1996 TOYOTA CAMRY Owners Manual

Part 1Cigarette lighter and ashtray Clock
123
OPERATION OF
INSTRUMENTS
AND CONTROLSÐ
Chapter 1-8
Other equipment

Clock

Cigarette lighter and ashtray

Glovebox

Miscellany holder

Cup holder

Luggage cover

Parcel straps

Floor mat
The digital clock indicates the time
with the ignition key at the ACCº or
ONº position. To reset the hour, de-
press the Hº button. To reset the min-
utes, depress the Mº button. To ad-
just the time to a full hour, depress the
:00º button.
For example, if the :00º button is de-
pressed when the time is between
1:01Ð1:29, the time will change to 1:00.
If the time is between 1:30Ð1:59, the time
will change to 2:00.
When the instrument panel lights are
turned on, the brightness of the time indi-
cation will be reduced.
Once the electrical power source has
been disconnected from the clock, the
time is automatically set to 1:00 (one
o'clock).To use the cigarette lighter, press it in.
When it becomes heated, it automati-
cally pops out ready for use.
If the engine is not running, the key must
be in the ACCº position.
Do not hold the cigarette lighter pressed
in.
When finished with your cigarette, thor-
oughly extinguish it in the ashtray to pre-
vent other cigarette butts from catching
fire. After using the ashtray, push it back
in completely.
To remove the ashtray, press down on the
lock spring plate and pull out.
Use a Toyota genuine cigarette lighter or
equivalent for replacement.
ProCarManuals.com

124
To reduce the chance of injury in
case of an accident or sudden stop
while driving, always push the ash-
tray back in completely after using.CAUTION
!
To open the glovebox door, pull the le-
ver. To lock the glovebox door, insert
the master key and turn it clockwise.
With the instrument panel lights on, the
glovebox light will come on when the door
is open.
To reduce the chance of injury in
case of an accident or a sudden
stop, always keep the glovebox
door closed while driving.CAUTION
!
To open the holder, pull the lever as
shown above.
To reduce the chance of injury in
case of an accident or a sudden
stop, always keep the miscellany
holder closed while driving.CAUTION
! Miscellany holder Glovebox
ProCarManuals.com

125
To use the cup holder, pull it out com-
pletely.
The cup holder is designed for holding
cups or drink-cans fit snugly in its holes.

Do not place anything else on the
cup holder, as such items may be
thrown about and possibly injure
people in the vehicle during sud-
den braking or an accident.

Keep the cup holder shut when not
in use.
CAUTION!
USING THE LUGGAGE COVER
To use the luggage cover, pull it out of
the retractor and hook it to the an-
chors.
To remove the luggage cover, pull the lock
release knobs and lift up the luggage cov-
er.Wagon with third seatÐ
Make sure the shoulder belt passes
through the hanger when using the lug-
gage cover.
This prevents the shoulder belt from being
damaged.
Seat belt must be removed from the
hanger when seat belt is in use.
CAUTION! Cup holder Luggage cover
ProCarManuals.com

126
HOLDING THE LUGGAGE COVER
EDGE UPRIGHT
When using the third seat, fold up the
luggage cover edge so that it does not
interfere with the passengers.
1. Unhook the strap from the anchor
tab.2. Fold the luggage cover edge. Then
pass the strap through the eyelet and
hook it onto the tab on the reverse side
of the luggage cover.
When using the luggage cover, hook the
strap onto the anchor tab.
ProCarManuals.com

127
To secure your parcels, hook the par-
cel straps to the catches and tighten
the straps by pulling on the free end.
See Luggage stowage precautionsº in
Part 2 for precautions to observe in load-
ing luggage.
Use a floor mat of the correct size.
If the floor mat has a hole, then it is de-
signed for use with a locking clip. Fix the
floor mat and locking clip into the hole in
the floor carpet.
Parcel straps (wagon)
Floor mat
ProCarManuals.com

128
Make sure the floor mat is properly
placed on the floor carpet. If the
floor mat slips and interferes with
the movement of the pedals during
driving, it may cause an accident.CAUTION
!
ProCarManuals.com

Part 2Break-in period Fuel
129
INFORMATION
BEFORE DRIVING
YOUR TOYOTA

Break-in period

Fuel

Operation in foreign countries

Three-way catalytic converters

Engine exhaust cautions

Facts about engine oil
consumption

Brake system

Brake pad wear limit indicators

Luggage stowage precautions

Your Toyota's identification

Theft prevention labels

Types of tires
Drive gently and avoid high speeds.
Your vehicle does not need an elaborate
break-in. But following a few simple tips
for the first 1600 km (1000 miles) can add
to the future economy and long life of your
vehicle:

Do not drive over 88 km/h (55 mph).

Run the engine at moderate speed be-
tween 2000 and 4000 rpm.

Avoid full-throttle starts.

Try to avoid hard stops during the first
300 km (200 miles).

Do not drive slowly with the manual
transmission in a high gear.

Do not drive for a long time at any
single speed, either fast or slow.

Do not tow a trailer during the first 800
km (500 miles).FUEL TYPE
Your new vehicle must use only un-
leaded gasoline.
To help prevent gas station mixups, your
Toyota has a new smaller fuel tank open-
ing. The special nozzle on pumps with un-
leaded fuel will fit it, but the larger stan-
dard nozzle on pumps with leaded gas will
not.
NOTICE
Do not use leaded gasoline. Use of
leaded gasoline will cause the
three-way catalytic converter to
lose its effectiveness and the
emission control system to function
improperly. Also, this can increase
maintenance costs.
OCTANE NUMBER
5S-FE engine: Select Research Octane
Number 91 (Octane Rating 87) or high-
er.
1MZ-FE engine: Select Research Oc-
tane Number 91 (Octane Rating 87) or
higher. For improved vehicle perfor-
mance, the use of premium unleaded
gasoline with a Research Octane Num-
ber of 96 (Octane Rating 91) or higher
is recommended.
ProCarManuals.com

130Use of unleaded fuel with an octane num-
ber or rating lower than stated above will
cause persistent heavy knocking. If se-
vere, this will lead to engine damage.
If your engine knocks...
If you detect heavy knocking even when
using the recommended fuel, or if you
hear steady knocking while holding a
steady speed on level roads, consult your
Toyota dealer.
However, now and then, you may notice
light knocking for a short time while accel-
erating or driving up hills. This is no cause
for concern.
GASOLINES CONTAINING DETER-
GENT ADDITIVES
Toyota recommends use of gasolines
that contain detergent additives to
avoid build-up of engine deposits.
For further details, ask your Toyota dealer
or a local gasoline retailer.
GASOLINES CONTAINING MTBE
Gasolines that contain MTBE (Methyl
Tertiary-Butyl Ether) are available in
the market. If you use a gasoline mixed
with MTBE, make certain that it does
not contain more than 15% of MTBE.If the use of gasolines containing MTBE
causes poor driveability and/or poor fuel
economy, you should discontinue the use
of fuels containing MTBE.
GASOLINES CONTAINING ALCOHOL
If you use gasohol in your Toyota, be
sure that it is unleaded, has an octane
rating no lower than 87 and does not
contain more than 10% ethanol.
Gasohol is a mixture of gasoline and etha-
nol.
Toyota does not recommend the use of
gasolines containing methanol. If you use
gasoline containing methanol, use only
gasoline meeting the requirements above
and also containing less than 5% metha-
nol with cosolvents and corrosion inhibi-
tors for methanol.
NOTICE
Do not use gasohol other than
stated above. It will cause fuel
system damage or vehicle perfor-
mance problems.
If driveability problems are en-
countered (poor hot starting, va-
porizing, engine knock, etc.), dis-
continue the use.
Take care not to spill gasohol dur-
ing refueling. Gasohol may cause
paint damage.
FUEL TANK CAPACITY
70 L (18.5 gal., 15.4 Imp. gal.)If you plan to drive your Toyota in
another country...
First, comply with the vehicle registration
laws.
Second, confirm the availability of the
correct fuel (unleaded and minimum oc-
tane number).
Operation in foreign countries
