1996 FORD WINDSTAR headrest

Safety Restraints
27
*
[SR14400(ALL)05/95]
When possible, put children in the rear seat of your vehicle. Accident
statistics suggest that children are safer when properly restrained in the
rear seating positions than in the front seating positions.
*
[SR14500(ALL)05/95]
Built-In Child Seat (If equipped)
[SR14600(ALL)04/95]
The second row bench seat may include two optional built-in
child safety seats (one on the driver side and one on the
passenger side). This child restraint is to be usedonlyby
children who are at least one year old, weigh between 9 and
27 kilograms (20 and 60 pounds) and whose shoulders (top) are
below the bottom of the headrest in thefull upposition.
*
[SR14625(ALL)05/95]
If your child is less than one year old or weighs less than
9 kilograms (20 pounds),alwaysuse a rear facing infant or
convertible seat because a child of that size is not sufficiently
developed to withstand crash forces in a front facing position.
Follow the specific manufacturer's instructions for weight and
height restrictions.
*
[SR14700(ALL)05/95]
RWARNING
Always latch the vehicle seat to the floor, whether the
seat is occupied or empty. If not latched, the seat may
cause injury during a sudden stop.
*
[SR15200(ALL)05/95]
Children must be properly buckled before riding in the vehicle.
It is the law in every state and province. This child seat
conforms to all Federal/Canadian motor vehicle safety
standards.
*
[SR15301(ALL)05/95]
Built-in child seat belt retractors
*
[SR15320(ALL)06/95]
The belts on the built-in child seat are equipped with a retractor
that locks when both belt tongues are latched into the crotch
safety belt and buckle.
*
[SR15340(ALL)04/95]
The retractor will switch from the emergency locking mode to
the automatic locking mode when the shoulder belts are pulled
all the way out. The retractor will switch back to emergency
locking mode when the belts are unbuckled and the shoulder
belts retract completely.
File:wnsrs.ex
Update:Tue Mar 19 08:27:08 1996

Safety Restraints
29
*
[SR15800(ALL)05/95]
How to use the Built-In Child Seat
*
[SR15900(ALL)05/95]
Read the following procedures and all of the labels on the
Built-In Child Seat before using the seat.
*
[SR16000(ALL)05/95]
RWARNING
Never use the Built-In Child Seat as a booster cushion
with the adult safety belts. A child using the adult belts
could slide forward and out from under the safety belts.
[SR16100(ALL)04/00]1.
Push the headrest release lever and grasp the headrest as
shown in Figure 1. Then release the lever and rotate the
headrestfull upuntil the latch ªclicksº in thefull up
position. Refer to Figure 2.
[SR16200(ALL)04/95]
10-1/2 pica
art:0050134-B
Figure 1: Releasing the headrest
File:wnsrs.ex
Update:Tue Mar 19 08:27:08 1996

30
[SR16300(ALL)04/95]
17-1/2 pica
art:0050135-B
Figure 2: Release the lever and rotate the headrest to the full up position
[SR16401(ALL)04/95]2.
Lower the seat cushion. Refer to Figure 3. The child safety
seat will move to a semi-reclined position as the seat cushion
is lowered.
[SR16501(ALL)04/95]3.
Read the information and warnings on the child seat cushion
protector flap and shoulder safety belt. Refer to Figure 3.
Check the child's size, weight and age to be sure the child is
not too small or too large for the child seat. Then fold the
flap down onto the adult seat cushion.
File:wnsrs.ex
Update:Tue Mar 19 08:27:08 1996

Safety Restraints
37
[SR18900(ALL)06/95]
To fold up the child seat:
[SR19000(ALL)04/95]1.
Fold the protector flap over the child seat cushion. Refer
back to Figure 3.
[SR19100(ALL)11/93]2.
Rotate the child seat cushion upward.
[SR19200(ALL)04/95]3.
Push the headrest release lever and slide the headrest
downward until it latches against the child seat cushion.
Refer back to Figures 1 and 2.
[SR19300(ALL)05/95]4.
When the child seat isnotin use, it may be folded up so
that an adult may use the vehicle's rear seat.
*
[SR19500(ALL)05/95]
Inspection after a collision
*
[SR19601(ALL)06/95]
RWARNING
All built-in child restraints, including seats, buckles,
retractors, seat latches, interlocks, and attaching hardware
should be inspected by a qualified dealer technician after
any collision.
*
[SR19620(ALL)05/95]
If the child seat was in use during a collision, Ford recommends
replacing it. However, if the collision was minor and a qualified
tehcnician finds that the child restraints do not show damage
and continue to operate properly, they do not need to be
replaced. If there is any bending of the vehicle seat back or seat
structure, it should also be replaced. Built-in child seats not in
use during a collision should also be inspected and replaced if
either damage or improper operation is noted.
*
[SR19700(ALL)05/95]
Cleaning
*
[SR19800(ALL)05/95]
Your Built-In Child Seat may be cleaned with mild soap and
water. Do not use household cleaners as they may weaken the
webbing or damage the plastic parts. For your convenience, the
liner is made to be machine washable and air dried.
File:wnsrs.ex
Update:Tue Mar 19 08:27:08 1996

172
[FV14946(ALL)06/94]
7-1/2 pica art:0050172-A
Head restraint adjustment
[FV14951(ALL)06/94]
NOTE: On GL models, front bucket seats are designed with
integral headrests.
[FV14960(ALL)06/94]
E-Z access operation Ð passenger side optional
second row bucket seats
[FV14965(ALL)03/94]
To provide easy access to the rear of the vehicle, the passenger
side second row bucket seatback can be tilted forward.
*
[FV14970(ALL)11/93]
To tilt seat forward:
*
[FV14975(ALL)11/93]1.
Put the seatback in the upright position.
[FV14980(ALL)11/93]2.
Lift upward on the handle on the right (outboard) side of
the seat (also the recliner release handle).
*
[FV14985(ALL)11/93]3.
The seat can now be tilted forward.
*
[FV14990(ALL)11/93]
To latch the seat in its normal position, push seatback rearward
until it is latched in position.
[FV15020(ALL)11/93]
Adjustable Three Passenger Bench Seat (If equipped)
[FV15040(ALL)12/93]
Your vehicle's third row passenger bench seat may be adjustable
forward and backward. This adjustment allows for additional
cargo space with the seat adjusted to the full forward position
and extra leg room when adjusted rearward.
[FV15060(ALL)04/95]
Rotate the release handle upward to unlatch. The release handle
is located on the right side of the seat near the floor. Adjust to
the desired seat position and release the handle. Make certain
the seat is latched and secure.
