1999 HONDA ODYSSEY Owners Manual

Protecting Children

3. After the belt has retracted, tug on it. If the belt is locked, you will not
be able to pull it out. If you can pull
the belt out, it is not locked and you will need to repeat these steps.
4. After confirming that the belt islocked, grab the shoulder part of
the belt near the buckle and pull
up to remove any slack from the
lap part of the belt. Remember, if
the lap part of the belt is not tight,
the child scat will not be secure.
To remove slack, it may help to put weight on the child seat, or
push on the back of the scat, while
pulling up on the belt. 5. Push and pull the child seat
forward and from side to side to
verify that it is secure enough to stay upright during normal driving
maneuvers. If the child seat is not
secure, unlatch the belt, allow it to retract fully, then repeat these

steps.

Driver and Passenger SafetyProCarManuals.comMain Menu Table of Contents s t

Protecting Children

To deactivate the locking mechanism and remove a child seat,
unlatch the buckle, unroute the seat
belt, and let the belt fully retract. Installing a Rear-Facing Child Seat in
the Center Position of the Third Seat
To install a rear-facing child seat in the center position of the third seat,
use the lap part of the lap/shoulderbelt. Follow instruction number 1 on
page 31 for routing and latching theseat belt.
Then pull hard on the loose end of the belt to remove any slack (it may
help to put weight on the child seat
while pulling on the belt). Finally, follow instruction number 5
on page 32 to verify that the child
seat is secure.

CONTINUED

Driver and Passenger SafetyProCarManuals.comMain Menu Table of Contents s t

Protecting Children

Rear-Facing Child Seat Installation
Tips

For proper protection, an infant must
ride in a reclined, or semi-reclined
position. To determine the proper reclining angle, check with the baby'sdoctor or follow the seat maker's
recommendations.
To achieve the desired reclining angle, it may help to put a rolled up
towel under the toe of the child seat,
as shown.
When properly installed, a rear-
facing child seat may prevent the
driver or a front-seat passenger from
moving the seat as far back as
recommended (see page 12 ). Or it
may prevent them from locking the seat-back in the desired upright
position (see page 13).
In either case, we recommend that
you place the child seat in another back seating position, or leave theaffected seat unoccupied. If the
problem cannot be solved, you may
wish to get a smaller rear-facing child seat.
Additional Precautions for Infants
Never hold an infant on your lap.

If you are not wearing a seat belt
in a crash, you could be thrown
forward into the dashboard and crush the infant.
If you are wearing a seat belt, the
infant can be torn from your arms. For example, if your vehicle
crashes into a parked vehicle at 30
mph (48 km/h), a 20-lb (9 kg)
infant will become a 600-lb (275
kg) force, and you will not be able
to hold on.
Never put a seat belt over yourself

and an infant. During a crash, the
belt could press deep into the infant and cause very serious
injuries.

Driver and Passenger SafetyProCarManuals.comMain Menu Table of Contents s t

Protecting Children

Protecting Small Children

Child Seat Type

A child who can sit up without support, and who fits within the child
seat maker's weight and height
limits, should be restrained in a
forward-facing, upright child seat. Of the different seats available, we
recommend those that have a five-
point harness system as shown.
We also recommend that a small child stay in the child seat as long as
possible, until the child reaches the
weight or height limit for the seat.
Child Seat Placement

In this vehicle, the best place to
install a forward-facing child seat is
in one of the seating positions in a
back seat.

Placing a forward-facing child seat in
the front seat of a vehicle equipped

with a passenger's airbag can be

hazardous. If the vehicle seat is too
far forward, or the child's head is thrown forward during a collision, an
inflating passenger's airbag can
strike the child with enough force to
cause very serious or fatal injuries. If
a small child must be closely
watched, we recommend that
another adult sit in a back seat with the child.

CONTINUED

Driver and Passenger SafetyProCarManuals.comMain Menu Table of Contents s t

Protecting Children

If it is necessary to put a forward-
facing child seat in the front, move
the vehicle seat as far to the rear as
possible, be sure the child seat is firmly secured to the vehicle, and the
child is properly strapped in the seat.
Installing a Child Seat with a Lap/
Shoulder Belt

The lap/shoulder belts in the outer back and front passenger seating
positions have a locking mechanism
that must be activated to secure a
child seat.
The following pages provide instructions on how to secure a
forward-facing child seat with this type of seat belt.
See page 38 for how to secure a
forward-facing child seat in the
center position of the third seat with
the lap part of the lap/shoulder belt. 1. With the child seat in the desired
seating position, route the belt
through the child seat according
to the seat maker's instructions,
then insert the latch plate into the
buckle.

Driver and Passenger Safety

Improperly placing a forward-
facing child seat in the front seat can result in serious injury
or death if the airbags inflate.
If you must place a forward-
facing child seat in front, move
the vehicle seat as far back as possible and properly restrain
the child.ProCarManuals.comMain Menu Table of Contents s t

Protecting Children

2. To activate the lockable retractor, slowly pull the shoulder part of the
belt all the way out until it stops, then let the belt feed back into theretractor (you might hear a
clicking noise as the belt retracts).
3. After the belt has retracted, tug on it. If the belt is locked, you will not
be able to pull it out. If you can pullthe belt out, it is not locked and
you will need to repeat these steps. 4. After confirming that the belt is
locked, grab the shoulder part of
the belt near the buckle and pull
up to remove any slack from the
lap part of the belt. Remember, if the lap part of the belt is not tight,
the child seat will not be secure. It may help to put weight on the
child seat, or push on the back of
the seat, while pulling up on the belt. 5. Push and pull the child seat
forward and from side to side to
verify that it is secure enough to stay upright during normal drivingmaneuvers. If the child seat is not
secure, unlatch the belt, allow it to
retract fully, then repeat these

steps.

CONTINUED

Driver and Passenger SafetyProCarManuals.comMain Menu Table of Contents s t

Protecting Children

To deactivate the locking
mechanism and remove a child seat, unlatch the buckle, unroute
the seat belt, and let the belt fully retract. Installing a Child Seat in the Center
Position of the Third Seat
To install a forward-facing child seat in the center position of the third
seat, use the lap part of the lap/
shoulder belt. Follow instructionnumber 1 on page 36 for routing and
latching the seat belt.
Then pull hard on the loose end of the belt to remove any slack (it may
help to put weight on the child seat
while pulling on the belt). Finally, follow instruction number 5 on page 37 to verify that the child

seat is secure.

Driver and Passenger SafetyProCarManuals.comMain Menu Table of Contents s t

Protecting Children

Additional Precautions for Small
Children
Never hold a small child on your

lap. If you are not wearing a seat
belt in a crash, you could be
thrown forward into the dashboard and crush the child.
If you are wearing a seat belt, the
child can be torn from your armsduring a crash. For example, if
your vehicle crashes into a parked
vehicle at 30 mph (48 km/h), a 30-lb (14 kg) child will become a
900-lb (410 kg) force, and you will
not be able to hold on.
Never put a seat belt over yourself

and a child. During a crash, the

belt could press deep into the child
and cause very serious injuries.
Protecting Larger Children
When a child reaches the recommended weight or height limit
for a forward-facing child seat, the child should sit in the back seat and
wear a lap/shoulder belt.
If a child is too short for the shoulder
part of the belt to properly fit, we
recommend that the child use a
booster seat until they are tallenough to use the seat belt without a

booster.

The following pages give instructions on how to check properseat belt fit, what kind of boosterseat to use if one is needed, and
important precautions for children
who must sit in the front seat.
CONTINUED

Driver and Passenger Safety

Allowing a larger child to sit
improperly in the front seat can
result in injury or death if the
airbags inflate.
If a larger child must sit in front,
make sure the child moves the
seat as far back as possible
and wears the seat belt properly.ProCarManuals.comMain Menu Table of Contents s t
