1996 FORD SUPER DUTY Owners Manual

46
*
[SR18400(BEF )04/95]
Attaching Safety Seats With Tether Straps
*
[SR18410(BEF )03/01]
General Instructions
[SR18413(BEF )02/95]
Some manufacturers make safety seats that
include an upper tether strap that goes over the
seatback and attaches to an anchoring point.
Other manufacturers offer the tether strap as an
accessory. Contact the manufacturer of your
child safety seat for information about ordering
a tether strap.
[SR18415( F )02/95]
You can install a tether strap anchor bracket to
the cab inner back panel by using a tether
anchor bracket kit (613D74) available at no
charge from any Ford dealer.
*
[SR18420(BEF )03/91]
Read and follow the instructions provided with
the kit carefully for installation of the child
tether strap anchor.
*
[SR18501(BEF )03/91]
Follow the child seat manufacturer's instructions
to attach the tether strap to the tether bracket.
[SR18800( F )05/95]
Ford recommends placement of tethered safety
seats in a rear seating position (Crew Cab and
Super Cab with forward facing rear seat only)
with the tether strap installed to the tether
anchoring point as shown in the instructions
provided with the child tether strap anchor kit.
*
[SR18950(BEF )05/95]
RWARNING
Only use the tether attachment hole
locations shown in the illustrations. The
tether anchor may not perform properly if
the wrong mounting location is used.
File:ltsrf.ex
Update:Thu May 9 15:26:26 1996

47
*
[SR19100( F )12/91]
If a tethered seat is installed in the front seat,
Ford recommends placement of the tethered
safety seat in the center front seating position,
with the tether strap secured to the center rear
lap belt tongue or to the webbing of the buckled
center rear lap belt behind the child safety seat.
*
[SR19400(B F )04/95]
The rear lap/shoulder safety belts should not be
used to secure the tether strap of a safety seat
located in the front seat.
*
[SR19500(BEF )05/95]
RWARNING
Failure to follow these precautions could
increase the chance of injury in an
accident.
[SR19575( F )05/95]
In SuperCabs equipped with center facing jump
seats, the tether strap anchor bracket should be
installed only at the center of the cab's back
panel with the child seat in the front center
seating position. Installing an anchor bracket at
the right rear of the cab may increase risk of
injury to an occupant of the right rear center
facing jump seat in the event of a collision or
sudden stop. If a tethered child seat is installed
in the right front seating position, secure the
tether strap to the webbing of the buckled right
rear lap belt.
*
[SR19600( F )05/95]
RWARNING
Do not install a child seat in a center
facing jump seat.
File:ltsrf.ex
Update:Thu May 9 15:26:26 1996

49
Starting Your F-Series
*
[ST01700( ALL)03/95]
Ignition
%*
[ST01800( ALL)01/95]
Understanding the Positions of the Ignition
*
[ST02000( ALL)05/90]
quarter page art:0020004-B
The positions of the key in the ignition lock cylinder.
*
[ST02200( ALL)03/95]
ON allows you to test your vehicle's warning
lights (except the brake system warning light) to
make sure they work before you start the
engine. The key returns to the ON position once
the engine is started and remains in this position
while the engine runs.
*
[ST02300( ALL)03/95]
START cranks the engine. Release the key once
the engine starts so that you do not damage the
starter. The key should return to ON when you
release it. The START position also allows you
to test the brake warning light.
*
[ST02400( ALL)03/95]
OFF allows you to shut off the engine and all
accessories without locking the steering wheel or
the automatic transmission gearshift lever.
[ST02500(B F )05/95]
LOCK locks the steering wheel. It also locks the
gearshift if your vehicle's gearshift is on the
column.
File:ltstf.ex
Update:Thu May 9 15:26:52 1996

50
*
[ST02600(B F )05/95]
RWARNING
LOCK position does not lock the gearshift
on floor-mounted gearshifts. If the
parking brake is not set and the gearshift
is moved out of Park (automatic
transmission) or out of gear (manual
transmission), your vehicle may move
unexpectedly.
[ST02635(B F )05/95]
With the transfer case in N (Neutral), the vehicle
is free to move with either the automatic
transmission in P (Park) or with the manual
transmission in any driving gear.
*
[ST02650(B F )05/95]
RWARNING
Do not leave the vehicle unattended with
the transfer case in the N (Neutral)
position. Always set the parking brake
fully and turn off the ignition when
leaving the vehicle.
*
[ST02700( ALL)01/95]
LOCK is the only position that allows you to
remove the key. The LOCK feature helps to
protect your vehicle from theft.
%*
[ST02800( ALL)05/95]
If the key is stuck in the LOCK position, move
the steering wheel left or right until the key
turns freely.
%*
[ST02900( ALL)03/95]
ACCESSORY allows some of your vehicle's
electrical accessories such as the radio and the
windshield wipers to operate while the engine is
not running.
*
[ST02950(B F )01/95]
In order to turn the key from the ON or OFF
position to the ACCESSORY position, you must
push the key release button if your vehicle's
manual transmission gearshift is mounted on the
floor.
File:ltstf.ex
Update:Thu May 9 15:26:52 1996

51
*
[ST03025(BEF )03/91]
Ignition Key Buzzer or Chime
*
[ST03050(BEF )03/91]
The buzzer or chime will sound if you open the
driver's door while the key is in the ignition.
Never leave your vehicle unattended with the
key in the ignition.
%*
[ST03075( ALL)02/95]
Removing the Key From the Ignition
*
[ST03100(B F )03/91]
Procedures for removing your key from the
ignition will vary, depending on the type of
gearshift your vehicle has. Gearshift levers may
be mounted on the steering column or on the
floor or console.
*
[ST03115(B F )05/91]
If you have a manual transmission, you have a
key release lever which allows you to remove
your key from the ignition. The key release lever
is on the upper right of the steering column, just
above the key lock cylinder. The lever says
PUSH.
*
[ST03120(B F )05/91]
quarter page art:0020833-A
Key release lever
*
[ST03300(B F )03/91]
If your vehicle's gearshift lever is mounted
on the column:
*
[ST03400( ALL)03/95]
1. Put the gearshift in Park.
*
[ST03500( ALL)03/91]
2. Set the parking brake fully before removing
your foot from the service brake. (This will
avoid ªbindingº or ªloadingº the park gear
if you park on a grade.)
*
[ST03600( ALL)03/95]
3. Turn the ignition key to LOCK.
File:ltstf.ex
Update:Thu May 9 15:26:52 1996

52
*
[ST03700( ALL)03/95]
4. Remove the key.
*
[ST03800(B F )03/91]
If your vehicle's gearshift lever is mounted
on the floor:
*
[ST03950(B F )03/95]
1. Put the gearshift in 1 (First).
*
[ST04000(B F )03/91]
2. Turn the ignition key to OFF.
*
[ST04100(B F )05/91]
3. Set the parking brake fully before removing
your foot from the service brake.
*
[ST04200(B F )06/92]
4. Push and hold in the key release button.
*
[ST04300(B F )10/90]
5. Turn the key to LOCK.
*
[ST04400(B F )03/95]
6. Remove the key.
*
[ST04600(B F )05/95]
RWARNING
Always set the parking brake fully and
make sure that the gearshift is latched in
P (Park) (automatic transmission) or 1
(First) (manual transmission).
[ST04635(B F )05/95]
With the transfer case in N (Neutral), the vehicle
is free to move with either the automatic
transmission in P (Park) or with the manual
transmission in any driving gear.
*
[ST04650(B F )05/95]
RWARNING
Do not leave the vehicle unattended with
the transfer case in the N (Neutral)
position. Always set the parking brake
fully and turn off the ignition when
leaving the vehicle.
File:ltstf.ex
Update:Thu May 9 15:26:52 1996

53
*
[ST04750( ALL)01/93]
RWARNING
Do not leave children, unreliable adults,
or pets alone in your vehicle. They could
accidentally injure themselves or others
through inadvertent operation of the
vehicle. Further, on hot, sunny days,
temperatures in a closed vehicle could
quickly become high enough to cause
severe and possibly fatal injuries to
people as well as animals.
%
*
[ST04800( ALL)03/95]
Fuel-Injected Engines
*
[ST04850( EF )04/94]
NOTE: For owners of diesel-powered vehicles,
refer to theDiesel Engine Owners Guide
Supplementfor information on starting
your vehicle.
*
[ST04900(BEF )03/95]
When starting a fuel-injected engine,the most
important thing to remember is to avoid
pressing down on the accelerator before or
during starting. Only use the accelerator when
you have problems getting your vehicle started.
SeeStarting Your Enginein this chapter for
details about when to use the accelerator while
you start your vehicle.
*
[ST05000(B F )01/95]
Because your vehicle's engine is electronically
controlled by a computer, some control
conditions are maintained by power from the
battery. If you ever disconnect the battery, install
a new battery, or experience a dead battery, you
must allow the computer to ªrelearnº its idle
conditions before your vehicle will idle at its
best. To let the engine do this, apply the parking
brake, put the gearshift in Park (automatic
transmission) or Neutral (manual transmission),
turn off all the accessories, and start the vehicle.
Let the engine idle for at least one minute.
File:ltstf.ex
Update:Thu May 9 15:26:52 1996

54
*
[ST05100(BEF )03/95]
If you do not let the engine relearn its idle, the
idle quality of your vehicle may be adversely
affected until the idle is relearned. Your vehicle
will eventually relearn its idle while you drive
it, but it takes much longer than if you use the
previous procedure.
[ST05150( ALL)02/95]Starting your vehicle
%*
[ST05200( ALL)05/94]
Preparing to Start Your Vehicle
*
[ST05300( ALL)05/95]
RWARNING
Do not start your vehicle in a closed
garage or other enclosed area. Never sit in
a stopped vehicle for more than a short
period of time with the engine running.
Exhaust fumes are toxic. SeeGuarding
Against Exhaust Fumesin this chapter for
more instructions.
*
[ST05400( ALL)01/95]
Before you start your vehicle, do the following:
*
[ST05500(BEF )01/95]
1. Make sure you and all your passengers
buckle your safety belts. SeeSafety Restraints
in the Index for more details.
*
[ST05600( ALL)03/95]
2. Make sure the headlamps and other
accessories are turned off when starting.
*
[ST05700(B F )10/94]
3.If you have an automatic transmission,
make sure that the gearshift lever is in P
(Park) and the parking brake is set before
you turn the key.
*
[ST05800(B F )03/91]
4.If you have a manual transmission,make
sure that the parking brake is fully set, push
the clutch pedal to the floor, and put the
gearshift into Neutral before you turn the
key. (Remember, the starter will operate only
if the clutch pedal is pushed in all the way).
File:ltstf.ex
