1996 TOYOTA RAV4 Vacuum

BR02G−04
BR−2
− BRAKETROUBLESHOOTING
1996 RAV4 (RM447U)
TROUBLESHOOTING
PROBLEM SYMPTOMS TABLE
Use the table below to help you find the cause of the problem. The numbers indicate the priority of the likely
cause of the problem. Check each part in order. If necessary, replace these parts.
SymptomSuspect AreaSee page
Lower pedal or spongy pedal
1. Brake system (Fluid leaks)
2. Brake system (Air in)
3. Piston seals (Worn or damaged)
4. Rear Brake shoe clearance (Out of adjustment)
5. Master cylinder (Faulty)
6. Booster push rod (Out of adjustment)DI−282
−
BR−23
BR−33
BR−9
BR−19
Brake drag
1. Brake pedal freeplay (Minimal)
2. Parking brake lever travel (Out of adjustment)
3. Parking brake wire (Sticking)
4. Rear brake shoe clearance (Out of adjustment)
5. Pad or lining (Cracked or distorted)
6. Piston (Stuck)
7. Piston (Frozen)
8. Anchor or return spring (Faulty)
9. Booster push rod (Out of adjustment)
10. Booster system (Vacuum leaks)
11. Master cylinder (Faulty)BR−6
BR−8
−
BR−33
BR−20
BR−29
BR−23
BR−23
BR−29
BR−29
BR−19
BR−16
BR−9
Brake pull
1. Piston (Stuck)
2. Pad or lining (Oily)
3. Piston (Frozen)
4. Disc (Scored)
5. Pad or lining (Cracked or distorted)BR−23
BR−20
BR−29
BR−23
BR−29
BR−20
BR−20
BR−29

− BRAKETROUBLESHOOTING
BR−3
1996 RAV4 (RM447U) Hard pedal but brake inefficient
1. Brake system (Fluid leaks)
2. Brake system (Air in)
3. Pad or lining (Worn)
4. Pad or lining (Cracked or distorted)
5. Rear brake shoe clearance (Out of adjustment)
6. Pad or lining (Oily)
7. Pad or lining (Glazed)
8. Disc (Scored)
9. Booster push rod (Out of adjustment)
10. Booster system (Vacuum leaks)DI−282
−
BR−20
BR−29
BR−20
BR−29
BR−33
BR−20
BR−29
BR−20
BR−29
BR−23
BR−19
BR−16
Noise from brake
1. Pad or lining (Cracked or distorted)
2. Installation bolt (Loose)
3. Disc (Scored)
4. Pad support plate (Loose)
5. Sliding pin (Worn)
6. Pad or lining (Dirty)
7. Pad or lining (Glazed)
8. Anchor or return spring (Faulty)
9. Anti−squeal shim (Damage)
10. Hold−down spring (Damage)BR−20
BR−29
BR−23
BR−23
BR−23
BR−23
BR−20
BR−29
BR−20
BR−29
BR−29
BR−20
BR−29

R10851
Pedal Height Push RodStop Light
Switch
BR1DV−01
BR4980
R00935
Pedal Freeplay BR−6
− BRAKEBRAKE PEDAL
1996 RAV4 (RM447U)
BRAKE PEDAL
ON−VEHICLE INSPECTION
1. CHECK PEDAL HEIGHT
Pedal height from asphalt sheet:
157.1 − 167.1 mm (6.185 − 6.579 in.)
If the pedal height is incorrect, adjust it.
2. IF NECESSARY, ADJUST PEDAL HEIGHT
(a) Disconnect the connector from the stop light switch.
(b) Loosen the stop light switch lock nut and remove the stop
light switch.
(c) Loosen the push rod lock nut.
(d) Adjust the pedal height by turning the pedal push rod.
(e) Tighten the push rod lock nut.
Torque: 25 N·m (260 kgf·cm, 19 ft·lbf)
(f) Install the stop light switch and turn it until it lightly con-
tacts with the pedal stopper.
(g) Turn the stop light switch back one turn.
(h) Check the clearance (A) between stop light switch and
pedal.
Clearance: 0.5 − 2.4 mm (0.020 − 0.094 in.)
(i) Tighten the stop light switch lock nut.
(j) Connect the connector to the stop light switch.
(k) Check that the stop lights come on when the brake pedal
is depressed, and go off when the brake pedal is re-
leased.
(l) After adjusting the pedal height, check the pedal freeplay.
HINT:
If clearance (A) between the stop light switch and the brake
pedal stopper has been adjusted correctly, the pedal freeplay
will meet the specifications.
3. CHECK PEDAL FREEPLAY
(a) Stop the engine and depress the brake pedal several
times until there is no more vacuum left in the booster.
(b) Push in the pedal by hand until the resistance begins to
be felt, then measure the distance, as shown.
Pedal freeplay: 1 − 6 mm (0.04 − 0.24 in.)

BR02S−02
R10718
BR−18
− BRAKEBRAKE BOOSTER ASSEMBLY
1996 RAV4 (RM447U)
REMOVAL
1. REMOVE MASTER CYLINDER (See page BR−9)
2. REMOVE CHARCOAL CANISTER
3. DISCONNECT VACUUM HOSE FROM BRAKE
BOOSTER
4. REMOVE PEDAL RETURN SPRING
5. REMOVE CLIP AND CLEVIS PIN
6. REMOVE BRAKE BOOSTER
(a) Remove the 4 nuts and clevis.
(b) Pull out the brake booster and gasket.

BR0M3−01
F03521
SST
Gasket
N00744
SST
− BRAKEBRAKE BOOSTER ASSEMBLY
BR−19
1996 RAV4 (RM447U)
INSTALLATION
1. INSTALL BRAKE BOOSTER
(a) Install the booster and a new gasket.
(b) Install the clevis to the operating rod.
(c) Install and torque the booster installation nuts.
Torque:
13 N·m (130 kgf·cm, 9 ft·lbf)
(d) Insert the clevis pin into clevis, brake pedal, and install the
clip to the clevis pin.
(e) Install the pedal return spring.
2. ADJUST LENGTH OF BOOSTER PUSH ROD
(a) Install a new gasket on the master cylinder.
(b) Set the SST on the gasket, and lower the pin until its tip
slightly touches the piston.
SST 09737−00010
(c) Turn the SST upside down, and set it on the booster.
SST 09737−00010
(d) Measure the clearance between the booster push rod
and pin head (SST).
Clearance: 0 mm (0 in.)
(e) Adjust the booster push rod length until the push rod
slightly touches the pin head.
3. INSTALL CHARCOAL CANISTER TO ORIGINAL POSI-
TION
4. INSTALL MASTER CYLINDER
5. CONNECT VACUUM HOSE TO BRAKE BOOSTER
6. FILL BRAKE RESERVOIR WITH BRAKE FLUID AND
BLEED BRAKE SYSTEM (See page BR−4)
7. M/T:
BLEED CLUTCH SYSTEM
8. CHECK FOR LEAKS
9. CHECK AND ADJUST BRAKE PEDAL
(See page BR−6)
Check and adjust the brake pedal, then tighten the clevis lock
nut.
Torque:
25 N·m (260 kgf·cm, 19 ft·lbf)
10. DO OPERATIONAL CHECK (See page BR−16)

CO0BO−02
Z00570
Radiator Cap Tester
Radiator Cap30° or More
S01265
Radiator Cap Tester CO−14
− COOLINGRADIATOR
1996 RAV4 (RM447U)
ON−VEHICLE INSPECTION
1. REMOVE RADIATOR CAP
CAUTION:
To avoid the danger of being burned, do not remove the ra-
diator cap while the engine and radiator are still hot, as fluid
and steam can be blown out under pressure.
2. INSPECT RADIATOR CAP
NOTICE:
If the radiator cap has contaminations, always rinse
it with water.
When performing steps (a) and (b) below, keep the ra-
diator cap tester at an angle of over 30°above the hor-
izontal.
(a) Using a radiator cap tester, slowly pump the tester and
check that air is coming from the vacuum valve.
Pump speed:
1 push/(3 seconds or more)
NOTICE:
Push the pump at a constant speed.
If air is not coming from the vacuum valve, replace the radiator
cap.
(b) Pump the tester and measure the relief valve opening
pressure.
Pump speed:
1 push within 1 second
NOTICE:
This pump speed is for the first pump only (in order to close
the vacuum valve). After this, the pump speed can be re-
duced.
Standard opening pressure:
74 − 103 kPa (0.75 − 1.05 kgf/cm
2, 10.7 − 14.9 psi)
Minimum opening pressure:
59 kPa (0.6 kgf/cm
2, 8.5 psi)
HINT:
Use the tester’s maximum reading as the opening pressure.
If the opening pressure is less than minimum, replace the radia-
tor cap.
3. INSPECT COOLING SYSTEM FOR LEAKS
(a) Fill the radiator with coolant and attach a radiator cap tes-
ter.
(b) Warm up the engine.
(c) Pump it to 118kPa (1.2 kgf/cm
2, 17.1 psi), and check that
the pressure does not drop.
If the pressure drops, check the hoses, radiator or water pump
for leaks. If no external leaks are found, check the heater core,
cylinder block and cylinder head.
4. REINSTALL RADIATOR CAP

− DIAGNOSTICSENGINE
DI−15
1996 RAV4 (RM447U) DTC No.
(See Page)
Detection ItemTrouble AreaMILMemory
P0172
(DI−48)System too Rich
(Fuel Trim)
Fuel line pressure
Injector blockage, leak
Oxygen sensor malfunction
Manifold absolute pressure sensor
Engine coolant temp. sensor
 *1
P0300
(DI−51)Random / Multiple
Cylinder Misfire DetectedIgnition system
Injector
Fuel line pressure
EGR
Compression pressure
Valve clearance not to specification
Valve timing
Manifold absolute pressure sensor
Engine coolant temp. sensor
 *2P0301
P0302
P0303
P0304
(DI−51)Misfire Detected
− Cylinder 1
− Cylinder 2
− Cylinder 3
− Cylinder 4
P0325
(DI−56)Knock Sensor 1 Circuit
MalfunctionOpen or short in knock sensor 1 circuit
Knock sensor 1 (looseness)
ECM
 *1
P0335
(DI−59)Crankshaft Position Sensor
”A” Circuit Malfunction
Open or short in crankshaft position sensor circuit
Crankshaft position sensor
Starter
ECM
 *1
P0336
(DI−62)Camshaft Position Sensor
Circuit Range / PerformanceDistributor
ECM malfunction (for back up) *1
P0340
(DI−63)Camshaft Position Sensor
Circuit Malfunction
Open or short in camshaft position sensor circuit
Camshaft position sensor
Starter
ECM
 *1
P0401
(DI−65)Exhaust Gas Recirculation
Flow Insufficient Detected
EGR valve stuck close
Open or short in VSV circuit for EGR
Vacuum or EGR hose disconnected
Manifold absolute pressure sensor
EGR VSV open or close malfunction
ECM
 *1
P0402
(DI−71)Exhaust Gas Recirculation
Flow Excessive Detected
EGR valve stuck open
Vacuum or EGR hose is connected to wrong post
Manifold absolute pressure sensor
ECM
 *1
P0420
(DI−73)Catalyst System Efficiency
Below ThresholdThree−way catalytic converter
Open or short in oxygen sensor circuit
Oxygen sensor
 *1
P0440
(DI−76)Evaporative Emission Control
System Malfunction
Vapor pressure sensor
Fuel tank cap incorrectly installed
Fuel tank cap cracked or damaged
Vacuum hose cracked, holed, blocked, damaged or
disconnected
Hose or tube cracked, holed, damaged or loose
Fuel tank cracked, holed, or damaged
Charcoal canister cracked, holed or damaged
 *1
*1: MIL lights up
*
2: MIL lights up or blinking

DI−16
− DIAGNOSTICSENGINE
1996 RAV4 (RM447U) DTC No.
(See Page)
Detection ItemTrouble AreaMILMemory
P0441
(DI−82)Evaporative Emission Control
System Incorrect Purge Flow
Open or short in VSV circuit for vapor pressure sensor
VSV for vapor pressure sensor
Open or short in vapor pressure sensor circuit
Vapor pressure sensor
Open or short in VSV circuit for EVAP
VSV for EVAP
Vacuum hose cracked, holed, blocked, damaged or
disconnected
Charcoal canister cracked, holed or damaged
 *1
P0446
(DI−82)Evaporative Emission Control
System Vent Control
Malfunction
P0450
(DI−92)Evaporative Emission Control
System Pressure Sensor
MalfunctionOpen or short in vapor pressure sensor circuit
Vapor pressure sensor
ECM
 *1
P0500
(DI−94)Vehicle Speed Sensor
Malfunction
Open or short in vehicle speed sensor circuit
Vehicle speed sensor
Combination meter
ECM
 *1
P0505
(DI−97)Idle Control System Malfunction
IAC valve is stuck or closed
Open or short in IAC valve circuit
Open or short AC1 single circuit
Air intake (hose loose)
 *1
*1: MIL lights up
MANUFACTURER DEFINED
DTC No.
(See Page)Detection ItemTrouble AreaMILMemory
P1300
(DI−100)Ignition Circuit Malfunction
Open or short in IGF or IGT circuit from igniter to ECM
Igniter
ECM
 *1
P1500
(DI−105)Starter Signal Circuit Malfunction
Open or short in starter signal circuit
Open or short in ignition switch or starter relay circuit
ECM
 *1
P1600
(DI−108)ECM BATT MalfunctionOpen in back up power source circuit
ECM *1
P1780
(DI−11 0)Park / Neutral Position Switch
MalfunctionShort in park / neutral position switch circuit
Park / neutral position switch
ECM
 *1
*1: MIL lights up
