1996 NISSAN MAXIMA Owners Manual

stoplights are not operating properly.
ªRº (Reverse):
Use this position to back up. Always be sure
the vehicle is completely stopped. With the
brake pedal depressed, push in the select
lever button and move the lever to the ªRº
position
ªNº (Neutral):
Neither forward nor reverse gear is engaged.
The engine can be started in this position. You
may shift to ªNº and restart a stalled engine
while the vehicle is moving.
ªDº (Drive):
Use this position for all normal forward driving.
ª2º (Second gear):
Use for hill climbing or engine braking on
downhill grades.
Do not exceed 73 MPH (117 km/h) in the ª2º
position.
ª1º (Low gear):
Use this position when climbing steep hills
slowly or driving slowly through deep snow,
sand or mud, or for maximum engine braking
on steep downhill grades.Do not exceed 40 MPH (65 km/h) in the ª1º
position.
Accelerator downshift
Ð In ªDº position Ð
For rapid passing or hill climbing, fully depress
the accelerator pedal to the floor. This shifts
the transmission down into second gear or first
gear, depending on the vehicle speed.
Overdrive switch
ON: For normal driving, push the overdrive
switch ªONº with the selector
switch in the ªDº position. The trans-
mission is upshifted into OVERDRIVE
as the vehicle speed increases.
The overdrive will not engage until the
engine has warmed up.
OFF: For driving up and down long slopes
where engine ªbrakingº would be ad-
vantageous, push the switch ªOFF
º. When cruising at a low speed
or climbing a gentle slope, you may
SD1007
4-8
Z01.2.1/A32-DX

feel uncomfortable shift shocks as the
transmission shifts between 3rd and
overdrive repeatedly. In this case, set
the overdrive switch in the ªOFF
º
position. The indicator light will come
on at this time.
When driving conditions change, reset the
overdrive switch in the ªON
º position.
Remember not to drive at high speeds for
extended periods of time with the overdrive
switch set in the ªOFF
º position. This
reduces the fuel economy.
Fail-safe
When the Fail-safe operation occurs, the next
time the key is turned to the ªONº position, the
O/D OFF light will blink for approximately 8
seconds after coming on for 2 seconds. While
the vehicle can be driven under these circum-
stances please note that the gears in the
automatic transmission will be locked in third
gear.If the vehicle is driven under extreme con-
ditions, such as excessive wheel spinning
and subsequent hard braking, the Fail-safe
system may be activated. This will occur
even if all electrical circuits are functioning
properly. In this case, turn the ignition key
ªOFFº and wait for 3 seconds. Then turn
the key back to the ªONº position. The
vehicle should return to its normal operat-
ing condition. If it does not return to its
normal operating condition, have your NIS-
SAN dealer check the transmission and
repair if necessary.
To change gears, fully depress the clutch
pedal, then move the gearshift lever. After
shifting, release the clutch slowly.
On the 5-speed transmission model, you can-
not shift directly from 5th gear into Reverse.
First shift into Neutral, then into Reverse.
If it is difficult to move the shift lever into
Reverse or 1st, shift into Neutral, then release
the clutch pedal and shift into Reverse or 1st
again.
SSD0002
DRIVING WITH MANUAL
TRANSMISSION
4-9
Z01.2.1/A32-DX

Driving precautions
IDo not rest your foot on the clutch pedal
while driving. This may cause clutch dam-
age.
IStop your vehicle completely before shifting
into reverse.
Suggested shift-up speeds
Shown below are suggested vehicle speeds
for shifting into a higher gear. These sugges-
tions relate to fuel economy and vehicle per-
formance. Actual shift-up speeds will vary ac-
cording to road conditions, the weather and
individual driving habits.
For normal acceleration in low altitude areas
[less than 4,000 ft (1,219 m)]:
Gear changeACCEL shift
point
MPH (km/h)CRUISE shift
point
MPH (km/h)
1st to 2nd 13 (24) 13 (24)
2nd to 3rd 23 (40) 16 (29)
3rd to 4th 33 (58) 27 (48)
4th to 5th 39 (64) 36 (63)
For quick acceleration when the engine is cold
or in high altitude areas [over 4,000 ft (1,219
m)]:Gear change MPH (km/h)
1st to 2nd 15 (24)
2nd to 3rd 25 (40)
3rd to 4th 40 (64)
4th to 5th 45 (72)
Suggested maximum speed in each
gear
Downshift to a lower gear if the engine is not
running smoothly, or if you need to accelerate.
Do not exceed the maximum suggested speed
(shown below) in any gear. For level road
driving, use the highest gear suggested for
that speed. Always observe posted speed
limits, and drive according to the road condi-
tions, which will ensure safe operation. Do not
overrev the engine when shifting to a lower
gear as it may cause engine damage or loss of
vehicle control.
Gear MPH(km/h)
1st 30 (50)
2nd 55 (90)
3rd 80 (130)
4th Ð
5th Ð1. Apply the parking brake.
2.Automatic transmission:
Move the selector lever to ªPº (Park) or ªNº
(Neutral). (ªPº preferred.)
The shift lever cannot be moved out of
ªPº and into any of the other gear posi-
tions if the key is removed from the
switch.
The starter is designed not to operate if
the selector lever is in one of the driving
positions.
Manual transmission:
Move the gearshift lever to ªNº (Neutral),
and depress the clutch pedal to the floor
while cranking the engine.
The starter is designed not to operate
unless the clutch pedal is depressed.
3. Crank the enginewith your foot off the
accelerator pedalby turning the ignition
key to ªSTARTº. Release the key when the
engine starts. If the engine starts, but fails
to run, repeat the above procedure.
Ð If the engine is very hard to start in
extremely cold or hot weather, depress
the accelerator pedal and hold it to help
start the engine.
STARTING THE ENGINE
4-10
Z01.2.1/A32-DX

Ð In the summer, when restarting the
engine within 30 minutes after it has
been stopped, keep the accelerator
pedal fully depressed while starting.
Do not operate the starter for more than
15 seconds at a time. If the engine does
not start, wait 10 seconds before crank-
ing again, otherwise the starter could be
damaged.
4.Warm-up
Allow the engine to idle for at least 30
seconds after starting. Drive at moderate
speed for a short distance first, especially in
cold weather.To apply:pull the lever up.
To release:pull the lever up slightly, push the
button and lower completely. Before driving,
be sure the parking brake warning light goes
out.SSD0018
PARKING BRAKE
4-11
Z01.2.1/A32-DX

The cruise control allows driving at a speed
between 30 to 89 MPH (48 to 144 km/h)
without keeping your foot on the accelerator
pedal.
To turn on the cruise control,push the main
switch on. The indicator light on the switch will
come on.
To set at cruising speed,accelerate your
vehicle to the desired speed, push the
SET/COAST switch and release it. (The
ªCRUISEº light will come on.) Take your foot
off the accelerator pedal. Your vehicle will
maintain the set speed.ITo pass another vehicle,depress the
accelerator pedal. When you release the
pedal, the vehicle will return to the previ-
ously set speed.
IThe vehicle may not maintain the set speed
when going up or down steep hills. If this
happens, drive without the cruise control.
To cancel the preset speed,follow either of
these three methods:
a) Push the cancel switch; The ªCRUISEº light
will go out.
b) Tap the brake pedal; The ªCRUISEº light
will go out.c) Turn the main switch off. Both the ªONº
indicator and ªCRUISEº lights will go out.
IIf you depress the brake pedal while push-
ing the ªACCELº set switch and reset at the
cruising speed, turn the main switch off
once and then turn it on again.
IThe cruise control will automatically be can-
celled if the vehicle slows down below
approximately 8 MPH (13 km/h).
IDepress the clutch pedal (manual transmis-
sion), or move the selector lever to ªNº
(automatic transmission). The ªCRUISEº
light will go out.
To reset at a faster cruising speed,use one
of the following three methods:
a) Depress the accelerator pedal. When the
vehicle attains the desired speed, push and
release the ªSET/COASTº switch.
b) Push and hold the ªACCELº set switch.
When the vehicle attains the speed you
desire, release the switch.
c) Push, then quickly release the ªACCELº set
switch. Each time you do this, the set speed
will increase by about 1 MPH (1.6 km/h).
SSD0019
CRUISE CONTROL
4-12
Z01.2.1/A32-DX

To reset at a slower cruising speed,use one
of the following three methods:
a) Lightly tap the brake pedal. When the ve-
hicle attains the desired speed, push the
ªSET/COASTº switch and release it.
b) Push and hold the ªSET/COASTº switch.
Release the switch when the vehicle slows
down to the desired speed.
c) Push, then quickly release the
ªSET/COASTº switch. Each time you do
this, the set speed will decrease by about 1
MPH (1.6 km/h).
To resume the preset speed,push and re-
lease the ªRESUMEº set switch. The vehicle
will resume the last set cruising speed when
the vehicle speed is over 30 MPH (48 km/h).
Precautions
Avoid using the cruise control when driv-
ing under the following conditions:
Iwhen it is not possible to keep the vehicle at
set speed.
Iin heavy traffic or in traffic that varies in
speed.
Ion winding roads, or hilly roads.
Ion slippery roads (rain, snow, ice, etc.)Iin very windy areas.
On manual transmission models, do not
shift into neutral without depressing the
clutch pedal when the cruise control is
on. This could cause engine damage. If
this happens, depress the clutch pedal
and turn the main switch off
immediately.
During the first 1,000 miles (1,600 km), follow
these recommendations for the future reliabil-
ity and economy of your new vehicle. Failure to
follow these recommendations may result in
vehicle damage or shortened engine life.
IDo not drive over 55 MPH (90 km/h) and do
not run the engine over 4,000 rpm. Avoid
driving for long periods at constant speed,
either fast or slow.
IDo not accelerate at full throttle in any gear.
IAvoid quick starts.
IAvoid hard braking as much as possible.
IDo not tow a trailer for the first 500 miles
(800 km).
BREAK-IN SCHEDULE
4-13
Z01.2.1/A32-DX

IAccelerate slowly and smoothly. Maintain
cruising speeds with a constant accelerator
position.
IDrive at moderate speeds on the highway.
Driving at high speed will lower fuel
economy.
IAvoid unnecessary stopping and braking.
Maintain a safe distance behind other ve-
hicles.
IUse a proper gear range which suits road
conditions. On level roads, shift into high
gear as soon as possible.
IAvoid unnecessary engine idling.IKeep your engine tuned up.
IFollow the recommended periodic mainte-
nance schedule.
IKeep the tires inflated at the correct pres-
sure. Low pressure will increase tire wear
and waste fuel.
IKeep the front wheels in correct alignment.
Improper alignment will cause not only tire
wear but also lower fuel economy.
IAir conditioner operation lowers fuel
economy. Use the air conditioner only when
necessary.
IWhen cruising at highway speeds, it is
more economical to use the air conditioner
and leave the windows closed to reduce
drag.
SD1001M
ECONOMY HINTS
4-14
Z01.2.1/A32-DX

Do not park the vehicle over flammable
materials such as dry grass, waste pa-
per or rags, as they may burn easily.
1. Firmly apply the parking brake.
2.Manual transmission models:
Place the gearshift lever in the ªREVERSEº
position. When parking on an uphill grade,
place the gearshift lever in the ª1stº posi-
tion.Automatic transmission models:
Move the gearshift lever to the ªPº (PARK)
position.
Safe parking procedures require that
both the parking brake be set and the
transmission placed into ªPº (park) po-
sition. Make sure the shift lever has
been pushed as far forward as it can go
and cannot be moved without depress-
ing the button at the end of the lever.
3. To help prevent the vehicle from rolling into
the street when parked on a sloping drive
way, it is a good practice to turn the wheels
as illustrated.
IHEADED DOWNHILL WITH CURB:
q1
Turn the wheels into the curb and move the
vehicle forward until the curb side wheel
gently touches the curb.
IHEADED UPHILL WITH CURB:
q2
Turn the wheels away from the curb and
move the vehicle back until the curb side
wheel gently touches the curb.
IHEADED UPHILL OR DOWNHILL, NO
CURB:
q3
Turn the wheels toward the side of the road
so the vehicle will move away from the
center of the road if it moves.
4. Turn the ignition key to the ªLOCKº position
and remove the key.
INever leave the engine running while
the vehicle is unattended.
INever leave children unattended in
MSD0002
PARKING/PARKING ON HILLS
4-15
Z01.2.1/A32-DX
