1997 FORD ASPIRE Owners Manual

127 % [ER03110(ALL)04/96]
thirty-six pica chart:0032232-D
File:10icerf.ex
Update:Tue Mar 4 08:55:59 1997

128 [ER03115(ALL)04/96]
fourteen pica chart:0032237-C
%*
[ER03120(ALL)01/96]
Checking and Replacing Fuses
[ER03125(ALL)01/96]
1. Find the fuse panel and remove the cover.
[ER03130(ALL)01/96]
2. Find the position of the fuse you want to
check.
[ER03135(ALL)01/96]
3. To remove the fuse, use the fuse puller
provided (located on the cover of the interior
fuse panel).
*
[ER03140(ALL)01/96]
quarter page art:0030248-C
Fuse puller tool and fuse
File:10icerf.ex
Update:Tue Mar 4 08:55:59 1997

129 [ER03145(ALL)01/96]
4. Look through the transparent side of the
fuse to see if the metal wire inside is
separated. If it is, replace the fuse with one
of the same amperage only. You can use the
amp rating number on the fuse as well as
the color to identify the correct replacement.
*
[ER03150(ALL)01/96]
WARNING
Always replace a fuse with one that has
the specified amperage rating. Using a
fuse with a higher amperage rating can
cause severe wire damage and could start
a fire.
[ER03155(ALL)01/96]
5. Reinstall the fuse puller on the inside of the
fuse panel cover.
[ER03160(ALL)01/96]
6. Install the fuse panel cover.
*
[ER03165(ALL)04/96]
Even after you replace a fuse, it may continue to
blow if you do not find what caused the
overload. If the fuse continues to blow, have
your electrical system checked.
*
[ER03170(ALL)01/96]
The following chart indicates the colors and
amperage ratings of standard fuses.
[ER03172(ALL)04/96]
NOTE: Some of your vehicle's components
may be protected by a fuse link. Ford
recommends that fuse links be replaced
by a qualified technician.
File:10icerf.ex
Update:Tue Mar 4 08:55:59 1997

130 [ER03175(ALL)04/96]
twelve pica chart:0032119-B
%*
[ER03800(ALL)02/96]
Changing a Tire
*
[ER03900(ALL)02/96]
If you get a flat tire while you are driving, do
not apply the brake heavily. Instead, gradually
decrease the speed. Hold the steering wheel
firmly and slowly move to a safe place on the
side of the road. Park on a level spot, turn off
the ignition, set the parking brake, and turn on
the hazard flashers.
%*
[ER04000(ALL)02/96]
The Temporary Spare Tire
*
[ER04100(ALL)02/96]
You may have a high pressure temporary spare
tire. This spare tire is smaller than a regular tire
and is designed for emergency use only. Use it
only when you get a flat tire and replace it as
soon as you can. This spare tire is marked with
the words ªTEMPORARY USE ONLYº so that
you can easily identify it.
*
[ER04200(ALL)02/96]
WARNING
If you use the temporary spare tire
continuously or do not follow these
precautions, the tire could fail, causing
you to lose control of the vehicle, possibly
injuring yourself or others.
File:10icerf.ex
Update:Tue Mar 4 08:55:59 1997

131
*
[ER04300(ALL)02/96]
When you drive with the temporary spare tire,
DO NOT:
*
[ER04400(ALL)02/96]
q
exceed 50 mph (80 km/h) under any
circumstances.
*
[ER04500(ALL)02/96]
q
load your vehicle so that it is heavier than
the maximum vehicle load rating listed on
the tire decal.
*
[ER04700(ALL)02/96]
q
use tire chains on this tire.
*
[ER04800(ALL)02/96]
q
try to repair the temporary spare tire or
remove it from its wheel.
*
[ER04900(ALL)02/96]
q
use the wheel for any other type of vehicle.
*
[ER05000(ALL)02/96]
q
drive through an automatic car wash with
this tire. Because the temporary spare tire is
smaller than a conventional tire, it reduces
the ground clearance. Your vehicle may get
caught in the rails and it could be damaged.
File:10icerf.ex
Update:Tue Mar 4 08:55:59 1997

132 %
*
[ER05100(ALL)02/96]
Spare Tire Location
[ER05600(ALL)01/96]
The spare tire and tools are stored in the rear
luggage compartment, under the carpet and
floorboard.
[ER05700(ALL)01/96]
half page art:0032236-B
The location of the temporary spare tire and jacking
equipment
[ER07500(ALL)01/96]
one third page art:0030145-C
The tool kit in the spare tire compartment
File:10icerf.ex
Update:Tue Mar 4 08:55:59 1997

133 %
*
[ER07600(ALL)03/96]
Preparing to Change the Tire
*
[ER07700(ALL)01/96]
1. Make sure that your vehicle will not move
or roll. If you have an automatic transaxle,
put the gearshift in P (Park). If you have a
manual transaxle, put the gearshift in 1
(First). Set the parking brake and block the
wheel that is diagonally opposite the tire
that you are changing.
[ER08000(ALL)01/96]
half page art:0030148-A
Blocking the wheel diagonally opposite the tire being
changed
*
[ER08090(ALL)01/96]
When one of the front wheels is off the ground,
the transaxle alone will not prevent the vehicle
from moving or slipping off the jack, even if the
vehicle is in P (Park) or 1 (First). To prevent the
vehicle from moving when you change one of
the front tires, put a block behind the wheel that
is diagonally opposite to the tire.
File:10icerf.ex
Update:Tue Mar 4 08:55:59 1997

134
*
[ER08100(ALL)03/96]
WARNING
If the vehicle slips off the jack, you or
someone else could be seriously injured.
*
[ER08250(ALL)01/96]
2. Get out the spare tire and jack.
[ER08275(ALL)04/96]
Remove the wheel lug wrench from the tool
kit. To remove the spare tire, turn the
hold-down bolt counterclockwise with the
wheel lug wrench. To remove the jack, turn
the jack hold-down bolt counterclockwise.
Remove the tire retaining tool from the tool
kit.
[ER08350(ALL)01/96]
3. Remove the wheelcover with the tapered
end of a wheel nut wrench. Insert the handle
of the wrench and twist it against the inner
wheelcover flange. Remove any chrome nuts
or plastic caps covering the wheel lug bolts.
[ER08400(ALL)01/96]
4. Remove the top lug bolt and insert the tire
retaining tool in its place. This will hold the
tire in place when the other lug bolts are
removed.
