1996 TOYOTA AVALON Owners Manual

104
ÐAir flow selector settings
ProCarManuals.com

105

To cool off your Toyota after it has been
parked in the hot sun, drive with the
windows open for a few minutes. This
vents the hot air, allowing the air condi-
tioning to cool the interior more quickly.
 Make sure the air intake grilles in front
of the windshield are not blocked (by
leaves or snow, for example).
 On humid days, do not blow cold air on
the windshield. The windshield could
fog up because of the difference in air
temperature on the inside and outside
of the windshield.
 Keep the area under the front seats
clear to allow air to circulate through-
out the vehicle.
 On cold days, turn the fan speed to
HIº for a minute to help clear the in-
take ducts of snow or moisture. This
can reduce the amount of fogging on
the windows. Heating
For best results, set controls to:
For automatic operationÐ
Press in the AUTOº button.
Temperature Ð To the desired
temperature
Air intake Ð FRESH (outside air)
Air conditioning Ð OFF
For manual operationÐ
Fan speed Ð Any setting except OFFº
Temperature Ð Towards WARM
Air intake Ð FRESH (outside air)
Air flow Ð FLOOR
Air conditioning Ð OFF
For quick heating, select recirculated
air for a few minutes. To keep the win-
dows from fogging, select fresh after
the vehicle interior has been warmed.
 Press the A/Cº button on for dehumid-
ified heating.
 Choose floor/windshield air flow to
heat the vehicle interior while defrost-
ing or defogging the windshield. Air conditioning
For best results, set controls to:
For automatic operationÐ
Press in the AUTOº button.
Temperature Ð To the desired
temperature
Air intake Ð FRESH (outside air)
Air conditioning Ð ON
For manual operationÐ
Fan speed Ð Any setting except OFFº
Temperature Ð Towards COLD
Air intake Ð FRESH (outside air)
Air flow Ð PANEL
Air conditioning Ð ON
For quick cooling, move the air intake
selector to recirculate for a few min-
utes.
ÐOperating tips
ProCarManuals.com

106Ventilation
For best results, set controls to:
For automatic operationÐ
Press in the AUTOº button.
Temperature Ð Towards low
temperature
Air intake Ð FRESH (outside air)
Air conditioning Ð OFF
For manual operationÐ
Fan speed Ð Any setting except OFFº
Temperature Ð Towards COLD
Air intake Ð FRESH (outside air)
Air flow Ð PANEL
Air conditioning Ð OFF
Defogging and defrosting
The inside of the windshield
For best results, set controls to:
For automatic operationÐ
Temperature Ð Towards high tem-
perature to heat; low
temperature to cool
Air intake Ð FRESH (outside air)
Air flow Ð WINDSHIELD
Air conditioning Ð ON
For manual operationÐ
Fan speed Ð Any setting except OFFº
Temperature Ð Towards WARM to
heat; COLD to cool
Air intake Ð FRESH (outside air)
Air flow Ð WINDSHIELD
Air conditioning Ð ON
On humid days, do not blow cold air on
the windshieldÐthe difference be-
tween the outside and inside tempera-
tures could make the fogging worse. The outside of the windshield
For best results, set controls to:
For automatic operationÐ
Temperature Ð Towards high
temperature
Air intake Ð FRESH (outside air)
Air flow Ð WINDSHIELD
Air conditioning Ð OFF
For manual operationÐ
Fan speed Ð Any setting except OFFº
Temperature Ð Towards WARM
Air intake Ð FRESH (outside air)
Air flow Ð WINDSHIELD
Air conditioning Ð OFF
To heat the vehicle interior while de-
frosting the windshield, choose floor/
windshield air flow.
ProCarManuals.com

107
Side vents
Lower ventIf air flow control is not satisfactory, check
the instrument panel vents. The instru-
ment panel vents may be opened or
closed as shown.
ÐInstrument panel vents
ProCarManuals.com

108ProCarManuals.com

Part 1Clock
109
OPERATION OF
INSTRUMENTS AND
CONTROLSÐ
Chapter 1-8
Other equipment

Clock

Cigarette lighter and ashtray

Glovebox

Miscellany box

Cup holder

Floor mat
The digital clock indicates the time.
The key must be in the ``ACCº or ``ON''
position.
To reset the hour: Push the ºHº button.
To reset the minutes: Push the Mº button.
If quick adjustment to a full hour is de-
sired, push the :00º button.
For example, if the :00º button is de-
pressed when the time is between
1:01Ð1:29, the time will change to 1:00.
If the time is between 1:30Ð1:59, the time
will change to 2:00. Once the electrical power source has
been disconnected from the clock, the
time is automatically set to 1:00 (one
o'clock).
When the instrument panel lights are
turned on, the brightness of the time indi-
cation will be reduced.
ProCarManuals.com

11 0
CIGARETTE LIGHTER
To use the cigarette lighter, first pull
the ashtray lid, then press in the ligh-
ter. When it becomes heated, it auto-
matically pops out ready for use.
If the engine is not running, the key must
be in the ºACCº position.
Do not hold the cigarette lighter pressed
in.
Use a Toyota genuine cigarette lighter or
equivalent for replacement.ASHTRAY
To use the ashtray, pull out the lid.
When finished with your cigarette, thor-
oughly extinguish it in the ashtray to pre-
vent other cigarette butts from catching
fire. After using the ashtray, push it back
in completely.
To remove the ashtray, pull the ashtray lid
and pull it out.To reduce the chance of injury in
case of an accident or sudden stop
while driving, always push the ash-
tray back in completely after using.
CAUTION
!
To use the glovebox, do this.
To open: Pull the lever.
With the instrument panel lights on, the
glovebox light will come on when the
glovebox is open.
To lock: Insert the master key and turn it
clockwise.
To reduce the chance of injury in
case of an accident or a sudden
stop, always keep the glovebox
door closed while driving.CAUTION
!
Cigarette lighter and ashtray Glovebox
ProCarManuals.com

111
To open the miscellany box, press on
the knob and pull out the box lid.
To reduce the chance of injury in
case of an accident or a sudden
stop, always keep the miscellany
box closed while driving.CAUTION
!
The cup holder is designed for holding
cups or drink-cans fit snugly in its
holes.
To use the cup holder, push on the lid.


Do not place anything else on the
cup holder, as such items may be
thrown about and possibly injure
people in the vehicle during sud-
den braking or an accident.

Keep the cup holder shut when not
in use.
CAUTION!
Cup holder
(with separate front seat) Cup holder
(with bench front seat)
Miscellany box
