86 [SS17600(ALL)02/96]7. Double-check that the retractor is in the
automatic locking mode. Try to pull more
belt out of the retractor. If you cannot, the
belt is in the automatic locking mode. See
Figure 8.
[SS17700(ALL)01/96]
half page art:0032275-A
Checking that retractor is in automatic locking mode
*
[SS17800(ALL)01/96]
8. Check to make sure that the child seat is
properly secured prior to each use. If the
retractor is not locked, repeat steps 4
through 7.
[SS17900(ALL)04/96]
NOTE: To remove the retractor from the
automatic lock mode, unbuckle the belt and
allow the seat belt to retract fully to its stowed
position and the retractor will automatically
switch back to the vehicle sensitive locking
mode for normal adult usage.
File:06icssf.ex
Update:Tue Mar 4 08:54:10 1997

87 %
*
[SS20200(ALL)04/96]
Attaching Safety Seats With Tether Straps
*
[SS20300(ALL)04/96]
Some manufacturers make safety seats that
include a tether strap that goes over the back of
the vehicle seat and attaches to an anchoring
point. Other manufacturers offer the tether strap
as an accessory. Contact the manufacturer of
your child safety seat for information about
ordering a tether strap.
*
[SS20350(ALL)01/96]
Front Seats
*
[SS20400(ALL)01/96]
To install a tether from a child safety seat in the
front seat:
[SS20425(ALL)01/96]
1. Buckle the lap/shoulder belt in the right rear
seat.
*
[SS20450(ALL)01/96]
2. Pull all the stored belt out of the rear seat
retractor to switch the retractor to automatic
locking mode.
*
[SS20500(ALL)03/96]
3. Let the retractor wind up the slack from the
lap/shoulder belt.
*
[SS20525(ALL)01/96]
4. Install the child safety seat in the front seat.
Refer to the previous section onInstalling
Safety Seats. Hook the tether strap hook
around the webbing near the center of the
shoulder portion of the locked lap/shoulder
belt.
*
[SS20550(ALL)05/96]
5. Tighten the tether strap.
*
[SS20575(ALL)08/95]
Rear Seats
*
[SS20600(ALL)08/95]
If you use a tethered safety seat on one of the
rear seats, you can anchor the strap to the
appropriate tether anchor directly behind that
seat position.
File:06icssf.ex
Update:Tue Mar 4 08:54:10 1997

88
*
[SS20650(ALL)01/96]
Tether Anchorage Hardware
[SS20700(ALL)01/96]
All vehicles built for sale in Canada include a
tether anchor hardware kit for use with
Canadian child safety seats.
[SS20725(ALL)04/96]
Vehicles built for sale in the USAdo notinclude
the tether anchor hardware kit, but it can be
obtained at no charge from any Ford or
Lincoln-Mercury dealer.
[SS20750(ALL)01/96]
Your vehicle has two tether attachment locations
in the luggage compartment. To access the tether
attachment locations, you must pry off the caps.
*
[SS20800(ALL)01/96]
Be sure to follow the child safety seat
manufacturer's instructions.
*
[SS20850(ALL)01/96]
WARNING
Tighten the anchor according to
specifications. Otherwise, the safety seat
may not be properly secured and the child
may be injured in a sudden stop or
collision.
File:06icssf.ex
Update:Tue Mar 4 08:54:10 1997

89 [SS20900(ALL)01/96]
half page art:0032241-C
Installing and positioning the anchor bracket
[SS21401(ALL)01/96]
Install the hardware for anchoring the tether
following the instructions in the tether anchorage
hardware kit. When attaching the anchor bracket
to the anchor, position the anchor bracket
straight up.
File:06icssf.ex
Update:Tue Mar 4 08:54:10 1997

90 %
*
[SS24110(ALL)01/96]
Safety Belts for Children
*
[SS24120(ALL)01/96]
Children who are too large for child safety seats
should always wear safety belts. (See instructions
with your child seat, or contact its manufacturer,
to determine maximum size of child that will
safely fit in the seat.)
*
[SS24130(ALL)01/96]
WARNING
If safety belts are not properly worn and
adjusted as described, the risk of serious
injury to the child in a collision will be
much greater.
*
[SS24140(ALL)01/96]
If the shoulder belt portion of one of the lap and
shoulder belts can be positioned so that it does
not cross or rest in front of the child's face or
neck, the child should wear the lap and shoulder
belt. Moving the child closer to the center of the
vehicle may help provide a good shoulder belt
fit.
File:06icssf.ex
Update:Tue Mar 4 08:54:10 1997

91
*
[SS24150(ALL)01/96]
To improve the fit of lap and shoulder belts on
children who have outgrown child safety seats,
Ford recommends use of a belt-positioning
booster seat that is labelled as conforming to all
Federal motor vehicle safety standards.
Belt-positioning booster seats raise the child and
provide a shorter, firmer seating cushion that
encourages safer seating posture and better fit of
lap and shoulder belts on the child. A
belt-positioning booster should be used if the
shoulder belt rests in front of the child's face or
neck, or if the lap belt does not fit snugly on
both thighs, or if the thighs are too short to let
the child sit all the way back on the seat cushion
when the lower legs hang over the edge of the
seat cushion. You may wish to discuss the
specific needs of your child with your
pediatrician.
*
[SS24160(ALL)01/96]
WARNING
Do not use a belt-positioning booster with
a lap-only belt.
*
[SS24170(ALL)01/96]
Lap belts and the lap belt portion of lap and
shoulder belts should always be worn snugly
and below the hips, touching the child's thighs.
File:06icssf.ex
Update:Tue Mar 4 08:54:10 1997

93
Starting
%*
[TO04100(ALL)01/96]
Fuel-Injected Engines
*
[TO04200(ALL)01/96]
When starting a fuel-injected engine,the most
important thing to remember is to avoid
pressing down on the accelerator before or
during starting. Only use the accelerator when
you have problems getting your vehicle started.
SeeStarting Your Enginein this chapter for
details about when to use the accelerator while
you start your vehicle.
*
[TO04500(ALL)01/96]
Starting Your Vehicle
%*
[TO05000(ALL)01/96]
Preparing to Start Your Vehicle
*
[TO05100(ALL)02/96]
WARNING
Do not start your vehicle in a closed
garage or in other enclosed areas. Exhaust
fumes can be toxic. Always open the
garage door before you start the engine.
*
[TO05200(ALL)01/96]
Before you start your vehicle, do the following:
*
[TO05300(ALL)01/96]
1. Make sure all occupants in the vehicle
buckle their safety belts. SeeSafety Restraints
in the Index for more details.
*
[TO05400(ALL)01/96]
2. Make sure the headlamps and other
accessories are turned off when starting.
File:08ictof.ex
Update:Tue Mar 4 08:54:32 1997

94
*
[TO05500(ALL)01/96]
3.If you have an automatic transaxle, make
sure that the gearshift is in P (Park) and the
parking brake is set before you turn the key.
*
[TO05600(ALL)01/96]
If you have a manual transaxle, make sure
that the parking brake is fully set, push the
clutch pedal to the floor, and put the
gearshift into Neutral before you turn the
key.(Remember, the starter will operate
only if the clutch pedal is pushed all the
way to the floor.)
*
[TO05800(ALL)02/96]
Before you start your vehicle, you should test
the warning lights on the instrument panel to
make sure that they work. Refer to the
Instrumentationchapter.
%*
[TO06000(ALL)01/96]
Starting Your Engine
*
[TO06100(ALL)01/96]
To start your engine:
*
[TO06300(ALL)01/96]
1. Follow the steps underPreparing to Start
Your Vehicleat the beginning of this section.
*
[TO06320(ALL)01/96]
2. Keep your foot on the brake pedal and turn
the ignition key to the ON position.
*
[TO06330(ALL)01/96]
3. DO NOT depress the accelerator pedal when
starting your engine. DO NOT use the
accelerator while the vehicle is parked.
*
[TO06340(ALL)01/96]
4. Turn the key to the START position
(cranking) until the engine starts. Allow the
key to return to the ON position after the
engine has started.
*
[TO06400(ALL)01/96]
If you have difficulty in turning the key,
rotate the steering wheel slightly because it
may be binding.
