1997 FORD ASPIRE Owners Manual

135 [ER08500(ALL)01/96]
half page art:0032243-A
Tire retaining tool
[ER08550(ALL)01/96]
NOTE: Be sure to thread the retaining tool
until no threads on the retaining tool
are visible.
[ER08600(ALL)01/96]
5. Loosen the wheel lug bolts by turning the
handle of the wrench one half turn
counterclockwise. Do not remove the wheel
lug bolts until you raise the tire off the
ground.
File:10icerf.ex
Update:Tue Mar 4 08:55:59 1997

136 %
*
[ER08650(ALL)01/96]
Removing and Replacing the Tire
[ER08700(ALL)04/96]
1. Find the jacking location near the door of
the tire that you are changing. Position the
jack and turn the handle of the jack
clockwise until the wheel is completely off
the ground.
*
[ER08800(ALL)01/96]
WARNING
To lessen the risk of personal injury, do
not put any part of your body under the
vehicle while changing a tire. Do not start
the engine when your vehicle is on the
jack. The jack is only meant for changing
the tire.
[ER09200(ALL)01/96]
one third page art:0032213-A
Jack mounting position
[ER09600(ALL)04/96]
2. Remove the wheel lug bolts by using the lug
wrench. Never loosen the hub nuts. See the
illustration following Step 1Preparing to
Change the Tireif you are not sure where to
find the wheel bolts.
[ER09700(ALL)01/96]
3. Replace the flat tire with the spare tire. Keep
the retaining tool in place.
File:10icerf.ex
Update:Tue Mar 4 08:55:59 1997

137 [ER09750(ALL)01/96]
half page art:0032248-B
Positioning spare tire
[ER09900(ALL)04/96]
4. Replace the wheel lug bolts, but do not fully
tighten them until you lower the vehicle. If
you do, you could force the vehicle off the
jack.
[ER10000(ALL)01/96]
5. Remove the retaining tool and replace it
with the final lug bolt.
[ER10090(ALL)01/96]
Your vehicle is built with metric (12 mm)
threads on the wheel hubs and lug bolts. Make
certain, during wheel removal, the same bolts
removed are reinstalled, or if replaced, bolts
with metric threads and the same chamfer
configuration are used.
File:10icerf.ex
Update:Tue Mar 4 08:55:59 1997

138 [ER10100(ALL)01/96]
WARNING
Installation of an English thread lug bolt
into a metric hub will not properly secure
the wheel to the hub. Damaged lug bolts
may result in wheel separation and
possible injury.
*
[ER10200(ALL)03/96]
6. Lower the vehicle by turning the jack handle
counterclockwise.
[ER10500(ALL)01/96]
7. Remove the jack and fully tighten the wheel
lug bolts in the order shown in the
illustration under Step 1.
[ER10700(ALL)01/96]
8. Put the tire, jack, retaining tool and wrench
away.
[ER10750(ALL)01/96]
9. Secure the conventional tire where the spare
was stored with the bolt provided.
*
[ER10850(ALL)03/96]
10. Unblock the wheels.
%
*
[ER12255(ALL)02/96]
Jump-Starting Your Vehicle
[ER12260(ALL)01/96]
Your vehicle's battery may become discharged
(ªdieº) if you leave the lights or any electrical
equipment on after you turn the engine off. If
this happens, you may be able to jump-start
from a booster battery to start your vehicle.
*
[ER12265(ALL)02/96]
WARNING
The gases around the battery can explode
if exposed to flames, sparks, or lit
cigarettes. An explosion could result in
injury or vehicle damage.
*
[ER12270(ALL)02/96]
WARNING
To protect yourself when charging a
battery, always shield your face and eyes.
Make sure that you can breathe fresh air.
File:10icerf.ex
Update:Tue Mar 4 08:55:59 1997

139 %
*
[ER12275(ALL)02/96]
WARNING
Applying too much pressure on the ends
when lifting a battery could cause acid to
spill. Lift the battery with a carrier or
with your hands on the opposite corners.
%*
[ER12280(ALL)02/96]
WARNING
Batteries contain sulfuric acid which burns
skin, eyes, and clothing.
*
[ER12285(ALL)02/96]
If the acid touches someone's skin, eyes, or
clothing, immediately flush the area with water
for at least 15 minutes. If someone swallows the
acid, have him or her drink lots of milk or water
first, then Milk of Magnesia, a beaten egg, or
vegetable oil. Call a doctor immediately.
*
[ER12290(ALL)01/96]
WARNING
Do not push-start your vehicle. You could
damage the catalytic converter. For further
information, seeJumper Cablesin the
Index.
*
[ER12295(ALL)02/96]
To avoid damaging your vehicle or your battery,
and to avoid injury to yourself, follow these
directions for preparing your vehicle to
jump-start and connecting the jumper cables in
the order they are given. If in doubt, call for
road service.
%*
[ER12300(ALL)02/96]
Preparing Your Vehicle
*
[ER12305(ALL)02/96]
1. Your vehicle has a 12-volt starting system, so
you need to use a 12-volt jumper system.
You will damage your starting motor,
ignition system, and other electrical parts if
you connect them to a 24-volt power supply
(either two 12-volt batteries in series or a
24-volt generator set).
File:10icerf.ex
Update:Tue Mar 4 08:55:59 1997

140
*
[ER12310(ALL)02/96]
2. Do not disconnect the battery of the disabled
vehicle. You could damage the vehicle's
electrical system.
*
[ER12315(ALL)02/96]
3. Park the booster vehicle close to the hood of
the disabled vehicle.Make sure the vehicles
do not touch each other.Set the parking
brake on both vehicles and stay clear of the
engine cooling fan and other moving parts.
*
[ER12320(ALL)02/96]
4. Check all battery terminals and remove any
excessive corrosion before you attach the
jumper cables.
*
[ER12325(ALL)03/96]
5. Turn on the heater fan in both vehicles.
Press the DEFROST button. Turn off all
other switches and gauges.
%*
[ER12330(ALL)02/96]
Connecting the jumper cables
*
[ER12335(ALL)02/96]
1. Connect one end of the first jumper cable to
the positive (+) terminal of the discharged
battery. (You can connect either jumper cable
to the positive (+) terminal, as long as you
use the same cable for both positive
terminals.) Most jumper cables have a red
cable and a black cable. The red cable is
generally used for the positive terminals and
the black for the negative ones.
*
[ER12340(ALL)02/96]
2. Connect the other end of the first cable to
the positive (+) terminal of the booster
battery.
*
[ER12345(ALL)02/96]
3. Connect one end of the second cable to the
negative (S) terminal of the booster battery
Ð NOT to the discharged battery.
File:10icerf.ex
Update:Tue Mar 4 08:55:59 1997

141
*
[ER12350(ALL)01/96]
4. Connect the other end of that cable to a
good metallic surface on the engine or frame
of the disabled vehicle. The following
illustration shows where you can find a
metallic surface.
*
[ER12355(ALL)02/96]
WARNING
Do not connect the end of the second
cable to the negative (S) terminal of the
battery to be jumped. A spark may cause
an explosion of the gases that surround
the battery.
[ER12360(ALL)04/96]
half page art:0032286-A
The sequence for connecting the jumper cables
File:10icerf.ex
Update:Tue Mar 4 08:55:59 1997

142
*
[ER12365(ALL)02/96]
Jump-Starting
*
[ER12370(ALL)02/96]
1. Make sure that the jumper cables are not in
the way of moving engine parts, then start
the booster vehicle. Run the engine at a
moderate speed.
*
[ER12375(ALL)02/96]
2. Let the discharged battery charge for a few
minutes and then start the disabled vehicle.
It may take a couple of tries before the
vehicle starts. If the vehicle does not start
after several attempts, there may be a
different problem.
*
[ER12380(ALL)02/96]
3. When both vehicles are running, let them
idle for a few minutes to charge the
discharged battery.
%*
[ER12385(ALL)02/96]
Removing jumper cables
*
[ER12390(ALL)02/96]
1.Always remove the jumper cables in the
reverse order.Remove the negative (S) end
of the jumper cable from the metallic surface
on the engine or frame of the disabled
vehicle.
*
[ER12395(ALL)03/96]
2. Remove the negative (S) cable from the
booster battery.
*
[ER12400(ALL)02/96]
3. Remove the positive (+) cable from the
booster battery.
*
[ER12405(ALL)02/96]
4. Remove the other end of the positive (+)
cable from the discharged battery.
*
[ER12410(ALL)02/96]
After the vehicle is started, let it idle for a while
to let the engine ªrelearnº its idle conditions.
Drive it around for a while with all electrical
accessories turned off to let the battery recharge.
Driveability may be deteriorated slightly until all
drive modes are ªrelearned.ºYou may need to
use a battery charger to fully recharge the
battery.
*
[ER12415(ALL)03/96]
If you need to replace your battery, seeBattery
in theMaintenance and Carechapter.
