DRIV E A XLE - 8 .2 5" & 9 .2 5" R IN G G EA R

1999 D odge P ic ku p R 1500
1998-99 DRIVE AXLES
CHRY - 8 1/4" & 9 1/4" Ring Gears
Dakota, Ram Pickup, Ram Van/Wagon
NOTE: For models using full-floating axles in which vehicle weight
is supported by axle housing tubes, see RBI FULL-FLOATING
AXLES article.
DESCRIPTION & OPERATION
Drive axle contains a solid semi-floating axle shaft splined
into the side gear. On semi-floating axle shafts, vehicle weight is
supported on axle shaft and bearing. Drive shaft rotates the pinion
which drives the ring gear. Power is transferred from ring gear
through side gears to the axle shafts (hypoid gear type).
On rear axles used in vehicles with Rear Wheel Anti-Lock
(RWAL) brakes, a brake sensor is mounted on top of axle housing, and
an exciter ring is mounted on the differential carrier. See Fig. 1.
Fig. 1: Exploded View Of Drive Axle
Courtesy of Chrysler Corp.
AXLE RATIO & IDENTIFICATION

from axle housing clips. Disconnect electrical connector from brake
sensor mounted on top of axle housing (if equipped).
4) Disconnect parking brake cables. Scribe mark on drive
shaft and pinion flange for reassembly reference. Remove bolts and "U"
joint straps at pinion flange. Support drive shaft aside to prevent
damage to rear "U" joint.
5) Remove shock absorber from axle housing. Support axle
housing with floor jack. Remove "U" bolt nuts. Remove "U" bolts and
spring brackets. Lower axle housing from vehicle.
Installation
1) To install, reverse removal procedure. Ensure rear spring
center bolts align with holes in spring pads on axle housing.
2) Ensure reference mark on drive shaft and pinion flange are
aligned. Tighten bolt/nuts to proper specification. See TORQUE
SPECIFICATIONS. Bleed and adjust brakes.
DIFFERENTIAL ASSEMBLY
NOTE: Differential assembly consists of differential carrier and
components mounted in axle housing. For differential assembly
servicing, see DIFFERENTIAL ASSEMBLY under OVERHAUL.
OVERHAUL
DIFFERENTIAL ASSEMBLY
NOTE: Check pinion bearing preload, side play and then ring gear
runout, in this order, before disassembling differential
assembly.
Disassembly
1) Remove axle shafts. See AXLE SHAFT & BEARING under REMOVAL
& INSTALLATION. Using INCH-lb. torque wrench, measure amount of force
required to rotate pinion. This is pinion bearing preload. Record
pinion bearing preload for reassembly reference if front pinion
bearing will be replaced.
2) To check side play, place pry bar between differential
carrier and axle housing. Pry differential carrier to one side and
note if any side play exists. No side play should exist. If side play
exists, remove bolt and adjuster lock. See Fig. 1. Using Adjuster
Rotator (C-4164), tighten adjuster to eliminate side play.
3) To check ring gear runout, install dial indicator on axle
housing at 90 degree angle to ring gear, with stem resting against
flat side of ring gear, opposite gear teeth. Rotate ring gear, and
note ring gear runout.
NOTE: Ring gear must be removed from differential carrier before
checking differential carrier flange runout. Differential
carrier and bearings must be reinstalled in axle housing to
check differential carrier flange runout.
4) Mark ring gear and differential carrier at point of
maximum ring gear runout for reassembly reference. If ring gear runout
does not exceed .005" (.13 mm), differential carrier and ring gear are\
okay. If ring gear runout exceeds .005" (.13 mm), check differential
carrier flange runout once ring gear is removed.
5) Remove brake sensor from top of axle housing (if
equipped). Mark bearing caps and axle housing for reassembly
reference.
CAUTION: Mark all bearing races and adjusters in relation to their

side gear clearance does not exceed .005" (.13 mm), determine if axle
shaft is contacting pinion shaft with feeler gauges installed. If axle
shaft is not contacting pinion shaft, side gear clearance is correct.
5) If side gear clearance exceeds .005" (.13 mm) and axle
shaft is not contacting pinion, record side gear clearance. Remove
pinion shaft, pinion gears, thrust washers, side gear and side gear
thrust washer. Measure thickness of side gear thrust washer.
6) Add thickness of side gear thrust washer to side gear
clearance measurement. This is required thickness of replacement side
gear thrust washer.
7) For example, if side gear clearance was .007" (.18 mm) an\
d
side gear thrust washer thickness is .033" (.84 mm), replacement side
gear thrust washer thickness is .040" (1.02 mm). Install replacement
side gear thrust washer and recheck side gear clearance.
8) If no side gear clearance exists, remove clip and axle
shaft. Remove pinion shaft, pinion gears, thrust washers, side gear
and side gear thrust washer. Measure and record thickness of side gear
thrust washer.
9) Reassemble side gear and components in differential
carrier. Install axle shaft in side gear. DO NOT install clip. Recheck
side gear clearance. If side gear clearance is now less than .012" (.
30 mm), add this measurement to thickness of side gear thrust washer
thickness. This is thickness of replacement side gear thrust washer.
10) If side gear clearance in step 9) is .012" (.30 mm) or
more, both side gears must be replaced and side gear clearance
rechecked. If side gear clearance is still .012" (.30 mm) or more with\
replacement side gears, replace differential carrier.
AXLE ASSEMBLY SPECIFICATIONS
AXLE ASSEMBLY SPECIFICATIONS








\









\









\









\









\









\









\







Application In. (mm)\
Maximum Differential Carrier Flange Runout .............. .003 (.08)\
Maximum Ring Gear Runout ................................ .005 (.13)\
Ring Gear Backlash ............................. .005-.008 (.13-.20)\
Ring Gear Backlash Variation ( 1) ........................ .003 (.08)
INCH Lbs. (N.m.)
Pinion Bearing Preload
New Bearings ......................................... 10-20 (1-2)\
Used Rear & New Front Bearing ............................. ( 2) 10
( 1) - This is amount of variation in ring gear backlash from reading
obtained at minimum point on ring gear. If ring gear backlash is
.005" (.13 mm) at minimum point, ring gear backlash should not
exceed .008" (.20 mm) anywhere on ring gear.
( 2) - Maximum increase over original pinion bearing preload before
disassembly.









\









\









\









\









\









\









\







TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS








\









\









\









\









\









\









\







Application Ft. Lbs. (N.m)\
Axle Housing Cover Bolt .................................... 35 (47)\
Bearing Cap Bolt ......................................... 100 (136)\
Brake Sensor ............................................... 18 (24)\
