1996 TOYOTA CAMRY Owners Manual

59 If the washer does not work, check to see
whether the washer tank is empty. For in-
formation on adding washer fluid, see
Adding washer fluidº in Chapter 7-3.
In cold weather, warm the windshield with
the defroster before using the washer.
This will help prevent icing, which could
block your vision.
NOTICE
Do not operate the wipers if the
windshield is dry. It may scratch the
glass.
To turn the wipers on, move the lever.
To make the washer squirt, push the
button on the end of the lever.
The key must be in the ONº position.
The wipers will operate at intervals when
the lever is in the INTº position.
If a single wipe is desired in mist, pull the
lever toward you and release it.
If the washer does not work, check to see
whether the washer tank is empty. For in-
formation on adding washer fluid, see
Adding washer fluidº in Chapter 7-3.In cold weather, warm the windshield with
the defroster before using the washer.
This will help prevent icing, which could
block your vision.
NOTICE
Do not operate the wipers if the
windshield is dry. It may scratch the
glass.
Windshield wipers and washer
(without interval adjuster)
ProCarManuals.com

60
To turn the rear wipers and washers on,
twist the knob at the end of the lever.
The key must be in the ONº position.
The wipers will operate at intervals when
the knob is in the INTº position.
The washer squirts at the two marked
knob positions. The knob will automatical-
ly return from these positions when it is re-
leased.
If the washer does not work, check to see
whether the washer tank is empty. For in-
formation on adding washer fluid, see
Adding washer fluidº in Chapter 7-3.
NOTICE
Do not operate the rear wipers if the
rear window is dry. It may scratch
the glass.
To defog or defrost the rear window,
push the switch.
The key must be in the ONº position.
The thin heater wires on the inside of the
rear window will quickly clear the sur-
faces. An indicator light will illuminate to
indicate the defogger is operating.
Push the switch once again to turn the de-
fogger off.
The system will automatically shut off af-
ter the defogger has operated about 15
minutes.
Rear window wipers and
washer (wagon) Rear window defogger
ProCarManuals.com

61 Make sure you turn the defogger off when
the window is clear. Leaving the defogger
on for a long time could cause the battery
to discharge, especially during stop-and-
go driving. The defogger is not designed
for drying rain water or for melting snow.
NOTICE
When cleaning the inside of the rear
window, be careful not to scratch or
damage the heater wires.
ProCarManuals.com

62ProCarManuals.com

Part 1Fuel gauge
63
OPERATION OF
INSTRUMENTS AND
CONTROLSÐ
Chapter 1-5
Gauges, Meters
and Service reminder
indicators

Fuel gauge

Engine coolant temperature
gauge

Tachometer

Odometer and trip meter

Service reminder indicators
and warning buzzers
The gauge works when the ignition
switch is on and indicates the approxi-
mate quantity of fuel remaining in the
tank.
It is a good idea to keep the tank over 1/4
full.
This fuel gauge has a non-return type
needle which remains at the last indicated
position when the ignition switch is turned
off.
If the level approaches Eº or the low fuel
level warning light comes on, fill the fuel
tank as soon as possible.If the fuel tank is completely empty, the
malfunction indicator lamp comes on. Fill
the fuel tank immediately.
The indicator lamp goes off after driving
several times. If the indicator lamp does
not go off, contact your Toyota dealer as
soon as possible.
ProCarManuals.com

64
The gauge indicates the engine cool-
ant temperature when the ignition
switch is on. The engine operating
temperature will vary with changes in
weather and engine load.
If the needle points to the red zone or high-
er, stop your vehicle and allow the engine
to cool.
Your vehicle may overheat during severe
operating conditions, such as:

Driving up a long hill on a hot day.

Reducing speed or stopping after high
speed driving.

Idling for a long period with the air con-
ditioning on in stop-and-go traffic.

Towing a trailer.
NOTICE
Do not remove the thermostat in
the engine cooling system as this
may cause the engine to overheat.
The thermostat is designed to
control the flow of coolant to keep
the temperature of the engine
within the specified operating
range.
Do not continue driving with an
overheated engine. See If your
vehicle overheatsº in Part 4.
The tachometer indicates engine
speed in thousands of rpm (revolu-
tions per minute). Use it while driving
to select correct shift points and to
prevent engine lugging and overrev-
ving.
Driving with the engine running too fast
causes excessive engine wear and poor
fuel economy. Remember, in most cases
the slower the engine speed, the greater
the fuel economy.
NOTICE
Do not let the indicator needle get
into the red zone. This may cause
severe engine damage.
Tachometer Engine coolant temperature
gauge
ProCarManuals.com

65
The odometer records the total dis-
tance the vehicle has been driven. The
trip meter may be set to zero to record
the distance on each trip. To reset the
trip meter, press the trip meter reset
knob.
The black digits on white indicate tenths of
kilometers or miles.
Odometer and trip meterService reminder indicators
and warning buzzers
ProCarManuals.com

66(a) Brake System Warning Light
This light has the following functions:
Parking brake reminder
If this light is on, make sure the parking
brake is fully released. The light should go
off.
Low brake fluid level warning
If this light comes on and stays on while
you are driving, slow down and pull off the
road. Then stop the vehicle carefully.
There may be a problem somewhere in
the brake system. Check the fluid level of
the see-through reservoir.
To make sure the parking brake has not
caused the warning light to come on,
check to see that the parking brake is fully
released.
If the brake fluid level is low...
At a safe place, test your brakes by start-
ing and stopping.

If you judge that the brakes still work
adequately, drive cautiously to your
nearest dealer or shop for repairs.

If the brakes are not working, have the
vehicle towed in for repairs. (For tow-
ing information, see Part 4.)
It is dangerous to continue driving
normally when the brake fluid level
is low.CAUTION
!
If the brake fluid level is correct...
Have the warning system checked by
your Toyota dealer.
(b) Seat Belt Reminder Light and Buzzer
Once the ignition key is turned to ONº or
STARTº, the reminder light and buzzer
come on if the driver's seat belt is not fas-
tened. Unless the driver fastens the belt,
the light stays on and the buzzer stops af-
ter about 4 to 8 seconds.
(c) Discharge Warning Light
This light warns that the battery is being
discharged.
If it comes on while you are driving, there
is a problem somewhere in the charging
system.
The engine ignition will continue to oper-
ate, however, until the battery is dis-
charged. Turn off the air conditioning,
blower, radio, etc., and drive directly to the
nearest Toyota dealer or repair shop.
NOTICE
Do not continue driving if the
engine drive belt is broken or loose.
(d) Malfunction Indicator Lamp
This lamp comes on in the following
cases.
a. The fuel tank is completely empty.
(See Fuel gaugeº in Chapter 1-5 for in-
structions.)b. The fuel tank cap is not tightened se-
curely. (See Fuel tank capº in Chapter
1-2 for instructions.)
c. There is a problem somewhere in your
engine or automatic transmission electri-
cal system.
If it comes on while you are driving in case
c, have your vehicle checked/repaired by
your Toyota dealer as soon as possible.
(e) Low Fuel Level Warning Light
This light comes on when the fuel level in
the tank becomes nearly empty. Fill up the
tank as soon as possible.
(f) Low Oil Pressure Warning Light
This light warns that the engine oil pres-
sure is too low.
If it flickers or stays on while you are driv-
ing, pull off the road to a safe place and
stop the engine immediately. Call a Toyota
dealer or qualified repair shop for assis-
tance.
The light may occasionally flicker when
the engine is idling or it may come on brief-
ly after a hard stop. There is no cause for
concern if it then goes out when the en-
gine is accelerated slightly.
The light may come on when the oil level
is extremely low. It is not designed to indi-
cate low oil level, and the oil level must be
checked using the level dipstick.
