7. AUTO CANCEL FUNCTION
A) IF ANY OF THE FOLLOWING OPERATING CONDITIONS OCCURS DURING CRUISE CONTROL OPERATION, THE SET SPEED IS
ERASED, CURRENT FLOW TO THE MAGNETIC CLUTCH IS STOPPED AND THE CRUISE CONTROL IS RELEASED. (MAIN SW TURNS
OFF).
WHEN THIS OCCURS, THE IGNITION SW MUST BE TURNED OFF ONCE BEFORE THE MAIN SW WILL TURN ON.
*WHEN CURRENT CONTINUED TO FLOW TO THE MOTOR INSIDE THE ACTUATOR IN THE THROTTLE VALVE OPENº DIRECTION.
*THE MOTOR DOES NOT OPERATE DESPITE THE MOTOR DRIVE SIGNAL BEING OUTPUT.
B) IF ANY OF THE FOLLOWING OPERATING CONDITIONS OCCURS DURING CRUISE CONTROL OPERATION, THE SET SPEED IS
ERASED, CURRENT FLOW TO THE MAGNETIC CLUTCH IS STOPPED AND THE CRUISE CONTROL IS RELEASED. (MAIN SW TURN
OFF).
WHEN THIS OCCURS, THE CANCEL STATE IS CLEARED AS THE MAIN SW WILL TURN ON AGAIN.
*OVER CURRENT TO TRANSISTOR DRIVING THE MOTOR AND/OR THE MAGNETIC CLUTCH.
*OPEN CIRCUIT IN THE MAGNETIC CLUTCH.
*MOMENTARY INTERRUPTION OF VEHICLE SPEED SIGNAL.
*SHORT CIRCUIT IN THE CRUISE CONTROL SW.
*WHEN THE VEHICLE SPEED FALLS MORE THAN 16 KM/H (10 MPH) BELOW THE SET SPEED, E.G. ON AN UPWARD SLOPE.
C) IF ANY OF THE FOLLOWING CONDITIONS OCCURS DURING CRUISE CONTROL OPERATION, THE SET SPEED IS ERASED AND
THE CRUISE CONTROL IS RELEASED. (THE POWER TO THE MAGNETIC CLUTCH IS CUT OFF UNTIL THE SET SW IS ONº AGAIN.)
*WHEN THE VEHICLE SPEED FALLS BELOW THE MINIMUM SPEED LIMIT, APPROX. 40 KM/H (25 MPH)
*WHEN POWER TO THE CRUISE CONTROL SYSTEM IS MOMENTARILY CUT OFF.
D) IF ANY OF THE FOLLOWING CONDITIONS OCCURS DURING CRUISE CONTROL OPERATION, THE CRUISE CONTROL IS
RELEASED.
*OPEN THE CIRCUIT FOR TERMINAL 2 OF THE STOP LIGHT SW.
8. AUTOMATIC TRANSMISSION CONTROL FUNCTION
*IN OVERDRIVE, IF THE VEHICLE SPEED BECOMES LOWER THAN THE OVERDRIVE CUT SPEED (SET SPEED MINUS APPROX. 4
KM/H, 2.5 MPH) DURING CRUISE CONTROL OPERATION, SUCH AS DRIVING UP A HILL, THE OVERDRIVE IS RELEASED AND THE
POWER INCREASED TO PREVENT A REDUCTION IN VEHICLE SPEED.
*AFTER RELEASING THE OVERDRIVE, VEHICLE SPEED BECOMES HIGHER THAN THE OVERDRIVE RETURN SPEED (SET SPEED
MINUS APPROX. 2 KM/H, 1.2 MPH) AND THE ECU JUDGES BY THE SIGNALS FROM THE ACTUATOR'S POTENTIOMETER THAT THE
UPWARD SLOPE HAS FINISHED, THE OVERDRIVE IS RESUMED AFTER APPROXIMATELY 2 SECONDS.
*DURING CRUISE CONTROL DRIVING, THE CRUISE CONTROL OPERATION SIGNAL IS OUTPUT FROM THE CRUISE CONTROL
ECU TO THE ENGINE CONTROL MODULE. UPON RECEIVING THIS SIGNAL, THE ENGINE CONTROL MODULE CHANGES THE SHIFT
PATTERN TO NORMAL.
TO MAINTAIN SMOOTH CRUISE CONTROL OPERATION (ON A DOWNWARD SLOPE ETC.), THE LOCK-UP RELEASE OF THE
TRANSMISSION WHEN THE IDLING POINT OF THE THROTTLE POSITION IS ONº IS FORBIDDEN.
C 3 CRUISE CONTROL ACTUATOR
1-3 : APPROX. 2 KW
5-4 : APPROX. 38 W
C12 CRUISE CONTROL SW [COMB. SW]
5-3 : CONTINUITY WITH THE CRUISE MAIN SW ON
4-3 : APPROX. 418 W WITH THE CANCEL SW ON
APPROX. 68 W WITH THE SET/COAST SW ON
APPROX. 198W WITH THE RESUME/ACCEL SW ON
C16 CRUISE CONTROL ECU
14-GROUND : APPROX. 12 VOLTS WITH THE IGNITION SW AT ON POSITION
15-GROUND : ALWAYS APPROX. 12 VOLTS
20-GROUND :4 PULSES WITH 1 ROTATION OF THE ROTOR SHAFT
18-GROUND : APPROX. 418 W WITH THE CANCEL SW ON IN THE CONTROL SW
APPROX. 198 W WITH THE SET/COAST SW ON IN THE CONTROL SW
APPROX. 68 W WITH THE RESUME/ACCEL SW ON IN THE CONTROL SW
13-GROUND : ALWAYS CONTINUITY
SERVICE HINTS

150
CRUISE CONTROL
: PARTS LOCATION
CODESEE PAGECODESEE PAGECODESEE PAGE
C 328E 4A31P1A29
C 930E 6B31P 1B29
C1230F 831S 531
C1530J 731V 229
C1630J10A31
D 128J11B31
: RELAY BLOCKS
CODESEE PAGERELAY BLOCKS (RELAY BLOCK LOCATION)
223R/B NO. 2 (ENGINE COMPARTMENT LEFT)
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
CODESEE PAGEJUNCTION BLOCK AND WIRE HARNESS (CONNECTOR LOCATION)
1A20INSTRUMENT PANEL WIRE AND J/B NO 1 (LOWER FINISH PANEL)1B20INSTRUMENT PANEL WIRE AND J/B NO. 1 (LOWER FINISH PANEL)
1E20FUSE BLOCK ASSY WIRE AND J/B NO 1 (LOWER FINISH PANEL)1F20FUSE BLOCK ASSY WIRE AND J/B NO. 1 (LOWER FINISH PANEL)
1G
1H20INSTRUMENT PANEL WIRE AND J/B NO 1 (LOWER FINISH PANEL)1I20INSTRUMENT PANEL WIRE AND J/B NO. 1 (LOWER FINISH PANEL)
1J
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
CODESEE PAGEJOINING WIRE HARNESS AND WIRE HARNESS (CONNECTOR LOCATION)
EA134ENGINE WIRE AND ENGINE ROOM MAIN WIRE (INSIDE OF R/B NO. 2)
IB136ENGINE ROOM MAIN WIRE AND INSTRUMENT PANEL WIRE (LEFT KICK PANEL)
IB236ENGINE ROOM MAIN WIRE AND INSTRUMENT PANEL WIRE (RIGHT KICK PANEL)
IG138ENGINE WIRE AND INSTRUMENT PANEL WIRE (UNDER THE INSTRUMENT PANEL CENTER)IG238ENGINE WIRE AND INSTRUMENT PANEL WIRE (UNDER THE INSTRUMENT PA N E L CENTER)
: GROUND POINTS
CODESEE PAGEGROUND POINTS LOCATION
ID36LEFT KICK PANEL
IG36RIGHT KICK PANEL
: SPLICE POINTS
CODESEE PAGEWIRE HARNESS WITH SPLICE POINTSCODESEE PAGEWIRE HARNESS WITH SPLICE POINTS
I538ENGINE WIREI 838INSTRUMENT PANEL WIRE
I738INSTRUMENT PANEL WIREI1138INSTRUMENT PANEL WIRE

152
COMBINATION METER
AUGE
BLOCK] FROM POW ER SOURCE SYSTEM (
SEE PAGE 54)
IG 1 2B1
IF EC
TAC HO
FU EL
WATER TEMP. FU EL
MALFUNCTION
INDICATOR LAMP
OIL
AB S
A 8
A 11 A10 C6B6A13 A12 B5B4A9B8B7
R R-L R-L
L- B
R-Y
B
R- L
Y-R
BR
BR
Y-G
G-R
Y-R
R-Y R-L R- L
TO ABS ECU
ESSURE SPEEDCO M BIN ATIO N M ETERB C 9 , C10AC, C 1 1
A 2
V-W
FROM ENGINE CO NTRO L
MODULE
A C
B BBB JUNCTION
CONNECTORB J10 , J11A
CRUISE
A 6
G-R
TO CRUISE CONTROL
ECU
A G
USE
-L
8 3
D D
IG 2 9IG210
IG 2 8ID 1 5ID19IG27IG26IG25I10
ID 11011 1
BR 3 23
12
L- B
R-Y
B
R- L
Y- R Y-B
BR
Y-G
Y-R
R-Y BR
BR BRB
VEHICLE SPEED SENSOR
(
COM BINATION METER)
JU NC TIO N
CONNECTOR
V
J 4
TO ENGINE
CONTROL MODULE
IL PR
W
W ATER TEMP. SENDER
1
UB) F11
F12 FROM IGNITER-
1E 8
1B 8R L
2FUEL SENDE R (
S
FUEL SENDER (
MA IN)
1
2
O
S O
W 1
10
[F
4F

155
B 2 BRAKE FLUID LEVEL WARNING SW
1-2 : CLOSED WITH THE FLOAT DOWN
P 2 PARKING BRAKE SW
1-GROUND : CLOSED WITH THE PARKING BRAKE LEVER PULLED UP
O 1 OIL PRESSURE SW
1-GROUND : CLOSED WITH THE OIL PRESSURE ABOVE APPROX. 20 KPA (2.8 PSI, 0.2 KG/CM2)W 1 WATER TEMP. SENDER
1-GROUND : APPROX. 160-240 W (50
C, 122
F)
APPROX. 17.1-21.2 W (120
C, 288
F)
F11 FUEL SENDER (MAIN)
2-3 : APPROX. 3 W AT FUEL FULL
APPROX. 11 0 W AT FUEL EMPTY
C 9 (A), C10 (B), C11 (C) COMBINATION METER
(A) 8, (C) 9-GROUND : APPROX. 12 VOLTS WITH THE IGNITION SW AT ON POSITION
(A) 12, (B) 2, (B) 5-GROUND : ALWAYS CONTINUITY
(C) 2-GROUND : ALWAYS APPROX. 12 VOLTS
: PARTS LOCATION
CODESEE PAGECODESEE PAGECODESEE PAGE
A 528F1232 (2-DOOR), 33 (4-DOOR)J10A31
B 228J 131J11B31
C9A30J 431O 129
C10B30J 531P 231
C11C30J 731V 229
F 831J 8A31W 129
F 1132 (2-DOOR), 33 (4-DOOR)J 9B31
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
CODESEE PAGEJUNCTION BLOCK AND WIRE HARNESS (CONNECTOR LOCATION)
1B20INSTRUMENT PANEL WIRE AND J/B NO 1(LOWER FINISH PANEL)1C20INSTRUMENT PANEL WIRE AND J/B NO. 1(LOWER FINISH PANEL)
1E20FUSE BLOCK ASSY WIRE AND J/B NO. 1 (LOWER FINISH PANEL)
1G
1I20INSTRUMENT PANEL WIRE AND J/B NO 1 (LOWER FINISH PANEL)1J20INSTRUMENT PANEL WIRE AND J/B NO. 1 (LOWER FINISH PANEL)
1M
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
CODESEE PAGEJOINING WIRE HARNESS AND WIRE HARNESS (CONNECTOR LOCATION)
IB136ENGINE ROOM MAIN WIRE AND INSTRUMENT PANEL WIRE (LEFT KICK PANEL)
ID136FLOOR WIRE AND INSTRUMENT PANEL WIRE (LEFT KICK PANEL)
IG138ENGINE WIRE AND INSTRUMENT PANEL WIRE (UNDER THE INSTRUMENT PANEL CENTER)IG238ENGINE WIRE AND INSTRUMENT PANEL WIRE (UNDER THE INSTRUMENT PANEL CENTER)
: GROUND POINTS
CODESEE PAGEGROUND POINTS LOCATION
EA34RADIATOR RIGHT
EC34INTAKE MANIFOLD
IF36INSTRUMENT PANEL BRACE RH
IG36RIGHT KICK PANEL
SERVICE HINTS

159
FAN MOTOR OPERATION
WHEN THE IGNITION SW IS TURNED ON, CURRENT FROM THE ECU-IG FUSE FLOWS TO THE FAN NO. 1 RELAY (COIL SIDE) AND
THE FAN NO. 2 RELAY (COIL SIDE) "TERMINAL 2 OF THE A/C SINGLE PRESSURE SW "TERMINAL 3 "TERMINAL 2 OF THE A/C
WATER TEMP. SW "TERMINAL 1 "GROUND, AND THE FAN NO. 1 RELAY AND THE FAN NO. 2 RELAY ARE TURNED ON.
AT THE SAME TIME THAT THIS CURRENT FLOWS, CURRENT FROM THE ECU-IG FUSE FLOWS TO THE E/G MAIN RELAY (COIL
SIDE) "GROUND, AND THE E/G MAIN RELAY IS TURNED ON. AS A RESULT, CURRENT FROM THE ALT FUSE FLOWS TO THE CDS
FA N FUSE AND RDI FAN FUSE.
*LOW SPEED OPERATION
WHEN THE IGNITION SW IS TURNED ON AND THE A/C IS ACTIVATED, CURRENT FLOWS FROM THE MG/C RELAY (POINT SIDE) "
THE FAN NO. 3 RELAY (COIL SIDE) "GROUND, AND THE FAN NO. 3 RELAY IS TURNED ON. AS A RESULT, CURRENT FROM THE
CDS FAN FUSE FLOWS TO TERMINAL 2 OF THE A/C CONDENSER FAN MOTOR "TERMINAL 1 "THE FAN NO. 2 RELAY (POINT
SIDE) "THE FAN NO. 3 RELAY (POINT SIDE) "TERMINAL 2 OF THE RADIATOR FAN MOTOR "TERMINAL 1 "GROUND, AND
BOTH OF THE FAN MOTORS, WITH THE RESULT THAT THE FANS ARE ACTIVATED AT LOW SPEED.
IF THE ENGINE COOLANT TEMPERATURE IS APPROX. 90
C (194
F) OR LESS, AND THE REFRIGERANT PRESSURE IS APPROX.
15.5 KG/CM
2 (1323 KPA, 191.7 PSI) OR LESS, BOTH THE A/C WATER TEMP. SW AND THE A/C SINGLE PRESSURE SW ARE CLOSED,
SO THAT THE FAN NO. 1 RELAY AND THE FAN NO. 2 RELAY ARE TURNED ON. AS A RESULT, BOTH OF THE FAN MOTOR OPERATE
AT LOW SPEED.
*HIGH SPEED OPERATION
WHEN, DURING A/C OPERATION, THE REFRIGERANT PRESSURE BECOMES HIGHER THAN ORDINARY LEVEL (APPROX. 15.5
KG/CM
2 (1323 PSI. 191.7 KPA)), THE A/C SINGLE PRESSURE SW IS TURNED OFF. AS A RESULT, THE FAN NO. 1 RELAY AND THE
FAN NO. 2 RELAY ARE TURNED OFF, AND THE CURRENT FLOWS FROM THE RDI FAN FUSE TO FAN NO. 1 RELAY (POINT SIDE) "
TERMINAL 2 OF THE RADIATOR FAN MOTOR "TERMINAL 1 "GROUND, AND CURRENT FROM THE CDS FAN FUSE FLOWS TO
TERMINAL 2 OF THE A/C CONDENSER FAN MOTOR "TERMINAL 1 "THE FAN NO. 2 RELAY (POINT SIDE) "GROUND, AND TO
BOTH OF THE FAN MOTORS IN PARALLEL, THUS CAUSING THE FAN MOTORS TO OPERATE AT HIGH SPEED.
NOTE THAT, BECAUSE THE CURRENT FLOWS IN THE SAME MANNER EVEN IF THE COOLANT TEMPERATURE IS APPROX. 90
C
(194
F) OR HIGHER, THE FAN MOTORS STILL OPERATE AT HIGH SPEED.
A 3 A/C SINGLE PRESSURE SW
2-3 : OPEN ABOVE APPROX. 15.5 KG/CM2 (191.7 PSI, 1323 KPA)
CLOSE BELOW APPROX. 12.5 KG/CM2 (142 PSI, 980 KPA)A 4 A/C WATER TEMP. SW
1-2 : OPEN ABOVE APPROX. 90
C (194
F)
CLOSED BELOW APPROX. 83
C (181.4
F)
: PARTS LOCATION
CODESEE PAGECODESEE PAGECODESEE PAGE
A 128F 728R 129
A 328F 831
A 428J 131
: RELAY BLOCKS
CODESEE PAGERELAY BLOCKS (RELAY BLOCK LOCATION)
223R/B NO. 2 (ENGINE COMPARTMENT LEFT)
625R/B NO. 6 (ENGINE COMPARTMENT LEFT)
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
CODESEE PAGEJUNCTION BLOCK AND WIRE HARNESS (CONNECTOR LOCATION)
1A20INSTRUMENT PANEL WIRE AND J/B NO.1 (LOWER FINISH PANEL)
1E20FUSE BLOCK ASSY WIRE AND J/B NO. 1 (LOWER FINISH PANEL)
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
CODESEE PAGEJOINING WIRE HARNESS AND WIRE HARNESS (CONNECTOR LOCATION)
IB236ENGINE ROOM MAIN WIRE AND INSTRUMENT PANEL WIRE (RIGHT KICK PANEL)
: GROUND POINTS
CODESEE PAGEGROUND POINTS LOCATION
EA34RADIATOR RIGHT
EB34RADIATOR LEFT
SYSTEM OUTLINE
SERVICE HINTS

161
EA1 6 25
66 B-L
B-L
W-BB-L
B- RL-BB-L
Y
G-
A/C AM PLIFIER A12R-W
TO FAN NO. 3
RELAY E 1
1366 B- L
B-L
W
B- L
MG/C RELAYI 7 YY EFROSTER
ODE SW3
1
2 1 3
B- RB- LW-R
A/C DUAL PRESSURE SW
TC H A 3
A 2
1 2IG 2 3IG24
IB 2 11 IB212 4L
BR BR
W-RBR
BR
W-R
Y
G-W
R-Y
Y-G
B L-B L-Y W-B
L-Y
L-B
A/C THERMISTOR A14
JU NC TIO N
CO NNECTO R J 3
IG 2 84
D D ENGINE CONTROL
MODULE E 6IG NITE R
JUNCTION
CO OR J 4
BB
I 2
OFF
ON
4 5 6
A/C CONTROL SW A13
1 2
D
M D
A/C M AG NETIC CLU
AND LOCK SENSOR
EX T
10 21
NNECT
ACT A C1
4 1 7 10 8 14 13 9 12 2 5
E IG+ M G C TE SS R- SSR+ A/C LE D+ ACT A C1 IG-
A
A
A

162
AIR CONDITIONING
HEATER BLOWER MOTOR OPERATION
CURRENT IS APPLIED AT ALL TIMES THROUGH THE HTR FUSE TO TERMINAL 5 OF THE HEATER RELAY.
WHEN THE IGNITION SW IS TURNED ON, CURRENT FLOWS THROUGH THE GAUGE FUSE TO TERMINAL 1 OF THE HEATER RELAY
"THE COIL "TERMINAL 3 "TERMINAL 5 OF THE BLOWER SW.
*LOW SPEED OPERATION
WHEN THE BLOWER SW IS MOVED TO LO POSITION, THE CURRENT FLOWS TO TERMINAL 5 OF THE BLOWER SW "TERMINAL 6
"GROUND, CAUSING THE HEATER RELAY TO SWITCH ON. THIS CAUSES THE CURRENT TO FLOW FROM THE HTR FUSE "
TERMINAL 5 OF THE HEATER RELAY "TERMINAL 4 "TERMINAL 1 OF THE BLOWER MOTOR "TERMINAL 2 "TERMINAL 1 OF
THE BLOWER RESISTOR "TERMINAL 4 "GROUND, CAUSING THE BLOWER MOTOR TO ROTATE AT LOW SPEED.
*MEDIUM SPEED OPERATION (OPERATION AT M1, M2)
WHEN THE BLOWER SW IS MOVED TO M1 POSITION, THE CURRENT FLOWING TO TERMINAL 5 OF THE BLOWER SW "
TERMINAL 6 "GROUND, TURNS THE HEATER RELAY ON. THIS CAUSES THE CURRENT TO FLOW FROM THE HTR FUSE "
TERMINAL 5 OF THE HEATER RELAY "TERMINAL 4 "TERMINAL 1 OF THE BLOWER MOTOR "TERMINAL 2 "TERMINAL 1 OF
THE BLOWER RESISTOR "TERMINAL 2 "TERMINAL 1 OF THE BLOWER SW "TERMINAL 6 "GROUND. THIS TIME, THE
BLOWER RESISTANCE OF THE BLOWER RESISTOR IS LESS THAN AT LOW SPEED, SO THE BLOWER MOTOR ROTATES AT
MEDIUM LOW SPEED.
WHEN THE BLOWER SW IS MOVED TO M2 POSITION, CURRENT FLOWING THROUGH THE MOTOR FLOWS FROM TERMINAL 1 OF
THE BLOWER RESISTOR "TERMINAL 3 "TERMINAL 2 OF THE BLOWER SW "TERMINAL 6 "GROUND. THIS TIME,
RESISTANCE OF THE BLOWER RESISTOR IS LESS THAN AT M1 POSITION, SO THE BLOWER MOTOR ROTATES AT MEDIUM HIGH
SPEED.
*HIGH SPEED OPERATION
WHEN THE BLOWER SW IS MOVED TO HI POSITION, THE CURRENT FLOWS TO TERMINAL 5 OF THE BLOWER SW "TERMINAL 6
"GROUND AND TURNS THE HEATER RELAY ON.
THIS CAUSES THE CURRENT TO FLOW FROM THE HTR FUSE TO TERMINAL 5 OF THE HEATER RELAY "TERMINAL 4 "
TERMINAL 1 OF THE BLOWER MOTOR "TERMINAL 2 "TERMINAL 8 OF THE BLOWER SW "TERMINAL 6 "GROUND, CAUSING
THE BLOWER MOTOR TO ROTATE AT HIGH SPEED.
A 3 A/C DUAL PRESSURE SW
1-4 : OPEN WITH THE PRESSURE LESS THAN 2.0 KG/CM2 (30 PSI, 206 KPA) OR ABOVE 32 KG/CM2 (384 PSI, 2648 KPA)A12 A/C AMPLIFIER
12-5 : CONTINUITY WITH THE A/C CONTROL SW ON AND THE IGNITION SW AT ON POSITION
13-GROUND : ALWAYS CONTINUITY
05-GROUND : ALWAYS CONTINUITY
02-GROUND : APPROX. 12 VOLTS WITH THE IGNITION SW ON
A14 A/C THERMISTOR
1-2 : APPROX. 2341
234 W AT 15
C (59
F)
B 4 BLOWER RESISTOR
1-3 : APPROX. 0.4 W
1-2 : APPROX. 1.1 W
1-4 : APPROX. 2.8 W
B 5 BLOWER SW
5-6 : CONTINUITY WITH THE BLOWER SW AT LO, M1, M2 OR HI POSITION
1-6 : CONTINUITY WITH THE BLOWER SW AT M1 POSITION
2-6 : CONTINUITY WITH THE BLOWER SW AT M2 POSITION
8-6 : CONTINUITY WITH THE BLOWER SW AT HI POSITION
: PARTS LOCATION
CODESEE PAGECODESEE PAGECODESEE PAGE
A 228B 430I 229
A 328B 530J 331
A1230D 330J 431
A1330E 631J10A31
A1430F 728J11B31
B 330F 831
: RELAY BLOCKS
CODESEE PAGERELAY BLOCKS (RELAY BLOCK LOCATION)
625R/B NO. 6 (ENGINE COMPARTMENT LEFT)
SYSTEM OUTLINE
SERVICE HINTS

163
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
CODESEE PAGEJUNCTION BLOCK AND WIRE HARNESS (CONNECTOR LOCATION)
1B20INSTRUMENT PANEL WIRE AND J/B NO. 1 (LOWER FINISH PANEL)
1E20FUSE BLOCK ASSY WIRE AND J/B NO. 1 (LOWER FINISH PANEL)
4A22ENGINE WIRE AND J/B NO. 4 (RIGHT KICK PANEL)
4B22INSTRUMENT PANEL WIRE AND J/B NO 4 (RIGHT KICK PANEL)4C22INSTRUMENT PANEL WIRE AND J/B NO. 4 (RIGHT KICK PANEL)
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
CODESEE PAGEJOINING WIRE HARNESS AND WIRE HARNESS (CONNECTOR LOCATION)
EA134ENGINE WIRE AND ENGINE ROOM MAIN WIRE (INSIDE OF R/B NO. 2)
IB236ENGINE ROOM MAIN WIRE AND INSTRUMENT PANEL WIRE (RIGHT KICK PANEL)
IG238ENGINE WIRE AND INSTRUMENT PANEL WIRE (UNDER THE INSTRUMENT PANEL CENTER)
IH138HEATER BLOWER WIRE AND INSTRUMENT PANEL WIRE (RIGHT KICK PANEL)
: GROUND POINTS
CODESEE PAGEGROUND POINTS LOCATION
IG36RIGHT KICK PANEL
: SPLICE POINTS
CODESEE PAGEWIRE HARNESS WITH SPLICE POINTSCODESEE PAGEWIRE HARNESS WITH SPLICE POINTS
E 134ENGINE ROOM MAIN WIREI 838INSTRUMENT PANEL WIRE
I 738INSTRUMENT PANEL WIRE
