1996 FORD MUSTANG reset

54
*
[ST10473( ALL)08/95]
Whenever you start your vehicle, release the key
as soon as the engine starts. Excessive cranking
could damage the starter.
*
[ST10476( ALL)05/95]
After you start the engine, let it idle for a few
seconds. Keep your foot on the brake pedal and
put the gearshift lever in gear. Release the
parking brake. Slowly release the brake pedal
and drive away in the normal manner.
[ST10478( ALL)12/94]
NOTE: Your vehicle has an interlock that
prevents you from shifting out of P
(Park) unless your foot is on the brake
pedal.
%*
[ST10480( ALL)04/95]
If the engine does not start after two attempts:
*
[ST10492( ALL)04/95]
1. Turn the ignition key to the OFF position.
*
[ST10494( ALL)04/95]
2. Press the accelerator all the way to the floor
and hold it.
*
[ST10496( ALL)04/95]
3. Turn the ignition key to the START position.
*
[ST10497( ALL)04/95]
4. Release the ignition key when the engine
starts.
*
[ST10498( ALL)04/95]
5. Release the accelerator gradually as the
engine speeds up. Then drive away in the
normal manner.
*
[ST10500( ALL)04/95]
If the engine still does not start, the fuel pump
shut-off switch may have been triggered. For
directions on how to reset the switch seeFuel
Pump Shut-Off Switchlater in this chapter.
*
[ST11100( ALL)07/95]
A computer system controls the engine's idle
speed. When you start your vehicle, the engine's
idle speed normally runs higher than when it's
warmed up. These faster engine speeds will
make your vehicle move slightly faster than its
normal idle speed. It should, however, slow
down after a short time. If it does not, have the
idle speed checked.
File:04rcstm.ex
Update:Wed Mar 27 09:28:42 1996

57 [ST14000( ALL)12/94]
If the engine is idling while you are stopped in
an open area for long periods of time, open the
windows at least one inch (2.5 cm). Also, the
heating or air conditioning system should be set
to any function except MAX A/C or AUTO.
[ST14100(M )12/88]
q
If you use the heater, set the fan speed on
MEDIUM or HIGH with the function control
knob at any desired position.
[ST14150(M )12/88]
q
If you use the air conditioner, set the fan
speed on MEDIUM or HIGH with the
function control knob at any position except
OFF and the temperature control lever at
mid-position.
%
*
[ST17100( ALL)03/95]
If the Engine Cranks but Does
Not Start or Does Not Start After
a Collision
[ST17110( ALL)07/95]
Fuel System Shut-off Switch
[ST17200( ALL)07/95]
If the engine cranks but does not start or does
not start after a collision, the fuel system shut-off
switch may have been triggered. The shut-off
switch is a device intended to stop the fuel
system when your vehicle has been involved in
a substantial jolt.
[ST17410(M )12/94]
Once the shut-off switch is triggered, you must
reset the switch by hand before you can start
your vehicle. The switch is on the left side of the
trunk near the left tail lamp.
File:04rcstm.ex
Update:Wed Mar 27 09:28:42 1996

58 [ST17500(M )09/93]
one third page art:0010012-DThe fuel pump shut-off switch
*
[ST18700( ALL)05/95]
RWARNING
If you see or smell fuel, do not reset the
switch or try to start your vehicle. Have
all the passengers get out of the vehicle
and call the local fire department or a
towing service.
*
[ST18800( ALL)03/95]
If your engine cranks but does not start after a
collision or substantial jolt:
*
[ST18900( ALL)04/95]
1. Turn the ignition key to the OFF position.
*
[ST19000( ALL)03/95]
2. Check under the vehicle for leaking fuel.
*
[ST19100( ALL)03/95]
3. If you do not see or smell fuel, push the red
reset button down. If the button is already
set, you may have a different mechanical
problem.
*
[ST19200( ALL)03/95]
4. Turn the ignition key to the ON position for
a few seconds, then turn it to the OFF
position.
File:04rcstm.ex
Update:Wed Mar 27 09:28:42 1996

75 %
*
[LG14800( ALL)01/95]
Speedometer
[LG14850(M )05/95]
one third page art:0011345-A
The speedometer
*
[LG14900( ALL)01/95]
The speedometer tells you how many miles
(kilometers) per hour your vehicle is moving.
%*
[LG15000( ALL)01/95]
Odometer
*
[LG15100( ALL)01/95]
The odometer tells you the total number of miles
(kilometers) your vehicle has been driven.
%*
[LG15200( ALL)11/94]
Trip Odometer
*
[LG15300( ALL)03/93]
If you want to track your mileage up to 999.9
miles (kilometers), use the trip odometer. Simply
set the trip odometer to zero by pressing the
reset button firmly when beginning the distance
you wish to measure.
*
[LG15350( ALL)01/95]
Since the trip odometer displays distance
independent of the odometer it will not always
advance to the next mile (kilometer) at the same
time as the odometer.
File:05rclgm.ex
Update:Wed Mar 27 09:29:39 1996

99
*
[SC11000( ALL)08/95]
If you drive up or down a steep hill, your
vehicle may momentarily slow down or speed
up, even though the speed control is on. This is
normal.
*
[SC11030( ALL)03/95]
NOTE: If your speed increases above your set
speed while driving in D (Drive) on a
downhill grade, you may want to
depress the Transmission Control
Switch located on the shift lever to
turn off overdrive to reduce vehicle
speed. Speed control cannot reduce the
vehicle speed if it goes above your set
speed on a downhill grade.
[SC11045(M )03/95]
NOTE: If your vehicle is equipped with a 5
speed manual transmission, and if your
speed increases above your set speed
while driving in 5 (Fifth) gear on a
downhill grade, you may want to shift
to 4 (Fourth) gear to reduce vehicle
speed. Depressing the clutch pedal
cancels speed control, therefore speed
control must be reset by pressing the
SET/ACCEL or RESUME buttons.
Speed control cannot reduce the vehicle
speed if it goes above your set speed
on a downhill grade.
*
[SC11100( ALL)08/95]
RWARNING
Do not use the speed control in heavy
traffic or on roads that are winding,
slippery, or unpaved.
File:07rcscm.ex
Update:Wed Mar 27 09:30:54 1996

100 %
*
[SC11200( ALL)08/95]
Accelerating With the Speed Control
Operating
*
[SC11300( ALL)08/95]
You can use the accelerator pedal to speed up
momentarily. When you take your foot off the
accelerator, the vehicle will return to the set
speed.
%*
[SC11400( ALL)08/95]
Resetting the Speed Control
*
[SC11450( ALL)08/95]
To reset the speed control to alower speed, use
one of the following procedures:
[SC11500( ALL)05/94]
q
COAST ÐPress and hold the COAST switch.
Release the switch when the vehicle slows
down to the desired speed.
*
[SC11550( ALL)08/95]
q
Lightly tap the brake pedal. When the vehicle
attains the desired speed, press the SET
ACCEL switch and release it immediately.
% [SC11600(M GV)05/95]
q
TAP-DOWNÐ Press and then quickly
release the COAST switch. Each time you
ªtapº the switch, the set speed will decrease
by one (1) mph (1.6 km/h). Multiple taps
will cause the set speed to decrease in
increments of one (1) mph (1.6 km/h). For
example, if the current set speed is 60 mph
(96 km/h) five (5) taps of the COAST switch
will decrease the vehicle speed and SET it at
55 mph (88 km/h).
*
[SC11650( ALL)08/95]
If vehicle speed is reduced below 30 mph
(50 km/h) by any of the above methods, then
you must manually accelerate to a speed over
30 mph (50 km/h) and reset the system.
*
[SC11700( ALL)08/95]
To reset the speed control toa higher speed,
follow one of these procedures:
[SC11750( ALL)05/94]
q
ACCEL ÐPress and hold the SET ACCEL
switch. Release the switch when the vehicle
has accelerated to the desired speed.
File:07rcscm.ex
Update:Wed Mar 27 09:30:54 1996

111
*
[FV08080( ALL)02/95]
Locking the doors
*
[FV08085( ALL)02/95]
To lock all the doors, press the LOCK button.
*
[FV08090(MBC )01/95]
If you would like a signal that the doors are
being locked, press the LOCK button again
within five seconds. The doors will lock again,
the horn will beep and the low beam headlamps
and tail lamps will flash.
%*
[FV08114( ALL)02/95]
Activating the remote personal alarm
*
[FV08120( ALL)02/95]
If you wish to activate the remote personal
alarm, press the PANIC button. This will honk
the horn and flash the low beam headlamps and
tail lamps for approximately two minutes and
forty-five seconds. You can turn it OFF by
pressing the PANIC button again or by turning
the ignition key to the RUN position.
[FV08125( ALL)05/94]
When you use the remote entry UNLOCK,
TRUNK or PANIC buttons, the illuminated entry
system turns on the interior lights for 25
seconds. You can turn these lights off with the
LOCK button or by turning the ignition to the
RUN position. The interior lights will not turn
off if you have turned them on manually or if a
door is open.
%*
[FV08200(M )05/95]
Arming and disarming the alarm system
[FV08300(M )05/95]
If your vehicle is equipped with the optional
factory installed anti-theft system, the remote
entry system will automatically arm it when the
doors are locked with the remote entry LOCK
button. The remote entry UNLOCK button will
disarm or reset a triggered anti-theft alarm.
*
[FV08400(M )05/95]
The remote entry system is designed to work
with the factory installed anti-theft system. It
may not work with other anti-theft systems.
File:08rcfvm.ex
Update:Wed Mar 27 09:32:34 1996

144
*
[AS23200(MBC )10/95]
q
Setting the Station Memory Preset buttons
*
[AS23300(MBC )10/95]
Your radio is equipped with 6 station
memory buttons. These buttons can be used
to select up to 6 preset AM stations and 12
FM stations (6 in FM1 and 6 in FM2).
*
[AS23400(MBC )10/95]
Follow the easy steps below to set these buttons
to the desired frequencies:
*
[AS23500(MBC )10/95]
1. Select a band, then select a frequency.
*
[AS23700(MBC )10/95]
2. Press one of the memory preset buttons and
hold the button until the sound returns. That
station is now held in memory on that
button.
*
[AS23800(MBC )10/95]
3. Follow the two steps above for each station
memory preset button you want to set.
[AS23900(MBC )09/95]
NOTE: If the vehicle's battery is disconnected,
the station memory preset buttons will
need to be reset.
*
[AS24000(MBC )10/95]
Adjusting the tone balance and speaker
output of your radio
*
[AS24100(MBC )10/95]
q
Increasing or decreasing bass response
*
[AS24250(MBC )06/95]
Push the ªAUDIOº button repeatedly until
the display reads ªBASS.º Push the right (+)
side of the ªVOLUMEº button to increase
bass (more ªlowsº), and push the left (s)
side to decrease bass (less ªlowsº).
*
[AS24300(MBC )10/95]
q
Increasing or decreasing treble response
[AS24450(MBC )06/95]
Push the ªAUDIOº button repeatedly until
the display reads ªTREB.º Push the right (+)
side of the ªVOLUMEº button to increase
treble (more ªhighsº), and push the left (S)
side to decrease treble (less ªhighsº).
File:09rcasm.ex
Update:Wed Mar 27 09:33:20 1996
