY ELECTRICALBODY ELECTRICAL SYSTEM
BE±9
2229 Author: Date:
ºWindow Lock Illuminationº does not light up.1. Power Window Master SwitchBE±60
Key±off power window does not operate.
1. GAUGE Fuse (I/P J/B No.1)
2. Integration Relay (I/P J/B No.1)
3. Ignition Switch
4. Door Courtesy Switch
5. Wire Harness±
BE±60
BE±14
BE±32
±
POWER DOOR LOCK CONTROL SYSTEM
SymptomSuspect AreaSee page
ºDoor lock systemº does not operate at all.
1. POWER M±Fuse (I/P J/B No.1)
2. CIG Fuse (I/P J/B No.1)
3. DOOR Fuse (I/P J/B No.1)
4. Integration Relay (I/P J/B No.1)
5. Wire Harness±
±
±
BE±70
±
Door lock system does not operate by manual switch.
1. Power Window Master Switch
2. Door Lock Manual Switch
3. Integration Relay (I/P J/B No.1)
4. Wire HarnessBE±60
BE±70
BE±70
±
Door lock system does not operate by door key.
1. Door Key Lock and Unlock Switch
2. Integration Relay (I/P J/B No.1)
3. Wire Harness
4. Door Lock Link DisconnectedBE±70
BE±70
±
±
Fault in 2±Operation unlock function of Driver's side door key lock
and unlock switch.1. Door Key Lock and Unlock Switch
2. Integration Relay (I/P J/B No.1)
3. Wire HarnessBE±70
BE±70
±
Fault in key confine prevention operate.
1. Integration Relay (I/P J/B No.1)
2. Key Unlock Warning Switch
3. Door Courtesy Switch
4. Wire HarnessBE±70
BE±14
BE±32
±
Only one door lock does not operate.1. Door Lock Motor
2. Wire HarnessBE±70
±
SLIDING ROOF SYSTEM
SymptomSuspect AreaSee page
Sliding roof system does not operate.
(Door Lock does not operate)1. POWER M±Fuse (I/P J/B No.1)
2. Power Main Relay (I/P J/B No.1)
3. Wire Harness±
BE±60
±
Sliding roof system does not operate.
(Door Lock is normal)
1. Ignition Switch
2. Sliding Roof Control Relay and Switch
3. Sliding Roof Motor and Limit Switch
4. Wire HarnessBE±14
BE±74
BE±74
±
Sliding roof system operates abnormally.
1. Sliding Roof Control Relay and Switch
2. Sliding Roof Motor and Limit Switch
3. Wire HarnessBE±74
BE±74
±
Sliding roof system stops operation half way.
(Stones of foreign material trapped in motor assembly)1. Sliding Roof Control Relay and Switch
2. Sliding Roof Motor and Limit Switch
3. Wire HarnessBE±74
BE±74
±
ºKey±off Sliding Roofº operation does not operate.
1. DOME Fuse (E/G Room J/B No.2)
2. GAUGE Fuse (I/P J/B No.1)
3. Ignition Switch
4. Integration Relay (I/P J/B No.1)
5. Wire Harness±
±
BE±14
BE±14
±
