3. Check the fluid level with the engine idling.
4. Remove the dipstick and wipe it clean with
lint-free paper.
5. Reinsert the dipstick into the charging pipe
as far as it will go.
6. Remove the dipstick and note the reading.
If the level is at the low side of either range,
add fluid to the charging pipe.
DO NOT OVERFILL.
USE Nissan Matic ªDº (Continental U.S.
and Alaska) or Genuine Nissan Auto-
matic Transmission Fluid (Canada).NOTE:
If the vehicle has been driven for a long
time at high speeds, or in city traffic in hot
weather, or if it is being used to pull a
trailer, the accurate fluid level cannot be
read. You should wait until the fluid has
cooled down (about 30 minutes).
Check the fluid level in the reservoir tank.
The fluid level should be checked using the
ªHOTº range at fluid temperatures of 122 to
176ÉF (50 to 80ÉC) or using the ªCOLDº range
at fluid temperatures of 32 to 86ÉF (0 to 30ÉC).
IDo not overfill.
IThe recommended fluid is Type
DEXRON
TMII or equivalent.
SDI0334SDI0118
POWER STEERING FLUID
7-10
Z01.2.1/A32-DX

Check the fluid level in the reservoir. If the fluid
is below the Min. line or the brake warning light
comes on, addDOT 3fluid up to the Max. line.
If fluid must be added frequently, the system
should be thoroughly checked by your NIS-
SAN dealer.
IUse only new fluid. Old, inferior, or
contaminated fluid may damage the
brake and clutch systems. The use of
improper fluids can damage thebrake system and affect the vehicle's
stopping ability.
IDo not spill the fluid on painted sur-
faces. This will damage the paint. If
fluid is spilled, wash with water.
Type A
Add fluid when the low washer fluid warning
light comes on. Add a washer solvent to the
water for better cleaning. In the winter season,
add a windshield washer anti-freeze. Follow
the manufacturer's instructions for the mixture
ratio.
SDI0119SDI0189
BRAKE AND CLUTCH FLUID WINDOW WASHER FLUID
7-11
Z01.2.1/A32-DX

Type B
To check the fluid level, use your finger to plug
the center hole of the cap/tube assembly (as
shown above), then remove it from the tank. If
there is no fluid in the tube, add fluid. Add awasher solvent to the water for better cleaning.
In the winter season, add a windshield washer
anti-freeze. Follow the manufacturer's instruc-
tions for the mixture ratio.
Do not substitute engine anti-freeze
coolant for window washer solution.
This may result in damage to the paint.
IKeep the battery surface clean and dry. Any
corrosion should be washed off with a
solution of baking soda and water.
IMake certain the terminal connections are
clean and securely tightened.
IIf the vehicle is not to be used for 30 days or
longer, disconnect the ªÐº negative battery
terminal cable to prevent discharge.
Do not expose the battery to flames or
electrical sparks. Hydrogen gas gener-
ated by battery action is explosive. Do
not allow battery fluid to contact your
skin, eyes, fabrics, or painted surfaces.
After touching a battery or battery cap,
do not touch or rub your eyes. Thor-
oughly wash your hands. If the acid
contacts your eyes, skin or clothing,
immediately flush with water for at least
15 minutes and seek medical attention.
SDI0190
BATTERY
7-12
Z01.2.1/A32-DX

Check the fluid level in each cell. It should be
between the MAX. and MIN. lines.
If it is necessary to add fluid, add only distilled
water to bring the level to the indicator in each
filler opening.Do not overfill.
1. Remove the cell plugs.
2. Add distilled water up to the MAX. level.
3. Tighten cell plugs.
JUMP STARTING
If jump starting is necessary, see the ªIn case
of emergencyº section. If the engine does not
start by jump starting, the battery may have to
be replaced. Contact your NISSAN dealer.
Be sure the ignition key is ªOFFº.
1. Visually inspect each belt for signs of un-
usual wear, cuts, fraying, oil adhesion or
looseness. If the belt is in poor condition or
loose, have it replaced or adjusted by your
NISSAN dealer.
2. Have the belts checked regularly for condi-
tion and tension in accordance with the
maintenance schedule in this manual.
DI0137MSDI0141
DRIVE BELTS
7-13
Z01.2.1/A32-DX

Be sure the engine and ignition switch
are off and that the parking brake is
engaged securely.
Be sure to use the correct wrench to
remove the plugs. An incorrect wrench
can cause damage.
SPARK PLUG REPLACEMENT
7-14
Z01.2.1/A32-DX

1. Remove the rocker cover ornament using a
suitable hexagon wrench. (Front side)
2. Disconnect the electrical connectors.
3. Loosen the ignition coil fixing bolts. And
remove the ignition coil to give access to
the spark plugs.
4. Remove the spark plugs with a spark plug
wrench.
The plug wrench has a rubber seal that
holds the spark plug so that it will not fall
when it is pulled out. Make sure that each
spark plug is snugly fitted into the plug
wrench.5. Fit the new plugs, one at a time, into the
spark plug wrench and install them. Turn
each plug in several full turns by hand, then
tighten with a spark plug wrench to the
correct torque. Do not overtighten.
Spark plug tightening torque:
14 to 22 ft-lb
(20 to 29 )6. Holding the ignition coil, re-connect each
ignition coil to its proper spark plug by
pushing it on until you feel a snap.
7. Tighten all ignition coils.
SDI0122SDI0123
7-15
Z01.2.1/A32-DX

Platinum-tipped spark plug
It is not necessary to replace the platinum-
tipped spark plugs as frequently as the con-
ventional type spark plugs since they will last
much longer. Follow the maintenance sched-
ule but, do not reuse them by cleaning or
regapping.
Always replace with recommended
platinum-tipped spark plugs.
Viscous paper type
The filter element should not be cleaned and
reused. Replace it according to the mainte-
nance intervals shown in the ªMaintenance
scheduleº section. When replacing the filter,
wipe the inside of the air cleaner housing and
the cover with a damp cloth.
Operating the engine with the air cleaner
off can cause you or others to be
burned. The air cleaner not only cleans
the air, it stops flame if the engine back-
SDI0124SDI0145SDI0121
AIR CLEANER FILTER
7-16
Z01.2.1/A32-DX

fires. If it isn't there, and the engine
backfires, you could be burned. Don't
drive with it off, and be careful working
on the engine with the air cleaner off.
1) CLEANING
If your windshield is not clear after using the
windshield washer of if the wiper blade
chatters when running, wax or other mate-
rial may be on the blade or windshield.
Clean the outside of the windshield with a
washer solution or a mild detergent. Your
windshield is clean if beads do not form
when rinsing with clear water.
Clean the blade by wiping it with a cloth
soaked in a washer solution or a mild
detergent. Then rinse the blade with clear
water. If your windshield is still not clearafter cleaning the blades and using the
wiper, replace the blades.
2) REPLACEMENT
1. Pull the wiper arm.
2. Push the lock pin, then remove the wiper
blade.
3. Insert the new wiper blade to the wiper arm
until a click sounds.
DI1018M
