1997 FORD CROWN VICTORIA Owners Manual

6
%*
[II03400( ALL)01/96]
Breaking Your Vehicle In
*
[II03500( ALL)01/96]
Your new vehicle goes through an adjustment or
break-in period during the first 1,000 miles
(1,600 km) that you drive it. During the break-in
period, you need to pay careful attention to how
you drive your vehicle.
%*
[II03600( ALL)01/96]
q
Avoid sudden stops.Because your vehicle
has new brake linings, you should take these
steps:
*
[II03700( ALL)01/96]
Ð Watch traffic carefully so that you can
anticipate when to stop.
*
[II03800( ALL)01/96]
Ð Begin braking well in advance.
*
[II03900( ALL)01/96]
Ð Apply the brakes gradually.
*
[II04000( ALL)01/96]
The break-in period for new brake linings
lasts for 100 miles (160 km) of city driving or
1,000 miles (1,600 km) of highway driving.
%*
[II04100( ALL)03/96]
q
Use only the type of engine oil that Ford
recommends.SeeEngine oil recommendations
in the Index. Do not use special ªbreak-inº
oils.
*
[II04200( ALL)03/96]
Your vehicle is equipped with an Electronic
Powertrain Control Module that limits engine
and/or vehicle speeds with a cut-out mode to
promote durability.
File:02rciiv.ex
Update:Tue Jun 11 15:17:45 1996

7
Instrumentation
[IS00500( V)12/95]
full page art:0010667-G
Crown Victoria instrument panel
File:03rcisv.ex
Update:Tue Jun 11 15:19:37 1996

8 %
*
[IS00600( ALL)01/96]
The instrument panel (dashboard) on your
vehicle is divided into several different sections.
The illustrations on the following pages show
the major parts of the instrument panel that are
described in this chapter. Some items shown
may not be on all vehicles.
[IS00900( GV)12/95]
Your vehicle is equipped with one of the
following clusters:
[IS01000( GV)12/95]
q
a mechanical cluster
[IS01100( GV)12/95]
q
an electronic cluster
File:03rcisv.ex
Update:Tue Jun 11 15:19:37 1996

9 % [IS01500( GV)12/95]
full page art:0010682-I
The mechanical cluster
File:03rcisv.ex
Update:Tue Jun 11 15:19:37 1996

10
%*
[IS01700( BCGV)01/96]
The Mechanical Cluster
*
[IS02000( BCGV)01/96]
The following warning lights and gauges are on
the mechanical cluster. All of the warning lights
and gauges alert you to possible problems with
your vehicle. Some of the lights listed are
optional. The following sections detail what each
of these indicators means.
%*
[IS02600( ALL)01/96]
Brake System Warning Light
*
[IS02700( ALL)03/96]
The warning light for the brakes can show two
things Ð that the parking brake is not fully
released, or that the brake fluid level is low in
the master cylinder reservoir. If the fluid level is
low, the brake system should be checked by a
qualified service technician.
[IS03050( GV)05/96]
one inch art:0010681-C
The brake system warning light
[IS03100( ALL)05/96]
This light comes on when the parking brake is
set, or if it is not set, it comes on briefly when
you turn the ignition key to START. It normally
goes off shortly after the engine starts and you
release the parking brake. If the light stays on
after you have fully released the parking brake,
have the hydraulic brake system serviced.
*
[IS03200( ALL)03/96]
RWARNING
The BRAKE light indicates that the brakes
may not be working properly. Have the
brakes checked immediately.
File:03rcisv.ex
Update:Tue Jun 11 15:19:37 1996

11 % [IS03300( ALL)04/96]
Anti-Lock Brake System Light
(If equipped)
[IS03400( ALL)12/95]
This warning light will go on each time you
start your vehicle. If it remains on for longer
than five seconds, you should shut off your
engine and restart. If the anti-lock brake light
stays on, this indicates that the anti-lock feature
is disabled and should receive immediate
attention by a qualified service technician.
Normal braking is not affected unless the brake
warning light is also lit.
*
[IS03500( ALL)03/96]
The Anti-Lock Brake System has self-check
capabilities. As previously described, the system
turns on the anti-lock light each time you start
your engine. After the engine is started and the
anti-lock light is out, the system performs
another test the first time the vehicle reaches
14 mph (22 km/h). The system turns on the
Anti-Lock Brake System (ABS) pump motor for
approximately 1/2 second. At this time a
mechanical noise may be heard. This is a normal
part of the self-check feature. If a malfunction is
found during this check the anti-lock light will
come on.
[IS03600( ALL)04/96]
one inch art:0011194-B
The anti-lock brake system light
File:03rcisv.ex
Update:Tue Jun 11 15:19:37 1996

12
*
[IS03700( ALL)03/96]
RWARNING
If the anti-lock brake system warning
light remains on or comes on while
driving, have the braking system checked
by a qualified service technician as soon
as possible.
*
[IS03800( ALL)03/96]
NOTE: If a fault occurs in the anti-lock
system, and the brake warning light is
not lit, the anti-lock system is disabled
but normal brake function remains
operational.
%*
[IS04600( ALL)03/96]
Safety Belt Warning Light and Chime
*
[IS04700( ALL)03/96]
This warning light and chime remind you to
fasten your safety belt. The following conditions
will take place:
*
[IS04900( GV)03/96]
q
If the driver's safety belt is not buckled when
the ignition is turned to the ON position, the
light will turn on for 1 to 2 minutes and the
chime will sound for 4 to 8 seconds.
*
[IS05200( GV)03/96]
q
If the driver's safety belt is buckled while the
light is on or the chime is sounding, both the
light and the chime will turn off.
*
[IS05400( GV)03/96]
q
If the driver's safety belt is buckled before the
ignition is turned to the ON position, neither
the light nor the chime will turn on.
[IS05600( ALL)04/96]
one inch art:0010118-A
The safety belt warning light
File:03rcisv.ex
Update:Tue Jun 11 15:19:37 1996

13 %
*
[IS06300( ALL)05/96]
Air Bag Readiness Light
*
[IS06400( ALL)05/96]
The air bag system uses a readiness light and a
tone to indicate the condition of the system. The
readiness light is in the instrument cluster. When
you turn the ignition key to the ON position,
this light will light up for six (6) seconds and
then turn off. This indicates that the system is
operating normally. NOTE: Regularly scheduled
maintenance of the air bag system is not
required.
*
[IS06500( ALL)05/96]
If the light fails to illuminate, continues to flash,
remains on, or you hear a beeping sound, have
the system serviced at your Ford or
Lincoln-Mercury dealer immediately.
[IS06600(M GV)04/96]
one inch art:0010514-A
The air bag readiness light
%*
[IS07500( ALL)01/96]
Charging System Light
*
[IS07600( ALL)05/96]
This light indicates that your battery is not being
charged and that you need to have the electrical
system checked.
[IS07700( ALL)04/96]
one inch art:0010119-B
The charging system light
File:03rcisv.ex
Update:Tue Jun 11 15:19:37 1996
