1996 FORD MUSTANG clutch

52
*
[ST07300( ALL)03/95]
Starting Your Vehicle
%*
[ST07400( ALL)05/94]
Preparing to Start Your Vehicle
*
[ST07500( ALL)09/95]
RWARNING
Do not start your vehicle in a closed
garage or other enclosed area. Never sit in
a stopped vehicle for more than a short
period of time with the engine running.
Exhaust fumes are toxic. SeeGuarding
Against Exhaust Fumesin this chapter for
more instructions.
*
[ST07600( ALL)01/95]
Before you start your vehicle, do the following:
*
[ST07700( ALL)08/95]
1. Make sure all occupants in the vehicle
buckle their safety belts. SeeSafety Restraints
in the Index for more details.
*
[ST07800( ALL)03/95]
2. Make sure the headlamps and other
accessories are turned off when starting.
[ST07900(M )03/95]
3.If you have an automatic transmission,
make sure that the gearshift is in P (Park)
and the parking brake is set before you turn
the key.
[ST08000(M )03/95]
If you have a manual transmission, make
sure that the parking brake is fully set, push
the clutch pedal to the floor, and put the
gearshift into Neutral before you turn the
key.The starter will operate only if the
clutch pedal is pushed in all the way.
*
[ST08400( ALL)03/95]
Before you start your vehicle, you should test
the warning lights on the instrument panel to
make sure that they work. Refer to theWarning
Lights and Gaugeschapter.
File:04rcstm.ex
Update:Wed Mar 27 09:28:42 1996

99
*
[SC11000( ALL)08/95]
If you drive up or down a steep hill, your
vehicle may momentarily slow down or speed
up, even though the speed control is on. This is
normal.
*
[SC11030( ALL)03/95]
NOTE: If your speed increases above your set
speed while driving in D (Drive) on a
downhill grade, you may want to
depress the Transmission Control
Switch located on the shift lever to
turn off overdrive to reduce vehicle
speed. Speed control cannot reduce the
vehicle speed if it goes above your set
speed on a downhill grade.
[SC11045(M )03/95]
NOTE: If your vehicle is equipped with a 5
speed manual transmission, and if your
speed increases above your set speed
while driving in 5 (Fifth) gear on a
downhill grade, you may want to shift
to 4 (Fourth) gear to reduce vehicle
speed. Depressing the clutch pedal
cancels speed control, therefore speed
control must be reset by pressing the
SET/ACCEL or RESUME buttons.
Speed control cannot reduce the vehicle
speed if it goes above your set speed
on a downhill grade.
*
[SC11100( ALL)08/95]
RWARNING
Do not use the speed control in heavy
traffic or on roads that are winding,
slippery, or unpaved.
File:07rcscm.ex
Update:Wed Mar 27 09:30:54 1996

101
*
[SC11800( ALL)08/95]
q
Depress the accelerator pedal. When the
vehicle attains the desired speed, press the
SET ACCEL switch and release it
immediately.
% [SC11850(M GV)05/95]
q
TAP-UPÐ Press and then quickly release the
SET ACCEL switch. Each time you ªtapº the
switch, the set speed will increase by one (1)
mph (1.6 km/h). Multiple taps will cause the
set speed to increase in increments of one (1)
mph (1.6 km/h). For example, if the current
set speed is 55 mph (88 km/h) five (5) taps
of the SET ACCEL switch will increase the
vehicle speed and SET it at 60 mph
(96 km/h).
%*
[SC12800( ALL)08/95]
Resuming a Set Speed
[SC12900(M )03/95]
If you press the brake or clutch pedal, speed
control is suspended. You can return to the set
speed you set by pressing the RESUME switch,
as long as you did not press the OFF switch.
You must be driving at least 30 mph (48 km/h).
*
[SC13400( ALL)05/95]
Your vehicle will gradually return to the
previously set speed and then maintain it.
%*
[SC13501( ALL)01/95]
To Turn Speed Control Off
*
[SC13601( ALL)08/95]
Press the OFF switch.
*
[SC13701( ALL)01/95]
Speed control is also turned OFF each time the
vehicle ignition is shut off.
File:07rcscm.ex
Update:Wed Mar 27 09:30:54 1996

182
*
[DR03200( ALL)06/95]
RWARNING
Always set the parking brake fully and
make sure the gearshift is securely latched
in P (Park).
*
[DR03225( ALL)06/95]
RWARNING
Never leave your vehicle unattended
while it is running.
*
[DR03400(MBC )01/95]
You can tell a console-mounted gearshift is
securely latched in P (Park) if the lever is
adjacent to the P (Park) and you cannot move it
without pushing in the thumb button.
%
*
[DR06100(M )03/95]
Driving with a Manual
Transmission
%*
[DR06200(M )03/95]
Using the Clutch
[DR06300(M )03/95]
After starting the engine with the clutch pedal
pushed to the floor, allow it to idle for a few
seconds. Then, hold your right foot on the brake
pedal. Release the hand brake. Move the
gearshift into 1 (First) or R (Reverse) gear.
[DR06400(M )03/95]
To move the vehicle, pull your right foot off the
brake pedal and then slowly release the clutch
pedal. (You may need to press down slowly on
the accelerator at the same time that you release
the clutch pedal.)
*
[DR06500(M )03/95]
Do not drive with your foot resting on the
clutch pedal and do not use the clutch to hold
your vehicle at a standstill while waiting on a
hill. These actions will seriously reduce clutch
life.
*
[DR06600(M )03/95]
Driving with your foot resting on the clutch may
cause the vehicle to jerk sharply when pressing
or removing your other foot from the
accelerator.
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

183 %
*
[DR06700(M )03/95]
Shifting the Gears
[DR06800(M )03/95]
The gearshift can be in one of seven possible
positions, as shown below.
[DR06950(M )03/95]
one third page art:0010574-B
The positions of the floor-mounted gearshift
[DR07000(M )03/95]
Always push the clutch pedal all the way in
when you shift. You should upshift according to
the speeds given in the chart in this section.
%*
[DR07100(M )03/95]
Backing up
*
[DR07200(M )03/95]
To shift into R (Reverse):
*
[DR07300(M )05/95]
1. Bring your vehicle to acompletestop.
[DR07400(M )03/95]
2. Push the clutch pedal in all the way to the
floor.
[DR07550(M )03/95]
3. Then move the gearshift all the way to the
right and pull it back into R (Reverse).
[DR07800(M )03/95]
4. Once R (Reverse) is engaged, slowly release
the clutch pedal from the floor.
[DR07900(M )03/95]
If R (Reverse) is not engaged, continue to push
the clutch pedal in while you put the gearshift
back into Neutral. Then, release the clutch pedal
for a moment and repeat steps 2 through 4.
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

185 %
*
[DR09000(M )05/95]
Downshifting
*
[DR09100(M )03/95]
When you slow down or climb a steep hill,
always downshift before the engine starts to lose
power. Downshifting reduces the chance of
stalling and gives your vehicle better acceleration
to increase speed again.
*
[DR09200(M )03/95]
When you drive down steep hills, downshifting
helps you keep a safe speed and helps prevent
unnecessary wear on the brakes.
*
[DR09300(M )03/95]
When you come to a stop, do not downshift
through each gear. Disengage the clutch and use
the brake as necessary. Downshifting through
the gears decreases your vehicle's fuel economy.
[DR09400(M )03/95]
NOTE: Do not downshift into 1 (First) when
your vehicle is moving faster than
15 mph (24 km/h). This will damage
the clutch.
*
[DR09500(M )03/95]
Parking
*
[DR09600(M )03/95]
To park your vehicle, shift into 1 (First), set the
parking brake fully, and turn off the ignition.
*
[DR09700(M )05/95]
RWARNING
Do not park your vehicle in Neutral, it
may move unexpectedly and injure
someone. Use 1 (First) gear and set the
parking brake fully.
% [DR09720( ALL)03/95]
Traction-Lok Axle (If equipped)
[DR09730( ALL)12/91]
This axle provides added traction on slippery
surfaces, particularly when one wheel is on a
poor traction surface. Under normal conditions
the Traction-Lok axle functions as a standard
rear axle.
File:10rcdrm.ex
Update:Wed Mar 27 09:33:56 1996

272
% [SV30875(M )12/94]
Manual Transmission Fluid
% [SV30925(M )03/95]
The fluid level and quality should not
deteriorate under normal driving conditions.
However, it is suggested that you have the fluid
level checked occasionally. If fluid is required,
seeLubricant Specificationsin the Index.
%
*
[SV30950(M )02/95]
The Clutch
[SV30975(M )12/94]
The clutch on your vehicle is operated by a
cable that adjusts itself with a little help from
you. Complete the following steps every
5,000-6,000 miles (10,000 km) to adjust the
clutch.
[SV31001(M )01/89]
1. Turn your engine off and put your gearshift
in First.
[SV31025(M )10/89]
2. Put your foot under the clutch pedal and
gently pull it up until the pedal stops.
[SV31050(M )01/89]
3. Then push the clutch down slowly. You will
hear a click if your clutch needed adjusting
and adjusted itself.
%
*
[SV31900( ALL)03/95]
Brake Fluid
*
[SV32000( ALL)04/95]
Under normal circumstances, your vehicle
should not use up brake fluid rapidly. However,
expect the level of the brake fluid to slowly fall
as you put more mileage on your vehicle and
the brake lining wears.
[SV32300(M )03/95]
Check the brake fluid at each scheduled engine
oil change or at least once a year. You can do
this by looking at the fluid level in the plastic
reservoir on the master cylinder. Also, see label
on reservoir cap. (To locate the master cylinder,
seeThe Engine Typesin the Index.) The fluid
level should be between the MIN and MAX
marks.
File:15rcsvm.ex
Update:Thu Mar 28 14:48:54 1996

Index 321
Cleaning your vehicle (continued)
engine compartment......... 242
exterior............... 5±6
exterior lamps............. 86
fabric................ 125
headlamps............... 86
instrument panel............ 80
instrument panel lens.......... 89
interior............... 125
interior lamps............. 89
mirrors............... 127
plastic parts.............. 7
polishing................ 6
rustproofing.............. 7
safety belts............... 21
tail lamps............... 86
upholstery and interior trim...... 125
washing............... 5±6
waxing................ 6
wheels................ 269
Climate control system
air conditioning............ 80
heating................ 80
heating only system........... 82
Clock.................. 89
Clutch
adjusting............... 272
fluid................. 272
fluid reservoir............ 272
operation while driving........ 182
recommended shift speeds....... 184
shifting the gears........... 183
specifications............. 300
Cold engine starting............ 53
Combination lap and shoulder belts . . . 9, 11
Compact disc player (see Electronic sound
system)............... 155
Console, description........... 129
