* If any components are damaged or bent, they
must be replaced.
\
\
\
\
\
\
\
\f
INSPECTION PROCEDURES TABLE - TOYOTA-9 \
\
\
\
\
\
\
Action Component or System
\
\
\b \
\
\
\
\
Replace After
* Air Bag Module(s)
Deployment
* Center Air Bag Sensor Assembly
* Front Air Bag Sensors
* Spiral Cable
* Steering Wheel
\
\
\b \
\
\
\
\
Inspect & If
* Wiring Harness & Connectors
Damaged, Replace
Component
(Even If Air
Bag Did Not
Deploy)
\
\
\b \
\
\
\
\
Comments
* If any components are damaged or bent, they
must be replaced.
* Wiring for Front Air Bag Sensors can be
repaired following manufacturer's
instructions.
\
\
\
\
\
\
\
\f
INSPECTION PROCEDURES TABLE - TOYOTA-10 \
\
\
\
\
\
\
Action Component or System
\
\
\b \
\
\
\
\
Replace After
* Air Bag Module(s)
Deployment
* Front Air Bag Sensors
* Spiral Cable
* Steering Wheel
\
\
\b \
\
\
\
\
Inspect & If
* Center Air Bag Sensor Assembly
Damaged, Replace
* Wiring Harness & Connectors
Component
(Even If Air
Bag Did Not
Deploy)
\
\
\b \
\
\
\
\
Comments
* If any components are damaged or bent, they
must be replaced.
* Wiring for Front Air Bag Sensors can be
repaired following manufacturer's
instructions.
\
\
\
\
\
\
\
\f
Page 1067 of 1501
SEATS - POWER
1998 Mitsubishi Montero
1998 ACCESSORIES & EQUIPMENT
Mitsubishi - Power Seats
Eclipse, Galant, Montero, 3000GT
DESCRIPTION & OPERATION
Power seat system consists of reversible motors, a control
switch assembly and a wiring harness. Circuit is protected by a
fusible link, located in main relay box in engine compartment.
Power assist adjustments offered are: forward and backward
movement, height adjustment and separately adjusted front or rear seat
tilt. Controls are located on side of seat cushion or on center
console.
COMPONENT LOCATIONS
COMPONENT LOCATIONS TABLE \
\
\
\
\
\
Component Location
Data Link Connector (DLC) ............ Under Left Of Dash,
Below Steering Column
ETACS-ECU
3000GT ......................... Left Of Steering Column
Seat Adjusting Motors .............. Under Each Front Seat
\
\
\
\
\
\
COMPONENT TESTS
LIMIT SWITCH/SENSOR
Galant (Driver's Seat)
Disconnect each limit switch harness connector. Operate each
switch to check continuity between specified pins using ohmmeter. See
LIMIT SWITCH CONTINUITY TABLE (GALANT) . See Fig. 1. Replace power seat
adjuster assembly if any switch fails testing.
LIMIT SWITCH CONTINUITY TABLE (GALANT)
\
\
\
\
\
\
Switch Check Continuity
Position Between Pins No.
Slide Limit Switch
Forward .......................................... 1 & 2
Backward ......................................... 1 & 3
Middle (ON) ................................... 1, 2 & 3
Front & Rear Height Limit Switch
Front Up ......................................... 1 & 3
Front Down ....................................... 1 & 2
Front Middle (ON) ............................. 1, 2 & 3
Rear Up .......................................... 1 & 3
Rear Down ........................................ 1 & 2
Rear Middle (ON) .............................. 1, 2 & 3
\
\
\
\
\
\
Page 1151 of 1501
deploys.
* After air bag deploys, air bag surface may contain deposits
of sodium hydroxide, which irritate skin. Always wear safety
glasses, rubber gloves and long-sleeved shirt during clean
up. Wash hands using mild soap and water. Follow correct
clean-up and disposal procedures.
* Because of critical system operating requirements, DO NOT
service any SRS components. Repairs are only made by
replacing defective part(s).
* DO NOT allow any electrical source near inflator on the back
of air bag module.
* When carrying live air bag module, trim cover should be
pointed away from body to minimize injury in case of
accidental air bag deployment.
* If SRS is not fully functional for any reason, DO NOT drive
vehicle until system is repaired and is fully functional. DO
NOT remove bulbs, modules, sensors or other components, or in
any way disable system from operating normally. If SRS is not
functional, park vehicle until repairs are made.
REMOVAL & INSTALLATION
STEERING WHEEL
WARNING: Wait at least 60 seconds after disconnecting negative
battery cable before servicing SRS. System reserve capacitor
maintains SRS voltage for about 60 seconds after battery is
disconnected. Servicing SRS before 60-second period may
cause accidental air bag deployment and possible personal
injury.
Removal
Disable air bag. See DISABLING & ACTIVATING AIR BAG SYSTEM .
Ensure steering wheel is straight ahead. Remove air bag. Place
reference mark on steering wheel and steering column shaft for
installation reference. Remove steering wheel nut and washer. Using
steering wheel puller, remove steering wheel.
CAUTION: DO NOT hammer on steering wheel during removal or
installation, as it may damage steering column.
Installation
To install, reverse removal procedure. Ensure reference marks
are aligned. Tighten fasteners to specification. See
TORQUE SPECIFICATIONS . Activate air bag. See DISABLING & ACTIVATING
AIR BAG SYSTEM.
COMBINATION SWITCH
CAUTION: When installing steering wheel, if rotating part of
clockspring is not properly centered with steering column
and front wheels, clockspring failure will result.
Removal & Installation
Remove lower instrument cover and lower heater duct. Remove
air bag and steering wheel. See STEERING WHEEL under
REMOVAL & INSTALLATION . Remove upper and lower steering column covers.
Disconnect clockspring electrical connector. Remove screws attaching
colckspring and remove clockspring. Disconnect combination switch
electrical connectors. Remove screws and combination switch. To
install, reverse removal procedure.
Page 1165 of 1501
* STEERING UNIFORM INSPECTION GUIDELINES *
1998 Mitsubishi Montero
GENERAL INFORMATION
Steering, Suspension, Wheel Alignment, Wheels and Tires
Motorist Assurance Program
Standards For Automotive Repair
All Makes and Models
INTRODUCTION TO MOTORIST ASSURANCE PROGRAM (MAP)
CONTENTS
Motorist Assurance Program (MAP)
OVERVIEW
OVERVIEW OF SERVICE REQUIREMENTS & SUGGESTIONS
Steering and Suspension
AIR RIDE SUSPENSION
AIR RIDE SUSPENSION - AIR SHOCKS AND AIR STRUTS
AIR RIDE SUSPENSION - AIR SPRING VALVES
AIR RIDE SUSPENSION - AIR SPRINGS
AIR RIDE SUSPENSION - COMPRESSORS
AIR RIDE SUSPENSION - HEIGHT SENSORS
AIR RIDE SUSPENSION - MODULES
AIR RIDE SUSPENSION - RELAYS (COMPRESSOR)
AIR RIDE SUSPENSION - SWITCHES (ON/OFF)
AIR RIDE SUSPENSION - TORSION SPRINGS (COUNTER BALANCING)
AIR RIDE SUSPENSION - TUBING
AIR RIDE SUSPENSION - WARNING LAMPS
AIR RIDE SUSPENSION - WIRING HARNESSES
BALL JOINTS
BUSHINGS
CENTER LINKS
CONTROL ARM SHAFTS
CONTROL ARMS
DRAG LINKS
ELECTRONIC RIDE CONTROL SHOCKS AND STRUTS
IDLER ARMS
KING PINS
PITMAN ARMS
POWER STEERING HOSES
POWER STEERING (HYDRAULIC) PUMPS
RADIUS ARMS
RELAY RODS
SHOCK ABSORBERS, STRUT CARTRIDGES AND STRUT ASSEMBLIES
SPINDLES
SPRINGS - COIL, LEAF AND TORSION BAR
STEEL POWER STEERING LINES
STEERING ARMS
STEERING DAMPERS
STEERING GEARS (EXCEPT RACK AND PINION)
STEERING GEARS - RACK AND PINION
STEERING KNUCKLES
STRIKE OUT BUMPERS
STRUT RODS
STRUT UPPER BEARING PLATE ASSEMBLIES
SWAY BAR LINKS
SWAY BARS
Page 1171 of 1501
![MITSUBISHI MONTERO 1998 Service Manual AIR RIDE SUSPENSION - COMPRESSORS
AIR RIDE SUSPENSION - COMPRESSOR INSPECTION \
\
\
\
\](/manual-img/19/57333/w960_57333-1170.png "MITSUBISHI MONTERO 1998 Service Manual AIR RIDE SUSPENSION - COMPRESSORS
AIR RIDE SUSPENSION - COMPRESSOR INSPECTION \
\
\
\
\")
AIR RIDE SUSPENSION - COMPRESSORS
AIR RIDE SUSPENSION - COMPRESSOR INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Attaching hardware bent . B ... Require repair or replacement
of bent part.
Attaching hardware
broken ................. A ... Require replacement of broken
part.
Attaching hardware
loose .................. A ... Require repair or replacement
of loose part.
Attaching hardware
missing ................ C .. Require replacement of missing
part.
Attaching hardware
threads damaged ........ A ... Require repair or replacement
of part with damaged threads.
Attaching hardware
threads stripped
(threads missing) ...... A ..... Require replacement of part
with stripped threads.
Connector bent .......... A .. Require repair or replacement.
Connector broken ........ A ............ Require replacement.
Connector loose ......... A .. Require repair or replacement.
Does not build pressure . A .......... ( 1) Further inspection
required.
Excessive run time ...... B .......... ( 2) Further inspection
required.
Inoperative ............. A ............ Require replacement.
Leaking ................. A .. Require repair or replacement.
Missing ................. C ............ Require replacement.
( 1) - If failure to build pressure is traced to the
compressor, require replacement.
( 2) - If excessive run time is traced to the compressor,
require replacement.
\
\
\
\
\
\
\
AIR RIDE SUSPENSION - HEIGHT SENSORS
AIR RIDE SUSPENSION - HEIGHT SENSOR INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Attaching hardware bent . B ... Require repair or replacement
of bent part.
Attaching hardware
broken ................. A ... Require replacement of broken
part.
Attaching hardware
corroded, affecting
structural integrity .... A .......... Require replacement of
corroded part.
Attaching hardware
loose .................. A ... Require repair or replacement
of loose part.
Attaching hardware
missing ................ C .. Require replacement of missing
part.
Attaching hardware
Page 1172 of 1501
threads damaged ........ A ... Require repair or replacement
of part with damaged threads.
Attaching hardware
threads stripped
(threads missing) ...... A ..... Require replacement of part
with stripped threads.
Dust boot missing ....... 2 ........ (1) Suggest replacement.
Dust boot split ......... 2 ........ ( 1) Suggest replacement.
Dust boot torn .......... 2 ........ ( 1) Suggest replacement.
Housing cracked ......... A ............ Require replacement.
Lead routing incorrect .. B .. Require rerouting according to
vehicle manufacturer's
specifications.
Loose ................... B ... Require adjustment to vehicle
manufacturer's specifications.
Missing ................. C ............ Require replacement.
Output signal incorrect . A .. Require repair or replacement.
Wire lead damaged ....... A .. Require repair or replacement.
( 1) - This condition can lead to damage of the sliding magnet,
which, in turn, causes premature sensor failure.
\
\
\
\
\
\
\
AIR RIDE SUSPENSION - MODULES
AIR RIDE SUSPENSION - MODULE INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Attaching hardware
loose .................. A ... Require repair or replacement
of loose part.
Attaching hardware
missing ................ C .. Require replacement of missing
part.
Attaching hardware
threads damaged ........ A ... Require repair or replacement
of part with damaged threads.
Attaching hardware
threads stripped
(threads missing) ...... A ..... Require replacement of part
with stripped threads.
Housing cracked ......... 2 .. Suggest repair or replacement.
Inoperative ............. A ............ Require replacement.
Missing ................. C ............ Require replacement.
\
\
\
\
\
\
\
AIR RIDE SUSPENSION - RELAYS (COMPRESSOR)
AIR RIDE SUSPENSION - RELAY (COMPRESSOR) INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Housing cracked ......... 2 ........ ( 1) Suggest replacement.
Intermittent ............ A ............ Require replacement.
Missing ................. C ............ Require replacement.
Output signal incorrect . A ............ Require replacement.
( 1) - If moisture enters the relay, it can reduce life
expectancy or impair function.
\
\
\
\
\
\
\
AIR RIDE SUSPENSION - SWITCHES (ON/OFF)
Page 1224 of 1501
Fig. 9: Inspecting Sun Roof Switch Continuity (Montero)
Courtesy of Mitsubishi Motor Sales of America
Fig. 10: Inspecting Sun Roof Switch Continuity (Montero Sport)
Courtesy of Mitsubishi Motor Sales of America
MOTOR ROTATION SENSOR CHECK (3000GT)
Page 1225 of 1501
1) Connect ohmmeter negative lead to terminal No. 3 and
positive lead to terminal No. 8. See Fig. 11. Continuity should exist.
Reverse ohmmeter leads. Continuity should not exist.
2) Remove motor cover. Connect ohmmeter negative lead to
terminal No. 7 and positive lead to terminal No. 8. See Fig. 11.
Continuity should not exist. Continuity should exist when light is
shone onto sensor receiver. Replace rotation sensor if continuity is
not as specified.
Fig. 11: Checking Motor Rotation Sensor (3000GT)
Courtesy of Mitsubishi Motor Sales of America
REMOVAL & INSTALLATION
