1996 NISSAN MAXIMA Owners Manual

with the defroster before you wash the
windshield.
To defog the rear window glass and outside
mirrors, start the engine and push the switch
on. (The indicator light will come on.) Push the
switch again to turn the defogger off.
It will automatically turn off in approximately 15
minutes.
When cleaning the inner side of the
window, be careful not to scratch or
damage the electrical conductors.
SIC0177
REAR WINDOW AND OUTSIDE
MIRROR DEFOGGER SWITCH
1-12
Z01.2.1/A32-DX

Lighting
Turn the switch to the ªº position:
The front clearance, side marker, tail, license
plate and instrument lights will come on.Turn the switch to the ª
º position:
Headlights will come on and all the other lights
remain on.
To select the high beam, push the lever for-
ward. Pull it back to select the low beam.
Daytime light system
(For Canada)
Even if the headlight control switch is off, the
headlights' high beams will illuminate after
starting the engine. The headlights will be a
little dimmer than they are with the headlight
switch in the ª
º position.
If the parking brake is applied before the
engine is started, the daytime lights will not be
illuminated. The daytime lights will illuminate
once the parking brake is released. Thereafter,
the daytime lights will not turn off when using
the parking brake at stop signals, etc.
When the daytime light system is active,
tail lights on your vehicle will not be on.
It is necessary at dusk to turn on your
headlights. Failure to do so could cause
an accident injuring yourself and others.
Passing signal
Pulling the lever toward you will turn on the
headlight high beam.
SIC0188
HEADLIGHT AND TURN SIGNAL
SWITCH
1-13
Z01.2.1/A32-DX

Turn signal
Move the lever up or down to signal the turning
direction. When the turn is completed, the turn
signals cancel automatically.
Lane change signal
To indicate a lane change, move the lever up
or down to the point where lights begin flash-
ing.
The cornering light provides additional illumi-
nation toward the turning direction. The light
will come on when the turn signal lever is
moved to the right or left with the headlights
on.The instrument brightness control operates
when the light switch is in the ª
ºor
ªº position.
Turn the control to adjust the brightness of
instrument panel lights (except clock) and
power window switch lights.
When the control is turned to the right until a
click sound is heard, the light intensity will be
at maximum. When the control is turned to the
left until a click sound is heard, the light will be
turned off.
IC1030IC1284MA
CORNERING LIGHT
INSTRUMENT BRIGHTNESS
CONTROL
1-14
Z01.2.1/A32-DX

To turn the fog lights on, turn the headlight
switch to the ªº position, then turn the
switch to the ªº position. To turn them off,
turn the switch to the ªOFFº position.
The headlights must be on for the fog lights to
operate.Push the switch on to warn other drivers when
you must stop or park under emergency con-
ditions. All turn signal lights will flash.
IWhen stalled or stopped on the road-
way under emergency conditions,
move the vehicle well off the road.
IDo not use the switch while moving
on the highway unless unusual cir-
cumstances force you to drive so
slowly that your vehicle might be-
come a hazard to other traffic.ISome state laws may prohibit the use
of the hazard warning flasher switch
while driving.
ITurn signals do not work when the
switch is operating.
The flasher can be actuated with the ignition
switch either off or on.
IC1292SIC0178
FRONT FOG LIGHT SWITCH
HAZARD WARNING FLASHER
SWITCH
1-15
Z01.2.1/A32-DX

The front seats are warmed by built-in heaters.
The switches located on the center console
can be operated independently of each other.
1. Start the engine.
The battery could run down if the seat
heater is operated while the engine is
not running.
2. Selecting heat range.IFor Low heat, press the top of the
switch.
IFor High heat, press the bottom of the
switch.
IFor No heat, the switch has a center
ªOFFº position between Low and High.
The indicator light in the switch will illumi-
nate when Low or High is selected.
The heater is controlled by a thermostat,
automatically turning the heater on and off.
The indicator light will remain on as long as
the switch is on.
3. When the vehicle's interior is warmed, or
before you leave the vehicle, be sure to turn
the switch off.
Do not use the seat heater for extended
periods, or when the seat is not occu-
pied.
IDo not put anything on the seat which
insulates heat, such as a blanket,
cushion, seat cover, etc. Otherwise,
the seat may become overheated.
IDo not place anything hard or heavyon the seat or pierce it with a pin or
similar object. This may result in
damage to the heater.
IAny liquid spilled on the heated seat
should be removed immediately with
a dry cloth.
IWhen cleaning the seat, never use
benzine, thinner, or any similar mate-
rials.
IIf any abnormalities are found or the
heated seat does not operate, turn
the switch OFF and have the system
checked by your NISSAN dealer.
SIC0179
HEATED SEAT
1-16
Z01.2.1/A32-DX

The cigarette lighter element is an accessory.
A genuine NISSAN cigarette lighter or equiva-
lent can be purchased from your local NISSAN
dealer.
The cigarette lighter operates when the igni-
tion switch is in the ªACCº or ªONº position.
Push the lighter in all the way. When the lighter
is heated, it will spring out.
Return the lighter to its original position after
use.
The cigarette lighter should not be used
while driving in order that full attention
may be given to the driving operation.
The pocket should not be used while
driving in order that full attention may be
SIC0180
SIC0181
CIGARETTE LIGHTER AND ASH
TRAYSPOCKET
1-17
Z01.2.1/A32-DX

given to the driving operation.
To accommodate different sized cups, remove
the finisher.
The cup and card holders should not be
used while driving in order that full at-
tention may be given to the driving
operation.
Avoid abrupt starting and braking when
the cup holder is being used to prevent
spilling the drink. If the liquid is hot, it
can scald you or your passenger.
SIC0472
CUP AND CARD HOLDERS
1-18
Z01.2.1/A32-DX

The power window only operates when the
ignition key is in the ªONº position.
To open or close the window, push down or
pull up the switch and hold it. The main switch
(driver side switches) will open or close all the
windows.
Locking passenger's window
When the lock button is pushed in, only the
driver side window can be opened or closed.
Push it in again to cancel.The passenger side switch will open or close
only the corresponding window. To open or
close the window, hold the switch down or up.
IMake sure that all passengers have
their hands, etc. inside the vehicle
before closing the windows.
IDo not leave children unattended in-
side the vehicle. They could unknow-
ingly activate switches.
Power window automatic switch
To fully open the driver side window, com-
pletely push down the switch and release it; it
need not be held. The window will automati-
cally open all the way. To stop the window, just
pull up the switch toward the ªCLOSEº side.
SIC0182SIC0183SIC0184
POWER WINDOW
1-19
Z01.2.1/A32-DX
