Ford Motor Co. (Taurus 3.4L SHO)
1) Discharge A/C system, using approved refrigerant
recovery/recycling equipment. Remove A/C compressor. Drain and measure
oil from compressor.
2) Remove pulley assembly. Using Spanner Wrench (T81P-19623-
MH), remove shaft nut and lock washer. Using a steering wheel puller,
remove clutch plate, shaft key and shim. Remove snap ring and pulley
assembly, by hand. If necessary, use a 3-jaw puller to remove pulley
assembly. Remove clutch coil wire from retaining brace on compressor.
Remove snap ring and clutch coil. See Fig. 1.
Installation
1) Install clutch coil. Ensure hole on back of clutch coil is
aligned with pin on compressor head. Install snap ring with beveled
side facing outward. Install clutch coil wire into retaining brace.
2) Slip pulley assembly onto compressor shaft and install
snap ring with beveled side facing outward. Install shim and shaft
key. Align clutch plate with shaft key and install clutch plate. Use
Hub Driven Plate Replacer (T80L-19703-F), if necessary. Using spanner
wrench, install lock washer and shaft nut. Tighten shaft nut to 10-14
ft. lbs. (14-19 N.m).
3) Using a feeler gauge, measure air gap between clutch plate
and pulley assembly at 3 equally spaced locations. Rotate pulley 180
degrees and measure air gap at 3 locations again. Air gap should be 0.
016-0.027" (0.41-0.69 mm). If air gap is not within specification, add\
or remove shims to obtain correct air gap.
4) Add correct amount of refrigerant oil to compressor and
install compressor. See COMPRESSOR REFRIGERANT OIL CHECKING. Evacuate
and charge A/C system. Perform leak test.
SANDEN MSC90-C SCROLL
CLUTCH ASSEMBLY
Removal
1) Discharge A/C system, using approved refrigerant
recovery/recycling equipment. Remove compressor. Drain oil from
compressor, and measure amount drained.
2) Remove pulley assembly. Using Spanner (MB991367) and Pins\
(MB991386), remove shaft nut. Remove clutch plate, snap ring and rotor\
assembly. Remove snap ring and clutch coil. See Fig. 6.
Installation
1) Install clutch coil. Ensure projection on back of clutch
coil is aligned with pin hole in compressor body. Install snap ring so
that tapered surface is facing outward.
2) Install rotor assembly and snap ring. Align match mark of
clutch plate with match mark of compressor shaft spline and install
clutch plate. Using spanner and pins, install shaft nut.
3) Using a feeler gauge, check air gap between clutch plate
and rotor assembly at more than one place. Air gap should be 0.016-0.
024" (0.40-0.60 mm). If air gap is not within specification, add or
remove shims as necessary. Install pulley assembly.
4) Add same amount of refrigerant oil to compressor as was
drained from it. Install A/C compressor. Evacuate and charge A/C
system. Perform leak test.

Fig. 6: Compressor Components (Sanden MSC90-C Scroll)
Courtesy of chrysler corp.
SANDEN SD-7H15 7-CYLINDER
NOTE: On Cherokee, Dakota, Durango, Ram Pickup and Wrangler,
compressor clutch can be serviced in vehicle, without
discharging A/C system.
CLUTCH ASSEMBLY
Removal (Cherokee, Dakota, Durango, Ram Pickup & Wrangler)
1) Disconnect and isolate negative battery cable. Remove
serpentine drive belt. Disconnect clutch coil harness connector.
Without disconnecting refrigerant lines, remove A/C compressor from
mounting bracket. Support compressor in engine compartment.
2) Using spanner wrench, hold clutch plate and remove
compressor shaft nut. See Fig. 1. Using a steering wheel puller,
remove clutch plate, compressor shaft key and shims. Remove external
front housing snap ring.
3) Install jaws of Rotor Puller (C-6141-1) into pulley snap
ring groove. Install Shaft Protector (C-6141-2) over compressor shaft.\
Install puller flange plate on jaws. Install Puller Through-Bolts (C-
6461) through puller flange plate into jaws and hand tighten. Tighten
pulley center bolt clockwise and remove pulley from compressor.
4) Remove clutch coil wire harness retainer from compressor
housing. Remove clutch coil snap ring and clutch coil.

Installation (Cherokee & Wrangler)
1) Install clutch coil and clutch coil snap ring. Install
clutch coil wire harness to compressor housing. Align pulley and
bearing assembly on front compressor housing hub. Using Installer (C-
6871), press pulley and bearing assembly onto compressor housing hub.
Thread installer on compressor shaft and tighten nut until pulley
assembly is seated.
2) Install external front snap ring with beveled side facing
outward. Ensure snap ring is properly seated. Install compressor shaft
key and original shims. Using a plastic mallet and Driver (C-6463),
install clutch plate on compressor shaft. Tighten compressor shaft nut
to 10 ft. lbs. (14 N.m).
3) Using feeler gauge, measure air gap between clutch plate
and pulley assembly in several areas. Air gap should be 0.016-0.031"
(0.41-0.79 mm). If air gap is not within specification, adjust shim
thickness as necessary. If air gap is not consistent around clutch
plate, lightly pry up or tap down on clutch plate to make corrections.
To complete installation, reverse removal procedure.
Installation (Dakota, Durango & Ram Pickup)
1) Install clutch coil and clutch coil snap ring. Install
clutch coil wire harness to compressor housing. Align pulley and
bearing assembly on front compressor housing hub.
2) Install Handle (6464) and Driver (6143) into pulley
assembly bearing cavity. Ensure outer edge of driver rests firmly on
inner race of bearing. Using hammer, install pulley and bearing
assembly. While tapping on handle, guide pulley and bearing assembly
to prevent binding. Ensure pulley assembly bottoms against compressor
housing. Install external snap ring.
3) Install original shim(s) and compressor shaft key. Use a
hammer and Shaft Protector (6141-2) to install clutch plate on
compressor shaft. Ensure clutch plate bottoms out on clutch shims.
Replace compressor shaft nut and tighten compressor shaft nut to 10
ft. lbs. (14 N.m).
4) Measure air gap between clutch plate and pulley assembly
in several areas. Air gap should be 0.016-0.031" (0.41-0.79 mm). If
air gap is not within specification, adjust shim thickness as
necessary. If air gap is not consistent around clutch plate, lightly
pry up or tap down on clutch plate to make corrections. To complete
installation, reverse removal procedure. Ensure A/C system operates
properly.
5) After completing compressor clutch installation, start
engine. Set A/C-heater control to recirculated air mode and high
blower motor speed. Set engine speed to 1500-2000 RPM. Cycle
compressor on for 5 seconds and off for 5 seconds, about 20 times to
break-in clutch.
Removal (Ford "F" Series Super Duty Pickup)
1) Disconnect and isolate negative battery cable. Discharge
A/C system, using approved refrigerant recovery/recycling equipment.
Disconnect clutch coil harness connector and remove compressor. Drain
oil from compressor, and measure amount drained.
2) Using Spanner Wrench (T70P-4067-A), hold clutch plate and\
remove compressor shaft nut. See Fig. 1. If necessary, use a steering
wheel puller to remove clutch plate and shim(s).
3) Using a flat-blade screwdriver, remove pulley assembly
bearing dust cover. Remove compressor shaft key and internal bearing
snap ring. Remove external front housing snap ring.
4) Install jaws of rotor puller into pulley assembly internal
bearing snap ring groove. Install shaft protector over compressor
shaft. Install puller flange plate on jaws. Install 2 puller bolts
through puller flange plate into jaws and hand tighten. Tighten pulley
center bolt clockwise and remove pulley assembly from compressor.
