1996 FORD MUSTANG torque

211
*
[RE08980( ALL)01/95]
6. Remove the jack and fully tighten the lug
nuts in the order shown in the following
illustration. As soon as possible, have your
dealer or a qualified service technician check
the lug nuts for proper torque specifications.
% [RE09100( ALL)03/93]
quarter page art:0010350-A
The lug nuts on the wheel
*
[RE09400( ALL)01/95]
7. Place any wheel covers and ornaments in the
trunk.
*
[RE09500( ALL)03/95]
8. Put the tire, jack, and wrench away. Make
sure the jack is securely fastened so it does
not rattle when you drive.
*
[RE09600( ALL)06/95]
9. Unblock the wheels.
% [RE10600(MBC )12/94]
Aluminum Road Wheel Ornaments
(If equipped)
[RE10700(MBC )03/93]
To remove the ornament, stick the tapered end
of the jack handle between the ornament and
wheel and pry off the ornament.
[RE10800(MBC )03/93]
To replace the ornament, stick one side of the
ornament into the center of the wheel and strike
the other side with the palm of your hand.
[RE11838(M GV)03/93]
Remove the wheelcover from the wheel using
the flanged end of the wheel nut wrench by
inserting the handle and then prying against the
inner wheelcover flange.
[RE11842(M GV)10/95]
Install the wheelcover on the wheel with the
valve stem in the wheel matching the hole in the
wheelcover. Push by hand on the outside edges
File:12rcrem.ex
Update:Wed Mar 27 09:34:49 1996

229 [AC00910(M )05/94]
NOTE: Use only hook and pad design roof
racks. Follow all manufacturers
recommendations including vehicle
speed, rack loads and tie down
procedures. Also, DO NOT over torque
the hook clamp, as vehicle damage
may occur.
*
[AC01400( ALL)01/95]
NOTE: When adding accessories, equipment,
passengers, and luggage to your
vehicle, do not exceed the total weight
capacity of the vehicle or of the front
or rear axle (GVWR, GAWR as shown
on the Safety Compliance Certification
Label). Consult your dealer for specific
weight information.
[AC01500( ALL)09/95]
NOTE: The Federal Communications
Commission (FCC) or in Canada the
Canadian Radio Telecommunications
Commission (CRTC) regulates the use
of mobile communications systems Ð
such as two-way radios, telephones,
and theft alarms Ð that are equipped
with radio transmitters. Any such
equipment installed in your vehicle
should comply with FCC regulation
and should be installed only by a
qualified technician.
File:14rcacm.ex
Update:Wed Mar 27 09:35:46 1996
