SEATS8G–1
BODY AND ACCESSORIES
SEATS
CONTENTS
Service Precaution 8G–1. . . . . . . . . . . . . . . . . . . . . .
Front Seat Assembly 8G–2. . . . . . . . . . . . . . . . . . . .
Front Seat Assembly and Associated
Parts 8G–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Removal 8G–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 8G–3. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disassembled View (Long Wheel Base) 8G–3. .
Disassembly 8G–4. . . . . . . . . . . . . . . . . . . . . . . . . .
Reassembly 8G–5. . . . . . . . . . . . . . . . . . . . . . . . . .
Disassembled View (Short Wheel Base) 8G–6. .
Disassembly 8G–6. . . . . . . . . . . . . . . . . . . . . . . . . .
Reassembly 8G–8. . . . . . . . . . . . . . . . . . . . . . . . . .
Power Seat Assembly 8G–9. . . . . . . . . . . . . . . . . . .
General Description 8G–9. . . . . . . . . . . . . . . . . . . . . .
Disassembled View 8G–9. . . . . . . . . . . . . . . . . . . .
Disassembly 8G–10. . . . . . . . . . . . . . . . . . . . . . . . . .
Reassembly 8G–12. . . . . . . . . . . . . . . . . . . . . . . . . .
Power Seat Switch 8G–12. . . . . . . . . . . . . . . . . . . . . .
Removal 8G–12. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 8G–12. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Tilt Motor / Rear Tilt Motor /
Slide Motor / Recliner Motor 8G–13. . . . . . . . . . . . . .
Parts Location 8G–13. . . . . . . . . . . . . . . . . . . . . . . .
Removal and Installation 8G–13. . . . . . . . . . . . . . .
Seat Heater System 8G–14. . . . . . . . . . . . . . . . . . . . .
General Description 8G–14. . . . . . . . . . . . . . . . . . . . . .
Seat Heater Switch Removal and
Installation 8G–14. . . . . . . . . . . . . . . . . . . . . . . . . . . Heat Unit Parts Location 8G–14. . . . . . . . . . . . . . . .
Heat Unit Removal and Installation 8G–14. . . . . .
Rear Seat Assembly 8G–15. . . . . . . . . . . . . . . . . . . . .
Rear Seat Assembly and Associated Parts 8G–15
Removal 8G–15. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 8G–15. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disassembled View (Split Type) 8G–16. . . . . . . . .
Disassembly (Split Type) 8G–17. . . . . . . . . . . . . . .
Reassembly (Split Type) 8G–18. . . . . . . . . . . . . . . .
Disassembled View (Short Wheel Base) 8G–19. .
Disassembly 8G–19. . . . . . . . . . . . . . . . . . . . . . . . . .
Reassembly 8G–20. . . . . . . . . . . . . . . . . . . . . . . . . .
Disassembled View (Bench Type) 8G–21. . . . . . .
Disassembly (Bench Type) 8G–22. . . . . . . . . . . . .
Reassembly (Bench Type) 8G–23. . . . . . . . . . . . . .
Third Seat Assembly 8G–23. . . . . . . . . . . . . . . . . . . . .
Parts Location 8G–23. . . . . . . . . . . . . . . . . . . . . . . .
Removal 8G–23. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 8G–24. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disassembled View 8G–24. . . . . . . . . . . . . . . . . . . .
Disassembly 8G–25. . . . . . . . . . . . . . . . . . . . . . . . . .
Reassembly 8G–25. . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Seat Foot Rest 8G–25. . . . . . . . . . . . . . . . . . . . .
Rear Seat Foot Rest and Associated Parts 8G–25
Removal 8G–26. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 8G–26
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Main Data and Specifications 8G–26. . . . . . . . . . . . .
Service Precaution
WARNING: IF SO EQUIPPED WITH A
SUPPLEMENTAL RESTRAINT SYSTEM (SRS),
REFER TO THE SRS COMPONENT AND WIRING
LOCATION VIEW IN ORDER TO DETERMINE
WHETHER YOU ARE PERFORMING SERVICE ON OR
NEAR THE SRS COMPONENTS OR THE SRS
WIRING. WHEN YOU ARE PERFORMING SERVICE
ON OR NEAR THE SRS COMPONENTS OR THE SRS
WIRING, REFER TO THE SRS SERVICE
INFORMATION. FAILURE TO FOLLOW WARNINGS
COULD RESULT IN POSSIBLE AIR BAG
DEPLOYMENT, PERSONAL INJURY, OR
OTHERWISE UNNEEDED SRS SYSTEM REPAIRS.CAUTION: Always use the correct fastener in the
proper location. When you replace a fastener, use
ONLY the exact part number for that application.
ISUZU will call out those fasteners that require a
replacement after removal. ISUZU will also call out
the fasteners that require thread lockers or thread
sealant. UNLESS OTHERWISE SPECIFIED, do not
use supplemental coatings (Paints, greases, or other
corrosion inhibitors) on threaded fasteners or
fastener joint interfaces. Generally, such coatings
adversely affect the fastener torque and the joint
clamping force, and may damage the fastener. When
you install fasteners, use the correct tightening
sequence and specifications. Following these
instructions can help you avoid damage to parts and
systems.

SEATS8G–3
Installation
To install, follow the removal steps in the reverse order,
noting the following points:1. Tighten the front seat assembly fixing bolts to the
specified torque.
Torque: 40 Nꞏm (4.1 kgꞏm/30 lb ft)
2. Install the longest bolt to the rear inner side fixing
location, if this model is equipped with power seats.
Disassembled View (Long Wheel Base)
750RX017
Legend
(1) Head Rest
(2) Seat Back Assembly
(3) Back Board Assembly
(4) Guide Holder
(5) Trim Cover
(6) Pad & Frame Assembly
(7) Seat Heater Assembly
(8) Reclining Device
(9) Slide Cover
(10) Reclining Knob
(11) Dial (W/Height Adjuster)
(12) Frame Assembly(13) Seat Heater Assembly
(14) Pad Assembly
(15) Trim Cover
(16) Spacer (W/O Height Adjuster)
(17) Release Wire
(18) Seat Adjuster/Seat Adjuster (W/Pretensioner)
(19) Seat Belt Buckle Assembly
(20) Height Adjuster
(21) Seat Cushion Assembly
(22) Hinge Cover
(23) Pad & Frame Assembly
(24) Trim Cover
(25) Armrest Assembly

8G–6SEATS
Disassembled View (Short Wheel Base)
750RX018
Legend
(1) Head Rest
(2) Seat Back Assembly
(3) Back Board Assembly
(4) Pad & Frame Assembly
(5) Trim Cover
(6) Guide Holder
(7) Reclining Device
(8) Slide Cover
(9) Reclining Knob
(10) Frame Assembly(11) Pad Assembly
(12) Trim Cover
(13) Walk–in Cover
(14) Walk–in Assembly
(15) Seat Adjuster/Seat Adjuster (W/Pretensioner)
(16) Release Wire
(17) Seat Belt Buckle Assembly
(18) Spacer
(19) Seat Cushion Assembly
(20) Hinge Cover
Disassembly
1. Remove the head rest.
2. Remove the reclining knob.
3. Remove the side cover.
4. Remove the hinge cover.5. Remove the back board assembly.Pull out the back board while prying the clip of the
back board free from the seat back assembly.

SEATS8G–19
Disassembled View (Short Wheel Base)
755RW036
Legend
(1) Back Board
(2) Release Knob
(3) Release Rod
(4) Device Cover
(5) Reclining Device
(6) Linkage Bush
(7) Pillow Assembly
(8) Pad & Frame Assembly
(9) Armrest Board
(10) Clip
(11) Band Hook Cover
(12) Trim Cover(13) Armrest Set Bracket
(14) Bush
(15) Armrest Assembly
(16) Trim Cover
(17) Mounting Bracket
(18) Frame Assembly
(19) Stopper Rubber
(20) Pad Assembly
(21) Seat Lock Cover
(22) Rear seat Belt Bukle and Lock Assembly
(23) Seat Cushion Assembly
(24) Free Hinge Cover
(25) Seat Back Assembly
Disassembly
1. Remove the back board.
Remove the clips and the back board.2. Remove the device cover.
3. Remove the release knob.Turn the knob counterclockwise to remove it.

EXTERIOR/INTERIOR TRIM8J–1
BODY AND ACCESSORIES
EXTERIOR / INTERIOR TRIM
CONTENTS
Service Precaution 8J–2. . . . . . . . . . . . . . . . . . . . . .
Dash Side Trim Panel 8J–3. . . . . . . . . . . . . . . . . . . .
Removal 8J–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 8J–3. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Assist Grip 8J–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts Location 8J–3. . . . . . . . . . . . . . . . . . . . . . . .
Removal and Installation 8J–3. . . . . . . . . . . . . . .
Consoles 8J–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Consoles and Associated Parts 8J–4. . . . . . . . .
Removal 8J–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 8J–5. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Door Trim Panel 8J–6. . . . . . . . . . . . . . . . . . .
Front Door Trim Panel and Associated
Parts 8J–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Removal 8J–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 8J–9. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Door Trim Panel 8J–10. . . . . . . . . . . . . . . . . . . .
Rear Door Trim Panel and Associated
Parts 8J–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Removal 8J–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 8J–11. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Mirror 8J–13. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Mirror and Associated Parts 8J–13. . . . . . . .
Removal 8J–13. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 8J–13. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Luggage Side and Quarter Upper Trim Cover
(Long Wheel Base) 8J–14. . . . . . . . . . . . . . . . . . . . .
Luggage Side, Quarter Upper Trim Cover
and Associated Parts 8J–14. . . . . . . . . . . . . . . . . .
Removal 8J–14. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 8J–16. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Luggage Side and Quarter Upper Trim Cover
(Short Wheel Base) 8J–17. . . . . . . . . . . . . . . . . . . . .
Luggage Side, Quarter Upper Trim Cover
and Associated
Parts 8J–17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Removal 8J–17. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 8J–19. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center Pillar and Roof Side Trim Cover
(Long Wheel Base) 8J–20. . . . . . . . . . . . . . . . . . . . .
Center Pillar, Roof Side Trim Cover and
Associated Parts 8J–20. . . . . . . . . . . . . . . . . . . . . .
Removal 8J–20. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 8J–21. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Roof Side Trim Cover (Short Wheel Base) 8J–22. . Roof Side Trim Cover and Associated
Parts 8J–22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Removal 8J–22. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 8J–22. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Pillar Trim Cover 8J–23. . . . . . . . . . . . . . . . . . .
Front Pillar Trim Cover and Associated
Parts 8J–23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Removal 8J–23
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 8J–23. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center Pillar Assist Grip 8J–24. . . . . . . . . . . . . . . . . .
Parts Location 8J–24. . . . . . . . . . . . . . . . . . . . . . . .
Removal and Installation 8J–24. . . . . . . . . . . . . . .
Assist Grip 8J–24. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts Location 8J–24. . . . . . . . . . . . . . . . . . . . . . . .
Removal and Installation 8J–24. . . . . . . . . . . . . . .
Fuel Filler Lid Opener Cable 8J–25. . . . . . . . . . . . . .
Fuel Filler Lid Opener Cable
and Associated Parts 8J–25. . . . . . . . . . . . . . . . . .
Removal 8J–25. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 8J–26. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel Filler Door 8J–26. . . . . . . . . . . . . . . . . . . . . . . . .
Parts Location 8J–26. . . . . . . . . . . . . . . . . . . . . . . .
Removal 8J–26. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 8J–26. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rocker Protector (Without Wheel
Opening Extension) 8J–27. . . . . . . . . . . . . . . . . . . . .
Rocker Protector (Without Wheel
Opening Extension) and Associated Parts 8J–27
Removal 8J–27. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 8J–27. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel Opening Extension and Rocker
Protector Assembly 8J–28. . . . . . . . . . . . . . . . . . . . .
Wheel Opening Extension, Rocker Protector
Assembly and Associated Parts 8J–28. . . . . . . . .
Removal 8J–28. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 8J–29. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mud Flaps (With Wheel Opening Extension) 8J–31
Mud Flaps (With Wheel Opening Extension)
and Associated Parts 8J–31. . . . . . . . . . . . . . . . . .
Removal 8J–31. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 8J–31. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ventilation Assembly 8J–32. . . . . . . . . . . . . . . . . . . . .
Ventilation Assembly and Associated Parts 8J–32
Removal 8J–32. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 8J–32. . . . . . . . . . . . . . . . . . . . . . . . . . . .

8J–14EXTERIOR/INTERIOR TRIM
Luggage Side and Quarter Upper Trim Cover (Long Wheel Base)
Luggage Side, Quarter Upper Trim Cover and Associated Parts
760RW017
Legend
(1) Assist Grip
(2) Rear Seat Belt Anchor Bolt Cover and Anchor
Bolt
(3) Quarter Upper Trim Cover
(4) Anchor Bolt
(5) Luggage Side Trim Cover
(6) Luggage Side Lower Cover
(7) Third Seat Assembly and seat Bracket(8) Third Seat Belt Anchor Bolt Cover and Anchor
Bolt
(9) Rear End Floor Trim Cover
(10) Luggage Side Cap
(11) Speaker Grille
(12) Rear Speaker
(13) Luggage Room Light
(14) Rear Roof Trim Cover
Removal
1. Disconnect the battery ground cable.
2. Remove the third seat assembly and seat bracket.
3. Remove the rear end floor trim cover.
4. Remove the luggage side cap.

EXTERIOR/INTERIOR TRIM8J–17
Luggage Side and Quarter Upper Trim Cover (Short Wheel Base)
Luggage Side, Quarter Upper Trim Cover and Associated Parts
760RW021
Legend
(1) Rear Assist Grip
(2) Quater Upper Trim Cover
(3) Seat belt adjust Shoulder Anchor Plate
(4) Front Seat Belt Anchor Bolt Cover and Anchor
Bolt
(5) Luggage Side Trim Cover
(6) Rear Seat Belt Anchor Bolt Cover and Anchor
Bolt(7) Rear End Floor Trim Cover
(8) Luggage Side Cap
(9) Speaker Grill
(10) Rear Speaker
(11) Luggage Room Light
(12) Rear Roof Trim Cover
Removal
1. Disconnect the battery ground cable.2. Remove the rear end floor trim cover.
3. Remove the luggage side cap.

8J–20EXTERIOR/INTERIOR TRIM
Center Pillar and Roof Side Trim Cover (Long Wheel Base)
Center Pillar, Roof Side Trim Cover and Associated Parts
643RW007
Legend
(1) Roof Side Trim Cover
(2) Front Pillar Trim Cover
(3) Assist Grip (Passenger Seat Side)
(4) Adjust Shoulder Anchor Assembly/Seat Belt
Anchor Plate
(5) Center Pillar Upper Trim Plate(6) Door Sill Plate (Front and Rear)
(7) Center Pillar Lower Trim Cover
(8) Front Seat Anchor Bolt Cover and Anchor Bolt
(9) Center Pillar Assist Grip
(10) Assist Grip
(11) Rear Quarter Upper Trim Cover
Removal
1. Disconnect the battery ground cable.
2. Remove the door sill plate (front and rear).
3. Remove the center pillar lower trim cover (2).
Turn up the finisher (1) and pry the trim cover
retainers free from the body panel, then slide the
trim cover downward.
643RS003
