1997 FORD CROWN VICTORIA Owners Manual

88 [CF17700( BCGV)12/95]Chime for headlamps on
*
[CF17800( ALL)12/95]
This chime sounds if the driver or any passenger
door is open when the parking lamps or
headlamps are on. The chime sounds until you
close the door, turn off the lamps or turn the
ignition to the ON position.
%*
[CF17900( GV)05/96]
Setting the Autolamp On/Off Delay
System
*
[CF18100( BCGV)01/96]
The autolamp sets the headlamps to turn on and
off automatically. You can use the autolamp to:
*
[CF18200( BCGV)01/96]
q
turn on the lamps automatically at night
*
[CF18300( BCGV)01/96]
q
turn off the lamps automatically during
daylight
*
[CF18400( BCGV)01/96]
q
keep the lamps on for up to three minutes
after you turn the key to OFF.
[CF18500( GV)12/95]
one third page art:0010198-F
The autolamp system on the left side of the instrument
panel
[CF18800( GV)12/95]
To activate the autolamp feature, simply turn the
headlamp knob counterclockwise towards the
autolamp delay area. The autolamp
automatically turns the lamps on and off for
you.
File:05rccfv.ex
Update:Thu Mar 27 07:20:00 1997

89
*
[CF19400( BCGV)10/95]
Do not put any articles on top of the photocell
that is located in the top right corner of the
instrument panel. This photocell controls the
autolamp. If you cover it, the photocell reacts as
if it is nighttime, and the lamps turn on.
[CF19600( GV)12/95]
You can adjust the autolamp to keep the lamps
on after you leave your vehicle. The further you
move the headlamp knob to the left
(counterclockwise), the longer the lamps stay on.
*
[CF19700( BCGV)01/96]
You can set the autolamp so the lamps stay on
for up to three minutes after you turn your
vehicle off.
%*
[CF20000( ALL)01/96]
Lighting Up the Interior and Instrument
Panel
[CF20400( GV)12/95]
With the parking lamps or headlamps
illuminated, you can brighten or dim the lights
in the instrument panel. To do this, locate the
switch above the headlight control knob and
press it up (to brighten the lights) or down (to
dim the lights). To turn the interior lights on
and off, push the headlamp knob in.
[CF20700( GV)12/95]
one third page art:0011308-B
The knob controls the light on the instrument panel and
the interior light (autolamp feature shown Ð other models
similar)
File:05rccfv.ex
Update:Thu Mar 27 07:20:00 1997

90
%*
[CF20800( ALL)03/96]
Clock
[CF20900( GV)12/95]
quarter page art:0011295-B
The digital clock
[CF21200( ALL)12/95]
1. To set the hour, press and hold the H
button. When the desired hour appears,
release the button.
[CF21300( ALL)12/95]
2. To set the minutes, press and hold the M
button. When the desired minute appears,
release the button.
%
*
[CF21400( GV)12/95]
Ashtray and Cupholder
[CF21500( GV)12/95]
Your vehicle is equipped with an
ashtray/cupholder mounted to the lower center
of the instrument panel.
*
[CF21600( GV)12/95]
To open the ashtray, pull out the bottom edge of
the drawer until it stops.
*
[CF21700( GV)12/95]
To close, remove cup(s) and push drawer
forward until closed.
File:05rccfv.ex
Update:Thu Mar 27 07:20:00 1997

91
[CF22600( ALL)01/96]
Storage Compartments
*
[CF22700(M GV)03/96]
Your vehicle may have several small storage
compartments:
[CF23100( BCGV)12/95]
q
a glove compartment that locks. Use the
round key to lock and unlock it.
[CF23200( ALL)01/96]
WARNING
Do not put objects on the ledge between
the back seat and the rear window, as
they can become dangerous projectiles and
injure someone.
File:05rccfv.ex
Update:Thu Mar 27 07:20:00 1997

92
% [CF23300( ALL)03/96]
Using the Remote Control for the
Trunk (If equipped)
[CF23600( GV)03/96]
You can use the remote control on the driver's
door to unlock and open the trunk unless you
lock the button with main key. The valet key
equipped with your vehicle can only open the
doors and start the engine.
[CF23900( GV)12/95]
one third page art:0010670-C
The remote control for the trunk
File:05rccfv.ex
Update:Thu Mar 27 07:20:00 1997

93
*
[CF24100( ALL)01/96]
Ignition
%*
[CF24200( ALL)01/96]
Understanding the Positions of the Ignition
[CF24300( ALL)12/95]
quarter page art:0010035-B
The positions of the key in the ignition
*
[CF24500( BCGV)04/96]
ACC allows some of your vehicle's electrical
accessories such as the radio and the windshield
wipers to operate while the engine is not
running.
% [CF24600( ALL)12/95]
LOCK locks the steering wheel. It also locks the
automatic transmission gearshift lever.
*
[CF24700( ALL)01/96]
LOCK is the only position that allows you to
remove the key. The LOCK feature helps to
protect your vehicle from theft.
*
[CF24800( ALL)01/96]
OFF allows you to shut off the engine and all
accessories without locking the steering wheel or
the automatic transmission gearshift lever.
*
[CF24900( ALL)01/96]
ON allows you to test your vehicle's warning
lights (except the brake system warning light) to
make sure they work before you start the
engine. The key returns to the ON position once
the engine is started and remains in this position
while the engine runs.
*
[CF25000( ALL)01/96]
START cranks the engine. Release the key once
the engine starts so that you do not damage the
starter. The key should return to ON when you
release it. The START position also allows you
to test the brake warning light.
File:05rccfv.ex
Update:Thu Mar 27 07:20:00 1997

94 %
*
[CF25100( ALL)03/96]
Removing the Key From the Ignition
*
[CF25200( BCGV)03/96]
1. Put the gearshift in P (Park).
*
[CF25400( ALL)01/96]
2. Set the parking brake fully.
*
[CF25500( BCGV)03/96]
3. Turn the ignition key to LOCK.
*
[CF25700( BCGV)03/96]
4. Remove the key.
[CF26300( BCGV)12/95]
NOTE: The automatic transmission gearshift
must be in P (Park) to move the key to
the lock position.
%*
[CF26400( ALL)01/96]
If the key is stuck in the LOCK position, move
the steering wheel left or right until the key
turns freely.
%*
[CF26500( ALL)12/95]
If the driver's door is open while the key is still
in the ignition, a warning chime sounds.
*
[CF26700( BCGV)05/96]
WARNING
Always set the parking brake fully and
make sure the gearshift is latched in P
(Park). Turn off the ignition whenever you
leave your vehicle.
*
[CF26800( ALL)03/96]
WARNING
Do not leave children, unreliable adults,
or pets unattended in your vehicle.
%
*
[CF26900( ALL)02/96]
The Turn Signal Lever
*
[CF27000( ALL)02/96]
You can use the turn signal lever on the left side
of the steering column to:
[CF27100( ALL)04/96]
q
operate the turn signals
*
[CF27200( ALL)03/96]
q
turn the high beams on/off
*
[CF27300( ALL)03/96]
q
flash the lamps
*
[CF27400( ALL)03/96]
q
turn the windshield wipers and washer
on/off
[CF27500( GV)12/95]
q
turn the cornering lamps on
File:05rccfv.ex
Update:Thu Mar 27 07:20:00 1997

95 [CF27600( ALL)12/95]
one third page art:0011292-A
The turn signal lever
%*
[CF27700( ALL)01/96]
Turn Signals
*
[CF27800( ALL)01/96]
Move the lever up to signal a right turn. Move
it down to signal a left turn. The corresponding
indicator light in the instrument cluster will
flash.
*
[CF27900( ALL)01/96]
If the turn signal stays on after you turn, move
the lever back to the center (off) position.
*
[CF28000( ALL)01/96]
For lane changes, move the lever far enough to
signal but not to latch. The lever will return to
the off position when you release it.
[CF28100( GV)12/95]
If your vehicle is equipped with cornering
lamps, they will automatically light on either the
right or left side (depending on the direction of
the turn), when the headlamps are ON.
%*
[CF28200( ALL)01/96]
High Beams
*
[CF28300( ALL)01/96]
To turn on the high beams, turn the headlamp
control knob to the headlamp ON position and
push the turn signal lever away from you until
it latches. When the high beams are ON, the
high beam indicator light on the instrument
panel comes on.
*
[CF28400( ALL)01/96]
To turn off the high beams, pull the lever
toward you until it latches. The high beam
indicator light turns off.
File:05rccfv.ex
Update:Thu Mar 27 07:20:00 1997
