1996 TOYOTA CAMRY Owners Manual

147
CAUTION!

Do not exceed 72 km/h (45 mph) or
the posted towing speed limit,
whichever is lower. Because insta-
bility (swaying) of a towing ve-
hicle-trailer combination usual-
ly increases as the speed in-
creases, exceeding 72 km/h (45
mph) may cause loss of control.

Slow down and downshift before
descending steep or long down-
hill grades. Do not make sudden
downshifts.

Avoid holding the pedal down too
long or too frequently. This could
cause the brakes to overheat and
result in reduced braking efficiency.Getting more kilometers/mileage from a li-
ter/gallon of fuel is easyÐjust take it easy.
It will help make your vehicle last longer,
too. Here are some specific tips on how to
save money on both fuel and repairs:

Keep your tires inflated at the cor-
rect pressure. Underinflation causes
tire wear and wastes fuel. See Chapter
7-2 for instructions.

Do not carry unneeded weight in
your vehicle. Excess weight puts a
heavier load on the engine, causing
greater fuel consumption.

Avoid lengthy warm-up idling.
Once the engine is running smoothly,
begin drivingÐbut gently. Remember,
however, that on cold winter days this
may take a little longer.

Accelerate slowly and smoothly.
Avoid jackrabbit starts. Get into high
gear as quickly as possible.

Avoid long engine idling. If you have
a long wait and you are not in traffic, it
is better to turn off the engine and start
again later.

Avoid engine lug or overrevving.
Use a gear position suitable for the
road on which you are travelling.
Avoid continuous speeding up and
slowing down. Stop-and-go driving
wastes fuel.

Avoid unnecessary stopping and
braking. Maintain a steady pace. Try
to time the traffic signals so you only
need to stop as little as possible or take
advantage of through streets to avoid
traffic lights. Keep a proper distance
from other vehicles to avoid sudden
braking. This will also reduce wear on
your brakes.

Avoid heavy traffic or traffic jams
whenever possible.

Do not rest your foot on the clutch
or brake pedal. This causes needless
wear, overheating and poor fuel econ-
omy.

Maintain a moderate speed on
highways. The faster you drive, the
greater the fuel consumption. By re-
ducing your speed, you will cut down
on fuel consumption.

Keep the front wheels in proper
alignment. Avoid hitting the curb and
slow down on rough roads. Improper
alignment not only causes faster tire
wear but also puts an extra load on the
engine, which, in turn, wastes fuel.
How to save fuel and make
your vehicle last longer, too
ProCarManuals.com

148
Keep the bottom of your vehicle
free from mud, etc. This not only
lessens weight but also helps prevent
corrosion.

Keep your vehicle tuned-up and in
top shape. A dirty air cleaner, improp-
er valve clearance, dirty plugs, dirty oil
and grease, brakes not adjusted, etc.
all lower engine performance and con-
tribute to poor fuel economy. For lon-
ger life of all parts and lower operating
costs, keep all maintenance work on
schedule, and if you often drive under
severe conditions, see that your ve-
hicle receives more frequent mainte-
nance (For scheduled maintenance in-
formation, please refer to the separate
Owner 's Manual Supplement/Main-
tenance Scheduleº).
CAUTION!
Never turn off the engine to coast
down hills. Your power steering
and brake booster will not function
without the engine running. Also,
the emission control system oper-
ates properly only when the engine
is running.
ProCarManuals.com

Part 4
If your vehicle will not startÐ
(a) Simple checks
149
IN CASE OF AN
EMERGENCY

If your vehicle will not start

If your engine stalls while
driving

If your vehicle overheats

If you have a flat tire

If your vehicle needs to be
towed

If you cannot shift automatic
transmission selector lever

If you lose your keys
Before making these checks, make sure
you have followed the correct starting pro-
cedure given in How to start the engineº
in Part 3 and that you have sufficient fuel.
If the engine is not turning over or is
turning over too slowlyÐ
1. Check that the battery terminals are
tight and clean.
2. If the battery terminals are O.K., switch
on the interior light.
3. If the light is out, dim or goes out when
the starter is cranked, the battery is dis-
charged. You may try jump starting. See
(c) Jump startingº for further instructions.
If the light is O.K., but the engine still will
not start, it needs adjustment or repair.
Call a Toyota dealer or qualified repair
shop.
NOTICE
Do not pull- or push-start the ve-
hicle. It may damage the vehicle or
cause a collision when the engine
starts. Also the three-way catalytic
converter may overheat and be-
come a fire hazard.
If the engine turns over at its normal
speed but will not startÐ
1. 5S-FE engine onlyÐCheck that all the
push-on connectors are tight. (For exam-
ple, connectors at the distributor and
spark plugs.)
2. If the connectors are O.K., the engine
may be flooded because of repeated
cranking. See (b) Starting a flooded en-
gineº for further instructions.
ProCarManuals.com

150If the engine will not start, your engine
may be flooded because of repeated
cranking.
If this happens, turn the key to STARTº
with the accelerator pedal held down.
Keep the key and accelerator pedal so for
15 seconds and release them. Then try
starting the engine with your foot off the
accelerator pedal.
If the engine does not start after 15 sec-
onds of cranking, release the key, wait a
few minutes and try again.
If the engine still will not start, it needs ad-
justment or repair. Call a Toyota dealer or
qualified repair shop for assistance.
NOTICE
Do not crank for more than 15 sec-
onds at a time. This may overheat
the starter and wiring systems.
To avoid serious personal injury and
damage to your vehicle which might
result from battery explosion, acid
burns, electrical burns, or damaged
electronic components, these instruc-
tions must be followed precisely.
If you are unsure about how to follow this
procedure, we strongly recommend that
you seek the help of a competent me-
chanic or towing service.

Batteries contain sulfuric acid
which is poisonous and corrosive.
Wear protective safety glasses
when jump starting, and avoid
spilling acid on your skin, clothing,
or vehicle.

If you should accidentally get acid
on yourself or in your eyes, remove
any contaminated clothing and
flush the affected area with water
for at least 15 minutes. Then get im -
mediate medical attention. If pos-
sible, continue to apply water with
a sponge or cloth while en route to
the medical office.CAUTION
! (b) Starting a flooded engine (c) Jump starting
ProCarManuals.com

151

The gas normally produced by a
battery will explode if a flame or
spark is brought near. Use only
standardized jumper cables and
do not smoke or light a match
while jump starting.
NOTICE
The battery used for boosting must
be 12 V. Do not jump start unless
you are sure that the booster battery
is correct.
JUMP STARTING PROCEDURE
1. If the booster battery is installed in
another vehicle, make sure the vehicles
are not touching. Turn off all unnecessary
lights and accessories.
2. If required, remove all the vent plugs
from the booster and discharged batter-
ies. Lay a cloth over the open vents on the
batteries. (This helps reduce the explo-
sion hazard, personal injuries and burns.)
3. If the engine in the vehicle with the
booster battery is not running, start it and
let it run for a few minutes. During jump
starting, run the engine at about 2000 rpm
with the accelerator pedal lightly de-
pressed.4. Connect the jumper cables in the exact
order shown in the illustration: positive
terminal (+º mark)-to-positive terminal
(+º mark), and negative terminal
(-º mark)-to-engine or body ground.
Note that you first connect the positive
cable to the discharged battery and then
to the booster battery. Next, connect the
negative cable to the booster battery and
then to a solid, stationary, unpainted, me-
tallic point (e.g. 5S-FE engineÐengine
hanging hook, 1MZ-FE engineÐcylinder
head) away from the battery. Do not con-
nect it to or near any part that moves when
the engine is cranked.
When making the connections, do
not lean over the battery or acciden -
tally let the jumper cables or clamps
touch anything except the correct
battery terminals or the ground.CAUTION
!
5. Start your engine in the normal way.
After starting, run it at about 2000 rpm for
several minutes with the accelerator ped-
al lightly depressed.
6. Carefully disconnect the cables in the
exact reverse order: the negative cable
and then the positive cable.
7. Carefully dispose of the battery cover
clothsÐthey may now contain sulfuric
acid.8. If removed, replace all the battery vent
plugs.
If the cause of your battery discharging is
not apparent (for example, lights left on),
you should have it checked.
ProCarManuals.com

152If your engine stalls while driving0
1. Reduce your speed gradually, keeping
a straight line. Move cautiously off the
road to a safe place.
2. Turn on your emergency flashers.
3. Try starting the engine again.
If the engine will not start, see If your ve-
hicle will not startº.
If the engine is not running, the
power assist for the brakes and
steering will not work so steering
and braking will be much harder
than usual.CAUTION
!
If your engine coolant temperature
gauge indicates overheating, if you
experience a loss of power, or if you
hear a loud knocking or pinging noise,
the engine has probably overheated.
You should follow this procedure0
1. Pull safely off the road, stop the vehicle
and turn on your emergency flashers. Put
the transmission in Pº (automatic) or neu-
tral (manual) and apply the parking brake.
Turn off the air conditioning if it is being
used.
2. If coolant or steam is boiling out of the
radiator or reservoir, stop the engine. Wait
until the steam subsides before opening
the hood. If there is no coolant boiling over
or steam, leave the engine running and
make sure the electric cooling fan is oper-
ating. If it is not, turn the ignition off.
To help avoid personal injury, keep
the hood closed until there is no
steam. Escaping steam or coolant
is a sign of very high pressure.CAUTION
!
3. Look for obvious coolant leaks from
the radiator, hoses, and under the vehicle.
However, note that water draining from
the air conditioning is normal if it has been
used.
When the engine is running, keep
hands and clothing away from the
moving fan and engine drive belts.CAUTION
!
4. If the coolant is leaking, stop the en-
gine immediately. Call a Toyota dealer for
assistance.
5. If there are no obvious leaks, check the
coolant reservoir. If it is dry, add coolant to
the reservoir while the engine is running.
Fill it about half full.
Do not attempt to remove the radia-
tor cap when the engine and radia-
tor are hot. Serious injury could re-
sult from scalding hot fluid and
steam blown out under pressure.CAUTION
!
6. After the engine coolant temperature
has cooled to normal, again check the
coolant level in the reservoir. If necessary,
bring it up to half full again. Serious cool-
ant loss indicates a leak in the system.
You should have it checked as soon as
possible at your Toyota dealer.
If your vehicle overheats
(5S-FE engine) If your engine stalls while
driving
ProCarManuals.com

153 If your engine coolant temperature
gauge indicates overheating, if you
experience a loss of power, or if you
hear a loud knocking or pinging noise,
the engine has probably overheated.
You should follow this procedure0
1. Pull safely off the road, stop the vehicle
and turn on your emergency flashers. Put
the transmission in Pº (automatic) or neu-
tral (manual) and apply the parking brake.
Turn off the air conditioning if it is being
used.
2. If coolant or steam is boiling out of the
radiator or reservoir, stop the engine. Wait
until the steam subsides before opening
the hood. If there is no coolant boiling over
or steam, leave the engine running.
To help avoid personal injury, keep
the hood closed until there is no
steam. Escaping steam or coolant
is a sign of very high pressure.CAUTION
!
3. Look for obvious coolant leaks from
the radiator, hoses, and under the vehicle.
However, note that water draining from
the air conditioning is normal if it has been
used.
When the engine is running, keep
hands and clothing away from the
moving fan and engine drive belts.CAUTION
!
4.
If the coolant is leaking, stop the en-
gine immediately. Call a Toyota dealer for
assistance.
5. If there are no obvious leaks, check the
coolant reservoir. If it is dry, add coolant to
the reservoir while the engine is running.
Fill it about half full.
Do not attempt to remove the en-
gine coolant filler cap when the en-
gine and radiator are hot. Serious
injury could result from scalding
hot fluid and steam blown out un-
der pressure.CAUTION
!
6. After the engine coolant temperature
has cooled to normal, again check the
coolant level in the reservoir. If necessary,
bring it up to half full again. Serious cool-
ant loss indicates a leak in the system.
You should have it checked as soon as
possible at your Toyota dealer.1. Reduce your speed gradually, keeping
a straight line. Move cautiously off the
road to a safe place well away from the
traffic. Avoid stopping on the center divid-
er of a highway. Park on a level spot with
firm ground.
2. Stop the engine and turn on your emer-
gency flashers.
3. Firmly set the parking brake and put
the transmission in Pº (automatic) or re-
verse (manual).
4. Have everyone get out of the vehicle
on the side away from traffic.
5. Read the following instructions thor-
oughly.
When jacking, be sure to observe
the following to reduce the possibil-
ity of personal injury:

Follow jacking instructions.

Use a jack only for lifting your ve-
hicle during wheel changing.

Never get beneath the vehicle
when supported by a jack.

Do not start or run the engine
while your vehicle is supported by
a jack.CAUTION
! If your vehicle overheats
1MZ-FE engine)If you have a flat tireÐ
ProCarManuals.com

154
NOTICE
Do not continue driving with a
deflated tire. Driving even a short
distance can damage a tire beyond
repair.
Compact spare tire
The compact spare tire is designed for
temporary emergency use only.
The compact spare tire is identified by the
distinctive wording TEMPORARY USE
ONLYº molded into the side wall of the tire.
The standard tire should be repaired and
replaced as soon as possible.The compact spare tire saves space in
your trunk or luggage compartment, and
its lighter weight helps to improve fuel
economy and permits easier installation in
case of a flat tire.
The compact spare tire can be used many
times, if necessary. It has tread life of up
to 4800 km (3000 miles) depending on
road conditions and your driving habits.
When tread wear indicators appear on the
tire, replace the tire.
See also the tire section in Chapter 7-2 for
details on the tread wear indicators and
other service information.

The compact spare tire was de-
signed especially for your Toyota.
Do not use it on any other vehicle.

Do not exceed 80 km/h (50 mph)
when driving with the compact
spare tire.CAUTION
!
NOTICE
Your ground clearance is reduced
when the compact spare tire is
installed so avoid driving over ob-
stacles and drive slowly on rough,
unpaved roads and speed bumps.
Also, do not attempt to go through
an automatic car wash as the ve-
hicle may get caught, resulting in
damage.
ProCarManuals.com
