1996 TOYOTA AVALON Owners Manual

Part 1
1
OPERATION OF
INSTRUMENTS
AND CONTROLSÐ
Chapter 1-1
Overview of instruments
and controls

Instrument panel overview

Instrument cluster overview

Indicator symbols on the
instrument panel
ProCarManuals.com

2
1. Side vent
2. Side defroster outlet
3. Tilt steering lock release lever
4. Automatic transmission selectorlever (column shift)
5. Center vents
6. Electric moon roof switch or front interior light, and front personal lights
7. Power door lock switch
8. Power window switches
9. Seat heater switch
10.Glovebox
11. Automatic transmission selector lever (floor shift)
12.Lower vent
13.Parking brake release lever
14. Parking brake pedal
Instrument panel overview
ProCarManuals.com

3
1. Instrument panel light control dial
2. Headlight and turn signal switch
3. Wiper and washer switches
4. Driving pattern selector button
5. Thermometer
6. Clock
7. Emergency flasher switch
8. Car audio
9. Miscellany box
10.Air conditioning controls
11. Ashtray and cigarette lighter
12.Rear window defogger switch
13.Ignition switch
14.Cruise control switch
15.Power rear view mirror control switch
16. Headlight cleaner switch
ProCarManuals.com

4
1. Fuel gauge
2. Engine coolant temperature gauge
3. Tachometer4. Speedometer
5. Odometer
6. Trip meter7. Trip meter reset knob
8. Service reminder indicators or
indicator lights
9. Theft deterrent system indicator light
Instrument cluster overview
ProCarManuals.com

Indicator symbols on the instrument panel5
Anti-lock brake system warning light *1Brake system warning light *1
Seat belt reminder light*1
Discharge warning light*1
Low oil pressure warning light*1
Malfunction indicator lamp*1
Low fuel level warning light *1
Open door warning light*1
SRS airbag warning light*1
Turn signal indicator lights
Headlight high beam indicator light
Rear light failure warning light*1
ProCarManuals.com

6
Driving pattern indicator light
Cruise control indicator light *
2
*1: For details, see Service reminder indicators and warn-ing buzzersº in Chapter 1-5.
*
2: If this light flashes, see Cruise controlº in Chapter 1-6.
Automatic transmission indicator lightsOverdrive-of f indicator light
ProCarManuals.com

Part 1Keys7
OPERATION OF
INSTRUMENTS AND
CONTROLSÐ
Chapter 1-2
Keys and Doors

Keys

Side doors

Power windows

Trunk lid

Hood

Theft deterrent system

Fuel tank cap

Electric moon roof
Your vehicle is supplied with two
kinds of key.
1. Master keyÐThis key works in every
lock.
2. SubkeyÐThis key will not work in the
glovebox and trunk.
To protect things locked in the glovebox
when you have your vehicle parked, leave
the subkey with the attendant.
Since the doors and trunk lid can be
locked without a key, you should always
carry a spare master key in case you acci-
dentally lock your keys inside the vehicle.KEY NUMBER PLATE
Your key number is shown on the
plate. Keep the plate in a safe place
such as your wallet, not in the vehicle.
If you should lose your keys or if you need
additional keys, duplicates can be made
by a Toyota dealer using the key number.
You should also put a copy of the key
number with your important papers.
ProCarManuals.com

8
LOCKING AND UNLOCKING WITH
KEY
Insert the key into the keyhole and turn
it.
To lock: Turn the key forward.
To unlock: Turn the key backward.
All the doors lock and unlock simulta-
neously with either front door. In the driv-
er 's door lock, turning the key once will un-
lock the driver's door and twice in
succession will unlock all the doors simul-
taneously.LOCKING AND UNLOCKING WITH IN-
SIDE LOCK KNOB
Move the lock knob.
To lock: Push the knob forward.
To unlock: Pull the knob backward.
Closing the door with the lock knob
pushed in w ill also lock the door. Be care-
ful not to lock your keys in the vehicle.
The door cannot be locked if you leave the
key in the ignition switch.Driver's side
Passenger 's side
Side doorsÐ
ProCarManuals.com
