1) Front HO2S is mounted in exhaust pipe below exhaust
header. Rear HO2S is mounted behind catalytic converter. HO2S is
equipped with a permanent pigtail which must be protected from damage
when HO2S is removed. Ensure HO2S is free of contaminants. Avoid using
cleaning solvents of any type.
2) HO2S may be difficult to remove when engine temperature is
less than 120
F (48 C). If using original sensor, always use anti-
seize compound on threads before installation. New sensor threads are
precoated with anti-seize. Tighten HO2S to specification. See
TORQUE SPECIFICATIONS .
THROTTLE BODY
Removal
1) Relieve fuel pressure. See FUEL SYSTEM PRESSURE RELEASE.
Drain enough coolant to ensure coolant level is below throttle body.
Disconnect air intake hose.
2) Remove accelerator, cruise control and A/T throttle valve
cables (if equipped). Disconnect fuel vapor hose, electrical harness
connector, vacuum hose and coolant hoses. Remove throttle body
retaining bolts.
Disassembly
Remove throttle position sensor. Remove idle air control
motor. Remove throttle bracket and connector bracket (if equipped).
Remove idle position switch and adjusting nut (if equipped).
CAUTION: DO NOT remove throttle valve. DO NOT use cleaning solvents
on throttle position sensor, idle air control motor or idle
position switch.
Cleaning
1) Clean all parts except throttle position sensor, idle air
control motor and idle position switch in solvent.
WARNING: Safety glasses MUST be worn whenever compressed air is used
for parts cleaning.
2) Check vacuum port and passage for clogging. Clean vacuum,
vapor and fuel passages using compressed air.
Reassembly
To reassemble, reverse disassembly procedure.
Installation
To install, reverse removal procedure.
THROTTLE POSITION (TP) SENSOR
Removal & Installation
Throttle Position (TP) sensor is located on throttle body.
Disconnect TP sensor electrical connector. Remove TP sensor screws and
TP sensor. To install, reverse removal procedure. Tighten TP sensor
screws to specification. See TORQUE SPECIFICATIONS. For TP sensor
adjustment procedure, see D - ADJUSTMENTS article.
TURBOCHARGERS
Removal (Eclipse)
1) Disconnect negative battery cable. Drain engine coolant
and oil. On models equipped with A/C, remove condenser fan motor
assembly. Remove front heated oxygen sensor. Remove oil dipstick guide
and "O" ring.
Page 999 of 1501
2) Disconnect air intake hose and vacuum hoses. Remove air
hose and air outlet housing. Remove heat protectors. Disconnect
exhaust pipe. Remove power steering oil pump and bracket. Remove
engine hanger bracket. Disconnect oil inlet pipe.
3) Disconnect engine coolant hoses and tubes from
turbocharger. Remove exhaust manifold nuts and bolts. Remove exhaust
manifold and gaskets. Disconnect oil pressure and return pipes. Remove
turbocharger and exhaust manifold assembly. Separate turbocharger from
exhaust manifold.
Removal (3000GT - Front)
1) Disconnect negative battery cable. Drain engine oil and
coolant. Remove radiator. Disconnect exhaust pipe. Remove air intake
hose, air hoses and air pipe. Remove generator and belt. Remove oil
dipstick guide.
2) Remove heat protector. Disconnect front heated oxygen
sensor connector. Remove oil return pipe. Remove turbocharger support
bracket, and remove turbocharger from exhaust manifold.
Removal (3000GT - Rear)
1) Disconnect battery cables, and remove battery. Drain
engine oil and cooling system. Remove accelerator cable. Remove air
hose, air pipe and heat protectors. Disconnect clutch booster vacuum
hose. Remove air intake hoses and EGR pipe. Disconnect heated oxygen
sensor connectors.
2) Remove oil pipe and EGR valve. Disconnect exhaust fitting,
and remove rear heat protector. Remove oil return pipe. Remove
turbocharger assembly.
Inspection (All Models)
Check turbine and compressor wheels for cracking and other
damage. Ensure turbine and compressor wheels turn smoothly. Check for
oil leakage from turbocharger assembly. Check for proper wastegate
valve operation. See I - SYSTEM/COMPONENT TESTS article.
CAUTION: Apply light coat of oil to inner surface of flared area on
water pipe (flare nut fitting) before connecting to engine.
Installation (All Models)
1) To install, reverse removal procedure. Before oil pipe
flare nut (above turbocharger) is installed, pour clean engine oil
into turbocharger oil pipe installation hole. Ensure oil and air hoses
are properly installed and securely clamped.
2) Use NEW gaskets. Adjust accelerator cable (if necessary).\
Refill engine oil and coolant. Check for oil and coolant leaks.
Tighten all bolts to specification. See TORQUE SPECIFICATIONS.
TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS TABLE\
\
\
\
\
\
Applications Ft. Lbs. (N.m)
Coolant Pipe-To-Turbocharger Banjo Bolt .......... 31 (42)
EGR Valve ........................................ 16 (22)
Engine Coolant Temperature Sensor ................ 22 (30)
Exhaust Manifold-To-Engine Nuts ............ 18-21 (24-29)
Exhaust Manifold-To-Turbocharger Bolts ..... 40-47 (54-64)
Exhaust Pipe Bolts ......................... 21-36 (29-49)
Fuel Filter Line ................................. 27 (36)
Fuel Tank Drain Plug ....................... 11-18 (15-24)
Fuel Tank Nuts ............................. 15-21 (20-29)
Page 1000 of 1501
Heated Oxygen Sensor
Front .................................... 29-33 (39-44)
Rear ..................................... 15-29 (20-39)
Heat Protector Bolts .................. 8.8-11 (12.0-15.0)
Intake Manifold Plenum Bolt/Nut .................. 13 (18)
Knock Sensor ............................... 15-18 (20-24)
Oil Return Pipe-To-Engine .................. 10-14 (14-19)
Oil Supply Pipe-To-Engine Nut .................... 14 (19)
Oil Supply Pipe-To-Turbocharger Nut .............. 14 (19)
Plenum-To-Intake Manifold Bolts ............ 11-15 (15-20)
Throttle Body .................................... 14 (19)
Turbocharger-To-Exhaust Manifold Bolt/Nut
Step 1 ......................................... 21 (29)
Step 2 ........................ Additional 60-70 Degrees
Water Pipe-To-Turbocharger
Eclipse .................................. 25-36 (34-49)
3000GT ......................................... 22 (30)
INCH Lbs. (N.m)
Camshaft Position Sensor .......................... 80 (9)
Crankshaft Position Sensor ........................ 80 (9)
Distributor Hold-Down Bolt ...................... 106 (12)
Engine Cover ............................. 22-40 (2.5-4.5)
Fuel Pressure Regulator ........................... 80 (9)
Fuel Pump Nuts .................................. 22 (2.5)
Fuel Rail Bolts ....................... 80-106 (9.0-12.0)
TP Sensor Screws ......................... 13-22 (1.5-2.5)
Wastegate Actuator Bolts ............... 80-106 (9.0-12.0)
\
\
\
\
\
\
Page 1006 of 1501
PASSIVE RESTRAINT SYSTEM INSPECTION
1998 Mitsubishi Montero
GENERAL INFORMATION
Passive Restraint System Inspection - Asian
* PLEASE READ THIS FIRST *
Follow all manufacturers servicing precautions when working
with air bag systems. See SERVICE PRECAUTIONS in the appropriate AIR
BAG RESTRAINT SYSTEM article in the ACCESSORIES/SAFETY EQUIPMENT
section.
INTRODUCTION
When a vehicle equipped with passive restraint system has
been involved in a collision, certain systems and components must be
inspected and or replaced regardless of whether or not the air bag has
deployed. Follow the manufacturer's guidelines provided in this
article.
ACURA (1988-98)
AIR BAG APPLICATION
AIR BAG APPLICATION TABLE - ACURA (1988-98) \
\
\
\
\
\
Model Year (1) Location
Integra .............. 1994-98 ..................... D/P
Legend ............... 1991-95 ..................... D/P
1988-90 ...................... DS
NSX .................. 1993-98 ..................... D/P
1991-92 ...................... DS
Vigor ................ 1993-94 ..................... D/P
1992 ........................ DS
2.2CL ................. 1997 ....................... D/P
2.3CL ................. 1998 ....................... D/P
2.5TL ................ 1995-98 ..................... D/P
3.0CL ................ 1997-98 ..................... D/P
3.2TL ................ 1996-98 ..................... D/P
3.5RL ................ 1996-98 ..................... D/P
SLX .................. 1996-98 ..................... D/P
( 1) - Location Definitions: D/P = Driver's & Passenger's
Side, DS = Driver's Side Only, SI = Side Impact.
\
\
\
\
\
\
INSPECTION PROCEDURES
INSPECTION PROCEDURES TABLE - ACURA (1988-98 EXCEPT SLX) \
\
\
\
\
\
\
Action Component or System
\
\
\b \
\
\
\
\
Replace After
* Air Bag Module(s)
Deployment
* Seat Belt Tensioners (If Equipped)
* SRS Control Unit
\
\
\b \
\
\
\
\
Inspect & If
* Cable Reel
Damaged, Replace
* Dash or Impact Sensors (If Equipped)
Component
* Seat Belts
Page 1008 of 1501
![MITSUBISHI MONTERO 1998 Service Manual INSPECTION PROCEDURES TABLE - HONDA (1991-98 EXCEPT PASSPORT) \
\
\
\
\
\
\](/manual-img/19/57333/w960_57333-1007.png "MITSUBISHI MONTERO 1998 Service Manual INSPECTION PROCEDURES TABLE - HONDA (1991-98 EXCEPT PASSPORT) \
\
\
\
\
\
\")
INSPECTION PROCEDURES TABLE - HONDA (1991-98 EXCEPT PASSPORT) \
\
\
\
\
\
\
Action Component or System
\
\
\b \
\
\
\
\
Replace After
* Air Bag Module(s)
Deployment
* Seat Belt Tensioners (If Equipped)
* SRS Control Unit
\
\
\b \
\
\
\
\
Inspect & If
* Cable Reel
Damaged, Replace
* Dash Sensors (1991-94)
Component
* Seat Belts
(Even If Air
* SRS Control Unit
Bag Did Not
* Wiring Harness
Deploy)
\
\
\b \
\
\
\
\
Comments
* If any components are damaged or bent, they
must be replaced.
* DO NOT attempt SRS wiring repairs. If SRS
wiring or harness connectors are faulty,
replace faulty wiring harness.
* After vehicle is repaired, ensure AIR BAG
warning light is functioning properly.
\
\
\
\
\
\
\
\f
INSPECTION PROCEDURES TABLE - HONDA (1995 1/2-98 PASSPORT) \
\
\
\
\
\
\
Action Component or System
\
\
\b \
\
\
\
\
Replace After
* Air Bag Module(s)
Deployment
* Sensing & Diagnostic Module (SDM)
\
\
\b \
\
\
\
\
Inspect & If
* Instrument Panel Braces
Damaged, Replace
* Instrument Panel Steering Column
Component Reinforcement Plate
(Even If Air
* Seat Belts & Mounting Points
Bag Did Not
* Knee Bolsters & Mounting Points
Deploy)
* Steering Column
* SRS Coil Assembly
* Wiring Harnesses
\
\
\b \
\
\
\
\
Comments
* If any components are damaged or bent, they
must be replaced.
* DO NOT attempt wiring harness repairs.
Replace harness.
\
\
\
\
\
\
\
\f
HYUNDAI (1994-98)
AIR BAG APPLICATION
AIR BAG APPLICATION TABLE - HYUNDAI (1994-98) \
\
\
\
\
\
Model Year (1) Location
Accent ............... 1995-98 ..................... D/P
Elantra .............. 1996-98 ..................... D/P
1994-95 ...................... DS
Sonata ............... 1995-98 ..................... D/P
Tiburon .............. 1997-98 ..................... D/P
( 1) - Location Definitions: D/P = Driver's & Passenger's
Side, DS = Driver's Side Only, SI = Side Impact.
Page 1009 of 1501
![MITSUBISHI MONTERO 1998 Service Manual \
\
\
\
\
\
INSPECTION PROCEDURES
INSPECTION PROCEDURES TABLE - HYUNDAI](/manual-img/19/57333/w960_57333-1008.png "MITSUBISHI MONTERO 1998 Service Manual \
\
\
\
\
\
INSPECTION PROCEDURES
INSPECTION PROCEDURES TABLE - HYUNDAI")
\
\
\
\
\
\
INSPECTION PROCEDURES
INSPECTION PROCEDURES TABLE - HYUNDAI (1994-98) \
\
\
\
\
\
\
Action Component or System
\
\
\b \
\
\
\
\
Replace After
* Air Bag Module(s)
Deployment
* Control Module
* Steering Column Clockspring
\
\
\b \
\
\
\
\
Inspect & If
* Any Seat Belt In Use At Time Of Collision
Damaged, Replace
* Steering Column
Component
* Steering Wheel
(Even If Air
* Wiring Harness
Bag Did Not
Deploy)
\
\
\b \
\
\
\
\
Comments
* If any components are damaged or bent, they
must be replaced.
* DO NOT attempt SRS wiring repairs. If SRS
wiring or harness connectors are faulty,
replace faulty wiring harness.
\
\
\
\
\
\
\
\f
INFINITI (1990-98)
AIR BAG APPLICATION
AIR BAG APPLICATION TABLE - INFINITI (1990-98) \
\
\
\
\
\
\
Model Year (1) Location Inspection Table
G20 ......... 1993-96 ........... D/P ............... INFINITI-2
I30 ........... 1998 .......... D/P, SI ............. INFINITI-1
1997 ............ D/P ............... INFINITI-1
1996 ............ D/P ............... INFINITI-2
J30 ........... 1997 ............ D/P ............... INFINITI-1
1994-96 ........... D/P ............... INFINITI-2
1993 ............ D/P ............... INFINITI-3
M30 ......... 1990-92 ............ DS ............... INFINITI-3
Q45 ........... 1998 .......... D/P, SI ............. INFINITI-1
1997 ............ D/P ............... INFINITI-1
1994-96 ........... D/P ............... INFINITI-2
1990-93 ............ DS ............... INFINITI-3
QX4 ......... 1997-98 ........... D/P ............... INFINITI-1
( 1) - Location Definitions: D/P = Driver's & Passenger's Side,
DS = Driver's Side Only, SI = Side Impact.
\
\
\
\
\
\
\
INSPECTION PROCEDURES
INSPECTION PROCEDURES TABLE - INFINITI-1 \
\
\
\
\
\
\
Action Component or System
\
\
\b \
\
\
\
\
Replace After
* Air Bag Module(s)
Deployment
* Control Unit, Diagnosis
* Satellite Sensor ( 1)
* Seat Belt Pretensioners ( 2)
Page 1010 of 1501
![MITSUBISHI MONTERO 1998 Service Manual * Side Air Bag Module ( 1)
\
\
\b \
\
\
\](/manual-img/19/57333/w960_57333-1009.png "MITSUBISHI MONTERO 1998 Service Manual * Side Air Bag Module ( 1)
\
\
\b \
\
\
\")
* Side Air Bag Module ( 1)
\
\
\b \
\
\
\
\
Inspect & If
* Center Pillar Inner ( 1)
Damaged, Replace
* Instrument Panel
Component
* Seat ( 1)
(Even If Air
* Seat Belt Pretensioners ( 2)
Bag Did Not
* Spiral Cable
Deploy)
* Steering Wheel
* Wiring Harnesses
\
\
\b \
\
\
\
\
Comments
* Inspect all SRS components for dents,
deformities or rust.
* After repairs are completed, check AIR BAG
warning light to ensure system is functioning
properly.
\
\
\
\
\
\
\
(
1) - On side of impact.
(
2) - Except I30 and QX4.
\
\
\
\
\
\
\
\f
INSPECTION PROCEDURES TABLE - INFINITI-2 \
\
\
\
\
\
\
Action Component or System
\
\
\b \
\
\
\
\
Replace After
* Air Bag Module(s)
Deployment
* Control Unit, Diagnosis
* Instrument Panel
* Seat Belt Pretensioners ( 1)
\
\
\b \
\
\
\
\
Inspect & If
* All Sensors ( 2)
Damaged, Replace
* Spiral Cable
Component
* Steering Wheel
(Even If Air
* Wiring Harnesses
Bag Did Not
Deploy)
\
\
\b \
\
\
\
\
Comments
* Inspect all SRS components for dents,
deformities or rust.
* After repairs are completed, check AIR BAG
warning light to ensure system is functioning
properly.
\
\
\
\
\
\
\
(
1) - Except I30.
(
2) - Except 1996 I30, 1995-96 J30 and 1995-96 Q45.
\
\
\
\
\
\
\
\f
INSPECTION PROCEDURES TABLE - INFINITI-3 \
\
\
\
\
\
\
Action Component or System
\
\
\b \
\
\
\
\
Replace After
* Air Bag Module(s)
Deployment
* Control Unit, Diagnosis
* Sensors In Affected Collision Area
\
\
\b \
\
\
\
\
Inspect & If
* All Sensors
Damaged, Replace
* Spiral Cable
Component
* Steering Wheel
(Even If Air
* Wiring Harnesses
Bag Did Not
Deploy)
\
\
\b \
\
\
\
\
Comments
* Inspect all SRS components for dents,
deformities or rust.
Page 1011 of 1501
* After repairs are completed, check AIR BAG
warning light to ensure system is functioning
properly.
\
\
\
\
\
\
\
\f
ISUZU (1990-98)
AIR BAG APPLICATION
AIR BAG APPLICATION TABLE - ISUZU (1990-98) \
\
\
\
\
\
\
Model Year (1) Location Inspection Table
Hombre ....... 1996-97 ........... DS .................. ISUZU-1
Impulse ...... 1990-92 ........... DS .................. ISUZU-5
Oasis ........ 1996-98 .......... D/P .................. ISUZU-2
Rodeo ........ 1996-98 .......... D/P .................. ISUZU-3
1995 1/2 ......... D/P .................. ISUZU-3
Stylus ....... 1991-93 ........... DS .................. ISUZU-5
Trooper ...... 1996-98 .......... D/P .................. ISUZU-3
1995 ............ D/P .................. ISUZU-4
( 1) - Location Definitions: D/P = Driver's & Passenger's Side,
DS = Driver's Side Only, SI = Side Impact.
\
\
\
\
\
\
\
INSPECTION PROCEDURES
INSPECTION PROCEDURES TABLE - ISUZU-1 \
\
\
\
\
\
\
Action Component or System
\
\
\b \
\
\
\
\
Replace After
* Air Bag Module(s)
Deployment
* Sensors In Area Of Accident Damage
\
\
\b \
\
\
\
\
Inspect & If
* Instrument Panel Braces
Damaged, Replace
* Instrument Panel Steering Column
Component Reinforcement Plate
(Even If Air
* Seat Belts & Mounting Points
Bag Did Not
* Knee Bolster
Deploy)
* Sensors In Area Of Accident Damage
* SRS Coil Assembly
\
\
\b \
\
\
\
\
Comments
* Any sensor which the Diagnostic Energy
Reserve Module (DERM) indicates as bad must
be replaced.
* If any components are damaged or bent, they
must be replaced.
* SRS wiring can be repaired following
manufacturer's instructions.
\
\
\
\
\
\
\
\f
INSPECTION PROCEDURES TABLE - ISUZU-2 \
\
\
\
\
\
\
Action Component or System
\
\
\b \
\
\
\
\
Replace After
* Air Bag Module(s)
Deployment
* Seat Belt Tensioners (If Equipped)
* SRS Control Unit
\
\
\b \
\
\
\
\
Inspect & If
* Cable Reel
Damaged, Replace
* Dash Sensors (1991-94)
