1996 FORD MUSTANG engine

273
*
[SV32350( ALL)05/95]
RWARNING
Brake fluid is toxic.
*
[SV32375( ALL)07/95]
If brake fluid contacts eyes, flush eyes with
running water for 15 minutes. Get medical
attention if irritation persists. If taken internally,
drink water and induce vomiting. Get medical
attention immediately.
*
[SV32400( ALL)03/95]
If the fluid is low, carefully clean and remove
the cap from the reservoir. Fill the reservoir to
the MAX line with Ford High Performance DOT
3 Brake Fluid C6AZ-19542-AA, C6AZ-19542-BA,
or equivalent DOT 3 fluid meeting Ford
specification ESA-M6C25-A.
*
[SV33100( ALL)01/95]
RWARNING
If you use a brake fluid that is not DOT
3, you will cause permanent damage to
your brakes.
*
[SV33200( ALL)01/95]
Do not fill the reservoir above the MAX line.
[SV33400(M )05/95]
one third page art:0010386-C
The brake fluid reservoir Ð 3.8L engines
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

274 [SV33450(M )05/95]
one third page art:0011349-AThe brake fluid reservoir Ð 4.6L engines
*
[SV33700( ALL)01/95]
If you find that the fluid level is excessively low
Ð below the seam or ridge on the outside of the
plastic reservoir Ð have the brake system
inspected.
*
[SV33750( ALL)01/95]
RWARNING
Do not let the reservoir for the master
cylinder run dry. This may cause the
brakes to fail.
%
*
[SV34800( ALL)03/95]
Power Steering Fluid
*
[SV34900( ALL)01/95]
Check the level of the power steering fluid at
least twice a year (i.e., every Spring and Fall).
%*
[SV35000( ALL)03/95]
Checking and Adding Power Steering
Fluid
[SV35055(M )10/95]
3.8L SFI engine (check warm)
*
[SV35100( ALL)02/95]
1. Start the engine and let it run until the
power steering fluid reaches normal
operating temperature. The power steering
fluid will be at the right temperature when
the engine coolant temperature gauge in the
instrument cluster is near the center of the
NORMAL operating temperature range.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

275
*
[SV35200( ALL)01/95]
2. While the engine idles, turn the steering
wheel back and forth several times. Make
sure that the cap assembly is installed at this
time.
*
[SV35300( ALL)05/95]
3. Turn the engine off.
%*
[SV35400(MBC )03/94]
4. Check the fluid level on the dipstick (which
is highlighted in yellow in your vehicle). The
fluid level should be between the arrows in
the FULL HOT range, which is marked on
the side of the dipstick, opposite the side
marked FULL COLD. Do not add fluid if the
level is within the FULL HOT range.
*
[SV35500(MBC )07/94]
5. If the power steering fluid is low, add fluid
in small amounts, continuously checking the
level, until you reach the FULL HOT range.
Do not overfill.
*
[SV35600(MBC )03/95]
6. When you are finished, put the dipstick back
in and make sure that it fits snugly.
[SV35700(MBC )12/94]
half page art:0010485-C
The dipstick for power steering fluid
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

276 [SV35875(M GV)03/95]Use only power steering fluid that meets Ford
Specification MerconHATF XT-2-QDX.
*
[SV35900( ALL)01/95]
If the power steering fluid is low, do not drive
your vehicle for a long period of time before
adding fluid. This can damage the power
steering pump.
*
[SV36100(MBC )02/95]
If you check the power steering fluid when it is
cold, make sure that the fluid reaches the FULL
COLD range on the dipstick. The reading will
only be accurate if the fluid temperature is
approximately 50 to85ÊF (10 to 30ÊC).
[SV36105(M )10/95]
NOTE: The brakes on the 4.6L engine vehicles
are powered by power steering fluid
from the power steering pump. The
fluid level in the power steering
reservoir will rise and fall due to the
amount of charge in the brake booster
accumulator. Therefore the following is
required.
[SV36157(M )10/95]
4.6L SFI engine (check cold)
[SV36170(MBC )03/95]
1. Check the fluid level when the system is
COLD (allow at least one half hour after
driving for the power steering fluid to cool).
[SV36171(MBC )10/95]
2. Locate the power steering reservoir mounted
to the front upper left-hand corner of the
engine.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

277 [SV36174(M )10/95]
NOTE: Brake fluid and power steering fluid
CAN NOT be mixed. Only add brake
fluid to the brake master cylinder
reservoir. Only add power steering
fluid to the power steering reservoir.
[SV36179(M )10/95]
3. Visually verify that the fluid level is above
the MIN line adjacent to the reservoir ªsight
window.º
[SV36183(M )10/95]
4. If the power steering fluid is below the MIN
line, remove the cap and add fluid in small
amounts until the level is between the MIN
and MAX lines.
[SV36186(M )10/95]
5. Reinstall the reservoir cap.
[SV36188(M)02/96]
It is normal for the fluid level to be above the
MAX line after the brake pedal has been pushed
several times with the engine off. (If you want
to double check it; restart the engine and turn
steering wheel to full right turn, the full left turn
and then turn engine off and re-check fluid
level. It should be between the MIN and MAX
line.)
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

282 [SV37700(M )10/95]
twenty-four pica chart:0010492-G
%*
[SV39000( ALL)01/95]
High Current Fuses
*
[SV39200( ALL)01/95]
High current fuses are circuit protectors that are
part of the wiring harness for some electrical
equipment. These, like fuses, open when the
circuit load exceeds their amperage rating. High
current fuses may be purchased from your Ford
or Lincoln-Mercury dealer.
*
[SV39300(MBC )01/95]
The high current fuse panel is located in the
engine compartment on the left-hand fender
apron.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

294
%*
[SV52400( ALL)03/95]
Emission Control System
*
[SV52500( ALL)05/95]
Your vehicle is equipped with a catalytic
converter which enables your vehicle to comply
with applicable exhaust emission requirements.
*
[SV52550( ALL)06/95]
RWARNING
Exhaust leaks may result in the entry of
harmful and potentially lethal fumes into
the passenger compartment. Under
extreme conditions excessive exhaust
temperatures could damage the fuel
system, the interior floor covering, or
other vehicle components, possibly
causing a fire.
*
[SV52600( ALL)05/95]
To make sure that the catalytic converter and the
other emission control parts continue to work
properly:
*
[SV52700( ALL)01/95]
q
Use only unleaded fuel.
*
[SV52800( ALL)01/95]
q
Avoid running out of fuel.
*
[SV52900( ALL)01/95]
q
Do not turn off the ignition while your
vehicle is moving, especially at high speeds.
*
[SV52950( ALL)01/95]
q
Do not push start your vehicle.
*
[SV53000( ALL)03/95]
q
Have the services listed in theMaintenance
Schedule and Recordbooklet performed
according to the specified schedule. The
scheduled maintenance services are required
because they are considered essential to the
life and performance of your vehicle and to
its emissions system.
*
[SV53075( ALL)03/95]
In general, maintenance, replacement, or service
of the emissions control devices or systems in
your new Ford Motor Company vehicle or
engine may be performed at your expense by
any automotive repair establishment or
individual using automotive parts equivalent to
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

295
those which your vehicle or engine was
originally equipped.
*
[SV53150( ALL)05/95]
Ford strongly recommends the use of genuine
Ford replacement parts. If other than Ford or
Motorcraft parts or Ford authorized
remanufactured parts are used for maintenance
replacements or for the service of components
affecting emission control, such non-Ford parts
should be equivalent to genuine Ford Motor
Company parts in performance and durability. It
is the owner's responsibility to determine the
equivalency of such parts. Please consult your
warranty booklet for complete warranty
information.
*
[SV53175( ALL)05/95]
RWARNING
Do not park, idle, or drive your vehicle in
dry grass or other dry ground cover. The
emission system heats up the engine
compartment and exhaust system, which
can start a fire.
*
[SV53200( ALL)05/95]
Watch for fluid leaks, strange odors, smoke, loss
of oil pressure, the charge warning light, the
check engine light, or the temperature warning
light. These sometimes indicate that the emission
system is not working properly.
*
[SV53300( ALL)01/95]
Do not make any unauthorized changes to your
vehicle or engine. Changes that cause more
unburned fuel to reach the exhaust system can
increase the temperature of the engine or
exhaust system.
*
[SV53400( ALL)01/95]
By law, anyone who manufactures, repairs,
services, sells, leases, trades vehicles, or
supervises a fleet of vehicles is not permitted to
intentionally remove an emission control device
or prevent it from working. In some of the
United States and in Canada, vehicle owners
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996
